Image preview - the first page of the document
ma


>> Download ma documenatation <<

Text preview - extract from the document
MAINTENANCE


L MAINTENANCE

                                                                                                                                                                A




                                                                                             SECTION
                                                                                                            MAINTENANCE
                                                                                                                        MA                                      B



                                                                                                                                                                C


                                                                                                                                                                D


                                                                                                                                                                E
                                                               CONTENTS
PREPARATION .......................................................... 3
                                                                     .            INSPECTION AFTER REMOVAL ...................... 19                   .        F
 Special Service Tools .............................................. 3
                                                                     .            INSTALLATION .................................................. 20   .
 Commercial Service Tools ....................................... 3  .          Checking EVAP Vapor Lines ................................. 20         .
GENERAL MAINTENANCE ...................................... 4         .         CHASSIS AND BODY MAINTENANCE .................. 21                      .        G
 Explanation of General Maintenance ...................... 4         .          Checking Exhaust System ..................................... 21       .
PERIODIC MAINTENANCE ...................................... 6        .          Checking Clutch Fluid Level and Leaks ................ 21              .
 Introduction of Periodic Maintenance ...................... 6       .          Checking M/T Oil ................................................... 21.
                                                                                                                                                                H
 Schedule 1 .............................................................. 7
                                                                     .          Changing M/T Oil ................................................... 21.
   EMISSION CONTROL SYSTEM MAINTE-                                              Checking A/T Fluid ................................................ 21 .
   NANCE ................................................................. 7
                                                                     .          Changing A/T Fluid ................................................ 23 .
   CHASSIS AND BODY MAINTENANCE .............. 8                     .          Checking Transfer Fluid ........................................ 23    .         I
 Schedule 2 .............................................................. 9
                                                                     .          Changing Transfer Fluid ........................................ 24    .
   EMISSION CONTROL SYSTEM MAINTE-                                              Checking Propeller Shaft ....................................... 24    .
   NANCE ................................................................. 9
                                                                     .          Checking Differential Gear Oil ............................... 24      .        J
   CHASSIS AND BODY MAINTENANCE .............. 9                     .          Changing Differential Gear Oil ............................... 25      .
RECOMMENDED FLUIDS AND LUBRICANTS ......11                           .          Balancing Wheels (Bonding Weight Type) ............ 25                 .
 Fluids and Lubricants .............................................11
                                                                     .            REMOVAL .......................................................... 25.
                                                                                                                                                                K
 SAE Viscosity Number .......................................... 12  .            WHEEL BALANCE ADJUSTMENT .................... 25                     .
   GASOLINE ENGINE OIL ................................... 12        .          Tire Rotation .......................................................... 26
                                                                                                                                                       .
 Anti-Freeze Coolant Mixture Ratio ........................ 12       .          Checking Brake Fluid Level and Leaks ................. 27              .
ENGINE MAINTENANCE ........................................ 13       .          Checking Brake Lines and Cables ........................ 27            .        MA
 Checking Drive Belts ............................................. 13
                                                                     .          Changing Brake Fluid ............................................ 27   .
 Tension Adjustment ............................................... 14
                                                                     .          Checking Disc Brake ............................................. 27   .
   ALTERNATOR AND POWER STEERING OIL                                              ROTOR ............................................................... 27
                                                                                                                                                       .        M
   PUMP BELT ....................................................... 14
                                                                     .            CALIPER ............................................................ 28
                                                                                                                                                       .
   A/C COMPRESSOR BELT ................................ 14           .            PAD .................................................................... 28
                                                                                                                                                       .
 Changing Engine Coolant ..................................... 15    .          Checking Steering Gear and Linkage .................... 28             .
   DRAINING ENGINE COOLANT ........................ 15               .            STEERING GEAR .............................................. 28      .
   REFILLING ENGINE COOLANT ....................... 15               .            STEERING LINKAGE ........................................ 28         .
   FLUSHING COOLING SYSTEM ........................ 17               .          Checking Power Steering Fluid and Lines ............. 28               .
 Checking Fuel Lines .............................................. 17
                                                                     .          Axle and Suspension Parts ................................... 29       .
 Changing Air Cleaner Filter ................................... 17  .          Drive Shaft ............................................................. 29
                                                                                                                                                       .
   VISCOUS PAPER TYPE .................................... 17        .          Lubricating Locks, Hinges and Hood Latch ........... 30                .
 Changing Engine Oil ............................................. 17.          Checking Seat Belt, Buckles, Retractors, Anchors
 Changing Oil Filter ................................................ 18
                                                                     .          and Adjusters ......................................................... 30
                                                                                                                                                       .
   REMOVAL .......................................................... 18
                                                                     .         SERVICE DATA AND SPECIFICATIONS (SDS) ..... 31                          .
   INSTALLATION .................................................. 18.          Standard and Limit ................................................. 31.
   INSPECTION AFTER INSTALLATION .............. 19                   .            BELT DEFLECTION AND TENSION ................. 31                     .
 Changing Spark Plugs (Platinum-Tipped Type) .... 19                 .            ENGINE COOLANT CAPACITY (APPROXI-
   REMOVAL .......................................................... 19
                                                                     .            MATE) ................................................................. 31
                                                                                                                                                       .


                                                                         MA-1
ENGINE OIL CAPACITY (APPROXIMATE) ....... 31
                                      .          WHEEL BALANCE .............................................31  .
SPARK PLUG (PLATINUM-TIPPED TYPE) ....... 31
                                      .        Tightening Torque ..................................................32
                                                                                                                .




                                          MA-2
                                                       PREPARATION

PREPARATION                                                                                                                   PFP:00002
                                                                                                                                               A
Special Service Tools                                                                                                               ALS00013

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
  Tool number                                                                                                                                  B
  (Kent-Moore No.)                                                                       Description
  Tool name

  KV10115801                                                                             Removing and installing oil filter
                                                                                                                                               C
  (J38956)
  Oil filter wrench

                                                                                                                                               D

                                                                         S-NT772


  (J45475)                                                                               Checking A/T fluid (Use for models up to
                                                                                                                                               E
  A/T fluid level gauge                                                                  serial 099999)


                                                                                                                                               F


                                                                         SCIA1182E
                                                                                                                                               G
  (J45475-1)
  Level gauge adapter
                                                                                                                                               H



                                                                                                                                                I
                                                                         SCIA1280E



Commercial Service Tools                                                                                                            ALS00014

                                                                                                                                               J
  Tool name
                                                                                         Description
  (Kent-Moore No.)

  Power tool                                                                             Loosening bolts and nuts                              K


                                                                                                                                               MA


                                                                         PBIC0190E
                                                                                                                                               M
  Spark plug wrench                                                                      Removing and installing spark plug




                                                                         S-NT047


  Belt tension gauge                                                                     Checking drive belt tension
  (BT3373-F)




                                                                         AMA126




                                                                MA-3
                                             GENERAL MAINTENANCE

GENERAL MAINTENANCE                                                                                                           PFP:00000

Explanation of General Maintenance                                                                                               ALS0001C


General maintenance includes those items which should be checked during the normal day-to-day operation
of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform
checks and inspections themselves or have their INFINITI dealers do them.
OUTSIDE THE VEHICLE
The maintenance items listed here should be performed from time to time, unless otherwise specified.
 Item                                                                                                              Reference page
 Tires                     Check the pressure with a gauge, including the spare, at least once a month
                           and always prior to a long distance trips. Adjust to the specified pressure if nec-           --
                           essary. Check carefully for damage, cuts or excessive wear.
 Wheel nuts                When checking the tires, make sure no nuts are missing, and check for any
                                                                                                                         --
                           loose nuts. Tighten if necessary.
                           Clean the windshield on a regular basis. Check the windshield at least every six
 Windshield                                                                                                              --
                           months for cracks or other damage. Repair as necessary.
 Tire rotation             Tires should be rotated every 12,000 km (7,500 miles).                                      MA-26
 Wheel alignment and       If the vehicle pulls to either side while driving on a straight and level road, or if
 balance                   you detect uneven or abnormal tire wear, there may be a need for wheel align-
                                                                                                                   MA-25, FSU-7
                           ment. If the steering wheel or seat vibrates at normal highway speeds, wheel
                           balancing may be needed.
 Windshield wiper
                           Check for cracks or wear if they do not wipe properly.                                        --
 blades
 Doors and engine          Check that all doors and the engine hood operate smoothly as well as the trunk
 hood                      lid and back hatch. Also make sure that all latches lock securely. Lubricate if
                           necessary. Make sure that the secondary latch keeps the hood from opening
                                                                                                                       MA-30
                           when the primary latch is released.
                           When driving in areas using road salt or other corrosive materials, check lubri-
                           cation frequently.
 Lamps                     Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and
                           other lamps are all operating properly and installed securely. Also check head-               --
                           lamp aim. Clean the headlamps on a regular basis.

INSIDE THE VEHICLE
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the
vehicle, etc.
 Item                                                                                                         Reference page
 Warning lamps and
                           Make sure that all warning lamps and chimes are operating properly.                          --
 chimes
 Windshield wiper and      Check that the wipers and washer operate properly and that the wipers do not
                                                                                                                        --
 washer                    streak.
 Windshield defroster      Check that the air comes out of the defroster outlets properly and in sufficient
                                                                                                                        --
                           quantity when operating the heater or air conditioner.
 Steering wheel            Check that it has the specified play. Be sure to check for changes in the steering
                           condition, such as excessive play, hard steering or strange noises.                          --
                            Free play: Less than 35 mm (1.38 in)
 Seats                     Check seat position controls such as seat adjusters, seatback recliner, etc. to
                           make sure they operate smoothly and that all latches lock securely in every
                           position. Check that the head restrains move up and down smoothly and that                   --
                           the locks (if equipped) hold securely in all latched positions. Check that the
                           latches lock securely for folding-down rear seatbacks.
 Seat belts                Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and
                           retractors) operate properly and smoothly, and are installed securely. Check the            MA-30
                           belt webbing for cuts, fraying, wear or damage.
 Accelerator pedal         Check the pedal for smooth operation and make sure the pedal does not catch
                                                                                                                        --
                           or require uneven effort. Keep the floor mats away from the pedal.
 Brakes                    Check that the brake does not pull the vehicle to one side when applied.                     --


                                                                 MA-4
                                            GENERAL MAINTENANCE

 Item                                                                                                              Reference page
                                                                                                                                       A
 Brake pedal and          Check the pedal for smooth operation and make sure it has the proper distance
 booster                  under it when depressed fully. Check the brake booster function. Be sure to               BR-6, BR-18
                          keep the floor mats away from the pedal.
                          Make sure the pedal operates smoothly and check that it has the proper free                                  B
 Clutch pedal                                                                                                   CL-5, "CLUTCH PEDAL"
                          play.
 Parking brake            Check that the pedal or lever has the proper travel and make sure that the vehi-
                                                                                                                     PB-3, PB-4
                          cle is held securely on a fairly steep hill when only the parking brake is applied.                          C
 Automatic transmis-      Check that the lock release button on the selector lever operates properly and
 sion "Park" mecha-       smoothly. On a fairly steep hill check that the vehicle is held securely with the              --
 nism                     selector lever in the "P" position without applying any brakes.                                              D
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).
 Item                                                                                                            Reference page        E
 Windshield washer
                          Check that there is adequate fluid in the tank.                                                --
 fluid
 Engine coolant level     Check the coolant level when the engine is cold.                                             MA-15           F
 Radiator and hoses       Check the front of the radiator and clean off any dirt, insects, leaves, etc., that
                          may have accumulated. Make sure the hoses have no cracks, deformation,                         --
                          deterioration or loose connections.                                                                          G
 Brake and clutch fluid   Make sure that the brake and clutch fluid levels are between the "MAX" and
                                                                                                                    MA-27, MA-21
 level                    "MIN" lines on the reservoir.
 Battery                  Check the fluid level in each cell. It should be between the "MAX" and "MIN"                                 H
                          lines. Vehicles operated in high temperatures or under severe conditions require               --
                          frequent checks of the battery fluid level.
 Engine drive belts       Make sure that no belt is frayed, worn, cracked or oily.                                     MA-13            I
 Engine oil level         Check the level on the dipstick after parking the vehicle on a level spot and turn-
                                                                                                                       MA-17
                          ing off the engine.
 Power steering fluid     Check the level on the dipstick with the engine off. Check the lines for improper
                                                                                                                       MA-28
                                                                                                                                       J
 level and lines          attachment, leaks, cracks, etc.
 Exhaust system           Make sure there are no loose supports, cracks or holes. If the sound of the
                          exhaust seems unusual or there is a smell of exhaust fumes, immediately locate               MA-21
                                                                                                                                       K
                          the trouble and correct it.
 Underbody                The underbody is frequently exposed to corrosive substances such as those
                          used on icy roads or to control dust. It is very important to remove these sub-
                          stances, otherwise rust will form on the floor pan, frame, fuel lines and around                             MA
                                                                                                                         --
                          the exhaust system. At the end of winter, the underbody should be thoroughly
                          flushed with plain water, being careful to clean those areas where mud and dirt
                          can easily accumulate.
                                                                                                                                       M
 Fluid leaks              Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle
                          has been parked for a while. Water dripping from the air conditioner after use is
                                                                                                                         --
                          normal. If you should notice any leaks or gasoline fumes are evident, check for
                          the cause and correct it immediately.




                                                                MA-5
                                            PERIODIC MAINTENANCE

PERIODIC MAINTENANCE                                                                                                      PFP:00026

Introduction of Periodic Maintenance                                                                                         ALS0001D


Two different maintenance schedules are provided, and should be used, depending upon the conditions in
which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic
maintenance at the same mileage/time intervals.
              Follow Periodic Maintenance Schedule 1 if the driving habits frequently include     Emission Control Sys-
              one or more of the following driving conditions:                                    tem Maintenance
              q   Repeated short trips of less than 5 miles (8 km).
                                                                                                                            MA-7
              q   Repeated short trips of less than 10 miles (16 km) with outside temperatures
                  remaining below freezing.
 Schedule 1   q   Operating in hot weather in stop-and-go "rush hour" traffic.
              q   Extensive idling and/or low speed driving for long distances, such as police,   Chassis and Body
                  taxi or door-to-door delivery use.                                              Maintenance
              q   Driving in dusty conditions.                                                                              MA-8
              q   Driving on rough, muddy, or salt spread roads.
              q   Towing a trailer, using a camper or a car-top carrier.
              Follow Periodic Maintenance Schedule 2 if none of driving conditions shown in       Emission Control Sys-
                                                                                                                            MA-9
              Schedule 1 apply to the driving habits.                                             tem Maintenance
 Schedule 2
                                                                                                  Chassis and Body
                                                                                                                            MA-9
                                                                                                  Maintenance




                                                               MA-6
                                             PERIODIC MAINTENANCE

Schedule 1                                                                                                                              ALS0001E

EMISSION CONTROL SYSTEM MAINTENANCE                                                                                                                A
                             Abbreviations: R = Replace.   I = Inspect. Correct or replace if necessary.   [ ]: At the mileage intervals only
 MAINTENANCE OPERATION                                                  MAINTENANCE INTERVAL                                   Reference
 Perform at number of miles,       Miles x 1,000    3.75      7.50    11.25      15      18.75    22.5     26.25      30       Section -           B
 kilometers or months, which-      (km x 1,000)      (6)      (12)     (18)     (24)      (30)    (36)      (42)     (48)      Page or -
 ever comes first.                    Months          3        6         9       12        15      18        21       24      Content Title

 Drive belts                         NOTE (1)                                                                                    MA-13             C
 Air cleaner filter                  NOTE (2)                                                                        [R]         MA-17
 EVAP vapor lines                                                                                                     I*         MA-20
                                                                                                                                                   D
 Fuel lines                                                                                                           I*         MA-17
 Fuel filter                         NOTE (3)                                                                                       -
 Engine coolant                      NOTE (4)                                                                                    MA-15             E
 Engine oil                                          R         R        R        R        R        R         R        R          MA-17
 Engine oil filter (Use part No.
 15208 31U00 or 15208                                R         R        R        R        R        R         R        R          MA-18             F
 65F00 or equivalent.)
 Spark plugs (PLATINUM-
                                                               Replace every 105,000 miles (169,000 km).                         MA-19
 TIPPED type)                                                                                                                                      G
                                                                                                                                EM-91,
 Intake & exhaust valve clear-
                                     NOTE (5)                                                                                "Valve Clear-
 ance*
                                                                                                                                 ance"
                                                                                                                                                   H
 MAINTENANCE OPERATION                                                   MAINTENANCE INTERVAL                                  Reference
 Perform at number of miles,        Miles x 1,000    33.75     37.5     41.25      45     48.75    52.5     56.25      60      Section -
 kilometers or months, which-       (km x 1,000)      (54)     (60)      (66)     (72)     (78)    (84)      (90)     (96)     Page or -            I
 ever comes first.                     Months          27       30        33       36       39      42        45       48     Content Title

 Drive belts                         NOTE (1)                                                                          I*        MA-13
                                                                                                                                                   J
 Air cleaner filter                  NOTE (2)                                                                         [R]        MA-17
 EVAP vapor lines                                                                                                      I*        MA-20
 Fuel lines                                                                                                            I*        MA-17             K
 Fuel filter                         NOTE (3)                                                                                       -
 Engine coolant                      NOTE (4)                                                                          R*        MA-15
 Engine oil                                            R         R          R      R       R        R         R        R         MA-17             MA
 Engine oil filter (Use part No.
 15208 31U00 or 15208 65F00                            R         R          R      R       R        R         R        R         MA-18
 or equivalent.)                                                                                                                                   M
 Spark plugs (PLATINUM-
                                                                Replace every 105,000 miles (169,000 km).                        MA-19
 TIPPED type)
                                                                                                                                 EM-91,
 Intake & exhaust valve clear-
                                     NOTE (5)                                                                                 "Valve Clear-
 ance*
                                                                                                                                  ance"
NOTE:
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found
     damaged.
(2) If operating mainly in dusty conditions, more frequent maintenance may be required.
(3) Maintenance-free item. For service procedures, refer to FL section.
(4) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(5) If valve noise increases, inspect valve clearance.
* Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform
such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are
required.




                                                                MA-7
                                                   PERIODIC MAINTENANCE

CHASSIS AND BODY MAINTENANCE
                                                                       Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary.
 MAINTENANCE OPERATION                                                        MAINTENANCE INTERVAL                                  Reference
 Perform at number of miles,          Miles x 1,000    3.75   7.50          11.25     15      18.75    22.5     26.25      30       Section -
 kilometers or months, which-         (km x 1,000)      (6)   (12)           (18)    (24)      (30)    (36)      (42)     (48)      Page or -
 ever comes first.                       Months          3      6              9      12        15      18        21       24      Content Title

 Brake lines & cables
                                                                                          I                                   I       MA-27

 Brake pads & rotors
                                                                   I                      I                 I                 I       MA-27

 Automatic transmission fluid,
                                                                                                                                   MA-21, MA-
 manual transmission gear
                                        NOTE (1)                                          I                                   I    24 , MA-21 ,
 oil, transfer fluid & differential
                                                                                                                                     MA-23
 gear oil
 Drive shaft boots and propel-                                                                                                     MA-29,MA-
                                                                   I                      I                 I                 I
 ler shaft (AWD models)                                                                                                               24
 Steering gear & linkage, axle                                                                                                     MA-28, RSU-
                                                                   I                      I                 I                 I
 & suspension parts                                                                                                                 5 , MA-29
 Tire rotation                                                                                                                        MA-4,
                                        NOTE (2)
                                                                                                                                      MA-26
 Exhaust system
                                                                   I                      I                 I                 I       MA-21

 In-cabin microfilter                                                                  R                                   R         ATC-129

 MAINTENANCE OPERATION                                                       MAINTENANCE INTERVAL                                  Reference
 Perform at number of miles,          Miles x 1,000   33.75   37.5         41.25      45      48.75   52.5      56.25     60       Section -
 kilometers or months, which-         (km x 1,000)     (54)   (60)          (66)     (72)      (78)   (84)       (90)    (96)      Page or -
 ever comes first.                       Months         27     30            33       36        39     42         45      48      Content Title

 Brake lines & cables
                                                                                      I                                   I          MA-27

 Brake pads & rotors
                                                               I                      I                 I                 I          MA-27

 Automatic transmission fluid,
                                                                                                                                  MA-21, MA-24
 manual transmission gear
                                       NOTE (1)                                       I                                   I       , MA-21 , MA-
 oil, transfer fluid & differen-
                                                                                                                                       23
 tial gear oil
 Drive shaft boots and propel-
                                                               I                      I                 I                 I       MA-29, MA-24
 ler shaft (AWD models)
 Steering gear & linkage, axle                                                                                                    MA-28, RSU-
                                                               I                      I                 I                 I
 & suspension parts                                                                                                                5 , MA-29
 Tire rotation                                                                                                                       MA-4,
                                       NOTE (2)
                                                                                                                                     MA-26
 Exhaust system
                                                               I                      I                 I                 I          MA-21

 In-cabin microfilter                                                                 R                                   R         ATC-129
NOTE:
(1) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every
30,000 miles (48,000 km) or 24 months. Using automatic transmission fluid other than Genuine Nissan Matic J ATF will cause
deterioration in driveability and automatic transmission durability, and may damage the automatic transmission, which is not
covered by the INFINITI new vehicle limited warranty.
(2) Refer to "Tire rotation" under the "General maintenance" heading earlier in this section.




                                                                       MA-8
                                             PERIODIC MAINTENANCE

Schedule 2                                                                                                                               ALS0001F

EMISSION CONTROL SYSTEM MAINTENANCE                                                                                                                 A
                             Abbreviations: R = Replace.    I = Inspect. Correct or replace if necessary.    [ ]: At the mileage intervals only
 MAINTENANCE OPERATION                                                     MAINTENANCE INTERVAL
                                                                                                                            Reference Sec-          B
 Perform at number of miles,           Miles x 1,000        7.5      15    22.5    30     37.5      45      52.5    60      tion - Page or -
 kilometers or months, whichever       (km x 1,000)        (12)     (24)   (36)   (48)    (60)     (72)     (84)   (96)       Content Title
 comes first.                             Months             6       12     18     24      30       36       42     48
 Drive belts                            NOTE (1)                                                                     I*          MA-13              C
 Air cleaner filter                                                                [R]                              [R]          MA-17
 EVAP vapor lines                                                                  I*                                I*          MA-20
                                                                                                                                                    D
 Fuel lines                                                                        I*                                I*          MA-17
 Fuel filter                            NOTE (2)                                                                                    -
 Engine coolant                         NOTE (3)                                                                    R*           MA-15              E
 Engine oil                                                 R        R      R      R       R        R        R       R           MA-17
 Engine oil filter (Use part No.
 15208 31U00 or 15208 65F00                                 R        R      R      R       R        R        R       R           MA-18              F
 or equivalent.)
 Spark plugs (PLATINUM-
                                                                   Replace every 105,000 miles (169,000 km).                     MA-19
 TIPPED type)                                                                                                                                       G
 Intake & exhaust valve clear-                                                                                               EM-91, "Valve
                                        NOTE (4)
 ance*                                                                                                                        Clearance"
NOTE:                                                                                                                                               H
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found
damaged.
(2) Maintenance-free item. For service procedures, refer to FL section.
(3) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.                                                I
(4) If valve noise increases, inspect valve clearance.
* Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform
such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are             J
required

CHASSIS AND BODY MAINTENANCE
                                                                  Abbreviations: R = Replace.    I = Inspect. Correct or replace if necessary.      K
 MAINTENANCE OPERATION                                                     MAINTENANCE INTERVAL
                                                                                                                            Reference Sec-
 Perform at number of miles, kilo-     Miles x 1,000        7.5      15    22.5     30    37.5      45      52.5    60      tion - Page or -
 meters or months, whichever           (km x 1,000)        (12)     (24)   (36)    (48)   (60)     (72)     (84)   (96)       Content Title         MA
 comes first.                             Months             6       12     18      24     30       36       42     48
 Brake lines & cables
                                                                      I             I                I               I           MA-27
                                                                                                                                                    M
 Brake pads & rotors
                                                                      I             I                I               I           MA-27

 Automatic transmission fluid,
 manual transmission gear oil,                                                                                              MA-21, MA-24 ,
                                         NOTE (1)                     I             I                I               I
 transfer fluid & differential gear                                                                                         MA-23 , MA-21
 oil
 Drive shaft boots and propeller
                                                                      I             I                I               I       MA-29, MA-24
 shaft (AWD models)
 Steering gear & linkage, axle &                                                                                              MA-28,
                                                                                    I                                I
 suspension parts                                                                                                           RSU-5, MA-29
                                                                                                                                 MA-4,
 Tire rotation                           NOTE (2)
                                                                                                                                 MA-26
 Exhaust system
                                                                                    I                                I           MA-21

 In-cabin microfilter                                                R              R               R                R          ATC-129



                                                                   MA-9
                                          PERIODIC MAINTENANCE

NOTE:
(1) Using automatic transmission fluid other than Genuine Nissan Matic J ATF will cause deterioration in driveability and auto-
matic transmission durability, and may damage the automatic transmission, which is not covered by the INFINITI new vehicle
limited warranty.
(2) Refer to "Tire rotation" under the "General maintenance" heading earlier in this section.




                                                          MA-10
                               RECOMMENDED FLUIDS AND LUBRICANTS

RECOMMENDED FLUIDS AND LUBRICANTS                                                                                         PFP:00000
                                                                                                                                           A
Fluids and Lubricants                                                                                                           ALS0001G


                                                     Capacity (Approximate)
                                                                                              Recommended Fluids/Lubricants                B
                                         US measure      Imp measure          Liter

Engine       With oil filter change                                                   q   API Certification Mark*1
                                            5 qt            4-1/8 qt          4.7
oil                                                                                   q   API grade SG/SH, Energy Conserving I & II
Drain and                                                                                                                                  C
             Without oil filter change                                                    or API grade SJ or SL, Energy Conserv-
refill                                    4-5/8 qt          3-7/8 qt          4.4
                                                                                          ing*1
Dry engine (Overhaul)                     5-3/4 qt          4-3/4 qt          5.4     q   ILSAC grade GF-I, GF-II & GF-III *1
                                                                                                                                           D
                                                                                      Genuine Nissan Long Life Antifreeze/ Cool-
Cooling      With reservoir tank          9-1/4 qt          7-5/8 qt          8.7
                                                                                      ant or equivalent
system
             Reservoir tank                7/8 qt            3/4 qt           0.8
                                                                                                                                           E
                                                                                      Genuine Nissan Manual Transmission Fluid
Manual transmission gear oil              3-1/8 qt          2-1/2 qt          2.9     (MTF) HQ Multi 75W-85 or API GL-4, Viscos-
                                                                                      ity SAE 75W-85 or 75W-90
                                                                                                                                           F
Automatic transmission fluid              10-7/8 qt         9-1/8 qt          10.3    Genuine Nissan Matic J ATF *2
                                                                                      Genuine Nissan Matic D ATF (Continental
Transfer fluid                            2-5/8 pt          2-1/4 pt          1.25    U.S. and Alaska) or Canada NISSAN Auto-
                                                                                      matic Transmission Fluid *3                          G
Power steering fluid (PSF)                1-1/8 qt           7/8 qt           1.0     Genuine NISSAN PSF or equivalent *4
                                                                                      Genuine Nissan Super Heavy Duty Brake
Brake (and clutch) fluid                     --               --               --     Fluid*5 or equivalent DOT 3 (US FMVSS No.
                                                                                                                                           H
                                                                                      116)
                               Front      1-3/8 pt          1-1/8 pt          0.65
Differential gear oil                                                                 API GL-5, Viscosity SAE 80W-90 *6                     I
                               Rear         3 pt            2-1/2 pt          1.4
Multi-purpose grease                         --               --               --     NLGI No. 2 (Lithium soap base)
                                                                                      Genuine Nissan Windshield Washer Concen-             J
Windshield washer fluid                      --               --               --
                                                                                      trate Cleaner & Antifreeze Fluid or equivalent
*1: For further details, see "SAE Viscosity Number".
*2: Using automatic transmission fluid other than Genuine Nissan Matic J ATF will cause deterioration in driveability and auto-
                                                                                                                                           K
matic transmission durability, and may damage the automatic transmission, which is not covered by the INFINITI new vehicle
limited warranty.
*3: DEXRONTM III/ MERCONTM or equivalent may also be used. Outside the continental United States and Alaska contact an INFINITI
dealer for more information regarding suitable fluids, including recommended brand(s) of DEXRONTM III/ MERCON TM automatic trans-          MA
mission fluid.
*4: For Canada, NISSAN Automatic Transmission Fluid (ATF), DEXRONTM III/ MERCONTM , or equivalent ATF may also be used.
*5: Available in mainland U.S.A. through your INFINITI dealer.                                                                             M
*6: For hot climates, viscosity SAE 90 is suitable for ambient temperatures above 0



◦ Jabse Service Manual Search 2022 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
