Image preview - the first page of the document
pr


>> Download pr documenatation <<

Text preview - extract from the document
PROPELLER SHAFT


D DRIVELINE/AXLE

                                                                                                                                                       A




                                                                                            SECTION
                                                                                         PROPELLER SHAFT
                                                                                                                     PR                                B



                                                                                                                                                       C


                                                                                                                                                       PR


                                                                                                                                                       E
                                                             CONTENTS
                                2WD                                         TROUBLESHOOTING ............................................. 12  .        F
                                                                             NVH Troubleshooting Chart .................................. 12  .
PREPARATION .......................................................... 2
                                                                  .         FRONT PROPELLER SHAFT ................................. 13        .
 Special Service Tools .............................................. 2
                                                                  .          On-Vehicle Service ................................................ 13
                                                                                                                                              .        G
 Commercial Service Tools ....................................... 2
                                                                  .            PROPELLER SHAFT VIBRATION ..................... 13             .
NOISE, VIBRATION AND HARSHNESS (NVH)                                           APPEARANCE CHECKING ............................... 13         .
TROUBLESHOOTING ............................................... 3 .          Removal and Installation ....................................... 13
                                                                                                                                              .
 NVH Troubleshooting Chart .................................... 3 .                                                                                    H
                                                                               COMPONENTS .................................................. 13
                                                                                                                                              .
REAR PROPELLER SHAFT ..................................... 4      .            REMOVAL .......................................................... 13
                                                                                                                                              .
 On-Vehicle Service .................................................. 4
                                                                  .            INSPECTION ..................................................... 14
                                                                                                                                              .
   PROPELLER SHAFT VIBRATION ....................... 4            .            INSTALLATION .................................................. 15
                                                                                                                                              .         I
   APPEARANCE CHECKING ................................. 4        .         REAR PROPELLER SHAFT ................................... 16       .
 Removal and Installation ......................................... 5
                                                                  .          On-Vehicle Service ................................................ 16
                                                                                                                                              .
   COMPONENTS ................................................... 5
                                                                  .            PROPELLER SHAFT VIBRATION ..................... 16             .        J
   REMOVAL ............................................................ 5
                                                                  .            APPEARANCE CHECKING ............................... 16         .
   INSPECTION ....................................................... 5
                                                                  .          Removal and Installation ....................................... 17
                                                                                                                                              .
   INSTALLATION .................................................... 6
                                                                  .            COMPONENTS .................................................. 17
                                                                                                                                              .
 Disassembly and Assembly .................................... 7  .                                                                                    K
                                                                               REMOVAL .......................................................... 17
                                                                                                                                              .
   DISASSEMBLY .................................................... 7
                                                                  .            INSPECTION ..................................................... 17
                                                                                                                                              .
   ASSEMBLY .......................................................... 8
                                                                  .            INSTALLATION .................................................. 19
                                                                                                                                              .
SERVICE DATA AND SPECIFICATIONS (SDS) ..... 10                    .          Disassembly and Assembly ................................... 20  .        L
 General Specifications .......................................... 10
                                                                  .            DISASSEMBLY .................................................. 20
                                                                                                                                              .
   JOURNAL AXIAL PLAY ..................................... 10    .            ASSEMBLY ........................................................ 21
                                                                                                                                              .
   PROPELLER SHAFT RUNOUT LIMIT .............. 10                 .         SERVICE DATA AND SPECIFICATIONS (SDS) ..... 23                    .        M
                                                                             General Specifications ........................................... 23
                                                                                                                                              .
                                AWD                                          Front Propeller Shaft ............................................. 23
                                                                                                                                              .
                                                                               JOURNAL AXIAL PLAY ...................................... 23   .
PREPARATION .........................................................11
                                                                 .             PROPELLER SHAFT RUNOUT LIMIT ............... 23                .
 Special Service Tools .............................................11
                                                                 .           Rear Propeller Shaft .............................................. 23
                                                                                                                                              .
 Commercial Service Tools ......................................11
                                                                 .             JOURNAL AXIAL PLAY ...................................... 23   .
NOISE, VIBRATION AND HARSHNESS (NVH)                                           PROPELLER SHAFT RUNOUT LIMIT ............... 23                .




                                                                       PR-1
                                                       PREPARATION
                                                                                                                             [2WD]
PREPARATION
[2WD]                                                                                                                       PFP:00002

Special Service Tools                                                                                                           ADS0010A

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
  Tool number
  (Kent-Moore No.)                                                                       Description
  Tool name

  ST38060002                                                                             Removing and installing lock nut
  (J34311)
  Companion flange wrench




                                                                         NT113


  ST30031000                                                                             Remove rear propeller shaft center bearing
  (J22912
