Image preview - the first page of the document
sb


>> Download sb documenatation <<

Text preview - extract from the document
SEAT BELTS


H RESTRAINTS

                                                                                                                                                              A




                                                                                                SECTION                    SB
                                                                                                                     SEAT BELTS
                                                                                                                                                              B



                                                                                                                                                              C


                                                                                                                                                              D


                                                                                                                                                              E
                                                               CONTENTS
PRECAUTIONS ......................................................... 2
                                                                     .            INSTALLATION .................................................... 5
                                                                                                                                                    .         F
 Precautions for Supplemental Restraint System                                  Seat Belt Inspection ................................................. 6
                                                                                                                                                    .
 (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                          AFTER A COLLISION .......................................... 6    .
 SIONER" ................................................................. 2
                                                                     .            PRELIMINARY CHECKS ..................................... 6        .         G
 Precaution for Seat Belt Service ............................. 2    .            SEAT BELT RETRACTOR ON-VEHICLE
   AFTER A COLLISION .......................................... 2    .            CHECK ................................................................. 7
                                                                                                                                                    .
SEAT BELTS ............................................................. 4
                                                                     .            SEAT BELT RETRACTOR OFF-VEHICLE
                                                                                                                                                              SB
 System Description ................................................. 4
                                                                     .            CHECK ................................................................. 8
                                                                                                                                                    .
   SEAT BELT WARNING CHIME ........................... 4             .         LATCH (LOWER ANCHORS AND TETHER FOR
   SEAT BELT WARNING LAMP ............................. 4            .         CHILDREN) SYSTEM ................................................ 9  .
 Removal and Installation of Front Seat Belt ............ 4          .          Removal and Installation ......................................... 9.          I
   REMOVAL OF SEAT BELT RETRACTOR ........... 4                      .            REMOVAL ............................................................ 9
                                                                                                                                                    .
   INSTALLATION OF SEAT BELT RETRACTOR..... 5                                     INSTALLATION .................................................... 9
                                                                                                                                                    .
   REMOVAL OF SEAT BELT BUCKLE ................... 5                 .         TOP TETHER STRAP CHILD RESTRAINT ............ 10                     .          J
   INSTALLATION OF SEAT BELT BUCKLE ........... 5                    .          Removal and Installation ....................................... 10 .
 Removal and Installation of Rear Seat Belt ............ 5           .            REMOVAL .......................................................... 10
                                                                                                                                                    .
   REMOVAL ............................................................ 5
                                                                     .            INSTALLATION .................................................. 10.
                                                                                                                                                              K


                                                                                                                                                              L



                                                                                                                                                              M




                                                                         SB-1
                                              PRECAUTIONS

PRECAUTIONS                                                         PFP:00001

Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER"                                                                                           AHS0001A


The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
q    To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
     in the event of a collision which would result in air bag inflation, all maintenance must be per-
     formed by an authorized NISSAN/INFINITI dealer.
q    Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
     sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
     Bag Module, see the SRS section.
q    Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
     Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
     harness connectors.
Precaution for Seat Belt Service                                                                              AHS00002


CAUTION:
q  Before removing the front seat belt pre-tensioner assembly, turn the ignition switch off, discon-
   nect the battery ground cable and wait at least 3 minutes.
q  Do not use electrical test equipment for front seat belt pre-tensioner connector.
q  After replacing or reinstalling front seat belt pre-tensioner assembly, or reconnecting front seat
   belt pre-tensioner connector, check the system function. Refer to SRS-18, "SRS Operation Check"
   .
q  Deploy front seat belt pre-tensioner assembly before disposing. Refer to SRS-51, "DISPOSAL OF
   AIR BAG MODULE AND SEAT BELT PRE-TENSIONER" .
q  Do not use disassemble buckle or seat belt assembly.
q  Replace anchor bolts if they are deformed or worn out.
q  Never oil tongue and buckle.
q  If any component of seat belt assembly is questionable, do not repair. Replace the whole seat belt
   assembly.
q  If webbing is cut, frayed, or damaged, replace seat belt assembly.
q  When replacing seat belt assembly, use a genuine NISSAN seat belt assembly.
AFTER A COLLISION
WARNING:
Inspect all seat belt assemblies including retractors and attaching hardware after any collision.
NISSAN recommends that all seat belt assemblies in use during a collision be replaced unless the col-
lision was minor and the belts show no damage and continue to operate properly. Failure to do so
could result in serious personal injury in an accident. Seat belt assemblies not in use during a colli-
sion should also be replaced if either damage or improper operation is noted. Seat belt pre-tensioner
should be replaced even if the seat belts are not in use during a frontal collision in which the air bags
are deployed.
Replace any seat belt assembly (including anchor bolts) if:
q    The seat belt was in use at the time of a collision (except for minor collisions and the belts, retractors and
     buckles show no damage and continue to operate properly).
q    The seat belt was damaged in an accident (i.e. torn webbing, bent retractor or guide).
q    The seat belt attaching point was damaged in an accident. Inspect the seat belt attaching area for damage
     or distortion and repair as necessary before installing a new seat belt assembly.
q    Anchor bolts are deformed or worn out.

                                                      SB-2
                                            PRECAUTIONS

q   The front seat belt pre-tensioner should be replaced even if the seat belts are not in use during the colli-
    sion in which the air bags are deployed.                                                                       A


                                                                                                                   B



                                                                                                                   C


                                                                                                                   D


                                                                                                                   E



                                                                                                                   F


                                                                                                                   G


                                                                                                                   SB



                                                                                                                    I


                                                                                                                    J



                                                                                                                   K


                                                                                                                   L



                                                                                                                   M




                                                    SB-3
                                              SEAT BELTS

SEAT BELTS                                                                                           PFP:86884

System Description                                                                                         AHS00018

SEAT BELT WARNING CHIME
q    With ignition switch turned ON and seat belt unfastened (seat belt switch ON), warning chime will sound
     for approximately 6 seconds.
q    If warning chime does not sound, refer to DI-50, "Seat Belt Warning Chime Does Not Operate" .
SEAT BELT WARNING LAMP
q    Fasten driver's seat belt.
q    The seat belt warning lamp should go out.
q    If the seat belt warning lamp does not go out, refer to DI-26, "Wiring Diagram -- WARN --" .
Removal and Installation of Front Seat Belt                                                                AHS00003




                                                                                                    PHIA0089E

CAUTION:
Before servicing SRS, turn the ignition switch off, disconnect both battery cables and wait at least 3
minutes.
REMOVAL OF SEAT BELT RETRACTOR
1.   Remove the adjuster cover on the seat belt anchor.
2.   Remove the anchor bolt.
3.   Slide up outer anchor cover, and remove the anchor bolt.
4.   Remove the center pillar upper and lower garnish. Refer to EI-39, "BODY SIDE TRIM" .
5.   Disconnect the front seat belt pre-tensioner connector.
     CAUTION:
     q For installing/removing pre-tensioner seat belt connec-
        tor, insert screwdriver wrapped in tape into notch, lift
        lock and remove connector.
     q Install connector with lock raised, and push lock into
        connector.



                                                                                                       PHIA0341E



6.   Remove the front seat belt pre-tensioner retractor fixing screw and anchor bolt, and then remove the seat
     belt retractor.



                                                    SB-4
                                             SEAT BELTS

INSTALLATION OF SEAT BELT RETRACTOR
CAUTION:                                                                                                           A
Before servicing SRS, turn the ignition switch off, disconnect both battery cables and wait at least 3
minutes.
To install, reverse the removal procedure.                                                                         B
REMOVAL OF SEAT BELT BUCKLE
1.   Remove the front seat. Refer to SE-67, "REMOVAL" .
2.   Remove the screws, and remove the seat cushion inner finisher. Refer to SE-64, "Removal and Installa-         C
     tion" .
3.   Remove the anchor bolt, and remove the seat belt buckle.
                                                                                                                   D


                                                                                                                   E



                                                                                                                   F


                                                                                                     PHIA0090E
                                                                                                                   G
INSTALLATION OF SEAT BELT BUCKLE
To install, reverse the removal procedure.
Removal and Installation of Rear Seat Belt                                                              AHS00004
                                                                                                                   SB



                                                                                                                    I


                                                                                                                    J



                                                                                                                   K


                                                                                                                   L



                                                                                                                   M


                                                                                                 PHIA0091E


REMOVAL
1.   Remove the rear seat. Refer to SE-71, "Removal and Installation" .
2.   Remove the rear pillar finisher. Refer to EI-39, "BODY SIDE TRIM" .
3.   Remove the rear parcel shelf finisher. Refer to EI-41, "REAR PARCEL SHELF FINISHER" .
4.   Remove the outer and inner anchor bolts.
5.   Remove seat belt retractor mounting screw and anchor bolt, and remove the seat belt assembly.
INSTALLATION
To install, reverse the removal procedure.




                                                  SB-5
                                                SEAT BELTS

Seat Belt Inspection                                                                                         AHS00005

AFTER A COLLISION
WARNING:
Inspect all seat belt assemblies including retractors and attaching hardware after any collision.
NISSAN recommends that all seat belt assemblies in use during a collision be replaced unless the col-
lision was minor and the belts show no damage and continue to operate properly. Failure to do so
could result in serious personal injury in an accident. Seat belt assemblies not in use during a colli-
sion should also be replaced if either damage or improper operation is noted. Seat belt pre-tensioners
should be replaced even if the seat belts are not in use during a frontal collision in which the air bags
are deployed.
Replace any seat belt assembly (including anchor bolts) if:
q    The seat belt was in use at the time of a collision (except for minor collisions and the belts, retractors and
     buckles show no damage and continue to operate properly).
q    The seat belt was damaged in an accident (i.e. torn webbing, bent retractor or guide).
q    The seat belt attaching point was damaged in an accident. Inspect the seat belt attaching area for damage
     or distortion and repair as necessary before installing a new seat belt assembly.
q    Anchor bolts are deformed or worn out.
q    The front seat belt pre-tensioner should be replaced even if the seat belts are not in use during the colli-
     sion in which the air bags are deployed.
PRELIMINARY CHECKS
1.   Check the seat belt warning lamp/chime for proper operation as follows:
a.   Switch ignition ON. The seat belt warning lamp should illuminate. Also, the seat belt warning chime should
     sound for about six seconds.
b.   Fasten driver's seat belt. The seat belt warning lamp should go out and the chime (if sounding) should
     stop.
2.   If the air bag warning lamp is blinking, conduct self-diagnosis using CONSULT-II, and air bag warning
     lamp. Refer to SRS-18, "SRS Operation Check" .
3.   Check that the seat belt retractor, seat belt anchor and buckle bolts are securely attached.
4.   Check the shoulder seat belt guide and shoulder belt height adjuster for front seats. Ensure guide swivels
     freely and that belt lays flat and does not bind in guide. Ensure height adjuster operates properly and
     holds securely.
5.   Check retractor operation:
a.   Fully extend the seat belt webbing and check for twists, tears or other damage.
b.   Allow the seat belt to retract. Ensure that belt returns smoothly and completely into the retractor. If the
     seat belt does not return smoothly, wipe the inside of the loops with a clean paper cloth, because dirt built
     up in the loops of the upper anchors can cause the seat belts to retract slowly.
c.   Fasten the seat belt. Check the seat belt returns smoothly and completely to the retractor. If the belt does
     not return smoothly, the cause may be an accumulation of dust or dirt. Use the "SEAT BELT TAPE SET"
     and perform the following steps.
     Inspect the front seat belt though-anchor:
     1. Pull the seat belt out to a length of 500 mm (19.69 in) or more.
     2. Use a clip or other device to the fix the seat belt at the center pillar belt opening.
     3. Pass a thin wire though the though-anchor belt opening. Hold both ends of the wire and pull taut while
        moving it up and down several times along the belt opening surface to remove dirt.
     4. Any dirt that cannot be removed with the wire can be removed by cleaning the opening with a clean
        cloth.
     5. Apply tape at the point where the belt contacts the though-anchor belt opening.
        NOTE:
        Apply the tape so that there is no looseness or wrinkling.
     6. Remove the clip fixing the seat belt and check that the belt returns smoothly.
     7. Repeat steps above as necessary to check the other seat belts.




                                                      SB-6
                                                 SEAT BELTS

SEAT BELT RETRACTOR ON-VEHICLE CHECK
Emergency Locking Retractors (ELR) and Automatic Locking Retractors (ALR)                                                 A
NOTE:
All seat belt retractors are of the Emergency Locking Retractors (ELR) type. In an emergency (sudden stop)
the retractor will lock and prevent the belt from extending any further. All 3-point type seat belt retractors            B
except the driver's seat belt also have an Automatic Locking Retractors (ALR) mode. The ALR mode (also
called child restraint mode) is used when installing child seats. The ALR mode is activated when the seat belt
is fully extended. When the belt is then retracted partially, the ALR mode automatically locks the seat belt in a         C
specific position so the belt cannot be extended any further. To cancel the ALR mode, allow the seat belt to
fully wind back into the retractor.
Check the seat belt retractors using the following test(s) to determine if a retractor assembly is operating prop-
erly.                                                                                                                     D
ELR Function Stationary Check
Grasp the shoulder belt and pull forward quickly. The retractor should lock and prevent the belt from extending           E
further.
ALR Function Stationary Check
1.   Pull out entire length of seat belt from retractor until a click is heard.                                           F
2.   Retract the belt partially. A clicking noise should be heard as the belt retracts indicating that the retractor is
     in the Automatic Locking Retractor (ALR) mode.
3.   Grasp the seat belt and try to pull out the retractor. The belt must lock and not extend any further. If neces-      G
     sary replace the retractor assembly.
4.   Allow the entire length of the belt to retract to cancel the automatic locking mode.
ELR Function Moving Check                                                                                                 SB
WARNING:
Perform the following test in a safe, open area clear of other vehicles and obstructions (for example, a
large, empty parking lot). Road surface must be paved and dry. DO NOT perform the following test on                        I
wet or gravel roads or on public streets and highways. This could result in an accident and serious
personal injury. The driver and passenger must be prepared to brace themselves in the event the
retractor does not lock.                                                                                                   J
1. Fasten driver's seat belt. Buckle a passenger into the seat for the belt that is to be tested.
2. Proceed to the designated safe area.
3. Drive the vehicle at approximately 16 km/h (10 MPH). Notify any passengers of a pending sudden stop.                   K
    The driver and passenger must be prepared to brace themselves in the event the retractor does not lock.
    Apply brakes firmly and make a very hard stop.
During stop, seat belts should lock and not be extended. If the seat belt retractor assembly does not lock, per-          L
form the retractor off-vehicle check.

                                                                                                                          M




                                                       SB-7
                                               SEAT BELTS

SEAT BELT RETRACTOR OFF-VEHICLE CHECK
1.   Remove the seat belt retractor assembly.
2.   Slowly pull out belt while tilting the retractor assembly forward from the mounted position without twisting
     the retractor assembly as shown in the illustration.




                                                                                                       PHIA0092E


        15 degrees or less tilt     : Belt can be pulled out.
        35 degrees or more tilt     : Belt locks and cannot be pulled out.
     If NG, replace the retractor assembly.




                                                     SB-8
        LATCH (LOWER ANCHORS AND TETHER FOR CHILDREN) SYSTEM

LATCH (LOWER ANCHORS AND TETHER FOR CHILDREN) SYSTEM                PFP:75466
                                                                                   A
Removal and Installation                                                AHS00006


CAUTION:
Replace anchor bolts if they are deformed or worn out.                             B
REMOVAL
1.   Remove the rear seat. Refer to SE-71, "Removal and Installa-
     tion" .                                                                       C
2.   Remove LATCH (Lower Anchors and Tether for Children) sys-
     tem.
                                                                                   D


                                                                                   E


                                                                     PHIA0093E
                                                                                   F
INSTALLATION
To install, reverse the removal procedure.
                                                                                   G


                                                                                   SB



                                                                                    I


                                                                                    J



                                                                                   K


                                                                                   L



                                                                                   M




                                                SB-9
                            TOP TETHER STRAP CHILD RESTRAINT

TOP TETHER STRAP CHILD RESTRAINT                                          PFP:88000

Removal and Installation                                                      AHS00007


CAUTION:
Replace anchor bolts if they are deformed or worn out.
REMOVAL
1.   Remove the top tether strap child restraint cover. Refer to EI-41,
     "REAR PARCEL SHELF FINISHER" .
2.   Remove the top tether strap child restraint.




                                                                           PHIA0094E


INSTALLATION
To install, reverse the removal procedure.




                                                    SB-10



◦ Jabse Service Manual Search 2023 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
