Image preview - the first page of the document
>> Download fax documenatation <<
Text preview - extract from the document
FRONT AXLE
D DRIVELINE/AXLE
A
SECTION FAX FRONT AXLE
B
C
FAX
E
CONTENTS
2WD FRONT WHEEL HUB AND KNUCKLE ................... 12 . F
On-Vehicle Inspection and Service ........................ 12 .
PREPARATION .......................................................... 2 . WHEEL BEARING INSPECTION ...................... 12 .
Special Service Tools (SST) .................................... 2 . Removal and Installation ....................................... 12 . G
Commercial Service Tools ....................................... 2 . REMOVAL .......................................................... 12 .
NOISE, VIBRATION AND HARSHNESS (NVH) INSPECTION AFTER REMOVAL ...................... 13 .
TROUBLESHOOTING ............................................... 3 . INSTALLATION .................................................. 14 .
NVH Troubleshooting Chart .................................... 3 . H
Disassembly and Assembly ................................... 14 .
FRONT WHEEL HUB AND KNUCKLE ..................... 4 . DISASSEMBLY .................................................. 14 .
On-Vehicle Inspection and Service ......................... 4 . INSPECTION AFTER DISASSEMBLY ............... 14 .
WHEEL BEARING INSPECTION ........................ 4 . ASSEMBLY ........................................................ 15 . I
Removal and Installation ......................................... 4 . FRONT DRIVE SHAFT ............................................ 16 .
REMOVAL ............................................................ 4. On Vehicle Inspection and Service ........................ 16 .
INSPECTION AFTER REMOVAL ........................ 5 . DRIVE SHAFT BOOT REPLACEMENT ............. 16 . J
INSTALLATION .................................................... 6 . Removal and installation ....................................... 19 .
SERVICE DATA ......................................................... 7 . REMOVAL .......................................................... 19 .
Wheel Bearing ......................................................... 7
. INSPECTION AFTER REMOVAL ...................... 20 .
Ball Joint .................................................................. 7
. K
INSTALLATION .................................................. 20 .
Disassembly and Assembly ................................... 21 .
AWD DISASSEMBLY .................................................. 21 .
INSPECTION AFTER DISASSEMBLY ............... 22 . L
PRECAUTIONS ......................................................... 8 . ASSEMBLY ........................................................ 23 .
Caution .................................................................... 8
. SERVICE DATA ....................................................... 27 .
PREPARATION .......................................................... 9. Wheel Bearing ....................................................... 27. M
Special Service Tools (SST) .................................... 9 . Ball Joint ................................................................ 27
.
Commercial Service Tools ..................................... 10 . Drive Shaft ............................................................. 27
.
NOISE, VIBRATION AND HARSHNESS (NVH) Z80T70C ............................................................ 27
.
TROUBLESHOOTING ..............................................11 . Z80T82F ............................................................. 27
.
NVH Troubleshooting Chart ...................................11 . Tightening Torque .................................................. 27 .
Edition; 2004 September FAX-1 2005 G35 Sedan
PREPARATION
[2WD]
PREPARATION
[2WD] PFP:00002
Special Service Tools (SST) ADS000YS
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.) Description
Tool name
HT7252 0000
(J25730-A)
Ball joint remover
Removing steering outer socket
a: 33 mm (1.30 in)
b: 50 mm (1.97 in)
r: 11.5 mm (0.453 in)
NT546
ST3127 S000
(See J25742-1)
Preload Gauge
1. GG91030000
Torque wrench (J25765) Measuring rotating torque of ball joint
2. HT62940000 ( -- )
Socket adapter (1/2)
3. HT62900000 ( -- )
NT124
Socket adapter (3/8)
Commercial Service Tools ADS000YT
Tool name Description
q Removing wheel nuts
Power tool q Removing undercover
q Removing brake caliper assembly
PBIC0190E
Edition; 2004 September FAX-2 2005 G35 Sedan
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
[2WD]
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003
A
NVH Troubleshooting Chart ADS000YU
Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
B
NVH in WT section.
NVH in WT section.
NVH in PS section.
FAX-4
FAX-4
--
Reference page C
FAX
Improper installation, looseness
Wheel bearing damage
E
Parts interference
Possible cause and SUSPECTED PARTS
ROAD WHEEL
F
STEERING
TIRES
G
