Image preview - the first page of the document
fsu

>> Download fsu documenatation <<

Text preview - extract from the document

FRONT SUSPENSION

E SUSPENSION

B
SECTION
FRONT SUSPENSION C

FSU
CONTENTS
PRECAUTIONS ......................................................... 2 . TRANSVERSE LINK ................................................ 13 . F
Caution .................................................................... 2
. Removal and Installation ....................................... 13 .
PREPARATION .......................................................... 3. REMOVAL .......................................................... 13 .
Special Service Tools .............................................. 3 . INSPECTION AFTER REMOVAL ...................... 13 . G
Commercial Service Tools ....................................... 3 . INSTALLATION .................................................. 13 .
NOISE, VIBRATION AND HARSHNESS (NVH) UPPER LINK ............................................................ 14
.
TROUBLESHOOTING ............................................... 4 . Removal and Installation ....................................... 14 .
H
NVH Troubleshooting Chart .................................... 4 . REMOVAL .......................................................... 14 .
FRONT SUSPENSION ASSEMBLY .......................... 5 . INSPECTION AFTER REMOVAL ...................... 14 .
On-Vehicle Inspection and Service ......................... 5 . INSTALLATION .................................................. 15 .
INSPECTION OF BALL JOINT END PLAY OF COMPRESSION ROD .............................................. 16 . I
EACH LINK .......................................................... 5
. Removal and Installation ....................................... 16 .
SHOCK ABSORBER INSPECTION .................... 5 . REMOVAL .......................................................... 16 .
Wheel Alignment Inspection .................................... 6 . INSPECTION AFTER REMOVAL ...................... 16 . J
DESCRIPTION ..................................................... 6 . INSTALLATION .................................................. 17 .
PRELIMINARY CHECK ....................................... 6 . STABILIZER BAR .................................................... 18 .
GENERAL INFORMATION AND RECOMMEN- Removal and Installation ....................................... 18 .
K
DATIONS ............................................................. 6
. REMOVAL .......................................................... 18 .
THE ALIGNMENT PROCESS ............................. 7 . INSPECTION AFTER REMOVAL ...................... 18 .
INSPECTION OF CAMBER, CASTER AND INSTALLATION .................................................. 18 .
KINGPIN INCLINATION ANGLES ....................... 7 . FRONT SUSPENSION MEMBER ............................ 19 . L
Components ............................................................ 8
. Removal and Installation ....................................... 19 .
Removal and Installation ......................................... 9 . REMOVAL .......................................................... 19 .
REMOVAL ............................................................ 9
. INSPECTION AFTER REMOVAL ...................... 19 . M
INSTALLATION .................................................... 9 . INSTALLATION .................................................. 19 .
COIL SPRING AND SHOCK ABSORBER .............. 10 . SERVICE DATA AND SPECIFICATIONS (SDS) ..... 20 .
Removal and Installation ....................................... 10 . Wheel Alignment (Unladen*) ................................. 20 .
REMOVAL .......................................................... 10. Ball Joint ................................................................ 20
.
INSTALLATION .................................................. 10 . Wheelarch Height (Unladen*) ................................ 20 .
Disassembly and Assembly .................................. 10 .
DISASSEMBLY .................................................. 10 .
INSPECTION AFTER DISASSEMBLY ...............11 .
ASSEMBLY .........................................................11 .

Revision: 2006 August FSU-1 2006 G35 Coupe
PRECAUTIONS

PRECAUTIONS PFP:00001

Caution NES0001Z

q When installing rubber bushings, final tightening must be carried out under unladen conditions with tires
on ground. Oil will shorten the life of rubber bushings. Be sure to wipe off any spilled oil.
q Unladen conditions mean that fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and
mats are in designated positions.
q After servicing suspension parts, be sure to check wheel alignment.
q Caulking nuts are not reusable. Always use new ones when installing. Since new caulking nuts are pre-
oiled, tighten as they are.
q Avoid burden to front cross bar.

Revision: 2006 August FSU-2 2006 G35 Coupe
PREPARATION

PREPARATION PFP:00002
A
Special Service Tools NES000LI

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
B
(Kent-Moore No.) Description
Tool name

KV991040S0 Measuring wheel alignment C
( -- )
CCK gauge attachment
1. Plate
D
2. Guide bolts
3. Nuts
4. Springs
5. Center plate FSU
6. KV99104020 Adapter A
a: 72 mm (2.83 in) dia.
7. KV99104030 Adapter B
b: 65 mm (2.56 in) dia. S-NT498 F
8. KV99104040 Adapter C
c: 57 mm (2.24 in) dia.
9. KV99104050 Adapter D
d: 53.4 mm (2.102 in) dia. G
ST35652000 Disassembling and assembling shock
( -- ) absorber
Strut attachment H

I
ZZA0807D

ST3127S000 Measuring rotating torque of ball joint
(J-25765-A) J
Preload gauge

K
ZZA0806D

Commercial Service Tools NES000LJ L

Tool name Description
Spring compressor Removing coil spring M

S-NT717

Power tool Loosening bolts and nuts

PBIC0190E

Revision: 2006 August FSU-3 2006 G35 Coupe
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003

NVH Troubleshooting Chart NES00022

Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.

NVH in FAX and FSU section.

NVH in RAX section.
NVH in RFD section.

NVH in WT section.
NVH in WT section.

NVH in BR section.
NVH in PS section.
NVH in PR section
FSU-18
FSU-11
FSU-8

FSU-8
FSU-6
--
--
--
Reference page

Shock absorber deformation, damage or deflection

FRONT AXLE AND FRONT SUSPENSION
Bushing or mounting deterioration
Improper installation, looseness

Possible cause and SUSPECTED PARTS

Incorrect wheel alignment
Suspension looseness

PROPELLER SHAFT
Stabilizer bar fatigue
Parts interference

DIFFERENTIAL

ROAD WHEEL
DRIVE SHAFT
Spring fatigue

STEERING
BRAKES
TIRES
Noise
