Image preview - the first page of the document

>> Download wt documenatation <<

Text preview - extract from the document

ROAD WHEELS & TIRES

E SUSPENSION

B
SECTION
ROAD WHEELS & TIRES C

WT
CONTENTS
PRECAUTIONS ......................................................... 3. Control Unit Input/Output Signal Standard ............ 17 . F
Precautions for Supplemental Restraint System ID Registration Procedure ..................................... 19 .
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN- ID REGISTRATION WITH ACTIVATION TOOL... 19
SIONER" ................................................................. 3
. ID REGISTRATION WITHOUT ACTIVATION G
Precautions for Battery Service ............................... 3 . TOOL .................................................................. 19
.
Service Notice or Precautions ................................. 3 . Transmitter Wake Up Operation ............................ 20 .
PREPARATION .......................................................... 4
. WITH ACTIVATION TOOL ................................. 20 .
H
Special Service Tools .............................................. 4. CONSULT-II Function (AIR PRESSURE MONI-
Commercial Service Tools ....................................... 4 . TOR) ...................................................................... 20
.
NOISE, VIBRATION AND HARSHNESS (NVH) CONSULT-II MAIN FUNCTION .......................... 20 .
TROUBLESHOOTING ............................................... 5 . CONSULT-II SETTING PROCEDURE ............... 20 . I
NVH Troubleshooting Chart .................................... 5 . WORK SUPPORT MODE .................................. 21 .
ROAD WHEEL ........................................................... 6
. SELF-DIAG RESULTS MODE ........................... 22 .
Inspection ................................................................ 6
. DATA MONITOR MODE ..................................... 23 . J
ALUMINUM WHEEL ............................................ 6 . ACTIVE TEST MODE ........................................ 23 .
STEEL WHEEL .................................................... 6 . Diagnosis Procedure with Warning Lamp Function
ROAD WHEEL TIRE ASSEMBLY ............................. 7 . (Without CONSULT-II) ........................................... 25 .
K
Balancing Wheels (Bonding Weight Type) .............. 7 . DESCRIPTION ................................................... 25 .
REMOVAL ............................................................ 7
. FUNCTION ......................................................... 25 .
WHEEL BALANCE ADJUSTMENT ..................... 7 . MALFUNCTION CODE CHART ......................... 25 .
Tire Rotation ............................................................ 8
. LOW TIRE PRESSURE WARNING LAMP L
DESCRIPTION ..................................................... 8 . SYMPTOM CHART ............................................ 26 .
LOW TIRE PRESSURE WARNING SYSTEM ......... 10 . Preliminary Check ................................................. 28 .
System Components ............................................. 10 . BASIC INSPECTION .......................................... 28 . M
System Description ............................................... 10 . TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC
TRANSMITTER .................................................. 10 . ITEMS ....................................................................... 29
.
REMOTE KEYLESS ENTRY RECEIVER .......... 10 . Transmitter or Control Unit (BCM) ......................... 29 .
BCM (BODY CONTROL MODULE) ....................11 . MALFUNCTION CODE NO. 21, 22, 23 OR 24 ... 29
LOW TIRE PRESSURE WARNING LAMP .........11 . Transmitter - 1 ....................................................... 29
.
Can Communication ...............................................11 . MALFUNCTION CODE NO. 31, 32, 33, 34, 41,
SYSTEM DESCRIPTION ....................................11 . 42, 43, 44, 45, 46, 47 OR 48 .............................. 29 .
TROUBLE DIAGNOSES ......................................... 12 . Transmitter - 2 ....................................................... 30
.
How to Perform Trouble Diagnosis ....................... 12 . MALFUNCTION CODE NO. 35, 36, 37 OR 38 ... 30
BASIC CONCEPT .............................................. 12 . Vehicle Speed Signal ............................................. 31 .
INTRODUCTION ................................................ 12 . MALFUNCTION CODE NO. 52 .......................... 31 .
WORK FLOW ..................................................... 13 . TROUBLE DIAGNOSIS FOR SYMPTOMS ............. 32 .
Wiring Diagram -- T/WARN -- ............................. 14 . Warning Lamp Does Not Come On When Ignition
Trouble Diagnosis Chart ........................................ 16 . Switch Is Turned On .............................................. 32 .
TROUBLE DIAGNOSIS CHART FOR SYMP- DIAGNOSTIC PROCEDURE ............................. 32 .
TOMS ................................................................. 16
. Warning Lamp Stays On When Ignition Switch Is

Revision: 2006 August WT-1 2006 G35 Coupe
Turned On .............................................................. 32
. TRANSMITTER ........................................................36 .
DIAGNOSTIC PROCEDURE ............................. 32 . Removal and Installation ........................................36 .
Warning Lamp Blinks When Ignition Switch Is REMOVAL ...........................................................36 .
Turned On .............................................................. 34
. INSTALLATION ...................................................36 .
DIAGNOSTIC PROCEDURE ............................. 34 . SERVICE DATA AND SPECIFICATIONS (SDS) .....38 .
Turn Signal Lamp Blinks When Ignition Switch Is Road Wheel ...........................................................38 .
Turned On .............................................................. 35
. Tire .........................................................................38
.
DIAGNOSTIC PROCEDURE ............................. 35 . Tightening Torque ..................................................38 .
ID Registration Can Not Be Completed ................. 35 .
DIAGNOSTIC PROCEDURE ............................. 35 .

Revision: 2006 August WT-2 2006 G35 Coupe
PRECAUTIONS

PRECAUTIONS PFP:00001
A
Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER" NES000DM

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along B
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front C
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING: D
q To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer. WT
q Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section. F
q Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
G
Precautions for Battery Service NES000BK

Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interfer-
ence between the window edge and the vehicle when the door is opened/closed. During normal operation, the H
window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic
window function will not work with the battery disconnected.
I
Service Notice or Precautions NES000CM

q Low tire pressure warning lamp flashes 1min., then turns ON when occurring any malfunction except low
tire pressure. J
Delete the memory with CONSULT-II, or register the ID to turn low tire pressure warning lamp OFF. Refer
to WT-22, "Erase Memory" , WT-19, "ID Registration Procedure" .
q ID registration is required when replacing wheels.Refer to WT-19, "ID Registration Procedure" .
K
q Replace grommet seal, valve core and cap of the transmitter in TPMS every tire replacement by reaching
wear limit of tire.
L

Revision: 2006 August WT-3 2006 G35 Coupe
PREPARATION

PREPARATION PFP:00002

Special Service Tools NES000BL

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.) Description
Tool name

(J-45295) ID registration
Transmitter activation tool

SEIA0462E

Commercial Service Tools NES000BM

Tool name Description
Power tool Removing wheel nuts

PBIC0190E

Revision: 2006 August WT-4 2006 G35 Coupe
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003
A
NVH Troubleshooting Chart NES00030

Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
B

Refer to ROAD WHEEL in this chart.
NVH in RAX and RSU sections.
NVH in FAX and FSU sections.

Refer to TIRES in this chart.
C

FAX-4, FSU-8

WT-38

WT-38
WT-6

WT-7

NVH in RFD section.

NVH in RAX section.
--

NVH in PR section.

NVH in BR section.

NVH in PS section.
Reference page
D

FRONT AXLE AND FRONT SUSPENSION
F

REAR AXLE AND REAR SUSPENSION
Improper installation, looseness

Deformation or damage
Possible cause and SUSPECTED PARTS
Incorrect tire pressure

PROPELLER SHAFT
H

Incorrect tire size
Uneven tire wear

ROAD WHEELS
DIFFERENTIAL

DRIVE SHAFT
Non-uniformity
Out-of-round

STEERING
Imbalance

BRAKE
TIRES
Noise
