Image preview - the first page of the document
acc


>> Download acc documenatation <<

Text preview - extract from the document
ACCELERATOR CONTROL SYSTEM


B ENGINE

                                                                                                                                                           A


                                                                                                                                                           ACC
                                                                               SECTION
                                              ACCELERATOR CONTROL SYSTEM                                                                                   C


                                                                                                                                                           D


                                                                                                                                                           E
                                                               CONTENTS
PRECAUTIONS ......................................................... 2
                                                                     .         Components ............................................................ 3
                                                                                                                                                 .         F
 Precautions for Supplemental Restraint System                                 Removal and Installation ......................................... 3
                                                                                                                                                 .
 (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                        REMOVAL ............................................................ 3
                                                                                                                                                 .
 SIONER" ................................................................. 2
                                                                     .          INSTALLATION .................................................... 3
                                                                                                                                                 .         G
 Precautions for Battery Service ............................... 2   .          INSPECTION AFTER INSTALLATION ................. 3                .
ACCELERATOR CONTROL SYSTEM ..................... 3                   .
                                                                                                                                                           H



                                                                                                                                                            I


                                                                                                                                                           J



                                                                                                                                                           K


                                                                                                                                                           L



                                                                                                                                                           M




Revision: 2006 August                                                   ACC-1                                                   2007 G35 Coupe
                                              PRECAUTIONS

PRECAUTIONS                                                         PFP:00001

Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER"                                                                                           NBS00137


The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
q    To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
     in the event of a collision which would result in air bag inflation, all maintenance must be per-
     formed by an authorized NISSAN/INFINITI dealer.
q    Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
     sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
     Bag Module, see the SRS section.
q    Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
     Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
     harness connectors.
Precautions for Battery Service                                                                               NBS00138


Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interfer-
ence between the window edge and the vehicle when the door is opened/closed. During normal operation, the
window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic
window function will not work with the battery disconnected.




Revision: 2006 August                                ACC-2                                        2007 G35 Coupe
                                       ACCELERATOR CONTROL SYSTEM

ACCELERATOR CONTROL SYSTEM                                                                         PFP:18005
                                                                                                                    A
Components                                                                                               NBS00139




                                                                                                                    ACC



                                                                                                                    C


                                                                                                                    D


                                                                                                                    E



                                                                                                                    F


                                                                                                                    G
                                                                                                  PBIC2080E

     1.   Accelerator pedal assembly

Removal and Installation                                                                                 NBS0013A
                                                                                                                    H
REMOVAL
1.    Disconnect accelerator pedal position sensor harness connector.
2.    Loosen nuts, and remove accelerator pedal assembly.                                                            I
      CAUTION:
      q Do not disassemble accelerator pedal assembly. Do not remove accelerator pedal position sen-
        sor from accelerator pedal assembly.                                                                        J
      q Avoid impact from dropping etc. during handling.

      q Be careful to keep accelerator pedal assembly away from water.
                                                                                                                    K
INSTALLATION
Install in the reverse order of removal.
INSPECTION AFTER INSTALLATION                                                                                       L
q     Make sure that accelerator pedal moves smoothly within the whole operation range.
q     Make sure that accelerator pedal securely returns to the original position.
                                                                                                                    M
q     For the electrical inspection of accelerator pedal position sensor. Refer to EC-592, "DTC P2122, P2123
      APP SENSOR" , EC-599, "DTC P2127, P2128 APP SENSOR" and EC-613, "DTC P2138 APP SEN-
      SOR" .
      CAUTION:
      When harness connector of accelerator pedal position sensor is disconnected, perform "Acceler-
      ator Pedal Released Position Learning". Refer to EC-79, "Accelerator Pedal Released Position
      Learning" .




Revision: 2006 August                             ACC-3                                    2007 G35 Coupe
                        ACCELERATOR CONTROL SYSTEM




Revision: 2006 August             ACC-4              2007 G35 Coupe
