Image preview - the first page of the document

>> Download lu documenatation <<

Text preview - extract from the document

ENGINE LUBRICATION SYSTEM

B ENGINE

LU
SECTION
ENGINE LUBRICATION SYSTEM C

E
CONTENTS
PRECAUTIONS ......................................................... 2. Components .......................................................... 11
. F
Precautions for Battery Service ............................... 2 . Removal and Installation ....................................... 11 .
Precautions for Liquid Gasket ................................. 2 . REMOVAL .......................................................... 11
.
LIQUID GASKET APPLICATION PROCEDURE 2 ..... INSPECTION AFTER REMOVAL ...................... 12 . G
PREPARATION .......................................................... 3
. INSTALLATION .................................................. 12 .
Special Service Tools .............................................. 3. INSPECTION AFTER INSTALLATION ............... 12 .
Commercial Service Tools ....................................... 3 . OIL PUMP ................................................................ 13
.
H
LUBRICATION SYSTEM ........................................... 4 . Components .......................................................... 13
.
Lubrication Circuit ................................................... 4
. Removal and Installation ....................................... 13 .
System Chart .......................................................... 5
. REMOVAL .......................................................... 13
.
ENGINE OIL .............................................................. 7
. INSTALLATION .................................................. 13 . I
Inspection ................................................................ 7
. INSPECTION AFTER INSTALLATION ............... 13 .
OIL LEVEL ........................................................... 7
. Disassembly and Assembly ................................... 13 .
OIL APPEARANCE .............................................. 7 . DISASSEMBLY .................................................. 13 . J
OIL LEAKAGE ...................................................... 7. INSPECTION AFTER DISASSEMBLY ............... 14 .
OIL PRESSURE CHECK ..................................... 8 . ASSEMBLY ........................................................ 15
.
Changing Engine Oil ............................................... 9 . SERVICE DATA AND SPECIFICATIONS (SDS) ..... 16 .
K
OIL FILTER .............................................................. 10
. Standard and Limit ................................................. 16
.
Removal and Installation ....................................... 10 . OIL PRESSURE ................................................. 16 .
REMOVAL .......................................................... 10
. OIL CAPACITY (APPROXIMATE) ...................... 16 .
INSTALLATION .................................................. 10 . OIL PUMP .......................................................... 16
. L
INSPECTION AFTER INSTALLATION .............. 10 . REGULATOR VALVE ......................................... 16 .
OIL COOLER ............................................................11
.
M

Revision: 2006 August LU-1 2007 G35 Coupe
PRECAUTIONS

PRECAUTIONS PFP:00001

Precautions for Battery Service NBS000KY

Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interfer-
ence between the window edge and the vehicle when the door is opened/closed. During normal operation, the
window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic
window function will not work with the battery disconnected.
Precautions for Liquid Gasket NBS000KZ

LIQUID GASKET APPLICATION PROCEDURE
1. Remove old liquid gasket adhering to the liquid gasket application surface and the mating surface.
q Remove liquid gasket completely from the liquid gasket application surface, mounting bolts, and bolt
holes.
2. Wipe the liquid gasket application surface and the mating surface with white gasoline (lighting and heating
use) to remove adhering moisture, grease and foreign materials.
3. Apply liquid gasket to the liquid gasket application surface.
Use Genuine RTV Silicone Sealant or equivalent. Refer to GI-46, "RECOMMENDED CHEMICAL
PRODUCTS AND SEALANTS" .
q Within five minutes of liquid gasket application, install the mating component.

q If liquid gasket protrudes, wipe it off immediately.

q Do not retighten mounting bolts or nuts after the installation.

q After 30 minutes or more have passed from the installation, fill engine oil and engine coolant.

Revision: 2006 August LU-2 2007 G35 Coupe
PREPARATION

PREPARATION PFP:00002
A
Special Service Tools NBS000L0

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number LU
(Kent-Moore No.) Description
Tool name

ST25051001 Measuring oil pressure
C
(J25695-1) Maximum measuring range: 2,452 kPa (25
Oil pressure gauge kg-cm2 , 356 psi)

NT050

ST25052000 Adapting oil pressure gauge to upper oil pan
E
(J25695-2) (upper)
Hose
F

S-NT559
G
KV10115801 Removing oil filter
(J38956) a: 64.3 mm (2.531 in)
Oil filter wrench
H

I
S-NT375

J
Commercial Service Tools NBS000L1

Tool name Description
K
Deep socket Removing and installing oil pressure switch
a: 26 mm (1.02 in)

PBIC2072E M
Power tool Loosening bolts and nuts

PBIC0190E

Revision: 2006 August LU-3 2007 G35 Coupe
LUBRICATION SYSTEM

LUBRICATION SYSTEM PFP:15010

Lubrication Circuit NBS000L2

M/T Models

PBIC3486E

Revision: 2006 August LU-4 2007 G35 Coupe
LUBRICATION SYSTEM

A/T Models
A

PBIC1933E I
System Chart NBS000L3

M/T Models J

PBIC3487E

Revision: 2006 August LU-5 2007 G35 Coupe
LUBRICATION SYSTEM

A/T Models

PBIC2071E

Revision: 2006 August LU-6 2007 G35 Coupe
ENGINE OIL

ENGINE OIL PFP:KLA92
A
Inspection NBS002VE

OIL LEVEL
NOTE: LU
Before starting engine, put vehicle horizontally and check the oil level. If engine is already started, stop it and
allow 10 minutes before checking.
1. Pull out oil level gauge and wipe it clean.
C
2. Insert oil level gauge and make sure the oil level is within the
range shown in the figure.
3. If it is out of range, adjust it.
D

F
PBIC3101E

NOTE:
When checking oil level, insert oil level gauge with its tip aligned with G
oil level gauge guide on cylinder head. (In the figure, air cleaner case
and air duct are removed.)
H

KBIA1343E
J

OIL APPEARANCE
q Check the engine oil for white turbidity or heavy contamination. K
q If the engine oil becomes turbid and white, it is highly probable that it is contaminated with engine coolant.
Repair or replace damaged parts.
OIL LEAKAGE L
Check for oil leakage around the following areas:
q Oil pans (lower and upper)
q Oil pan drain plug M
q Oil pressure switch
q Oil filter
q Oil cooler
q Water pump cover
q Chain tensioner cover
q Intake valve timing control solenoid valve
q Intake valve timing control cover (A/T models)
q Valve timing control cover (M/T models)
q Mating surface between cylinder head and rocker cover
q Mating surface between front timing chain case and rear timing chain case
q Mating surface between rear timing chain case and cylinder head
q Mating surface between rear timing chain case and cylinder block
q Mating surface between rear timing chain case and oil pan (upper)
q Mating surface between cylinder block and cylinder head
Revision: 2006 August LU-7 2007 G35 Coupe
ENGINE OIL

q Crankshaft oil seals (front and rear)
q Camshaft position sensor (PHASE)
OIL PRESSURE CHECK
WARNING:
q Be careful not to burn yourself, as engine oil may be hot.
q Oil pressure check should be done in "Neutral position" (M/T models) or "Parking position" (A/T
models).
1. Check oil level. Refer to LU-7, "OIL LEVEL" .
2. Remove undercover with power tool.
3. Disconnect oil pressure switch harness connector.
4. Remove oil pressure switch.

PBIC0818E

5. Install oil pressure gauge and hose (SST).

SLC926

6. Start engine and warm it up to normal operating temperature.
7. Check oil pressure with engine running under no-load.
NOTE:
When engine oil temperature is low, engine oil pressure becomes high.
Engine oil pressure [Engine oil temperature at 80
