Image preview - the first page of the document
>> Download fax documenatation <<
Text preview - extract from the document
FRONT AXLE
D DRIVELINE/AXLE
A
SECTION FAX FRONT AXLE
B
C
FAX
E
CONTENTS
2WD FRONT WHEEL HUB AND KNUCKLE ................... 12 . F
On-Vehicle Inspection and Service ........................ 12 .
PREPARATION .......................................................... 2 . WHEEL BEARING INSPECTION ...................... 12 .
Special Service Tools .............................................. 2 . Removal and Installation ....................................... 12 . G
Commercial Service Tools ....................................... 2 . REMOVAL .......................................................... 12 .
NOISE, VIBRATION AND HARSHNESS (NVH) INSPECTION AFTER REMOVAL ...................... 13 .
TROUBLESHOOTING ............................................... 3 . INSTALLATION .................................................. 14 .
NVH Troubleshooting Chart .................................... 3 . H
Disassembly and Assembly ................................... 14 .
FRONT WHEEL HUB AND KNUCKLE ..................... 4 . DISASSEMBLY .................................................. 14 .
On-Vehicle Inspection ............................................. 4 . INSPECTION AFTER DISASSEMBLY ............... 14 .
WHEEL BEARING INSPECTION ........................ 4 . ASSEMBLY ........................................................ 15 . I
Removal and Installation ......................................... 4 . FRONT DRIVE SHAFT ............................................ 16 .
COMPONENTS ................................................... 4 . On Vehicle Inspection and Service ........................ 16 .
REMOVAL ............................................................ 4. DRIVE SHAFT BOOT REPLACEMENT ............. 16 . J
INSPECTION AFTER REMOVAL ........................ 5 . Removal and installation ....................................... 19 .
INSTALLATION .................................................... 6 . REMOVAL .......................................................... 19 .
SERVICE DATA AND SPECIFICATIONS (SDS) ....... 7 . INSPECTION AFTER REMOVAL ...................... 20 .
Wheel Bearing ......................................................... 7
. K
INSTALLATION .................................................. 20 .
Ball Joint .................................................................. 7
. Disassembly and Assembly ................................... 21 .
DISASSEMBLY .................................................. 21 .
AWD INSPECTION AFTER DISASSEMBLY ............... 22 . L
ASSEMBLY ........................................................ 23 .
PRECAUTIONS ......................................................... 8 . SERVICE DATA AND SPECIFICATIONS (SDS) ..... 27 .
Caution .................................................................... 8
. Wheel Bearing ....................................................... 27. M
PREPARATION .......................................................... 9. Ball Joint ................................................................ 27
.
Special Service Tools .............................................. 9 . Drive Shaft ............................................................. 27
.
Commercial Service Tools ..................................... 10 . Z80T70C ............................................................ 27
.
NOISE, VIBRATION AND HARSHNESS (NVH) Z80T82F ............................................................. 27
.
TROUBLESHOOTING ..............................................11 .
NVH Troubleshooting Chart ...................................11 .
Revision: 2006 August FAX-1 2006 G35 Sedan
PREPARATION
[2WD]
PREPARATION
[2WD] PFP:00002
Special Service Tools NDS0004W
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.) Description
Tool name
HT72520000 Removing steering outer socket
(J-25730-A)
Ball joint remover
a: 33 mm (1.30 in)
b: 50 mm (1.97 in)
r: 11.5 mm (0.453 in)
NT546
ST3127S000 Measuring rotating torque of ball joint
(J-25765-A)
Preload gauge
ZZA0806D
Commercial Service Tools NDS0004X
Tool name Description
Power tool Loosening bolts and nuts
PBIC0190E
Revision: 2006 August FAX-2 2006 G35 Sedan
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
[2WD]
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003
A
NVH Troubleshooting Chart NDS0004Y
Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
B
NVH in WT section.
NVH in WT section.
NVH in PS section.
FAX-4
FAX-4
--
Reference page C
FAX
Improper installation, looseness
Wheel bearing damage
E
Parts interference
Possible cause and SUSPECTED PARTS
ROAD WHEEL
F
STEERING
TIRES
G
