Image preview - the first page of the document
mt


>> Download mt documenatation <<

Text preview - extract from the document
MANUAL TRANSMISSION


C TRANSMISSION/TRANSAXLE

                                                                                                                                                                   A




                                                                                                   SECTION
                                                                                   MANUAL TRANSMISSION
                                                                                                                              MT                                   B


                                                                                                                                                                   MT


                                                                                                                                                                   D


                                                                                                                                                                   E
                                                                   CONTENTS
PRECAUTIONS ......................................................... 2  .         SHIFT CONTROL .................................................... 12  .        F
 Service Notice or Precautions ................................. 2       .          Removal and Installation ....................................... 12   .
PREPARATION .......................................................... 3 .            COMPONENTS .................................................. 12    .
 Special Service Tools .............................................. 3  .            REMOVAL .......................................................... 12
                                                                                                                                                          .        G
 Commercial Service Tools ....................................... 5      .            INSTALLATION .................................................. 14  .
NOISE, VIBRATION AND HARSHNESS (NVH)                                                  INSPECTION AFTER INSTALLATION ............... 16                    .
TROUBLESHOOTING ............................................... 6        .         AIR BREATHER HOSE ........................................... 17       .
                                                                                                                                                                   H
 NVH Troubleshooting Chart .................................... 6        .          Removal and Installation ....................................... 17   .
DESCRIPTION ........................................................... 7.         TRANSMISSION ASSEMBLY ................................. 18             .
 Cross-Sectional View .............................................. 7   .          Removal and Installation ....................................... 18   .
   DOUBLE-CONE SYNCHRONIZER ..................... 8                      .            COMPONENTS .................................................. 18    .         I
   TRIPLE-CONE SYNCHRONIZER ....................... 8                    .            REMOVAL .......................................................... 18
                                                                                                                                                          .
M/T OIL ...................................................................... 9
                                                                         .            INSTALLATION .................................................. 20  .
 Changing M/T Oil .................................................... 9 .          Disassembly and Assembly ................................... 21       .        J
   DRAINING ............................................................ 9
                                                                         .            COMPONENTS .................................................. 21    .
   FILLING ................................................................ 9
                                                                         .            DISASSEMBLY .................................................. 26   .
 Checking M/T Oil ..................................................... 9.            INSPECTION AFTER DISASSEMBLY ............... 37                     .
                                                                                                                                                                   K
   OIL LEAKAGE AND OIL LEVEL .......................... 9                .            ASSEMBLY ........................................................ 40.
REAR OIL SEAL ..................................................... 10   .         SERVICE DATA AND SPECIFICATIONS (SDS) ..... 59                         .
 Removal and Installation ....................................... 10     .          General Specifications ........................................... 59 .
   REMOVAL .......................................................... 10 .          End Play ................................................................ 59
                                                                                                                                                          .        L
   INSTALLATION .................................................. 10    .          Snap Rings ............................................................ 60
                                                                                                                                                          .
POSITION SWITCH ..................................................11     .          Baulk Ring Clearance ............................................ 61  .
 Checking ................................................................11
                                                                         .                                                                                         M
   COMPONENT LOCATION ..................................11               .
   BACK-UP LAMP SWITCH ..................................11              .
   PARK/NEUTRAL POSITION SWITCH ...............11                        .




Revision: 2006 August                                                        MT-1                                                       2006 G35 Sedan
                                            PRECAUTIONS

PRECAUTIONS                                                                                            PFP:00001

Service Notice or Precautions                                                                             NCS000K8


q   Do not reuse transmission oil, once it has been drained.
q   Check oil level or replace oil with vehicle on level ground.
q   During removal or installation, keep inside of transmission clear of dust or dirt.
q   Check for the correct installation status prior to removal or disassembly. If matching marks are required,
    be certain they do not interfere with the function of the parts they are applied to.
q   In principle, tighten bolts or nuts gradually in several steps working diagonally from inside to outside. If
    tightening sequence is specified, observe it.
q   Be careful not to damage sliding surfaces and mating surfaces.
q   Do not hold control lever housing to prevent bushing of control lever housing from deformation when mov-
    ing transmission assembly.




Revision: 2006 August                               MT-2                                       2006 G35 Sedan
                                                       PREPARATION

PREPARATION                                                                                                                     PFP:00002
                                                                                                                                              A
Special Service Tools                                                                                                              NCS000K9

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
  Tool number                                                                                                                                 B
  (Kent-Moore No.)                                                                       Description
  Tool name

  ST30911000                                                                             q   Main shaft bearing installation
                                                                                                                                              MT
  (    --    )                                                                           q   5th-6th synchronizer assembly installation
  Inserter
  a: 98 mm (3.86 in) dia.                                                                q   Reverse main gear bushing installation
  b: 40 mm (1.57 in) dia.                                                                q   3rd gear bushing installation                    D
                                                                                         q   3rd-4th synchronizer assembly installation

                                                                        ZZA0920D


  ST30022000                                                                             q   3rd main gear installation
                                                                                                                                              E
  (    --    )                                                                           q   4th main gear installation
  Inserter
  a: 110 mm (4.33 in) dia.
                                                                                                                                              F
  b: 46 mm (1.81 in) dia.


                                                                        ZZA0920D
                                                                                                                                              G
  ST27861000                                                                             q   1st-2nd synchronizer assembly installation
  (    --     )                                                                          q   1st gear bushing installation
  Support ring
                                                                                                                                              H
  a: 62 mm (2.44 in) dia.
  b: 52 mm (2.05 in) dia.

                                                                                                                                               I
                                                                        ZZA0832D


  ST33400001                                                                             Rear oil seal installation
  (J-26082)
  Drift                                                                                                                                       J
  a: 60 mm (2.36 in) dia.
  b: 47 mm (1.85 in) dia.
                                                                                                                                              K
                                                                        ZZA0814D


  KV381054S0                                                                             Remove rear oil seal
  (     --     )                                                                                                                              L
  Oil seal puller


                                                                                                                                              M

                                                                        ZZA0601D


  ST30032000                                                                             Counter rear bearing inner race installation
  (J-26010-01)
  Inserter
  a: 80 mm (3.15 in) dia.
  b: 31 mm (1.22 in) dia.


                                                                        ZZA0920D


  KV32102700                                                                             Main drive gear bearing installation
  (     --   )
  Drift
  a: 48 mm (1.89 in) dia.
  b: 41 mm (1.61 in) dia.


                                                                        ZZA0534D




Revision: 2006 August                                           MT-3                                                  2006 G35 Sedan
                               PREPARATION

  Tool number
  (Kent-Moore No.)                                Description
  Tool name

  ST23860000                                      Reverse counter gear installation
  (     --   )
  Drift
  a: 38 mm (1.50 in) dia.
  b: 33 mm (1.30 in) dia.


                                      ZZA0534D


  ST01530000                                      Reverse synchronizer assembly installation
  (     --   )
  Drift
  a: 50 mm (1.97 in) dia.
  b: 41 mm (1.61 in) dia.


                                      ZZA0534D


  ST35291000                                      Striking rod oil seal installation
  (     --   )
  Drift
  a: 40 mm (1.57 in) dia.
  b: 29.5 mm (1.161 in) dia.
  c: 22.5 mm (0.886 in) dia.

                                      SCIA1575E


  KV40100630                                      4th counter gear thrust washer installation
  (J-26092)
  Inserter
  a: 67 mm (2.64 in) dia.
  b: 38 mm (1.50 in) dia.


                                      ZZA0920D


  KV38102100                                      Front cover oil seal installation
  (J-25803-01)
  Drift
  a: 44 mm (2.36 in) dia.
  b: 36 mm (1.42 in) dia.
  c: 24.5 mm (0.965 in) dia.

                                      ZZA1046D


  KV32103300                                      Reverse synchronizer assembly installation
  (J-46529)
  Press plate




                                      PCIB0165J




Revision: 2006 August             MT-4                                          2006 G35 Sedan
                                        PREPARATION

  Tool number
  (Kent-Moore No.)                                            Description                                         A
  Tool name

  ST30031000                                                  Inner baulk ring support
  (J-22912-01)                                                                                                    B
  Puller


                                                                                                                  MT

                                               ZZC0499D


  ST22490000                                                  Hold adapter plate                                  D
  (   --      )
  Adapter setting plate

                                                                                                                  E


                                               ZZC0465D
                                                                                                                  F
Commercial Service Tools                                                                               NCS000KA



  Tool name                                                   Description
                                                                                                                  G
  Puller                                                      Each bearing, gear and bushing removal


                                                                                                                  H



                                                                                                                   I
                                                  ZZB0823D


  Pin punch                                                   Each retaining pin removal and installation
  Tip diameter: 6.0 mm (0.24 in) dia.
                                                                                                                  J



                                                                                                                  K
                                                  ZZA0815D


  Puller                                                      q   Reverse synchronizer assembly removal
                                                                                                                  L
                                                              q   Reverse counter gear removal
                                                              q   Reverse main gear removal

                                                                                                                  M

                                                  NT077


  Power tool                                                  Loosening bolts and nuts




                                                  PBIC0190E




Revision: 2006 August                      MT-5                                          2006 G35 Sedan
         NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING                                                                                                                                                                                                                                                                                                         PFP:00003

NVH Troubleshooting Chart                                                                                                                                                                                                                                                                                                                                                       NCS000KB


Use the chart below to help you find the cause of the symptom. The numbers indicate the order of the inspec-
tion. If necessary, repair or replace these parts.




                                                                                                                             MT-21


                                                                                                                                                MT-21


                                                                                                                                                                             MT-12


                                                                                                                                                                                                            MT-24


                                                                                                                                                                                                                                                                        MT-24


                                                                                                                                                                                                                                                                                            MT-22


                                                                                                                                                                                                                                                                                                                     MT-22


                                                                                                                                                                                                                                                                                                                                                 MT-22


                                                                                                                                                                                                                                                                                                                                                                                  MT-22
                                                    MT-9


                                                                              MT-9


                                                                                                  MT-9
 Reference page




                                                                                                                                                                                                            CHECK PLUG RETURN SPRING AND CHECK BALL (Worn or damaged)
 SUSPECTED PARTS
 (Possible cause)




                                                                                                                                                                             SHIFT CONTROL LINKAGE (Worn)




                                                                                                                                                                                                                                                                                                                                                 BAULK RING (Worn or damaged)
                                                                                                                                                                                                                                                                                                                     BEARING (Worn or damaged)
                                                                                                                                                OIL SEAL (Worn or damaged)




                                                                                                                                                                                                                                                                                                                                                                                  INSERT SPRING (Damaged)
                                                                                                                                                                                                                                                                                            GEAR (Worn or damaged)
                                                                                                  OIL (Oil level is high.)


                                                                                                                             GASKET (Damaged)




                                                                                                                                                                                                                                                                        SHIFT FORK (Worn)
                                                    OIL (Oil level is low.)


                                                                              OIL (Wrong oil.)




                  Noise                                      1                      2                                                                                                                                                                                                               3                          3
                  Oil leakage                                                       3                      1                       2                      2
 Symptoms
                  Hard to shift or will not shift                                   1                      1                                                                            2                                                                                                                                                                   2                              2
                  Jumps out of gear                                                                                                                                                     1                                          1                                          2                     2




Revision: 2006 August                                                                            MT-6                                                                                                                                                                                                                2006 G35 Sedan
                                          DESCRIPTION

DESCRIPTION                                                                                        PFP:00000
                                                                                                                   A
Cross-Sectional View                                                                                    NCS000KC




                                                                                                                   B


                                                                                                                   MT


                                                                                                                   D


                                                                                                                   E



                                                                                                                   F


                                                                                                                   G


                                                                                                                   H



                                                                                                                    I


                                                                                                                   J


                                                                                                  PCIB0672E
                                                                                                                   K
   1.   Front cover               2.   Main drive gear            3.   5th-6th synchronizer hub
   4.   5th-6th coupling sleeve   5.   Transmission case          6.   6th main gear
   7.   2nd main gear             8.   1st-2nd synchronizer hub   9.   1st-2nd coupling sleeve                     L
   10. 1st main gear              11. 3rd main gear               12. 4th main gear
   13. Reverse main gear          14. Reverse coupling sleeve     15. Reverse synchronizer hub
   16. Striking rod               17. Counter shaft               18. Filler plug                                  M
   19. 6th counter gear           20. 2nd counter gear            21. 1st counter gear
   22. 3rd counter gear           23. 3rd-4th synchronizer hub    24. 3rd-4th coupling sleeve
   25. Drain plug                 26. 4th counter gear            27. Reverse idler gear
   28. Reverse idler shaft        29. Reverse counter gear        30. Main shaft
   31. Rear extension




Revision: 2006 August                            MT-7                                      2006 G35 Sedan
                                             DESCRIPTION

DOUBLE-CONE SYNCHRONIZER
The 4th gear is equipped with a double-cone synchronizer to reduce the operating force of the shift lever.
TRIPLE-CONE SYNCHRONIZER
The 1st, 2nd and 3rd gears is equipped with a triple-cone synchro-
nizer to reduce the operating force of the shift lever.




                                                                                                       PCIB1432E




Revision: 2006 August                               MT-8                                      2006 G35 Sedan
                                                     M/T OIL

M/T OIL                                                                                            PFP:KLD20
                                                                                                                   A
Changing M/T Oil                                                                                       NCS000KD

DRAINING
1.   Start the engine and warm up the transmission unit sufficiently.
                                                                                                             B
2.   After stopping engine, remove filler plug and drain plug to drain oil.
3.   Replace gasket on drain plug with new one. Screw drain plug into transmission case, and tighten to the
     specified torque. Refer to MT-21, "COMPONENTS" .                                                       MT
     CAUTION:
     Do not reuse gasket.
FILLING                                                                                                            D
1.   Fill new oil into the transmission to the level of the filler plug mounting hole.
        Oil grade and viscosity
                                                                                                                   E
            : Refer to MA-10, "RECOMMENDED FLUIDS AND LUBRICANTS" .
        Oil capacity
            : Approx. 2.9     (3-1/8 US qt, 2-1/2 lmp qt)                                                          F
2.   Replace gasket on filler plug with new one. Screw filler plug into transmission case, and tighten to the
     specified torque. Refer to MT-21, "COMPONENTS" .
     CAUTION:                                                                                                      G
     Do not reuse gasket.
Checking M/T Oil                                                                                        NCS000KE
                                                                                                                   H
OIL LEAKAGE AND OIL LEVEL
q    Check if oil is leaking from transmission or around it.
q    Check oil level from filler plug mounting hole as shown in the fig-                                           I
     ure.
     CAUTION:
     Never start engine while checking oil level.
                                                                                                                   J
q    When screwing in filler plug with a new gasket, first screw into
     the transmission by hand, then tighten to the specified torque.
     Refer to MT-21, "COMPONENTS" .
                                                                                                                   K
     CAUTION:
     Do not reuse gasket.
                                                                                                     PCIB0268E     L



                                                                                                                   M




Revision: 2006 August                                  MT-9                                 2006 G35 Sedan
                                             REAR OIL SEAL

REAR OIL SEAL                                                                                   PFP:33140

Removal and Installation                                                                            NCS000KF

REMOVAL
1.   Remove propeller shaft. Refer to PR-5, "Removal and Installation" .
2.   Remove rear oil seal using oil seal puller.
         Tool number       : KV381054S0 (       -- )




                                                                                                 PCIB0194E


INSTALLATION
1.   Apply multi-purpose grease to rear oil seal lip. Drive in rear oil
     seal until the edge is approximately 1.2 - 2.2 mm (0.047 - 0.087
     in) above the boss edge using drift.
         Tool number       : ST33400001 (J-26082)
     CAUTION:
     q Do not reuse rear oil seal.
     q When installing, do not tilt oil seal.




                                                                                                 PCIB0267E



2.   Install propeller shaft. Refer to PR-5, "Removal and Installation" .
     CAUTION:
     q If lubricant leak has occurred during the repair work, check oil level after finishing work. Refer
       to MT-9, "Checking M/T Oil" .




Revision: 2006 August                                  MT-10                             2006 G35 Sedan
                              POSITION SWITCH

POSITION SWITCH                                       PFP:32005
                                                                      A
Checking                                                   NCS000KG

COMPONENT LOCATION
                                                                      B


                                                                      MT


                                                                      D


                                                     PCIB1384E
                                                                      E
BACK-UP LAMP SWITCH
q      Check continuity.
              Gear position     Continuity
                                                                      F

    Reverse                        Yes
    Except reverse                 No                                 G


                                                                      H

                                                        SCIA0645E


PARK/NEUTRAL POSITION SWITCH                                           I
q      Check continuity.
              Gear position     Continuity                            J
    Neutral                        Yes
    Except neutral                 No
                                                                      K


                                                                      L

                                                        SCIA0645E



                                                                      M




Revision: 2006 August                 MT-11     2006 G35 Sedan
                                            SHIFT CONTROL

SHIFT CONTROL                                                                                          PFP:34103

Removal and Installation                                                                                     NCS000KH

COMPONENTS




                                                                                                      PCIB0689E

     1.   Insulator                   2.   Seat                        3.   Control lever assembly
     4.   Control lever spring        5.   Guide plate                 6.   Control lever boot
     7.   Hole cover                  8.   Shift knob

REMOVAL
1.    Remove shift knob with the following procedure.
a.    Release metal clips on console boot from center console. Refer
      to IP-11, "Removal and Installation" .




                                                                                                         PCIB0435E




Revision: 2006 August                                   MT-12                                    2006 G35 Sedan
                                             SHIFT CONTROL

b.   Lift console boot, and push down hole cover. Set water pump
     pliers or a suitable tool to control lever assembly.                                     A
     CAUTION:
     Put waste cloth between water pump pliers and control
     lever assembly to avoid damaging control lever assembly.                                 B


                                                                                              MT

                                                                                  SCIA2607E

                                                                                              D
c.   Set monkey wrench to shift knob.
     CAUTION:
     Put waste cloth between shift knob and monkey wrench to                                  E
     avoid damaging shift knob.


                                                                                              F


                                                                                              G
                                                                                  SCIA2608E



d.   Keeping control lever in place with water pump pliers, turn mon-                         H
     key wrench counterclockwise to loosen shift knob.
     NOTE:
     Remove shift knob from control lever keeping water pump pliers
     in place because a certain power to turn shift knob is still neces-                       I
     sary even after adhesive is peeled.
2.   Remove console boot. Refer to IP-11, "Removal and Installa-
     tion" .                                                                                  J


                                                                                  SCIA2609J
                                                                                              K
3.   Release the boot, remove control rod mounting bolt, and sepa-
     rate control lever and control rod.
                                                                                              L



                                                                                              M




                                                                                  SCIA1671E



4.   Remove the mounting bolts to remove hole cover.
5.   Remove the control lever boot.




                                                                                  SCIA1511E




Revision: 2006 August                                MT-13                 2006 G35 Sedan
                                             SHIFT CONTROL

6.   Remove guide plate mounting bolts, and then remove control
     lever assembly and control lever spring from control lever hous-
     ing.




                                                                                                     SCIA1365E


INSTALLATION
1.   Set control lever assembly and control lever spring in the control lever housing and loosely mount guide
     plate.
2.   After installing control lever assembly in control rod, tighten bolt
     to the specified torque. Refer to MT-12, "Removal and Installa-
     tion" .




                                                                                                     SCIA2561J



3.   After shifting control lever assembly into 6th gear, push it toward
     reverse gear (to the right) until it comes to a stop.
4.   At the point where the control lever assembly stops, bring the
     guide plate closer until guide plate stopper contacts control lever
     assembly claw, and then loosely tighten mounting bolt A.




                                                                                                     SCIA1665E




Revision: 2006 August                                MT-14                                   2006 G35 Sedan
                                             SHIFT CONTROL

5.  After shifting control lever assembly into 5th gear, push it toward
    reverse gear (to the right) until it comes to a stop.                                        A
6. At the point where control lever assembly stops, bring guide
    plate closer until the guide plate stopper contacts control lever
    assembly claw, and then tighten mounting bolt C to the specified                             B
    torque. Refer to MT-12, "Removal and Installation" .
7. Tighten guide plate bolts A and B to the specified torque. Refer
    to MT-12, "Removal and Installation" .
                                                                                                 MT
8. Install control lever boot.
9. Install hole cover and tighten bolts to the specified torque. Refer
    to MT-12, "Removal and Installation" .                                                       D
10. Install console boot to the center console. Refer to IP-11,
    "Removal and Installation" .
                                                                                                 E



                                                                                                 F


                                                                                                 G
                                                                                     SCIA1666E



11. As shown in the figure, assemble seat and insulator to control
    lever assembly.                                                                              H
    CAUTION:
    Do not reuse insulator.
12. Apply locking sealant to control lever threads, install shift knob.                           I
    CAUTION:
    Remove the remaining adhesive on control lever and shift
    knob threads.                                                                                J


                                                                                     SCIA1771E
                                                                                                 K
13. Put the shift knob in the correct position as the following indicates.
a. When tightening shift knob, if shift knob comes to the proper
    position within 1/2 turn from the position at which resistance                               L
    begins to be felt, tighten it 1 more turn to set it in the proper posi-
    tion.
b. If it takes more than 1/2 turn from the position at which resis-                              M
    tance begins to be felt, tighten it to set it in the proper position.
CAUTION:
q   Do not adjust the knob with loosing.
q   After adjusting to the regular position, until 30 minutes
    pass, do not operate the shift intensely such as screwing or
    turning the shift knob to opposite direction since a locking
    sealant because stiff.




                                                                                     SCIA1774E


Revision: 2006 August                                MT-15                    2006 G35 Sedan
                                           SHIFT CONTROL

INSPECTION AFTER INSTALLATION
After installing, confirm the following items:
q   When control lever assembly is shifted to each position, make sure there is no binding or disconnection in
    each boot.
q   When shifted to each position, make sure there is no noise, binding, and backlash. Especially when con-
    trol lever assembly is shifted to 5th, 6th without pressing downward, check for binding.
q   When control lever assembly is shifted to 1st, 2nd side and 5th, 6th side, confirm control lever assembly
    returns to neutral position smoothly.
q   In any position other than reverse, confirm that control lever assembly can be pressed downward.
q   With control lever assembly pressed downward, confirm that it can be shifted to reverse.
q   When shifted from reverse to neutral position, confirm control lever assembly returns to neutral position
    smoothly with spring power.
q   Without control lever assembly pressed downward, confirm that it cannot be shifted to reverse.




Revision: 2006 August                             MT-16                                      2006 G35 Sedan
                                        AIR BREATHER HOSE

AIR BREATHER HOSE                                                                       PFP:31098
                                                                                                         A
Removal and Installation                                                                      NCS000KI


Refer to the figure for air breather hose removal and installation information.
                                                                                                         B


                                                                                                         MT


                                                                                                         D


                                                                                                         E



                                                                                                         F


                                                                                                         G

                                                                                       PCIB0690E

   1.   Air breather hose                                                                                H
CAUTION:
q  Make sure there are no pinched or blocked areas on the air breather hose caused by bending
   when installing it.                                                                                    I
q  Insert overlap width of air breather hose as far as it will go.

                                                                                                         J



                                                                                                         K


                                                                                                         L



                                                                                                         M




Revision: 2006 August                               MT-17                         2006 G35 Sedan
                                   TRANSMISSION ASSEMBLY

TRANSMISSION ASSEMBLY                                                                             PFP:32010

Removal and Installation                                                                                NCS000KJ

COMPONENTS




                                                                                                 PCIB0691E

     1.   Transmission case           2.   Rear engine mounting member   3.   Insulator

REMOVAL
1.    Disconnect the battery cable from the negative terminal.
2.    Remove catalytic converter stay mounting nuts and bolts, and
      then remove exhaust mounting bracket. Refer to EX-4,
      "Removal and Installation" .




                                                                                                    SCIA1471E



3.    Remove nut connecting catalytic converter to exhaust manifold, and then remove three way catalyst and
      exhaust front tube as one unit.
4.    Remove propeller shaft. Refer to PR-5, "Removal and Installation" .
5.    Remove control rod mounting bolts and then separate control
      lever assembly from the control rod assembly.




                                                                                                    SCIA1364E




Revision: 2006 August                               MT-18                                  2006 G35 Sedan
                                    TRANSMISSION ASSEMBLY

6.   Using a suitable tool, release claws and separate console boot
     from center console. Refer to IP-11, "Removal and Installation" .                                         A


                                                                                                               B


                                                                                                               MT

                                                                                                   PCIB0063E

                                                                                                               D
7.   Remove hole cover mounting bolts and then separate hole
     cover from the floor panel.
8.   Separate control lever boot from guide plate.                                                             E



                                                                                                               F


                                                                                                               G
                                                                                                   PCIB0064E



9.   Remove guide plate mounting bolts and then separate control                                               H
     lever assembly from the control lever housing.


                                                                                                                I


                                                                                                               J


                                                                                                   SCIA1591E
                                                                                                               K
10. Remove clutch operating cylinder mounting bolts and then separate clutch operating cylinder from the
    transmission case. Refer to CL-11, "Removal and Installation" .
11. Remove crankshaft position sensor (POS).                                                                   L
    CAUTION:
    q Do not subject it to impact by dropping or hitting.

    q Do not disassemble.
                                                                                                               M
    q Do not allow iron dust, etc., to get on the sensor's front
       edge magnetic area.
    q Do not place in an area affected by magnetism.

12. Disconnect PNP switch and back-up lamp switch.
13. Separate heated oxygen sensor 2 wire harness, crankshaft
    position sensor (POS) wire harness, back-up lamp switch wire                                  SCIA1476E

    harness and PNP switch wire harness from the transmission.
14. Remove starter motor. Refer to SC-18, "Removal and Installation" .
15. Set transmission jack to the transmission.
    CAUTION:
    When setting transmission jack, be careful so that it does not contact with the switch.




Revision: 2006 August                              MT-19                                  2006 G35 Sedan
                                       TRANSMISSION ASSEMBLY

16. Remove rear engine mounting member. Refer to EM-140,
    "Removal and Installation (2WD Models)" .
17. Remove engine and transmission mounting bolts with power
    tool.
18. Remove transmission from the vehicle.
    CAUTION:
    Do not hold control lever housing to prevent bushing of
    control lever housing from deformation when moving trans-
    mission assembly.
                                                                                                       SCIA1531E


INSTALLATION
Install in the reverse order of removal procedure, following the cautions below:
q    When installing transmission to the engine, install mounting bolts in accordance with the standards below.
 Bolt No.                     1                   2                3
 Quantity                     1                   5                2

 "   " mm (in)             55 (2.17)         658 (2.56)        35 (1.38)
 Tightening torque
                                   75 (7.7, 55)              46.6 (4.8, 34)
 N



◦ Jabse Service Manual Search 2023 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
