Image preview - the first page of the document
ps


>> Download ps documenatation <<

Text preview - extract from the document
POWER STEERING SYSTEM


G STEERING

                                                                                                                                                                 A




                                                                     POWER STEERING SYSTEM
                                                                                                  SECTION                     PS                                 B



                                                                                                                                                                 C


                                                                                                                                                                 D


                                                                                                                                                                 E
                                                               CONTENTS
PRECAUTIONS ......................................................... 3
                                                                     .            SEAL, COLLAR AND UPPER JOINT ................ 15                      .        F
 Precautions for Supplemental Restraint System                                    REMOVAL OF STEERING COLUMN ASSEM-
 (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                          BLY ..................................................................... 15
                                                                                                                                                        .
 SIONER" ................................................................. 3
                                                                     .            INSPECTION AFTER REMOVAL OF STEER-                                             PS
 Precautions for Steering System ............................. 3     .            ING COLUMN ASSEMBLY ................................ 16               .
PREPARATION .......................................................... 4
                                                                     .            INSTALLATION OF STEERING COLUMN
 Special Service Tools (SST) .................................... 4  .            ASSEMBLY ........................................................ 16  .
                                                                                                                                                                 H
 Commercial Service Tools ....................................... 5  .            INSPECTION AFTER INSTALLATION OF
NOISE, VIBRATION AND HARSHNESS (NVH)                                              STEERING COLUMN ASSEMBLY .................... 16                      .
TROUBLESHOOTING ............................................... 6    .          Disassembly and Assembly ................................... 16         .
 NVH Troubleshooting Chart .................................... 6    .            COMPONENT (WITHOUT AUTOMATIC DRIVE                                              I
POWER STEERING FLUID ....................................... 7       .            POSITIONER) .................................................... 16   .
 Checking Fluid Level ............................................... 7
                                                                     .            DISASSEMBLY .................................................. 17     .
 Checking Fluid Leakage .......................................... 7 .            INSPECTION AFTER DISASSEMBLY ............... 17                       .         J
 Air Bleeding Hydraulic System ................................ 7    .            ASSEMBLY ........................................................ 17  .
STEERING WHEEL ................................................... 9 .            INSPECTION AFTER ASSEMBLY ..................... 17                    .
 On-Vehicle Inspection and Service ......................... 9       .            COMPONENT (WITH AUTOMATIC DRIVE
                                                                                                                                                                 K
   CHECKING CONDITION OF INSTALLATION ..... 9                                     POSITIONER) .................................................... 18   .
   CHECKING STEERING WHEEL PLAY ............... 9                    .            DISASSEMBLY .................................................. 19     .
   CHECKING NEUTRAL POSITION ON STEER-                                            INSPECTION AFTER DISASSEMBLY ............... 19                       .
   ING WHEEL ......................................................... 9
                                                                     .            ASSEMBLY ........................................................ 19  .        L
   CHECKING STEERING WHEEL TURNING                                                INSPECTION AFTER ASSEMBLY ..................... 19                    .
   FORCE ................................................................. 9
                                                                     .         POWER STEERING GEAR AND LINKAGE ........... 20                           .
   CHECKING FRONT WHEEL TURNING ANGLE 10                             ...        Removal and Installation ....................................... 20     .        M
 Removal and Installation ........................................11 .            COMPONENTS .................................................. 20      .
   REMOVAL ...........................................................11
                                                                     .            REMOVAL .......................................................... 20 .
   INSTALLATION ...................................................11.            INSTALLATION .................................................. 21    .
 Disassembly and Assembly .................................. 12      .            INSPECTION AFTER INSTALLATION ............... 21                      .
   COMPONENTS ................................................. 12   .         POWER STEERING GEAR ..................................... 22             .
   DISASSEMBLY .................................................. 12 .          Disassembly and Assembly ................................... 22         .
   ASSEMBLY ........................................................ 13
                                                                     .            COMPONENTS .................................................. 22      .
STEERING COLUMN .............................................. 14    .            DISASSEMBLY .................................................. 23     .
 Removal and Installation ....................................... 14 .            INSPECTION AFTER DISASSEMBLY ............... 24                       .
   COMPONENT .................................................... 14 .            ASSEMBLY ........................................................ 25  .
   REMOVAL OF LOWER JOINT, LOWER SHAFT,                                        POWER STEERING OIL PUMP .............................. 31                .
   HOLE COVER, CLAMP, HOLE COVER SEAL,                                          On-Vehicle Inspection and Service ........................ 31           .
   COLLAR AND UPPER JOINT ........................... 15             .            CHECKING RELIEF OIL PRESSURE ............... 31                       .
   INSTALLATION OF LOWER JOINT, LOWER                                           Removal and Installation ....................................... 31     .
   SHAFT, HOLE COVER, CLAMP, HOLE COVER                                           REMOVAL .......................................................... 31 .



Revision: 2006 August                                                     PS-1                                                        2006 G35 Sedan
   INSTALLATION ................................................... 32
                                                                 .         Components (AWD Models) ..................................38          .
 Disassembly and Assembly ................................... 32 .         Removal and Installation ........................................39   .
   INSPECTION BEFORE DISASSEMBLY ............ 32                 .        SERVICE DATA AND SPECIFICATIONS (SDS) .....40                          .
   DISASSEMBLY .................................................. 32
                                                                 .         Steering Wheel .......................................................40
                                                                                                                                                 .
   INSPECTION AFTER DISASSEMBLY ............... 33               .         Steering Angle ........................................................40
                                                                                                                                                 .
   ASSEMBLY ........................................................ 33
                                                                 .         Steering Column ....................................................40.
HYDRAULIC LINE ................................................... 36
                                                                 .         Steering Outer Socket and Inner Socket ................40             .
 Components (Except for 18 Inch Tire Models) ...... 36           .         Steering Gear .........................................................41
                                                                                                                                                 .
 Components (18 Inch Tire Models) ....................... 37     .         Oil Pump ................................................................41
                                                                                                                                                 .
                                                                           Steering Fluid .........................................................41
                                                                                                                                                 .
