Image preview - the first page of the document
chg


>> Download chg documenatation <<

Text preview - extract from the document
ELECTRICAL & POWER CONTROL

                                                                                                                                                                     A




                                                                                 SECTION                   CHG
                                                                                              CHARGING SYSTEM
                                                                                                                                                                     B



                                                                                                                                                                     C


                                                                                                                                                                     D


                                                                                                                                                                     E
                                                                 CONTENTS
BASIC INSPECTION ................................... 3
                                                .                                CHARGING SYSTEM ....................................... 18                          F
                                                                                   Symptom Table ......................................................18
                                                                                                                                                   .
DIAGNOSIS AND REPAIR WORKFLOW ......... 3
                                  .
  Work Flow ................................................................ 3
                                                                      .          PRECAUTION ............................................. 19
                                                                                                                                      .                              G
FUNCTION DIAGNOSIS .............................. 6
                                             .                                   PRECAUTIONS ................................................. 19
                                                                                   Precaution for Supplemental Restraint System
CHARGING SYSTEM ......................................... 6
                                                    .                              (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                           H
  System Diagram ....................................................... 6
                                                                  .                SIONER" ................................................................19
                                                                                                                                                       .
  System Description .................................................. 6
                                                                  .                Precaution for Power Generation Voltage Variable
  Component Parts Location ....................................... 6
                                                                  .                Control System .......................................................19
                                                                                                                                                       .             I
  Component Description ........................................... 7
                                                                  .
                                                                                 PREPARATION .......................................... 20
                                                                                                                                    .
POWER GENERATION VOLTAGE VARI-
ABLE CONTROL SYSTEM ................................ 8
                                               .                                 PREPARATION ................................................. 20                    J
  System Diagram ....................................................... 8
                                                                  .                Special Service Tool ...............................................20
                                                                                                                                                   .
  System Description .................................................. 8
                                                                  .                Commercial Service Tool .......................................20
                                                                                                                                                   .
  Component Parts Location ....................................... 8
                                                                  .                                                                                                  K
  Component Description ............................................ 8
                                                                  .              ON-VEHICLE MAINTENANCE ................... 21
                                                                                                                        .

COMPONENT DIAGNOSIS ........................ 10
                                         .                                       CHARGING SYSTEM PRELIMINARY IN-
                                                                                 SPECTION ........................................................ 21                L
B TERMINAL CIRCUIT .....................................10
                                                    .                              Inspection Procedure ..............................................21
                                                                                                                                                  .
  Description ............................................................. 10
                                                                       .
  Diagnosis Procedure .............................................. 10.         POWER GENERATION VOLTAGE VARI-                                       CHG
                                                                                 ABLE CONTROL SYSTEM OPERATION IN-
L TERMINAL CIRCUIT (OPEN) ........................11
                                              .                                  SPECTION ........................................................ 22
  Description ............................................................. 11
                                                                       .           Inspection Procedure ..............................................22
                                                                                                                                                  .
  Diagnosis Procedure .............................................. 11.                                                                                             N
                                                                                 ON-VEHICLE REPAIR ................................ 24
                                                                                                                                .
L TERMINAL CIRCUIT (SHORT) ......................13
                                             .
  Description ............................................................. 13
                                                                       .         ALTERNATOR .................................................. 24                    O
  Diagnosis Procedure .............................................. 13.
                                                                                 2WD ...........................................................................24
                                                                                                                                                            .
S TERMINAL CIRCUIT .....................................14
                                                    .                             2WD : Exploded View .............................................24       .
  Description ............................................................. 14
                                                                       .          2WD : Removal and Installation .............................25            .        P
  Diagnosis Procedure .............................................. 14.          2WD : Inspection ....................................................26   .

CHARGING SYSTEM ........................................15
                                                    .                            AWD ..........................................................................26
                                                                                                                                                           .
  Wiring Diagram -- CHARGING SYSTEM -- ......... 15
                                            .                                     AWD : Exploded View ............................................26       .
                                                                                  AWD : Removal and Installation .............................27           .
SYMPTOM DIAGNOSIS ............................. 18
                                            .                                     AWD : Inspection ....................................................28  .


Revision: October 2006                                                    CHG-1                                                         2007 G35 Sedan
SERVICE DATA AND SPECIFICATIONS                                       SERVICE DATA AND SPECIFICATIONS
(SDS) .......................................................... 29
                                                             .        (SDS) ................................................................ 29
                                                                                                                                         .
                                                                        Alternator ............................................................... 29
                                                                                                                                               .




Revision: October 2006                                         CHG-2                                                        2007 G35 Sedan
                         DIAGNOSIS AND REPAIR WORKFLOW
< BASIC INSPECTION >
BASIC INSPECTION                                                                      A
DIAGNOSIS AND REPAIR WORKFLOW
Work Flow                                                   INFOID:0000000000964263
                                                                                      B

OVEROALL SEQUENCE
                                                                                      C


                                                                                      D


                                                                                      E



                                                                                      F


                                                                                      G


                                                                                      H



                                                                                       I


                                                                                      J



                                                                                      K


                                                                                      L



                                                                                      CHG



                                                                                      N



                                                                                      O



                                                                                      P




                                                          JSMIA0009GB


DETAILED FLOW

Revision: October 2006               CHG-3               2007 G35 Sedan
                            DIAGNOSIS AND REPAIR WORKFLOW
< BASIC INSPECTION >
NOTE:
To ensure a complete and thorough diagnosis, the battery, starter and alternator test segments must be done
as a set from start to finish.
1.PRELIMINARY INSPECTION
Perform the preliminary inspection. Refer to CHG-21, "Inspection Procedure".

         >> GO TO 2.
2.STOP POWER GENERATION VOLTAGE VARIABLE CONTROL SYSTEM
Stop the operation of the power generation voltage variable control in either of the following procedures.
