Image preview - the first page of the document
inl


>> Download inl documenatation <<

Text preview - extract from the document
DRIVER CONTROLS

                                                                                                                                                                      A




                                                                    INTERIOR LIGHTING SYSTEM
                                                                                               SECTION                     INL                                        B



                                                                                                                                                                      C


                                                                                                                                                                      D


                                                                                                                                                                      E
                                                                  CONTENTS
BASIC INSPECTION ................................... 3
                                                .                                 POWER SUPPLY AND GROUND CIRCUIT .... 17                                             F

DIAGNOSIS AND REPAIR WORKFLOW ......... 3
                                  .                                               BCM ..........................................................................17
                                                                                                                                                            .
  Work Flow ................................................................ 3
                                                                      .            BCM : Diagnosis Procedure ...................................17          .
                                                                                                                                                                      G
                                                                                   BCM : Special Repair Requirement ........................17              .
FUNCTION DIAGNOSIS .............................. 6
                                             .
                                                                                  INTERIOR ROOM LAMP POWER SUPPLY
INTERIOR ROOM LAMP CONTROL SYSTEM                                                 CIRCUIT ............................................................ 18             H
                                 ..... 6                                            Description ..............................................................18
                                                                                                                                                          .
  System Diagram ....................................................... 6
                                                                  .                 Component Function Check ...................................18        .
  System Description .................................................. 6
                                                                  .                 Diagnosis Procedure ..............................................18  .           I
  Component Parts Location ....................................... 7
                                                                  .
  Component Description ........................................... 8
                                                                  .               INTERIOR ROOM LAMP CONTROL CIRCUIT
                                                                                                                    ... 20
INTERIOR ROOM LAMP BATTERY SAVER                                                    Description ..............................................................20
                                                                                                                                                          .           J
SYSTEM ............................................................. 9
                                                               .                    Component Function Check ...................................20        .
  System Diagram ....................................................... 9
                                                                  .                 Diagnosis Procedure ..............................................20  .
  System Description .................................................. 9
                                                                  .                                                                                                   K
  Component Parts Location ....................................... 9
                                                                  .               STEP LAMP CIRCUIT ....................................... 22
  Component Description ......................................... 10
                                                                  .                 Description ..............................................................22
                                                                                                                                                          .
                                                                                    Component Function Check ...................................22        .
ILLUMINATION CONTROL SYSTEM ...............11
                                       .                                                                                                                             INL
                                                                                    Diagnosis Procedure ..............................................22  .
  System Diagram ..................................................... 11
                                                                  .
  System Description ................................................ 11
                                                                  .               TRUNK ROOM LAMP CIRCUIT ....................... 24
  Component Parts Location ..................................... 11
                                                                  .                 Description ..............................................................24
                                                                                                                                                          .          M
  Component Description .......................................... 12
                                                                  .                 Component Function Check ...................................24        .
                                                                                    Diagnosis Procedure ..............................................24  .
DIAGNOSIS SYSTEM (BCM) ...........................13
                                              .
                                                                                  PUSH-BUTTON IGNITION SWITCH ILLUMI-                                                 N
COMMON ITEM ........................................................ 13
                                                                .                 NATION CIRCUIT ............................................. 26
 COMMON ITEM : CONSULT-III Function (BCM -                                          Description ..............................................................26
                                                                                                                                                          .
 COMMON ITEM) .................................................... 13
                                                                .                   Component Function Check ...................................26        .           O
                                                                                    Diagnosis Procedure ..............................................26  .
INT LAMP ................................................................. 13
                                                                        .
  INT LAMP : CONSULT-III Function (BCM - INT                                      INTERIOR ROOM LAMP CONTROL SYSTEM
  LAMP) .................................................................... 13
                                                                        .                                                                                             P
                                                                                                                   ... 28
BATTERY SAVER .................................................... 15
                                                              .                     Wiring Diagram --INTERIOR ROOM LAMP -- .....28
                                                                                                                            .
 BATTERY SAVER : CONSULT-III Function (BCM                                        ILLUMINATION ................................................. 36
 - BATTERY SAVER) .............................................. 15
                                                              .
                                                                                    Wiring Diagram --ILLUMINATION-- .....................36
                                                                                                                                     .
COMPONENT DIAGNOSIS ........................ 17
                                         .                                        ECU DIAGNOSIS ........................................ 46
                                                                                                                                     .


Revision: October 2006                                                      INL-1                                                        2007 G35 Sedan
BCM (BODY CONTROL MODULE) ................. 46
                                        .                                           Replacement .......................................................... 97
                                                                                                                                                       .
  Reference Value .................................................... 46.
  Wiring Diagram -- BCM -- .................................... 69       .        CIGARETTE LIGHTER ILLUMINATION .......... 98
                                                                                                                        .
  Fail Safe ................................................................ 74
                                                                         .          Exploded View ....................................................... 98
                                                                                                                                                       .
  DTC Inspection Priority Chart ............................. 76         .          Replacement .......................................................... 98
                                                                                                                                                       .
  DTC Index ............................................................. 77
                                                                         .        GLOVE BOX LAMP .......................................... 99
                                                                                                                                        .
COMBINATION METER ................................... 80
                                                  .                                 Exploded View ....................................................... 99
                                                                                                                                                       .
  Reference Value .................................................... 80.          Replacement .......................................................... 99
                                                                                                                                                       .
  Wiring Diagram -- METER -- ............................... 83          .        STEP LAMP ..................................................... 100
                                                                                                                                               .
  Fail Safe ................................................................ 92
                                                                         .
                                                                                    Exploded View ..................................................... 100
                                                                                                                                                       .
  DTC Index ............................................................. 93
                                                                         .
                                                                                    Removal and Installation ...................................... 100.
SYMPTOM DIAGNOSIS ............................ 94
                                           .                                        Replacement ........................................................ 100
                                                                                                                                                       .

INTERIOR LIGHTING SYSTEM SYMPTOMS ... 94                                          PERSONAL LAMP .......................................... 101
                                                                                                                                        .
                                                                                    Exploded View ..................................................... 101
                                                                                                                                                       .
  Symptom Table ..................................................... 94
                                                                  .
                                                                                    Removal and Installation ...................................... 101.
PRECAUTION ............................................ 95
                                                    .                               Replacement ........................................................ 102
                                                                                                                                                       .

PRECAUTIONS ................................................ 95
                                                         .                        TRUNK ROOM LAMP ..................................... 103
                                                                                                                                     .
  Supplemental Restraint System (SRS) "AIR B                                        Exploded View ..................................................... 103
                                                                                                                                                       .
  AG" and "SEAT BELT PRE-TENSIONER" ........ 95
                                             .                                      Removal and Installation ...................................... 103.
                                                                                    Replacement ........................................................ 103
                                                                                                                                                       .
ON-VEHICLE REPAIR ............................... 96
                                              .
                                                                                  SERVICE DATA AND SPECIFICATIONS
MAP LAMP ....................................................... 96
                                                             .                    (SDS) ......................................................... 104
  Exploded View ....................................................... 96
                                                                    .
  Removal and Installation ....................................... 96
                                                                    .             SERVICE DATA AND SPECIFICATIONS
  Replacement ......................................................... 96
                                                                    .             (SDS) ............................................................... 104
                                                                                                                                                     .
                                                                                    Bulb Specifications ............................................... 104
                                                                                                                                                      .
VANITY MIRROR LAMP .................................. 97
                                                  .
  Exploded View ....................................................... 97
                                                                    .




Revision: October 2006                                                      INL-2                                                    2007 G35 Sedan
                         DIAGNOSIS AND REPAIR WORKFLOW
< BASIC INSPECTION >
BASIC INSPECTION                                                                       A
DIAGNOSIS AND REPAIR WORKFLOW
Work Flow                                                   INFOID:0000000000962564
                                                                                       B

OVERALL SEQUENCE
                                                                                       C


                                                                                       D


                                                                                       E



                                                                                       F


                                                                                       G


                                                                                       H



                                                                                       I


                                                                                       J



                                                                                       K


                                                                                      INL


                                                                                      M



                                                                                       N



                                                                                       O



                                                                                       P
                                                          JPLIA0089GB




Revision: October 2006               INL-3               2007 G35 Sedan
                            DIAGNOSIS AND REPAIR WORKFLOW
< BASIC INSPECTION >

DETAILED FLOW
1.INTERVIEW FOR MALFUNCTION
Interview the symptom to the customer.

         >> GO TO 2.
2.SYMPTOM CHECK
Check the symptom from the customer's information.

         >> GO TO 3.
3.BASIC INSPECTION
Check the operation of each part. Check that any symptom occurs other than the interviewed symptom.

         >> GO TO 4.
4.SELF-DIAGNOSIS WITH CONSULT-III
Perform the self-diagnosis with CONSULT-III. Check that any DTC is detected.
Is any DTC detected?
  YES >> GO TO 5.
  NO     >> GO TO 6.
5.TROUBLE DIAGNOSIS BY DTC
Perform the trouble diagnosis for the detected DTC. Specify the malfunctioning part.

         >> GO TO 9.
6.FAIL-SAFE ACTIVATION CHECK
Check that the symptom is applied to the fail-safe activation.
Does the fail-safe activate?
 YES >> GO TO 7.
 NO     >> GO TO 8.
7.SYSTEM DIAGNOSIS
Perform the system diagnosis for the system that the fail-safe activates. Specify the malfunctioning part.



         >> GO TO 9.
8.SYMPTOM DIAGNOSIS
Perform the symptom diagnosis. Specify the malfunctioning part.

         >> GO TO 9.
9.MALFUNCTION PART REPAIR
Repair or replace the malfunctioning part.

         >> GO TO 11.
10.REPAIR CHECK (SELF-DIAGNOSIS WITH CONSULT-III)
Perform the self-diagnosis with CONSULT-III. Check that any DTC is not detected. Erase DTC if DTC is
detected before the repair. Check that DTC is not detected again.
Is any DTC detected?
  YES >> GO TO 5.

Revision: October 2006                              INL-4                                     2007 G35 Sedan
                           DIAGNOSIS AND REPAIR WORKFLOW
< BASIC INSPECTION >
 NO    >> GO TO 11.
11.REPAIR CHECK (OPERATION CHECK)                                            A

Check the operation of each part.
Does it operate normally?                                                    B
 YES >> INSPECTION END
 NO      >> GO TO 3.
                                                                             C


                                                                             D


                                                                             E



                                                                             F


                                                                             G


                                                                             H



                                                                             I


                                                                             J



                                                                             K


                                                                            INL


                                                                            M



                                                                             N



                                                                             O



                                                                             P




Revision: October 2006                 INL-5               2007 G35 Sedan
                         INTERIOR ROOM LAMP CONTROL SYSTEM
< FUNCTION DIAGNOSIS >
FUNCTION DIAGNOSIS
INTERIOR ROOM LAMP CONTROL SYSTEM
System Diagram                                                                                    INFOID:0000000000962565




                                                                                                JPLIA0090GB




System Description                                                                                INFOID:0000000000962566




OUTLINE
