Image preview - the first page of the document
pwo


>> Download pwo documenatation <<

Text preview - extract from the document
ELECTRICAL & POWER CONTROL

                                                                                                                                                   A




                                                               SECTION                 PWO POWER OUTLET
                                                                                                                                                   B



                                                                                                                                                   C


                                                                                                                                                   D


                                                                                                                                                   E
                                                     CONTENTS
COMPONENT DIAGNOSIS ......................... 2
                                         .                           Precaution for Supplemental Restraint System                                  F
                                                                     (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
CIGARETTE LIGHTER ...................................... 2
                                                   .                 SIONER" ................................................................. 6
                                                                                                                                         .
  Wiring Diagram -- Cigarette Lighter -- .................... 2
                                                       .                                                                                           G
                                                                   ON-VEHICLE REPAIR ................................. 7
                                                                                                                  .
POWER SOCKET .............................................. 4
                                                      .
  Wiring Diagram -- Power Socket -- ........................ 4
                                                      .            CIGARETTE LIGHTER ...................................... 7
                                                                     Exploded View ......................................................... 7
                                                                                                                                       .           H
PRECAUTION .............................................. 6
                                                     .               Removal and Installation ......................................... 7
                                                                                                                                       .
PRECAUTIONS .................................................. 6
                                                         .         POWER SOCKET .............................................. 9
                                                                                                                                                   I
                                                                     Exploded View ......................................................... 9
                                                                                                                                       .
                                                                     Removal and Installation ......................................... 9
                                                                                                                                       .

                                                                                                                                                   J



                                                                                                                                                   K


                                                                                                                                                   L



                                                                                                                                                   PWO



                                                                                                                                                   N



                                                                                                                                                   O



                                                                                                                                                   P




Revision: October 2006                                      PWO-1                                                       2007 G35 Sedan
                             CIGARETTE LIGHTER
< COMPONENT DIAGNOSIS >
COMPONENT DIAGNOSIS
CIGARETTE LIGHTER
Wiring Diagram --Cigarette Lighter --               INFOID:0000000000963854




                                                  JCMWA0001GB




Revision: October 2006                  PWO-2    2007 G35 Sedan
                          CIGARETTE LIGHTER
< COMPONENT DIAGNOSIS >

                                                               A


                                                               B



                                                               C


                                                               D


                                                               E



                                                               F


                                                               G


                                                               H



                                                               I


                                                               J



                                                               K


                                                               L



                                                               PWO



                                                               N



                                                               O

                                               JCMWA0002GB


                                                               P




Revision: October 2006         PWO-3          2007 G35 Sedan
                              POWER SOCKET
< COMPONENT DIAGNOSIS >
POWER SOCKET
Wiring Diagram --Power Socket --                INFOID:0000000000963855




                                              JCMWA0003GB




Revision: October 2006             PWO-4     2007 G35 Sedan
                          POWER SOCKET
< COMPONENT DIAGNOSIS >

                                                          A


                                                          B



                                                          C


                                                          D


                                                          E



                                                          F


                                                          G


                                                          H



                                                          I


                                                          J



                                                          K


                                                          L



                                                          PWO



                                                          N



                                                          O

                                          JCMWA0004GB


                                                          P




Revision: October 2006       PWO-5       2007 G35 Sedan
                                              PRECAUTIONS
< PRECAUTION >
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"                                                                                       INFOID:0000000000963856



The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
