Image preview - the first page of the document
vtl


>> Download vtl documenatation <<

Text preview - extract from the document
VENTILATION, HEATER & AIR CONDITIONER

                                                                                                                                                              A




                                                                                      SECTION
                                                                                      VENTILATION SYSTEM
                                                                                                                VTL                                           B



                                                                                                                                                              C


                                                                                                                                                              D


                                                                                                                                                              E
                                                                 CONTENTS
FUNCTION DIAGNOSIS .............................. 3
                                             .                                   PREPARATION .......................................... 17
                                                                                                                                    .                          F

SWITCHES AND THEIR CONTROL FUNC-                                                 PREPARATION ................................................. 17
TION ................................................................... 3
                                                                   .               Special Service Tool ...............................................17
                                                                                                                                                   .          G
                                                                                   Commercial Service Tool .......................................20
                                                                                                                                                   .
WITHOUT LEFT AND RIGHT VENTILATION TEM-                                            Sealant or/and Lubricant ........................................20
                                                                                                                                                   .
PERATURE SEPARATELY CONTROL SYSTEM ...... 3
 WITHOUT LEFT AND RIGHT VENTILATION                                              ON-VEHICLE MAINTENANCE ................... 21
                                                                                                                        .                                     H
 TEMPERATURE SEPARATELY CONTROL
 SYSTEM : System Description ................................ 3
                                                       .                         IN-CABIN MICROFILTER ................................. 21
                                                                                   Exploded View ........................................................21
                                                                                                                                                     .        VTL
WITH LEFT AND RIGHT VENTILATION TEMPER-                                            Removal and Installation ........................................21
                                                                                                                                                     .
ATURE SEPARATELY CONTROL SYSTEM ............ 3                  .                  Replacement ..........................................................22
                                                                                                                                                     .
 WITH LEFT AND RIGHT VENTILATION TEM-
 PERATURE SEPARATELY CONTROL SYSTEM                                              ON-VEHICLE REPAIR ................................ 23
                                                                                                                                .                              J
 : System Description ................................................ 3
                                                                .
                                                                                 PRESET SWITCH ............................................. 23
AIR DISTRIBUTION ........................................... 5
                                                       .                           Exploded View ........................................................23
                                                                                                                                                     .        K
  System Description .................................................. 5
                                                                 .                 Removal and Installation ........................................23
                                                                                                                                                     .

PRECAUTION .............................................. 6
                                                     .                           AUTO AMP. ....................................................... 24
                                                                                   Exploded View ........................................................24
                                                                                                                                                     .         L
PRECAUTIONS .................................................. 6
                                                         .                         Removal and Installation ........................................24
                                                                                                                                                     .
  Precaution for Supplemental Restraint System
  (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                        AMBIENT SENSOR .......................................... 25
                                                                                                                                                              M
  SIONER" .................................................................. 6
                                                                      .            Exploded View ........................................................25
                                                                                                                                                     .
  Precaution Necessary for Steering Wheel Rota-                                    Removal and Installation ........................................25
                                                                                                                                                     .
  tion after Battery Disconnect .................................... 6.
  Precaution for Battery Service ................................. 6  .          IN-VEHICLE SENSOR ...................................... 26                  N
  Precaution for Procedure without Cowl Top Cover 7                   ......       Exploded View ........................................................26
                                                                                                                                                     .
  Precautions For Xenon Headlamp Service .............. 7             .            Removal and Installation ........................................26
                                                                                                                                                     .
  Working with HFC-134a (R-134a) ............................ 7       .          SUNLOAD SENSOR ......................................... 27                  O
  General Refrigerant Precaution ............................... 8    .            Exploded View ........................................................27
                                                                                                                                                     .
  Refrigerant Connection ............................................ 8
                                                                      .
                                                                                   Removal and Installation ........................................27
                                                                                                                                                     .
  Service Equipment ................................................. 12
                                                                      .                                                                                       P
                                                                                 INTAKE SENSOR ............................................. 28
COMPRESSOR .................................................15
                                                        .                          Exploded View ........................................................28
                                                                                                                                                     .
  General Precautions .............................................. 15
                                                                .
                                                                                   Removal and Installation ........................................29
                                                                                                                                                     .
LEAK DETECTION DYE ...................................16
                                                  .                              BLOWER UNIT ................................................. 30
  General Precautions .............................................. 16
                                                                .
                                                                                   Exploded View ........................................................30
                                                                                                                                                     .
                                                                                   Removal and Installation ........................................30
                                                                                                                                                     .


Revision: 2007 June                                                       VTL-1                                                             G37 Coupe
BLOWER MOTOR ............................................ 32
                                                      .                          SIDE VENTILATOR GRILLE ................................... 44              .
  Exploded View ....................................................... 32
                                                                    .              SIDE VENTILATOR GRILLE : Exploded View ...... 45                         .
  Removal and Installation ....................................... 32
                                                                    .              SIDE VENTILATOR GRILLE : Removal and In-
                                                                                   stallation ................................................................. 45
                                                                                                                                                            .
INTAKE DOOR MOTOR ................................... 33
                                                  .
  Exploded View ....................................................... 33
                                                                    .            FRONT DEFROSTER NOZZLE, SIDE DEFROST-
  Removal and Installation ....................................... 33
                                                                    .            ER NOZZLE AND VENTILATOR DUCT .................. 45                .
                                                                                  FRONT DEFROSTER NOZZLE, SIDE DE-
HEATER & COOLING UNIT ASSEMBLY ........ 34
                                    .                                             FROSTER NOZZLE AND VENTILATOR DUCT :
  Exploded View ....................................................... 34
                                                                    .             Exploded View ....................................................... 45
                                                                                                                                                    .
  Removal and Installation ....................................... 35
                                                                    .             FRONT DEFROSTER NOZZLE, SIDE DE-
                                                                                  FROSTER NOZZLE AND VENTILATOR DUCT :
MODE DOOR MOTOR ..................................... 38
                                                  .                               Removal and Installation ........................................ 46
                                                                                                                                                    .
  Exploded View ....................................................... 38
                                                                    .
  Removal and Installation ....................................... 39
                                                                    .            SIDE DEFROSTER DUCT ....................................... 47              .
                                                                                   SIDE DEFROSTER DUCT : Exploded View .......... 47                         .
AIR MIX DOOR MOTOR ................................... 40
                                                   .                               SIDE DEFROSTER DUCT : Removal and Instal-
  Exploded View ....................................................... 40
                                                                    .              lation ...................................................................... 48
                                                                                                                                                             .
  Removal and Installation ....................................... 41
                                                                    .
                                                                                 FOOT GRILLE .......................................................... 48
                                                                                                                                                    .
HEATER CORE ................................................ 42
                                                         .                        FOOT GRILLE : Exploded View ............................ 48       .
  Exploded View ....................................................... 42
                                                                    .             FOOT GRILLE : Removal and Installation ............. 48           .
  Removal and Installation ....................................... 43
                                                                    .
                                                                                 FOOT DUCT ............................................................. 49
                                                                                                                                                     .
DUCT AND GRILLE ......................................... 44
                                                      .                           FOOT DUCT : Exploded View ............................... 49       .
                                                                                  FOOT DUCT : Removal and Installation ................ 50           .
CENTER VENTILATOR GRILLE ............................. 44               .
 CENTER VENTILATOR GRILLE : Exploded View 44                            ...      REAR FLOOR DUCT 1 ............................................ 50
                                                                                                                                            .
 CENTER VENTILATOR GRILLE : Removal and                                           REAR FLOOR DUCT 1 : Exploded View ............... 51      .
 Installation ............................................................. 44
                                                                        .         REAR FLOOR DUCT 1 : Removal and Installation
                                                                                                                                            ... 51




Revision: 2007 June                                                        VTL-2                                                                   G37 Coupe
                      SWITCHES AND THEIR CONTROL FUNCTION
< FUNCTION DIAGNOSIS >
FUNCTION DIAGNOSIS                                                                      A
SWITCHES AND THEIR CONTROL FUNCTION
WITHOUT LEFT AND RIGHT VENTILATION TEMPERATURE SEPARATELY
                                                                                        B
CONTROL SYSTEM
WITHOUT LEFT AND RIGHT VENTILATION TEMPERATURE SEPARATELY CON-
                                                                                        C
TROL SYSTEM : System Description                              INFOID:0000000001665906




                                                                                        D


                                                                                        E



                                                                                         F


                                                                                        G


                                                                                        H



                                                                                        VTL


                                                                                         J

                                                            JSIIA0662GB

                                                                                        K


                                                                                         L



                                                                                        M



                                                                                        N



                                                                                        O



                                                                                        P

                                                            JSIIA0663GB


WITH LEFT AND RIGHT VENTILATION TEMPERATURE SEPARATELY CON-
TROL SYSTEM
WITH LEFT AND RIGHT VENTILATION TEMPERATURE SEPARATELY CONTROL

Revision: 2007 June                  VTL-3                         G37 Coupe
                      SWITCHES AND THEIR CONTROL FUNCTION
< FUNCTION DIAGNOSIS >
SYSTEM : System Description                                   INFOID:0000000001665907




                                                            JSIIA0664GB




                                                            JSIIA0665GB




Revision: 2007 June                  VTL-4                         G37 Coupe
                         AIR DISTRIBUTION
< FUNCTION DIAGNOSIS >
AIR DISTRIBUTION
                                                                        A
System Description                            INFOID:0000000001665908




                                                                        B



                                                                        C


                                                                        D


                                                                        E



                                            JSIIA0866GB                  F


                                                                        G


                                                                        H



                                                                        VTL


                                                                         J



                                                                        K


                                                                         L



                                                                        M



                                                                        N



                                                                        O



                                                                        P




Revision: 2007 June           VTL-5                G37 Coupe
                                               PRECAUTIONS
< PRECAUTION >
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"                                                                                        INFOID:0000000001714446



The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the "SRS AIRBAG" and "SEAT BELT" of this
Service Manual.
WARNING:
