Image preview - the first page of the document
>> Download fe documenatation <<
Text preview - extract from the document
ACCELERATOR CONTROL, FUEL &
EXHAUST SYSTEMS
GI
SECTION FE MA
EM
LC
EC
CONTENTS
PREPARATION ...............................................................2 Fuel Tank .....................................................................5
Special Service Tool ....................................................2 REMOVAL .................................................................5 AT
Commercial Service Tools ...........................................2 INSTALLATION..........................................................5
ACCELERATOR CONTROL SYSTEM ...........................3 Fuel Pump, Fuel Level Sensor Unit and Fuel
Removal and Installation .............................................3 Filter .............................................................................6 AX
REMOVAL .................................................................3 REMOVAL .................................................................6
INSTALLATION..........................................................3 INSTALLATION..........................................................8
INSPECTION AFTER INSTALLATION .........................3 EXHAUST SYSTEM ........................................................9 SU
FUEL SYSTEM ................................................................4 Removal and Installation .............................................9
Removal and Installation .............................................4 BR
ST
RS
BT
HA
SC
EL
IDX
PREPARATION
Special Service Tool
Special Service Tool NHFE0001
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.) Description
Tool name
KV10114400 Loosening or tightening heated oxygen
(J-38365) sensors
Heated oxygen sensor a: 22 mm (0.87 in)
wrench
NT636
Commercial Service Tools NHFE0008
Tool number
(Kent-Moore No.) Description
Tool name
(J-43897-18) Reconditioning the exhaust system threads
(J-43897-12) before installing a new heated oxygen sen-
Oxygen sensor thread sor (Use with anti-seize lubricant shown
cleaner below.)
a: J-43897-18 (18 mm dia.) for zirconia
heated oxygen sensor
b: J-43897-12 (12 mm dia.) for titania
heated oxygen sensor
AEM488
Anti-seize lubricant Lubricating heated oxygen sensor thread
(Permatex 133AR or cleaning tool when reconditioning exhaust
equivalent meeting MIL system threads
specification MIL-A-
907)
AEM489
FE-2
ACCELERATOR CONTROL SYSTEM
Removal and Installation
Removal and Installation NHFE0002
CAUTION:
