Image preview - the first page of the document
>> Download lc documenatation <<
Text preview - extract from the document
ENGINE LUBRICATION &
COOLING SYSTEMS
GI
SECTION LC MA
EM
EC
CONTENTS
FE
ENGINE LUBRICATION SYSTEM..................................2 CHECKING COOLING SYSTEM FOR LEAKS ............10
Precautions ..................................................................2 Water Pump ...............................................................10 AT
LIQUID GASKET APPLICATION PROCEDURE ............2 REMOVAL AND INSTALLATION ...............................10
Preparation ..................................................................2 REMOVAL ...............................................................10
SPECIAL SERVICE TOOLS ........................................2 INSPECTION ...........................................................12 AX
Lubrication Circuit ........................................................3 INSTALLATION........................................................12
Oil Pressure Check......................................................4 Thermostat.................................................................14
Oil Pump ......................................................................4 REMOVAL AND INSTALLATION ...............................14 SU
REMOVAL AND INSTALLATION .................................4 INSPECTION ...........................................................14
DISASSEMBLY AND ASSEMBLY................................5 Water Control Valve...................................................15
OIL PUMP INSPECTION ............................................5 REMOVAL AND INSTALLATION ...............................15 BR
REGULATOR VALVE INSPECTION ............................6 INSPECTION ...........................................................15
OIL FILTER ...............................................................6 Radiator .....................................................................16
REMOVAL AND INSTALLATION ...............................16
ST
Service Data and Specifications (SDS).......................6
OIL PRESSURE ........................................................6 Cooling Fan Control System .....................................17
REGULATOR VALVE .................................................6 Refilling Engine Coolant ............................................17 RS
OIL PUMP .................................................................6 Radiator (Aluminum type)..........................................17
ENGINE COOLING SYSTEM..........................................7 PREPARATION .......................................................17
Precautions ..................................................................7 DISASSEMBLY ........................................................18 BT
LIQUID GASKET APPLICATION PROCEDURE ............7 ASSEMBLY .............................................................18
Preparation ..................................................................7 INSPECTION ...........................................................20
SPECIAL SERVICE TOOLS ........................................7 Overheating Cause Analysis .....................................21 HA
Cooling Circuit .............................................................8 Service Data and Specifications (SDS).....................22
System Check..............................................................9 THERMOSTAT ........................................................22
CHECKING COOLING SYSTEM HOSES .....................9 WATER CONTROL VALVE .......................................22 SC
CHECKING RADIATOR ..............................................9 RADIATOR ..............................................................22
CHECKING RADIATOR CAP ......................................9
EL
IDX
ENGINE LUBRICATION SYSTEM
Precautions
Precautions
LIQUID GASKET APPLICATION PROCEDURE NHLC0001
1. Use a scraper to remove all traces of old liquid gasket from
mating surfaces and grooves. Also, completely clean any oil
from these areas.
2. Apply a continuous bead of liquid gasket to mating surfaces.
(Use Genuine RTV silicone sealant Part No. 999MP-A7007
or equivalent.)
