Image preview - the first page of the document
>> Download lan documenatation <<
Text preview - extract from the document
LAN SYSTEM
K ELECTRICAL
A
SECTION LAN LAN SYSTEM
B
C
D
E
CONTENTS
CAN FUNDAMENTAL CAN F
PRECAUTIONS ......................................................... 3
. INDEX FOR DTC ...................................................... 40 .
Precautions When Using CONSULT-II .................... 3 . DTC No. Index ....................................................... 40
.
G
Precautions for Trouble Diagnosis .......................... 3 . HOW TO USE THIS SECTION ................................ 41 .
Precautions for Harness Repair .............................. 3 . Caution .................................................................. 41
.
SYSTEM DESCRIPTION ........................................... 4 . Abbreviation List .................................................... 41
.
CAN Communication System .................................. 4 . PRECAUTIONS ....................................................... 42 . H
SYSTEM DIAGRAM ............................................. 4 . Precautions for Supplemental Restraint System
CAN COMMUNICATION CONTROL CIRCUIT..... 5 (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
Diag on CAN ........................................................... 6
. SIONER" ................................................................ 42
. I
DESCRIPTION ..................................................... 6
. Precautions When Using CONSULT-II .................. 42 .
SYSTEM DIAGRAM ............................................. 6 . Precautions for Trouble Diagnosis ........................ 42 .
TROUBLE DIAGNOSIS ............................................. 7 . Precautions for Harness Repair ............................ 42 . J
Condition of Error Detection .................................... 7. TROUBLE DIAGNOSIS ........................................... 44 .
CAN COMMUNICATION SYSTEM ERROR ........ 7 . CAN Diagnostic Support Monitor ........................... 44 .
WHEN "U1000" OR "U1001" IS INDICATED MONITOR ITEM LIST (CONSULT-II) ................. 44 .
EVEN THOUGH CAN COMMUNICATION SYS- CAN System Specification Chart ........................... 50 . LAN
TEM IS NORMAL ................................................. 7. VEHICLE EQUIPMENT IDENTIFICATION
Symptom When Error Occurs in CAN Communi- INFORMATION ................................................... 51 .
cation System .......................................................... 8
. CAN Communication Signal Chart ........................ 52 . L
ERROR EXAMPLE .............................................. 8 . TYPE 1/TYPE 2/TYPE 3/TYPE 4/TYPE 5/TYPE
Self-Diagnosis ....................................................... 12
. 6/TYPE 7 ............................................................ 52
.
CAN Diagnostic Support Monitor .......................... 13 . TYPE 8/TYPE 9/TYPE 10/TYPE 11 ................... 55 . M
MONITOR ITEM (CONSULT-II) ......................... 13 . Schematic .............................................................. 58
.
MONITOR ITEM (ON-BOARD DIAGNOSIS) ..... 14 . Wiring Diagram -- CAN -- .................................... 59 .
TROUBLE DIAGNOSES WORK FLOW ................. 15 . Interview Sheet ...................................................... 64
.
Information Needed for Trouble Diagnosis ............ 15 . Data Sheet ............................................................. 65
.
How to Use CAN Communication Signal Chart .... 15 . CONSULT-II DATA ATTACHMENT SHEET ....... 65 .
Trouble Diagnosis Flow Chart ............................... 16 . CAN System (Type 1) ............................................ 70 .
Trouble Diagnosis Procedure ................................ 17 . DIAGNOSIS SHEET .......................................... 70 .
INTERVIEW WITH CUSTOMER ........................ 17 . CAN System (Type 2) ............................................ 71 .
INSPECTION OF VEHICLE CONDITION .......... 18 . DIAGNOSIS SHEET .......................................... 71 .
CHECK OF CAN SYSTEM TYPE (HOW TO USE CAN System (Type 3) ............................................ 72 .
CAN SYSTEM TYPE SPECIFICATION CHART) 19 ... DIAGNOSIS SHEET .......................................... 72 .
CREATE INTERVIEW SHEET ........................... 21 . CAN System (Type 4) ............................................ 73 .
CREATE DATA SHEET ...................................... 22 . DIAGNOSIS SHEET .......................................... 73 .
CREATE DIAGNOSIS SHEET ........................... 24 . CAN System (Type 5) ............................................ 74 .
DETECT THE ROOT CAUSE ............................ 25 . DIAGNOSIS SHEET .......................................... 74 .
CAN System (Type 6) ............................................ 75 .
DIAGNOSIS SHEET .......................................... 75 .
Revision: 2007 April LAN-1 2007 M35/M45
CAN System (Type 7) ............................................ 76 . ABS Actuator and Electric Unit (Control Unit) ........88 .
DIAGNOSIS SHEET ........................................... 76 . Main Line Between ABS Actuator and Electric Unit
CAN System (Type 8) ............................................ 77 . (Control Unit) and ICC Sensor Integrated Unit ......89 .
DIAGNOSIS SHEET ........................................... 77 . ECM Branch Line Circuit ........................................89 .
CAN System (Type 9) ............................................ 78 . AWD Control Unit Branch Line Circuit ...................90 .
DIAGNOSIS SHEET ........................................... 78 . AFS Control Unit Branch Line Circuit .....................91 .
CAN System (Type 10) .......................................... 79 . BCM Branch Line Circuit ........................................91 .
DIAGNOSIS SHEET ........................................... 79 . LDW Camera Unit Branch Line Circuit ..................92 .
CAN System (Type 11) .......................................... 80 . TCM Branch Line Circuit ........................................93 .
DIAGNOSIS SHEET ........................................... 80 . NAVI Control Unit Branch Line Circuit ...................93 .
Component Parts Location .................................... 81 . AV Control Unit Branch Line Circuit .......................94 .
Harness Layout ..................................................... 81
. Data Link Connector Branch Line Circuit ...............95 .
Malfunction Area Chart .......................................... 82 . Intelligent Key Unit Branch Line Circuit ..................95 .
MAIN LINE .......................................................... 82
. Unified Meter and A/C Amp. Branch Line Circuit ...96
BRANCH LINE ................................................... 82 . Steering Angle Sensor Branch Line Circuit ............97 .
SHORT CIRCUIT ............................................... 82 . Low Tire Pressure Warning Control Unit Branch Line
Main Line Between TCM and Data Link Connector 83 ... Circuit .....................................................................97
.
Main Line Between Data Link Connector and Pre- RAS Control Unit Branch Line Circuit ....................98 .
crash Seat Belt Control Unit .................................. 84 . Pre-Crash Seat Belt Control Unit Branch Line Circuit
Main Line Between Data Link Connector and RAS ...99
Control Unit ............................................................ 85
. Driver Seat Control Unit Branch Line Circuit ..........99 .
Main Line Between RAS Control Unit and Pre-crash ABS Actuator and Electric Unit (Control Unit) Branch
Seat Belt Control Unit ............................................ 86. Line Circuit ........................................................... 100
.
Main Line Between Pre-crash Seat Belt Control Unit ICC Sensor Integrated Unit Branch Line Circuit .. 101 .
and Driver Seat Control Unit .................................. 87 . IPDM E/R Branch Line Circuit .............................. 101 .
Main Line Between Driver Seat Control Unit and CAN Communication Circuit ................................ 102 .
Revision: 2007 April LAN-2 2007 M35/M45
PRECAUTIONS
[CAN FUNDAMENTAL]
PRECAUTIONS
[CAN FUNDAMENTAL] PFP:00001
A
Precautions When Using CONSULT-II NKS004H7
Use CONSULT-II CONVERTER when connecting CONSULT-II to data link connector.
CAUTION: B
CAN communication does not function properly if CONSULT-II is used without connecting CONSULT-II
CONVERTER.
Precautions for Trouble Diagnosis NKS004H8
C
CAUTION:
q Never apply 7.0 V or more to the measurement terminal.
D
q Use a tester with open terminal voltage of 7.0 V or less.
q Turn the ignition switch OFF and disconnect the battery cable from the negative terminal when
checking the harness.
E
Precautions for Harness Repair NKS004H9
q Solder the repaired area and wrap tape around the soldered
area. F
NOTE:
A fray of twisted lines must be within 110 mm (4.33 in).
G
H
SKIB8766E
I
q Bypass connection is never allowed at the repaired area.
NOTE:
Bypass connection may cause CAN communication error. The J
spliced wire becomes separated and the characteristics of
twisted line are lost.
LAN
L
SKIB8767E
q Replace the applicable harness as an assembly if error is detected on the shield lines of CAN communi- M
cation line.
Revision: 2007 April LAN-3 2007 M35/M45
SYSTEM DESCRIPTION
[CAN FUNDAMENTAL]
SYSTEM DESCRIPTION PFP:00000
CAN Communication System NKS004HA
q CAN communication is a multiplex communication system. This enables the system to transmit and
receive large quantities of data at high speed by connecting control units with two communication lines
(CAN-H and CAN-L).
q Control units on the CAN network transmit signals using the CAN communication control circuit. They
receive only necessary signals from other control units to operate various functions.
q CAN communication lines adopt twisted-pair line style (two lines twisted) for noise immunity.
SYSTEM DIAGRAM
SKIB8887E
Each control unit passes an electric current to the termination circuits when transmitting CAN communication
signal. The termination circuits produce an electrical potential difference between CAN-H and CAN-L. CAN
communication system transmits and receives CAN communication signals by the potential difference.
Component Description
Main line CAN communication line between splices
Branch line CAN communication line between splice and a control unit
Splice A point connecting a branch line with a main line
Termination circuit Refer to LAN-5, "CAN COMMUNICATION CONTROL CIRCUIT" .
Revision: 2007 April LAN-4 2007 M35/M45
SYSTEM DESCRIPTION
[CAN FUNDAMENTAL]
CAN COMMUNICATION CONTROL CIRCUIT
A
B
C
D
E
F
SKIB8713E
Component System description G
CAN controller It controls CAN communication signal transmission and reception, error detection, etc.
It converts digital signal into CAN communication signal, and CAN communication signal into digi-
Transceiver IC
tal signal.
H
Noise filter It eliminates noise of CAN communication signal.
Termination circuit* I
It produces potential difference.
(Resistance of approx. 120 )
*: These are the only control units wired with both ends of CAN communication system.
J
LAN
L
M
Revision: 2007 April LAN-5 2007 M35/M45
SYSTEM DESCRIPTION
[CAN FUNDAMENTAL]
Diag on CAN NKS004HB
DESCRIPTION
"Diag on CAN" is a diagnosis using CAN communication instead of previous DDL1 and DDL2 communication
lines, between control units and diagnosis unit.
SYSTEM DIAGRAM
SKIB8714E
Name Harness Description
Tx
DDL1 It is used for trouble diagnosis. (CAN-H and CAN-L are used for controlling)
Rx
DDL2 K-LINE It is used for trouble diagnosis. (CAN-H and CAN-L are used for controlling)
CAN-H
Diag on CAN It is used for trouble diagnosis and control.
CAN-L
Revision: 2007 April LAN-6 2007 M35/M45
TROUBLE DIAGNOSIS
[CAN FUNDAMENTAL]
TROUBLE DIAGNOSIS PFP:00004
A
Condition of Error Detection NKS004HC
"U1000" or "U1001" is indicated on SELF-DIAG RESULTS on CONSULT-II if CAN communication signal is not
transmitted or received between units for 2 seconds or more. B
CAN COMMUNICATION SYSTEM ERROR
q CAN communication line open (CAN-H, CAN-L, or both)
C
q CAN communication line short (ground, between CAN communication lines, other harnesses)
q Error of CAN communication control circuit of the unit connected to CAN communication line
WHEN "U1000" OR "U1001" IS INDICATED EVEN THOUGH CAN COMMUNICATION SYSTEM D
IS NORMAL
q CONSULT-II CONVERTER not connected: Error may be detected by the self-diagnosis when not using
CONSULT-II CONVERTER (Depending on the control unit which carries out CAN communication). E
q Removal/installation of parts: Error may be detected when removing and installing CAN communication
unit and related parts while turning the ignition switch ON. (A DTC except for CAN communication may be
detected.)
F
q Fuse blown out (removed): CAN communication of the unit may cease.
q Voltage drop: Error may be detected if voltage drops due to discharged battery when turning the ignition
switch ON (Depending on the control unit which carries out CAN communication).
G
q Error may be detected if the power supply circuit of the control unit, which carries out CAN communica-
tion, malfunctions (Depending on the control unit which carries out CAN communication).
q Error may be detected if reprogramming is not completed normally. H
NOTE:
CAN communication system is normal if "U1000" or "U1001" is indicated on SELF-DIAG RESULTS of CON-
SULT-II under the above conditions. Erase the memory of the self-diagnosis of each unit.
I
J
LAN
L
M
Revision: 2007 April LAN-7 2007 M35/M45
TROUBLE DIAGNOSIS
[CAN FUNDAMENTAL]
Symptom When Error Occurs in CAN Communication System NKS004HD
In CAN communication system, multiple units mutually transmit and receive signals. Each unit cannot transmit
and receive signals if any error occurs on CAN communication line. Under this condition, multiple control units
related to the root cause malfunction or go into fail-safe mode.
ERROR EXAMPLE
NOTE:
q Each vehicle differs in symptom of each unit under fail-safe mode and CAN communication line wiring.
q Refer to LAN-41, "Abbreviation List" for the unit abbreviation.
Example: TCM branch line open circuit
SKIB8738E
Unit name Symptom
ECM Engine torque limiting is affected, and shift harshness increases.
BCM Reverse warning chime does not sound.
EPS control unit Normal operation.
q Shift position indicator and OD OFF indicator turn OFF.
Combination meter
q Warning lamps turn ON.
ABS actuator and electric unit (control unit) Normal operation.
TCM No impact on operation.
IPDM E/R Normal operation.
Revision: 2007 April LAN-8 2007 M35/M45
TROUBLE DIAGNOSIS
[CAN FUNDAMENTAL]
Example: Data link connector branch line open circuit
A
B
C
D
E
F
SKIB8739E
Unit name Symptom G
ECM
BCM
H
EPS control unit
Combination meter Normal operation.
ABS actuator and electric unit (control unit) I
TCM
IPDM E/R
J
NOTE:
q When data link connector branch line is open, transmission and reception of CAN communication signals
are not affected. Therefore, no symptoms occur. However, be sure to repair malfunctioning circuit. LAN
q When data link connector branch line is open, the screen-display of the CONSULT-II "SELECT SYSTEM"
screen may be the same as when the CAN communication line has short-circuit. However, symptoms dif-
fer depending on the case. See below chart for the differences.
L
SELECT SYSTEM
Difference of symptom
(CONSULT-II)
Data link connector branch line open cir- M
Normal operation.
cuit
All Diag on CAN units are not
indicated. Most of the units which are connected to the CAN
CAN-H, CAN-L harness short-circuit communication system enter fail-safe mode or are
deactivated.
Revision: 2007 April LAN-9 2007 M35/M45
TROUBLE DIAGNOSIS
[CAN FUNDAMENTAL]
Example: Main Line Between Data Link Connector and ABS Actuator and Electric Unit (Con-
trol Unit) Open Circuit
SKIB8740E
Unit name Symptom
ECM Engine torque limiting is affected, and shift harshness increases.
q Reverse warning chime does not sound.
BCM q The front wiper moves under continuous operation mode even though the front
wiper switch being in the intermittent position.
EPS control unit The steering effort increases.
q The shift position indicator and OD OFF indicator turn OFF.
Combination meter q The speedometer is inoperative.
q The odo/trip meter stops.
ABS actuator and electric unit (control unit) Normal operation.
TCM No impact on operation.
When the ignition switch is ON,
IPDM E/R q The headlamps (Lo) turn ON.
q The cooling fan continues to rotate.
Revision: 2007 April LAN-10 2007 M35/M45
TROUBLE DIAGNOSIS
[CAN FUNDAMENTAL]
Example: CAN-H, CAN-L Harness Short Circuit
A
B
C
D
E
F
SKIB8741E
Unit name Symptom G
q Engine torque limiting is affected, and shift harshness increases.
ECM
q Engine speed drops.
H
q Reverse warning chime does not sound.
q The front wiper moves under continuous operation mode even though the front
wiper switch being in the intermittent position.
I
q The room lamp does not turn ON.
BCM
q The engine does not start (if an error or malfunction occurs while turning the igni-
tion switch OFF.)
J
q The steering lock does not release (if an error or malfunction occurs while turning
the ignition switch OFF.)
EPS control unit The steering effort increases.
LAN
q The tachometer and the speedometer do not move.
Combination meter q Warning lamps turn ON.
q Indicator lamps do not turn ON. L
ABS actuator and electric unit (control unit) Normal operation.
TCM No impact on operation.
When the ignition switch is ON, M
IPDM E/R q The headlamps (Lo) turn ON.
q The cooling fan continues to rotate.
Revision: 2007 April LAN-11 2007 M35/M45
TROUBLE DIAGNOSIS
[CAN FUNDAMENTAL]
Self-Diagnosis NKS004HE
Self-diagnosis item
DTC DTC detection condition Inspection/Action
(CONSULT-II indication)
When ECM is not transmitting or receiving CAN
communication signal of OBD (emission-related
diagnosis) for 2 seconds or more.
U1000 CAN COMM CIRCUIT
When a control unit (except for ECM) is not Refer to LAN-15,
transmitting or receiving CAN communication "TROUBLE DIAG-
signal for 2 seconds or more. NOSES WORK FLOW" .
When ECM is not transmitting or receiving CAN
U1001 CAN COMM CIRCUIT communication signal other than OBD (emis-
sion-related diagnosis) for 2 seconds or more.
Start the inspection.
When a control unit is not transmitting or receiv-
Refer to the applicable
U1002 SYSTEM COMM ing CAN communication signal for 2 seconds or
section of the indicated
less.
control unit.
When an error is detected during the initial diag- Replace the control unit
U1010 CONTROL UNIT [CAN]
nosis for CAN controller of each control unit. indicating "U1010".
Revision: 2007 April LAN-12 2007 M35/M45
TROUBLE DIAGNOSIS
[CAN FUNDAMENTAL]
CAN Diagnostic Support Monitor NKS004HF
A
CONSULT-II and CAN diagnostic support monitor (on-board diagnosis function) are used for detecting root
cause.
MONITOR ITEM (CONSULT-II) B
Example: CAN DIAG SUPPORT MNTR indication
C
D
E
F
G
H
SKIB8742E
Without PAST
Item PRSNT Description I
OK Normal at present
Initial diagnosis
NG Control unit error (Except for some control units)
J
OK Normal at present
Transmission diagnosis Unable to transmit signals for 2 seconds or more.
UNKWN
Diagnosis not performed LAN
OK Normal at present
Control unit name Unable to receive signals for 2 seconds or more.
L
(Reception diagnosis) UNKWN Diagnosis not performed
No control unit for receiving signals. (No applicable optional parts)
With PAST M
Item PRSNT PAST Description
OK Normal at present and in the past
OK Normal at present, but unable to transmit signals for 2 seconds or more
Transmission diagnosis 1 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
