Image preview - the first page of the document
>> Download lu documenatation <<
Text preview - extract from the document
ENGINE LUBRICATION SYSTEM
B ENGINE
A
ENGINE LUBRICATION SYSTEM
SECTION LU LU
C
D
E
CONTENTS
VQ35DE INSPECTION AFTER INSTALLATION ............... 19 . F
Disassembly and Assembly ................................... 19 .
PRECAUTIONS ......................................................... 3. DISASSEMBLY .................................................. 19
.
Precautions for Liquid Gasket ................................. 3 . INSPECTION AFTER DISASSEMBLY ............... 20 . G
LIQUID GASKET APPLICATION PROCEDURE 3 ..... ASSEMBLY ........................................................ 21
.
PREPARATION .......................................................... 4
. SERVICE DATA AND SPECIFICATIONS (SDS) ..... 22 .
Special Service Tools .............................................. 4. Standard and Limit ................................................. 22
.
Commercial Service Tools ....................................... 4 . H
ENGINE OIL PRESSURE .................................. 22 .
LUBRICATION SYSTEM ........................................... 5 . ENGINE OIL CAPACITY (APPROXIMATE) ....... 22 .
Lubrication Circuit ................................................... 5
. OIL PUMP .......................................................... 22
.
System Chart .......................................................... 6
. REGULATOR VALVE ......................................... 22 . I
ENGINE OIL .............................................................. 7
.
Inspection ................................................................ 7
.
ENGINE OIL LEVEL ............................................ 7 .
VK45DE
J
ENGINE OIL APPEARANCE ............................... 7 . PRECAUTIONS ....................................................... 23 .
ENGINE OIL LEAKAGE ....................................... 7 . Precautions for Liquid Gasket ............................... 23 .
OIL PRESSURE CHECK ..................................... 8 . LIQUID GASKET APPLICATION PROCEDURE 23 ...
Changing Engine Oil ............................................... 9 . K
PREPARATION ........................................................ 24.
OIL FILTER ...............................................................11
. Special Service Tools ............................................ 24 .
Removal and Installation ........................................11 . Commercial Service Tools ..................................... 24 .
REMOVAL ...........................................................11
. LUBRICATION SYSTEM ......................................... 25 . L
INSTALLATION ...................................................11 . Lubrication Circuit .................................................. 25
.
INSPECTION AFTER INSTALLATION ...............11 . System Chart ......................................................... 26
.
OIL FILTER BRACKET (AWD) ................................ 13 . ENGINE OIL ............................................................. 27
. M
Components .......................................................... 13
. Inspection .............................................................. 27
.
Removal and Installation ....................................... 13 . ENGINE OIL LEVEL ........................................... 27 .
REMOVAL .......................................................... 13
. ENGINE OIL APPEARANCE ............................. 27 .
INSTALLATION .................................................. 13 . ENGINE OIL LEAKAGE ..................................... 27 .
INSPECTION AFTER INSTALLATION .............. 14 . OIL PRESSURE CHECK ................................... 27 .
OIL COOLER ........................................................... 15
. Changing Engine Oil .............................................. 28 .
Components .......................................................... 15
. OIL FILTER .............................................................. 30
.
Removal and Installation ....................................... 16 . Removal and Installation ....................................... 30 .
REMOVAL .......................................................... 16
. REMOVAL .......................................................... 30
.
INSPECTION AFTER REMOVAL ...................... 17 . INSTALLATION .................................................. 30 .
INSTALLATION .................................................. 17 . INSPECTION AFTER INSTALLATION ............... 30 .
INSPECTION AFTER INSTALLATION .............. 17 . OIL PUMP ................................................................ 31
.
OIL PUMP ................................................................ 19
. Components .......................................................... 31
.
Components .......................................................... 19
. Removal and Installation ....................................... 31 .
Removal and Installation ....................................... 19 . REMOVAL .......................................................... 31
.
REMOVAL .......................................................... 19
. INSTALLATION .................................................. 31 .
INSTALLATION .................................................. 19 .
Revision: 2007 April LU-1 2007 M35/M45
INSPECTION AFTER INSTALLATION ............... 32 . SERVICE DATA AND SPECIFICATIONS (SDS) .....34 .
Disassembly and Assembly ................................... 32 . Standard and Limit .................................................34
.
DISASSEMBLY .................................................. 32
. ENGINE OIL PRESSURE ...................................34 .
INSPECTION AFTER DISASSEMBLY ............... 32 . ENGINE OIL CAPACITY (APPROXIMATE) .......34 .
ASSEMBLY ........................................................ 33
. OIL PUMP ...........................................................34
.
REGULATOR VALVE ..........................................34 .
Revision: 2007 April LU-2 2007 M35/M45
PRECAUTIONS
[VQ35DE]
PRECAUTIONS
[VQ35DE] PFP:00001
A
Precautions for Liquid Gasket NBS004PR
LIQUID GASKET APPLICATION PROCEDURE
1. Remove old liquid gasket adhering to the liquid gasket application surface and the mating surface.
LU
q Remove liquid gasket completely from the liquid gasket application surface, mounting bolts, and bolt
holes.
2. Wipe the liquid gasket application surface and the mating surface with white gasoline (lighting and heating
C
use) to remove adhering moisture, grease and foreign materials.
3. Apply liquid gasket to the liquid gasket application surface.
Use Genuine RTV Silicone Sealant or equivalent. Refer to GI-47, "RECOMMENDED CHEMICAL
PRODUCTS AND SEALANTS" . D
q Within five minutes of liquid gasket application, install the mating component.
q If liquid gasket protrudes, wipe it off immediately.
E
q Do not retighten mounting bolts or nuts after the installation.
q After 30 minutes or more have passed from the installation, fill engine oil and engine coolant.
F
G
H
I
J
K
L
M
Revision: 2007 April LU-3 2007 M35/M45
PREPARATION
[VQ35DE]
PREPARATION PFP:00002
Special Service Tools NBS004PS
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.) Description
Tool name
ST25051001 Measuring oil pressure
(J25695-1) Maximum measuring range: 2,452 kPa (25
Oil pressure gauge kg-cm2 , 356 psi)
NT050
ST25052000 Adapting oil pressure gauge to oil pan (upper)
(J25695-2)
Hose
S-NT559
KV10115801 Removing and installing oil filter
(J38956) a: 64.3 mm (2.531 in)
Oil filter wrench
S-NT375
Commercial Service Tools NBS004PT
Tool name Description
Power tools Loosening nuts and bolts
PBIC0190E
Deep socket Removing and installing oil pressure switch
a: 26 mm (1.02 in)
PBIC2072E
Revision: 2007 April LU-4 2007 M35/M45
LUBRICATION SYSTEM
[VQ35DE]
LUBRICATION SYSTEM PFP:15010
A
Lubrication Circuit NBS004PU
LU
C
D
E
F
G
H
I
PBIC1933E
J
K
L
M
Revision: 2007 April LU-5 2007 M35/M45
LUBRICATION SYSTEM
[VQ35DE]
System Chart NBS004PV
PBIC2071E
Revision: 2007 April LU-6 2007 M35/M45
ENGINE OIL
[VQ35DE]
ENGINE OIL PFP:KLA92
A
Inspection NBS004PW
ENGINE OIL LEVEL
NOTE: LU
Before starting engine, put vehicle horizontally and check the engine oil level. If engine is already started, stop
it and allow 10 minutes before checking.
1. Pull out oil level gauge and wipe it clean.
C
2. Insert oil level gauge and make sure the engine oil level is within
the range shown in the figure.
3. If it is out of range, adjust it.
D
E
F
PBIC0249E
NOTE: G
When checking the engine oil level, insert oil level gauge with its
tip aligned with oil level gauge guide on cylinder head. (In figure,
air cleaner case and air duct are removed.)
H
I
J
KBIA1343E
ENGINE OIL APPEARANCE
q Check engine oil for white turbidity or heavy contamination. K
q If engine oil becomes turbid and white, it is highly probable that it is contaminated with engine coolant.
Repair or replace damaged parts.
L
ENGINE OIL LEAKAGE
Check for engine oil leakage around the following areas:
q Oil pans (lower and upper) M
q Oil pan drain plug
q Oil pressure switch
q Oil filter
q Oil filter bracket (AWD models)
q Oil cooler
q Water pump cover
q Chain tensioner cover
q Intake valve timing control cover and intake valve timing control solenoid valve
q Mating surface between cylinder head and rocker cover
q Mating surface between front timing chain case and rear timing chain case
q Mating surface between rear timing chain case and cylinder head
q Mating surface between rear timing chain case and cylinder block
q Mating surface between rear timing chain case and oil pan (upper)
q Mating surface between cylinder block and cylinder head
Revision: 2007 April LU-7 2007 M35/M45
ENGINE OIL
[VQ35DE]
q Crankshaft oil seals (front and rear)
q Camshaft position sensor (PHASE)
OIL PRESSURE CHECK
WARNING:
q Be careful not to get burn yourself, as engine oil may be hot.
q Oil pressure check should be done in "Parking position".
1. Check the engine oil level. Refer to LU-7, "ENGINE OIL LEVEL" .
2. Remove front engine undercover with power tool.
3. Disconnect harness connector at oil pressure switch, and
remove oil pressure switch using deep socket (commercial ser-
vice tool).
CAUTION:
Do not drop or shock oil pressure switch.
SBIA0452E
q Remove the oil pressure switch using a 26 mm (1.02 in) box
wrench. (AWD models)
SBIA0453E
4. Install the oil pressure gauge (SST) and hose (SST).
SLC926
5. Start the engine and warm it up to normal operating temperature.
6. Check the engine oil pressure with engine running under no-load.
NOTE:
When the engine oil temperature is low, the engine oil pressure becomes high.
Engine oil pressure [Engine oil temperature at 80 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
