Image preview - the first page of the document
>> Download rax documenatation <<
Text preview - extract from the document
REAR AXLE
D DRIVELINE/AXLE
A
SECTION RAX REAR AXLE
B
C
RAX
E
CONTENTS
PRECAUTIONS ......................................................... 2 . REAR DRIVE SHAFT ................................................ 8. F
Caution .................................................................... 2
. Removal and Installation ......................................... 8
.
PREPARATION .......................................................... 3. COMPONENT ...................................................... 8
.
Special Service Tools [SST] .................................... 3 . REMOVAL ............................................................ 8
. G
Commercial Service Tools ....................................... 3 . INSPECTION AFTER REMOVAL ........................ 8 .
NOISE, VIBRATION AND HARSHNESS (NVH) INSTALLATION .................................................... 9
.
TROUBLESHOOTING ............................................... 4 . Disassembly and Assembly ..................................... 9 .
H
NVH Troubleshooting Chart .................................... 4 . COMPONENT ...................................................... 9
.
WHEEL HUB ............................................................. 5
. DISASSEMBLY .................................................... 9
.
On-Vehicle Inspection ............................................. 5 . INSPECTION AFTER DISASSEMBLY ............... 10 .
WHEEL BEARING INSPECTION ........................ 5 . ASSEMBLY ........................................................ 11
. I
Removal and Installation ......................................... 5 . SERVICE DATA AND SPECIFICATIONS (SDS) ..... 14 .
COMPONENT ...................................................... 5 . Wheel Bearing ....................................................... 14
.
REMOVAL ............................................................ 5
. Drive Shaft (VQ35DE model) ................................ 14 . J
INSPECTION AFTER REMOVAL ........................ 6 . Drive Shaft (VK45DE model) ................................. 14 .
INSTALLATION .................................................... 6 .
K
L
M
Revision: 2007 April RAX-1 2007 M35/M45
PRECAUTIONS
PRECAUTIONS PFP:00001
Caution NDS000FM
Observe the following precautions when disassembling and assembling drive shaft.
q Joint sub-assembly does not disassemble because it is non-overhaul parts.
q Perform work in a location which is as dust-free as possible.
q Before disassembling and assembling, clean the outside of parts.
q Prevention of the entry of foreign objects must be taken into account during disassembly of the service
location.
q Disassembled parts must be carefully reassembled in the correct order. If work is interrupted, a clean
cover must be placed over parts.
q Paper shop cloths must be used. Fabric shop cloths must not be used because of the danger of lint adher-
ing to parts.
q Disassembled parts (except for rubber parts) should be cleaned with kerosene which shall be removed by
blowing with air or wiping with paper shop cloths.
Revision: 2007 April RAX-2 2007 M35/M45
PREPARATION
PREPARATION PFP:00002
A
Special Service Tools [SST] NDS000FN
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
B
(Kent-Moore No.) Description
Tool name
C
KV38100500
( -- )
Drift Installing drive shaft plug RAX
a: 80 mm (3.15 in) dia.
b: 60 mm (2.36 in) dia.
ZZA0701D
E
KV38102200
( -- ) F
Drift Installing drive shaft plug
a: 90 mm (3.54 in) dia.
b: 31 mm (1.22 in) dia.
G
ZZA0920D
Commercial Service Tools NDS000FO
H
Tool name Description
q Removing wheel nuts I
q Removing brake caliper assembly
Power tool
q Removing suspension links
q Removing drive shaft J
PBIC0190E
K
L
M
Revision: 2007 April RAX-3 2007 M35/M45
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003
NVH Troubleshooting Chart NDS000FP
Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
Refer to DRIVE SHAFT in this chart.
Refer to REAR AXLE in this chart.
NVH in RAX and RSU sections.
NVH in RFD section.
NVH in WT section.
NVH in WT section.
NVH in BR section.
NVH in PR section.
NVH in PS section.
RAX-10
RAX-8
--
--
--
Reference page
REAR AXLE AND REAR SUSPENSION
Improper installation, looseness
Joint sliding resistance
PROPELLER SHAFT
Excessive joint angle
Possible cause and SUSPECTED PARTS
Parts interference
DIFFERENTIAL
ROAD WHEEL
DRIVE SHAFT
REAR AXLE
STEERING
Imbalance
BRAKES
TIRES
