Image preview - the first page of the document
gi


>> Download gi documenatation <<

Text preview - extract from the document
GENERAL INFORMATION


A GENERAL INFORMATION

                                                                                                                                                                       GI




                                                                                    GENERAL INFORMATION
                                                                                                              SECTION                     GI                            B



                                                                                                                                                                        C


                                                                                                                                                                        D


                                                                                                                                                                        E
                                                                   CONTENTS
PRECAUTIONS ......................................................... 3   .             DESCRIPTION ................................................... 16    .         F
 Description .............................................................. 3
                                                                          .           Abbreviations ......................................................... 22
                                                                                                                                                              .
 Precautions for Supplemental Restraint System                                      SERVICE INFORMATION FOR ELECTRICAL INCI-
 (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                            DENT ........................................................................ 23
                                                                                                                                                              .         G
 SIONER" ................................................................. 3
                                                                          .           How to Check Terminal .......................................... 23     .
 Precautions for NVIS/IVIS (NISSAN/INFINITI                                             CONNECTOR AND TERMINAL PIN KIT ........... 23                         .
 VEHICLE IMMOBILIZER SYSTEM - NATS) (If                                                 HOW TO PROBE CONNECTORS ..................... 23                      .
                                                                                                                                                                        H
 Equipped) ................................................................ 3
                                                                          .           How to Perform Efficient Diagnosis for an Electrical
 General Precautions ............................................... 4    .           Incident .................................................................. 26
                                                                                                                                                              .
 Precautions for Three Way Catalyst ........................ 5            .             WORK FLOW ..................................................... 26    .
 Precautions for Fuel (Unleaded Premium Gasoline                                        INCIDENT SIMULATION TESTS ....................... 26                  .         I
 Required) ................................................................ 5
                                                                          .             CIRCUIT INSPECTION ...................................... 29          .
 Precautions for Multiport Fuel Injection System or                                   Control Units and Electrical Parts .......................... 34        .
 Engine Control System ........................................... 6      .             PRECAUTIONS ................................................. 34      .         J
 Precautions for Hoses ............................................. 6    .         CONSULT-II CHECKING SYSTEM ......................... 36                   .
   HOSE REMOVAL AND INSTALLATION .............. 6                         .           Description ............................................................. 36
                                                                                                                                                              .
   HOSE CLAMPING ............................................... 6        .           Function and System Application .......................... 36           .
                                                                                                                                                                        K
 Precautions for Engine Oils ..................................... 7      .           Nickel Metal Hydride Battery Replacement ........... 36                 .
   HEALTH PROTECTION PRECAUTIONS ............ 7                           .           Checking Equipment ............................................. 37     .
   ENVIRONMENTAL PROTECTION PRECAU-                                                   CONSULT-II Start Procedure ................................. 37         .
   TIONS .................................................................. 7
                                                                          .           CONSULT-II Data Link Connector (DLC) Circuit ... 38                               L
 Precautions for Air Conditioning .............................. 7        .             INSPECTION PROCEDURE ............................. 39                 .
HOW TO USE THIS MANUAL .................................. 8               .         LIFTING POINT ........................................................ 40 .
 Description .............................................................. 8
                                                                          .           Special Service Tools ............................................ 40   .        M
 Terms ...................................................................... 8
                                                                          .           Garage Jack and Safety Stand .............................. 40          .
 Units ........................................................................ 8
                                                                          .           2-Pole Lift .............................................................. 41
                                                                                                                                                              .
 Contents .................................................................. 8
                                                                          .           Board-On Lift ......................................................... 42
                                                                                                                                                              .
 Components ............................................................ 9.         TOW TRUCK TOWING ............................................ 43          .
   SYMBOLS ............................................................ 9 .           Tow Truck Towing .................................................. 43  .
 How to Follow Trouble Diagnoses ......................... 10             .           Vehicle Recovery (Freeing a Stuck Vehicle) .......... 44                .
   DESCRIPTION ................................................... 10     .         TIGHTENING TORQUE OF STANDARD BOLTS ... 45
   HOW TO FOLLOW TEST GROUPS IN TROU-                                                 Tightening Torque Table ........................................ 45     .
   BLE DIAGNOSES .............................................. 10        .         RECOMMENDED CHEMICAL PRODUCTS AND
   HARNESS WIRE COLOR AND CONNECTOR                                                 SEALANTS .............................................................. 46.
   NUMBER INDICATION .......................................11            .           Recommended Chemical Products and Sealants... 46
   KEY TO SYMBOLS SIGNIFYING MEASURE-                                               IDENTIFICATION INFORMATION ........................... 47                 .
   MENTS OR PROCEDURES .............................. 12                  .           Model Variation ...................................................... 47
                                                                                                                                                              .
 How to Read Wiring Diagrams .............................. 14            .             IDENTIFICATION NUMBER ............................... 48              .
   CONNECTOR SYMBOLS .................................. 14                .             IDENTIFICATION PLATE ................................... 48           .
   SAMPLE/WIRING DIAGRAM - EXAMPL - ........ 15                           .             ENGINE SERIAL NUMBER ............................... 49               .


Revision; 2004 April                                                           GI-1                                                                  2003 M45
   AUTOMATIC TRANSMISSION NUMBER .......... 49                       .        TERMINOLOGY .......................................................50
                                                                                                                                              .
 Dimensions ............................................................ 49
                                                                     .         SAE J1930 Terminology List ..................................50.
 Wheels & Tires ...................................................... 49
                                                                     .




Revision; 2004 April                                                     GI-2                                                          2003 M45
                                              PRECAUTIONS

PRECAUTIONS                                                                                               PFP:00001
                                                                                                                         GI
Description                                                                                                   AAS0005J


Observe the following precautions to ensure safe and proper servicing. These precautions are not
described in each individual section.                                                                                     B
Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER"                                                                                           AAS0007A
                                                                                                                          C
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front               D
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.                                                                                                                      E
WARNING:
q    To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
     in the event of a collision which would result in air bag inflation, all maintenance must be per-                    F
     formed by an authorized NISSAN/INFINITI dealer.
q    Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
     sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
                                                                                                                         G
     Bag Module, see the SRS section.
q    Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
     Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
     harness connectors.                                                                                                  H

Precautions for NVIS/IVIS (NISSAN/INFINITI VEHICLE IMMOBILIZER SYSTEM -
NATS) (If Equipped)                                                                                           AAS0005L
                                                                                                                          I
NVIS/IVIS (NATS) will immobilize the engine if someone tries to start it without the registered key of NVIS/IVIS
(NATS).
Both of the originally supplied ignition key IDs have been NVIS/IVIS (NATS) registered.                                   J
The security indicator is located on the instrument panel. The indicator blinks when the immobilizer system is
functioning.
Therefore, NVIS/IVIS (NATS) warns outsiders that the vehicle is equipped with the anti-theft system.
                                                                                                                          K
q    When NVIS/IVIS (NATS) detects trouble, the security indicator lamp lights up while ignition switch is in
     "ON" position.
     This lighting up indicates that the anti-theft is not functioning, so prompt service is required.
                                                                                                                          L
q    When servicing NVIS/IVIS (NATS) (trouble diagnoses, system initialization and additional registration of
     other NVIS/IVIS (NATS) ignition key IDs), CONSULT-II hardware and CONSULT-II NVIS/IVIS (NATS)
     software is necessary.
     Regarding the procedures of NVIS/IVIS (NATS) initialization and NVIS/IVIS (NATS) ignition key ID regis-             M
     tration, refer to CONSULT-II operation manual, NVIS/IVIS (NATS).
Therefore, CONSULT-II NVIS/IVIS (NATS) software (program card and operation manual) must be kept
strictly confidential to maintain the integrity of the anti-theft function.
q    When servicing NVIS/IVIS (NATS) (trouble diagnoses, system initialization and additional registration of
     other NVIS/IVIS (NATS) ignition key IDs), it may be necessary to re-register original key identification.
     Therefore, be sure to receive all keys from vehicle owner. A maximum of four or five key IDs can be regis-
     tered into NVIS/IVIS (NATS).
q    When failing to start the engine first time using the key of NVIS/IVIS (NATS), start as follows.
1. Leave the ignition key in "ON" position for approximately 5 seconds.
2. Turn ignition key to "OFF" or "LOCK" position and wait approximately 5 seconds.
3. Repeat step 1 and 2 again.
4. Restart the engine while keeping the key separate from any others on key-chain.




Revision; 2004 April                                  GI-3                                               2003 M45
                                             PRECAUTIONS

General Precautions                                                                                         AAS0005M


q   Do not operate the engine for an extended period of time without
    proper exhaust ventilation.
    Keep the work area well ventilated and free of any inflammable
    materials. Special care should be taken when handling any
    inflammable or poisonous materials, such as gasoline, refriger-
    ant gas, etc. When working in a pit or other enclosed area, be
    sure to properly ventilate the area before working with hazard-
    ous materials.
    Do not smoke while working on the vehicle.

                                                                                                         SGI285




q   Before jacking up the vehicle, apply wheel chocks or other tire
    blocks to the wheels to prevent the vehicle from moving. After
    jacking up the vehicle, support the vehicle weight with safety
    stands at the points designated for proper lifting before working
    on the vehicle.
    These operations should be done on a level surface.
q   When removing a heavy component such as the engine or tran-
    saxle/transmission, be careful not to lose your balance and drop
    them. Also, do not allow them to strike adjacent parts, especially
    the brake tubes and master cylinder.
                                                                                                         SGI231




q   Before starting repairs which do not require battery power:
    Turn off ignition switch.
    Disconnect the negative battery terminal.
q   If the battery terminals are disconnected, recorded memory of
    radio and each control unit is erased.




                                                                                                         SEF289H




q   To prevent serious burns:
    Avoid contact with hot metal parts.
    Do not remove the radiator cap when the engine is hot.
q   Dispose of drained oil or the solvent used for cleaning parts in
    an appropriate manner.
q   Do not attempt to top off the fuel tank after the fuel pump nozzle
    shuts off automatically.
    Continued refueling may cause fuel overflow, resulting in fuel
    spray and possibly a fire.
q   Clean all disassembled parts in the designated liquid or solvent
    prior to inspection or assembly.                                                                      SGI233


q   Replace oil seals, gaskets, packings, O-rings, locking washers, cotter pins, self-locking nuts, etc. with new
    ones.
q   Replace inner and outer races of tapered roller bearings and needle bearings as a set.
q   Arrange the disassembled parts in accordance with their assembled locations and sequence.
q   Do not touch the terminals of electrical components which use microcomputers (such as ECM).
    Static electricity may damage internal electronic components.
q   After disconnecting vacuum or air hoses, attach a tag to indicate the proper connection.
q   Use only the fluids and lubricants specified in this manual.

Revision; 2004 April                                 GI-4                                              2003 M45
                                             PRECAUTIONS

q   Use approved bonding agent, sealants or their equivalents when required.
q   Use hand tools, power tools (disassembly only) and recom-                                                          GI
    mended special tools where specified for safe and efficient ser-
    vice repairs.
q   When repairing the fuel, oil, water, vacuum or exhaust systems,                                                     B
    check all affected lines for leaks.

                                                                                                                        C



                                                                                                         PBIC0190E
                                                                                                                        D


q   Before servicing the vehicle:
    Protect fenders, upholstery and carpeting with appropriate cov-                                                     E
    ers.
    Take caution that keys, buckles or buttons do not scratch paint.
                                                                                                                        F


                                                                                                                       G


                                                                                                         SGI234
                                                                                                                        H
WARNING:
To prevent ECM from storing the diagnostic trouble codes, do not carelessly disconnect the harness
connectors which are related to the engine control system and TCM (transmission control module)                         I
system. The connectors should be disconnected only when working according to the WORK FLOW of
TROUBLE DIAGNOSES in EC and AT sections.
                                                                                                                        J
Precautions for Three Way Catalyst                                                                          AAS0005N


If a large amount of unburned fuel flows into the catalyst, the catalyst temperature will be excessively high. To
prevent this, follow the instructions.
                                                                                                                        K
q     Use unleaded gasoline only. Leaded gasoline will seriously damage the three way catalyst.
q     When checking for ignition spark or measuring engine compression, make tests quickly and only when
      necessary.                                                                                                        L
q     Do not run engine when the fuel tank level is low, otherwise the engine may misfire, causing damage to
      the catalyst.
Do not place the vehicle on flammable material. Keep flammable material off the exhaust pipe and the three             M
way catalyst.
Precautions for Fuel (Unleaded Premium Gasoline Required)                                                   AAS0005O


Use unleaded premium gasoline with an octane rating of at least 91 AKI (Anti-Knock Index) number (Research
octane number 96).

If unleaded premium gasoline is not available, unleaded regular gasoline with an octane rating of at least 87
AKI number (Research octane number 91) can be used, but only under the following precautions:
q    have the fuel tank filled only partially with unleaded regular gasoline, and fill up with unleaded premium
     gasoline as soon as possible.
q    avoid full throttle driving and abrupt acceleration.
However, for maximum vehicle performance, the use of unleaded premium gasoline is recommended.

CAUTION:
Do not use leaded gasoline. Using leaded gasoline will damage the three way catalyst. Using a fuel
other than that specified could adversely affect the emission control devices and systems, and could
also affect the warranty coverage validity.

Revision; 2004 April                                 GI-5                                             2003 M45
                                             PRECAUTIONS

Precautions for Multiport Fuel Injection System or Engine Control System      AAS0005P


q   Before connecting or disconnecting any harness connector for
    the multiport fuel injection system or ECM:
    Turn ignition switch to "OFF" position.
    Disconnect negative battery terminal.
    Otherwise, there may be damage to ECM.
q   Before disconnecting pressurized fuel line from fuel pump to
    injectors, be sure to release fuel pressure.
q   Be careful not to jar components such as ECM and mass air
    flow sensor.

                                                                           SGI787


Precautions for Hoses                                                         AAS0005R

HOSE REMOVAL AND INSTALLATION
q   To prevent damage to rubber hose, do not pry off rubber hose
    with tapered tool or screwdriver.




                                                                           SMA019D




q   To reinstall the rubber hose securely, make sure that hose inser-
    tion length and orientation is correct. (If tube is equipped with
    hose stopper, insert rubber hose into tube until it butts up
    against hose stopper.)




                                                                           SMA020D


HOSE CLAMPING
q   If old rubber hose is re-used, install hose clamp in its original
    position (at the indentation where the old clamp was). If there is
    a trace of tube bulging left on the old rubber hose, align rubber
    hose at that position.
q   Discard old clamps; replace with new ones.




                                                                           SMA021D




Revision; 2004 April                                 GI-6                2003 M45
                                              PRECAUTIONS

q   After installing plate clamps, apply force to them in the direction
    of the arrow, tightening rubber hose equally all around.                                                             GI


                                                                                                                          B



                                                                                                                          C

                                                                                                           SMA022D

                                                                                                                          D
Precautions for Engine Oils                                                                                   AAS0005S


Prolonged and repeated contact with used engine oil may cause skin cancer. Try to avoid direct skin contact
with used oil.                                                                                                            E
If skin contact is made, wash thoroughly with soap or hand cleaner as soon as possible.
HEALTH PROTECTION PRECAUTIONS
q   Avoid prolonged and repeated contact with oils, particularly used engine oils.                                        F
q   Wear protective clothing, including impervious gloves where practicable.
q   Do not put oily rags in pockets.
q   Avoid contaminating clothes, particularly underpants, with oil.                                                      G
q   Heavily soiled clothing and oil-impregnated footwear should not be worn. Overalls must be cleaned regu-
    larly.
                                                                                                                          H
q   First aid treatment should be obtained immediately for open cuts and wounds.
q   Use barrier creams, applying them before each work period, to help the removal of oil from the skin.
q   Wash with soap and water to ensure all oil is removed (skin cleansers and nail brushes will help). Prepa-             I
    rations containing lanolin replace the natural skin oils which have been removed.
q   Do not use gasoline, kerosene, diesel fuel, gas oil, thinners or solvents for cleaning skin.
q   If skin disorders develop, obtain medical advice without delay.                                                       J
q   Where practical, degrease components prior to handling.
q   Where there is a risk of eye contact, eye protection should be worn, for example, chemical goggles or face
    shields; in addition an eye wash facility should be provided.                                                         K
ENVIRONMENTAL PROTECTION PRECAUTIONS
Dispose of used oil and used oil filters through authorized waste disposal contractors to licensed waste dis-
posal sites, or to the waste oil reclamation trade. If in doubt, contact the local authority for advice on disposal       L
facilities.
It is illegal to pour used oil on to the ground, down sewers or drains, or into water sources.
The regulations concerning pollution vary between regions.                                                               M
Precautions for Air Conditioning                                                                              AAS0005T


Use an approved refrigerant recovery unit any time the air conditioning system must be discharged. Refer to
ATC/MTC section "HFC-134a (R-134a) Service Procedure", "REFRIGERANT LINES" for specific instructions.




Revision; 2004 April                                  GI-7                                              2003 M45
                                    HOW TO USE THIS MANUAL

HOW TO USE THIS MANUAL                                                                                  PFP:00008

Description                                                                                                 AAS0005U


This volume explains "Removal, Disassembly, Installation, Inspection and Adjustment" and "Trouble Diag-
noses".
Terms                                                                                                       AAS0005V


q   The captions WARNING and CAUTION warn you of steps that must be followed to prevent personal
    injury and/or damage to some part of the vehicle.
    WARNING indicates the possibility of personal injury if instructions are not followed.
    CAUTION indicates the possibility of component damage if instructions are not followed.
    BOLD TYPED STATEMENTS except WARNING and CAUTION give you helpful information.
    Standard value:Tolerance at inspection and adjustment.
    Limit value:The maximum or minimum limit value that should not be exceeded at inspection and adjust-
    ment.
Units                                                                                                       AAS000KR


q   The UNITS given in this manual are primarily expressed as the SI UNIT (International System of Unit),
    and alternatively expressed in the metric system and in the yard/pound system.
    Also with regard to tightening torque of bolts and nuts, there are descriptions both about range and about
    the standard tightening torque.

    "Example"
    Range
        Outer Socket Lock Nut       : 59 - 78 N



◦ Jabse Service Manual Search 2024 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
