Image preview - the first page of the document
>> Download fsu documenatation <<
Text preview - extract from the document
FRONT SUSPENSION
E SUSPENSION
A
SECTION
FRONT SUSPENSION
FSU B
C
D
FSU
CONTENTS
PRECAUTIONS ......................................................... 2 . INSTALLATION .................................................... 8 . F
Caution .................................................................... 2
. Disassembly and Assembly ..................................... 9 .
PREPARATION .......................................................... 3. DISASSEMBLY .................................................... 9 .
Special Service Tools (SST) .................................... 3 . INSPECTION AFTER DISASSEMBLY ............... 10 . G
Commercial Service Tools ....................................... 3 . ASSEMBLY ........................................................ 10 .
NOISE, VIBRATION AND HARSHNESS (NVH) SUSPENSION ARM ................................................. 12 .
TROUBLESHOOTING ............................................... 4 . Removal and Installation ....................................... 12 .
H
NVH Troubleshooting Chart .................................... 4 . REMOVAL .......................................................... 12 .
FRONT SUSPENSION ASSEMBLY .......................... 5 . INSPECTION AFTER REMOVAL ...................... 12 .
On-Vehicle Inspection and Service ......................... 5 . INSTALLATION .................................................. 13 .
INSPECTION LOWER BALL JOINT END PLAY 5 ..... STABILIZER BAR .................................................... 14 . I
STRUT INSPECTION .......................................... 5 . Removal and Installation ....................................... 14 .
Wheel Alignment Inspection .................................... 5 . REMOVAL .......................................................... 14 .
DESCRIPTION ..................................................... 5 . INSPECTION AFTER REMOVAL ...................... 14 . J
PRELIMINARY INSPECTION .............................. 5 . INSTALLATION .................................................. 14 .
INSPECTION OF CAMBER, CASTER AND FRONT SUSPENSION MEMBER ............................ 15 .
KINGPIN INCLINATION ANGLES. ...................... 5 . Removal and Installation ....................................... 15 .
K
Components ............................................................ 7
. REMOVAL .......................................................... 15 .
COIL SPRING AND STRUT ...................................... 8 . INSPECTION AFTER REMOVAL ...................... 15 .
Removal and Installation ......................................... 8 . INSTALLATION .................................................. 15 .
REMOVAL ............................................................ 8
. SERVICE DATA ....................................................... 16 . L
Wheel Alignment (Unladen) ................................... 16 .
Ball Joint ................................................................ 16
.
Wheelarch Height (Unladen*) ................................ 16 . M
FSU-1
PRECAUTIONS
PRECAUTIONS PFP:00001
Caution EES000TR
q When installing rubber bushings, final tightening must be carried out under unladen conditions with tires
on ground. Oil will shorten the life of rubber bushings. Be sure to wipe off any spilled oil.
q Unladen conditions mean that fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and
mats are in designated positions.
q After servicing suspension parts, be sure to check wheel alignment.
q Caulking nuts are not reusable. Always use new ones when installing. Since new caulking nuts are pre-
oiled tighten as they are.
FSU-2
PREPARATION
PREPARATION PFP:00002
A
Special Service Tools (SST) EES000TS
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
B
(Kent-Moore No.) Description
Tool name
KV991040S0 C
( -- )
CCK gauge attachment
1.Plate
D
2.Guide bolts
3.Nuts
4.Springs
5.Center plate FSU
Measuring wheel alignment
6.KV99104020 Adapter A
a: 72 mm (2.83 in) dia.
7.KV99104030 Adapter B
b: 65 mm (2.56 in) dia. S-NT498 F
8.KV99104040 Adapter C
c: 57 mm (2.24 in) dia.
9.KV99104050 Adapter D
d: 53.4 mm (2.102 in) dia. G
ST3565 2000 H
( -- ) Disassembling and assembling strut
Strut attachment
I
ZZA0807D
ST3127 S000
(See J25765-A) J
Preload gauge
1. GG91030000
Torque wrench (J25765) Measuring rotating torque of ball joint
2. HT62940000 ( -- ) K
Socket adapter (1/2)
3. HT62900000 ( -- )
NT124
Socket adapter (3/8)
L
Commercial Service Tools EES000TT
Tool name Description
M
Spring compressor Removing coil spring
S-NT717
q Removing wheel nuts
q Removing undercover
Power tool
q Removing brake caliper assembly
q Removing suspension components parts
PBIC0190E
FSU-3
Symptom
