Image preview - the first page of the document
>> Download rax documenatation <<
Text preview - extract from the document
REAR AXLE
D DRIVELINE/AXLE
A
SECTION RAX REAR AXLE
B
C
RAX
E
CONTENTS
PRECAUTIONS ......................................................... 2 . INSTALLATION .................................................... 6 . F
Caution .................................................................... 2
. Disassembly and Assembly ..................................... 6 .
PREPARATION .......................................................... 3. DISASSEMBLY .................................................... 6 .
Special Service Tools (SST) .................................... 3 . INSPECTION AFTER DISASSEMBLY ................. 7 . G
Commercial Service Tools ....................................... 3 . ASSEMBLY .......................................................... 7
.
NOISE, VIBRATION AND HARSHNESS (NVH) INSPECTION AFTER ASSEMBLY ....................... 8 .
TROUBLESHOOTING ............................................... 4 . REAR DRIVE SHAFT ................................................ 9 .
H
NVH Troubleshooting Chart .................................... 4 . Removal and Installation ......................................... 9 .
WHEEL HUB ............................................................. 5
. REMOVAL ............................................................ 9
.
On-Vehicle Inspection and Service ......................... 5 . INSPECTION AFTER REMOVAL ........................ 9 .
WHEEL BEARING INSPECTION ........................ 5 . INSTALLATION .................................................... 9 . I
Removal and Installation ......................................... 5 . Disassembly and Assembly ................................... 10 .
REMOVAL ............................................................ 5
. DISASSEMBLY .................................................. 10 .
INSPECTION AFTER REMOVAL ........................ 6 . INSPECTION AFTER DISASSEMBLY ............... 11 . J
ASSEMBLY ........................................................ 12.
SERVICE DATA ....................................................... 15.
Wheel Bearing ....................................................... 15
.
K
Drive Shaft ............................................................. 15
.
Tightening Torque .................................................. 15
.
L
M
RAX-1
PRECAUTIONS
PRECAUTIONS PFP:00001
Caution EDS000WJ
Observe the following precautions when disassembling and servicing drive shaft.
q Perform work in a location which is as dust-free as possible.
q Before disassembling and servicing, clean the outside of parts.
q Prevention of the entry of foreign objects must be taken into account during disassembly of the service
location.
q Disassembled parts must be carefully reassembled in the correct order. If work is interrupted, a clean
cover must be placed over parts.
q Paper shop cloths must be used. Fabric shop cloths must not be used because of the danger of lint adher-
ing to parts.
q Disassembled parts (except for rubber parts) should be cleaned with kerosene which shall be removed by
blowing with air or wiping with paper shop cloths.
RAX-2
PREPARATION
PREPARATION PFP:00002
A
Special Service Tools (SST) EDS000WK
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
B
(Kent-Moore No.) Description
Tool name
C
ST3322 0000
( -- ) q Removing wheel hub
Drift q Removing wheel bearing outer side inner RAX
a: 32 mm (1.26 in) dia. race
b: 21 mm (0.83 in) dia.
ZZA0539D
E
ST3325 1000 F
( -- ) q Installing wheel hub
Drift
G
ZZA0982D
ST3530 0000 H
( -- )
Drift Installing wheel hub
a: 45 mm (1.77 in) dia.
b: 59 mm (2.32 in) dia. I
ZZA0881D
J
KV381 00500
( -- )
Drift Installing drive shaft plug
a: 80 mm (3.15 in) dia K
b: 60 mm (2.36 in) dia
ZZA0701D
L
KV381 02200
( -- )
Drift Installing drive shaft plug M
a: 90 mm (3.54 in) dia
b: 31 mm (1.22 in) dia
ZZA0920D
Commercial Service Tools EDS000WL
Tool name Description
q Removing wheel nuts
Power tool
q Removing brake caliper assembly
PBIC0190E
RAX-3
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003
NVH Troubleshooting Chart EDS000WM
Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
Refer to DRIVE SHAFT in this chart.
Refer to REAR AXLE in this chart.
NVH in FAX and FSU sections.
NVH in RFD section.
NVH in WT section.
NVH in WT section.
NVH in BR section.
NVH in PR section.
NVH in PS section.
RAX-11
RAX-5
--
--
--
Reference page
FRONT AXLE AND FRONT SUSPENSION
Improper installation, looseness
Joint sliding resistance
Possible cause and SUSPECTED PARTS
PROPELLER SHAFT
Excessive joint angle
Parts interference
DIFFERENTIAL
ROAD WHEEL
DRIVE SHAFT
REAR AXLE
STEERING
Imbalance
BRAKES
TIRES
