Image preview - the first page of the document
>> Download pb documenatation <<
Text preview - extract from the document
PARKING BRAKE SYSTEM
F BRAKES
A
SECTION
PARKING BRAKE SYSTEM
PB B
C
D
E
CONTENTS
PRECAUTIONS ......................................................... 2
. Components ............................................................ 4
. PB
Precautions for Supplemental Restraint System Removal and Installation ......................................... 4
.
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN- REMOVAL ............................................................ 4
.
SIONER" ................................................................. 2
. INSTALLATION .................................................... 5
. G
PARKING BRAKE SYSTEM ..................................... 3 . PARKING BRAKE SHOE .......................................... 6 .
On-Vehicle Service .................................................. 3
. Components ............................................................ 6
.
PEDAL STROKE .................................................. 3 . Removal and Installation ......................................... 6
.
H
INSPECT COMPONENTS ................................... 3 . REMOVAL ............................................................ 6
.
ADJUSTMENT ..................................................... 3. INSPECTION AFTER REMOVAL ........................ 7 .
PARKING BRAKE CONTROL .................................. 4 . INSTALLATION .................................................... 7
.
SERVICE DATA AND SPECIFICATIONS (SDS) ....... 9 . I
Parking Drum Brake ................................................ 9
.
Parking Brake Control ............................................. 9
.
J
K
L
M
Edition; 2004 May PB-1 2005 Q45
PRECAUTIONS
PRECAUTIONS PFP:00001
Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER" EFS005AS
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
q To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
q Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
q Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Edition; 2004 May PB-2 2005 Q45
PARKING BRAKE SYSTEM
PARKING BRAKE SYSTEM PFP:36010
A
On-Vehicle Service EFS004XM
PEDAL STROKE
q While depressing parking brake pedal to the specified force, B
make sure that pedal stroke is within the range of specified
stroke (number of notches).
Number of notches : 4-5 C
q Make sure that brake warning lamp comes on when parking
brake pedal is depressed in one notch.
D
SBR695A
E
INSPECT COMPONENTS
Check the following:
q Device assembly for bend, damage, and cracks. Replace there are. PB
q Cable and equalizer for wear and damage.
q Brake warning lamp switch. Refer to BRC-55, "PARKING BRAKE SWITCH" .
G
q Each part for deformation, or damage by contact with other parts. Replace there are.
ADJUSTMENT
1. Insert a deep socket wrench to rotate adjusting nut to loosen H
cable sufficiently. Then, after returning pedal completely, adjust
the clearance of rear shoes.
2. Remove tires. I
3. Using a wheel nut, secure disc rotor to hub preventing it from tilt-
ing.
J
SBR051C K
4. Remove adjuster hole plug installed on disc rotor. Using a flat-
bladed screwdriver, turn adjuster to clockwise in the figure until L
disc rotor is locked. After locking, turn adjuster to opposite direc-
tion by 5 or 6 notches.
5. Rotate disc rotor to make sure that there is no drag. Then install
adjuster hole plug. M
6. After adjusting the clearance of rear shoes, with no drag on rear
brake, adjust cable as follows:
a. Operate pedal 10 or more times with a force of 294 N (30 kg, 66
lb).
SBR046C
b. Depress pedal until a deep socket wrench can be inserted.
Insert deep socket, and rotate adjusting nut to adjust pedal stroke. Refer to PB-3, "PEDAL STROKE" .
CAUTION:
Do not reuse adjusting nut after removing it.
c. After operating pedal 3 to 4 times with a force of 196 N (20 kg, 44 lb), make sure that pedal stroke is within
specified value.
d. With brake pedal completely returned, make sure that there is no drag on rear brake.
Edition; 2004 May PB-3 2005 Q45
PARKING BRAKE CONTROL
PARKING BRAKE CONTROL PFP:36010
Components EFS004XN
SFIA2499E
1. Device assembly 2. Return spring 3. Brake warning lamp switch
4. Adjusting nut 5. Front cable 6. Lock plate
7. Return spring 8. RH rear cable 9. LH rear cable
10. Pin
Removal and Installation EFS004XO
REMOVAL
1. Remove center console. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove adjusting nut from device assembly.
3. Remove lock plate.
4. Disconnect the brake warning lamp connector.
5. Remove center muffler. Refer to EX-3, "Removal and Installation" .
6. Remove heat insulator of the three way catalyst and center muffler from vehicle.
7. Remove propeller shaft. Refer to PR-5, "Removal and Installation" .
8. Remove rear disc caliper and disc rotor. Refer to BR-32, "Disassembly and Assembly of Brake Caliper
Assembly" .
9. Remove parking brake shoe, and remove rear cable from toggle lever. Refer to PB-6, "Removal and
Installation" .
10. Remove the rear cable mounting bolts and nuts.
11. Remove right and left rear cable from vehicle.
12. Remove diagnosis sensor unit with sensor mount bracket. Refer to SRS-51, "Removal and Installation" .
Edition; 2004 May PB-4 2005 Q45
PARKING BRAKE CONTROL
13. Remove the front cable mounting bolts and nuts, and remove front cable from vehicle.
14. Remove mounting nuts of device assembly, and remove device assembly from vehicle. A
INSTALLATION
1. Install in the reverse order of the removal. Tighten the mounting bolts and nuts to the specified torque.
B
Refer to PB-4, "Components" .
CAUTION:
Do not reuse adjusting nut of front cable.
C
2. Adjust parking brake pedal stroke. Refer to PB-3, "ADJUSTMENT" .
D
E
PB
G
H
I
J
K
L
M
Edition; 2004 May PB-5 2005 Q45
PARKING BRAKE SHOE
PARKING BRAKE SHOE PFP:44060
Components EFS004XP
SFIA2282E
1. Toggle lever 2. Anti-rattle pin 3. Retainer
4. Anti-rattle spring 5. Return spring 6. Adjuster spring
7. Adjuster assembly 8. Shoe
Removal and Installation EFS004XQ
REMOVAL
WARNING:
Clean brakes with a vacuum dust collector to minimize a hazard of airborne particles or other materi-
als.
CAUTION:
q Remove wheel, and remove disc rotor with parking brake pedal completely released. Refer to BR-
32, "Disassembly and Assembly of Brake Caliper Assembly" .
q When removing disc rotor, mark both disc rotor and wheel hub for alignment.
q If disc rotor cannot be removed, remove as follows:
1. Remove rear tires from vehicle with a power tool.
2. Remove the disc rotor with the parking brake pedal in the completely released position.
3. If disc rotor cannot be removed, remove as follows:
a. Secure the disc rotor in place with wheel nuts and remove adjuster hole plug.
Edition; 2004 May PB-6 2005 Q45
PARKING BRAKE SHOE
b. Using flat-bladed screwdriver, rotate adjuster in direction "B" to
retract and loosen brake shoe. A
4. Remove anti-rattle pins, retainers, anti-rattle springs, then return
springs.
5. Remove parking brake shoes, adjuster assembly, adjuster B
spring and toggle lever.
C
PFIA0309E
D
INSPECTION AFTER REMOVAL
Shoe Thickness Inspection
q Check thickness of lining. E
Standard thickness (A) : 3.2 mm (0.126 in)
Repair limit thickness (A) : 1.5 mm (0.059 in)
PB
G
SBR021A H
Drum Inner Diameter Inspection
q Check drum inner diameter.
I
Standard inner diameter : 172.0 mm (6.77 in)
Maximum inner diameter : 173.0 mm (6.81 in)
J
K
SBR768A
L
Other Inspections
q Check the following:
