Image preview - the first page of the document
rsu

>> Download rsu documenatation <<

Text preview - extract from the document

REAR SUSPENSION

E SUSPENSION

SECTION RSU
REAR SUSPENSION
B

RSU
CONTENTS
PRECAUTIONS ......................................................... 2. RADIUS ROD ........................................................... 13. F
Cautions .................................................................. 2
. Removal and Installation ....................................... 13 .
PREPARATION .......................................................... 3
. REMOVAL .......................................................... 13 .
Special Service Tools .............................................. 3. INSPECTION AFTER REMOVAL ...................... 13 . G
Commercial Service Tools ....................................... 3 . INSTALLATION .................................................. 13 .
NOISE, VIBRATION AND HARSHNESS (NVH) FRONT LOWER LINK ............................................. 14 .
TROUBLESHOOTING ............................................... 4 . Removal and Installation ....................................... 14 .
H
NVH Troubleshooting Chart .................................... 4 . REMOVAL .......................................................... 14 .
REAR SUSPENSION ASSEMBLY ............................ 5 . INSPECTION AFTER REMOVAL ...................... 14 .
Components ............................................................ 5
. INSTALLATION .................................................. 14 .
On-Vehicle Inspection and Service ......................... 6 . REAR LOWER LINK & COIL SPRING .................... 15 . I
INSPECTION OF BALL JOINT END PLAY ......... 6 . Removal and Installation ....................................... 15 .
SHOCK ABSORBER INSPECTION .................... 6 . REMOVAL .......................................................... 15 .
Wheel Alignment Inspection .................................... 6 . INSPECTION AFTER REMOVAL ...................... 15 . J
DESCRIPTION ..................................................... 6 . INSTALLATION .................................................. 15 .
PRELIMINARY INSPECTION .............................. 6 . STABILIZER BAR .................................................... 16 .
CAMBER INSPECTION ....................................... 7 . Removal and Installation ....................................... 16 .
K
TOE-IN ................................................................. 7
. REMOVAL .......................................................... 16 .
SHOCK ABSORBER ................................................. 9 . INSPECTION AFTER REMOVAL ...................... 16 .
Removal and Installation ......................................... 9 . INSTALLATION .................................................. 16 .
REMOVAL ............................................................ 9
. REAR SUSPENSION MEMBER .............................. 17 . L
INSPECTION AFTER REMOVAL ........................ 9 . Removal and Installation ....................................... 17 .
INSTALLATION .................................................... 9 . REMOVAL .......................................................... 17 .
Disassembly and Assembly .................................... 9 . INSPECTION AFTER REMOVAL ...................... 17 . M
DISASSEMBLY .................................................... 9 . INSTALLATION .................................................. 17 .
INSPECTION AFTER DISASSEMBLY .............. 10 . SERVICE DATA ....................................................... 18 .
ASSEMBLY ........................................................ 10. Wheel Alignment ................................................... 18 .
SUSPENSION ARM .................................................11 . Ball Joint ................................................................ 18
.
Removal and Installation ........................................11 . Wheelarch Height (Unladen*) ................................ 18 .
REMOVAL ...........................................................11
.
INSPECTION AFTER REMOVAL .......................11 .
INSTALLATION .................................................. 12 .

Revision: 2004 April RSU-1 2002 Q45
PRECAUTIONS

PRECAUTIONS PFP:00001

Cautions EES000T4

q When installing bushings, final tightening must be carried out under unladen condition with tires on level
ground. Oil will shorten the life of rubber bushings. Be sure to wipe off any spilled oil.
q Unladen condition means that fuel, coolant and lubricant are full. However spare tire, jack, and hand tools
should be unloaded.
q After servicing suspension parts, be sure to check wheel alignment.
q Caulking nuts are not reusable. Always use new ones when installing. Since new caulking nuts are pre-
oiled tighten as they are.

Revision: 2004 April RSU-2 2002 Q45
PREPARATION

PREPARATION PFP:00002
A
Special Service Tools EES000TL

The actual shapes of Kent-Moore tools may differ from those of specified service tools illustrated here.
Tool number B
(Kent-Moore No.) Description
Tool name
C

ST3127 S000
Measurement ball joint of sliding torque D
( -- )

ZZA0806D
RSU
Commercial Service Tools EES000T5

Tool name Description
F

q Removing wheel nuts G
Power tool
q Removing stabilizer assembly

PBIC0190E
H

Revision: 2004 April RSU-3 2002 Q45
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING PFP:00003

NVH Troubleshooting Chart EES000T6

Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.

NVH in FAX and FSU sections.
NVH in RFD section.

NVH in RAX section.
NVH in WT section.

NVH in WT section.
RSU-16

NVH in PR section.

NVH in BR section.

NVH in PS section.
RSU-5

RSU-9

RSU-5

RSU-6
--

--
Reference page

Shock absorber defamation, damage or deflection

FRONT AXLE AND FRONT SUSPENSION
Bushing or mounting deterioration
Improper installation, looseness

Incorrect wheel alignment
Possible cause and SUSPECTED PARTS

Suspension looseness

PROPELLER SHAFT
Parts interference

Stabilizer fatigue

ROAD WHEEL
DIFFERENTIAL

DRIVE SHAFT
Spring fatigue

STEERING
BRAKES
TIRES
Noise
