Image preview - the first page of the document
gw


>> Download gw documenatation <<

Text preview - extract from the document
I BODY

                                                                                                                                                                A




                            GLASSES, WINDOW SYSTEM & MIRRORS
                                                                                       SECTION                     GW                                           B



                                                                                                                                                                C



                                                                                                                                                                D



                                                                                                                                                                E
                                                                CONTENTS
PRECAUTIONS ......................................................... 3
                                                                      .           AUTO OPERATION ............................................ 18       .        F
 Precautions for Supplemental Restraint System                                    POWER WINDOW SERIAL LINK ...................... 18                   .
 (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                          POWER WINDOW LOCK .................................. 18              .
 SIONER" ................................................................. 3
                                                                      .           RETAINED POWER OPERATION ..................... 18                    .        G
 Handling for Adhesive and Primer .......................... 3        .           ANTI-PINCH SYSTEM ....................................... 18         .
 Trouble Diagnosis Precaution ................................. 3     .           POWER WINDOW CONTROL BY THE FRONT
PREPARATION .......................................................... 4
                                                                      .           DOOR LOCK ASSEMBLY LH (KEY CYLINDER
                                                                                                                                                                H
 Special Service Tool ................................................ 4
                                                                      .           SWITCH) ............................................................ 19
                                                                                                                                                       .
 Commercial Service Tool ........................................ 4   .         CAN Communication System Description ............. 19                  .
SQUEAK AND RATTLE TROUBLE DIAGNOSES..... 5                                      Schematic .............................................................. 20
                                                                                                                                                       .
 Work Flow ............................................................... 5
                                                                      .         Wiring Diagram -- WINDOW -- ............................ 22            .        GW
   CUSTOMER INTERVIEW .................................... 5          .         Terminal and Reference Value for Main Power Win-
   DUPLICATE THE NOISE AND TEST DRIVE ...... 6                        .         dow and Door Lock/Unlock Switch ........................ 30            .
   CHECK RELATED SERVICE BULLETINS .......... 6                       .         Terminal and Reference Value for Power Window                                   J
   LOCATE THE NOISE AND IDENTIFY THE                                            and Door Lock/Unlock Switch RH ......................... 30            .
   ROOT CAUSE ..................................................... 6 .         Terminal and Reference Value for BCM ................ 32               .
   REPAIR THE CAUSE .......................................... 6      .         Work Flow .............................................................. 33
                                                                                                                                                       .
                                                                                                                                                                K
   CONFIRM THE REPAIR ...................................... 7        .         CONSULT-II Function (BCM) ................................ 33          .
 Generic Squeak and Rattle Troubleshooting .......... 7               .           CONSULT-II INSPECTION PROCEDURE ......... 33                         .
   INSTRUMENT PANEL ......................................... 7       .           ACTIVE TEST .................................................... 34  .
   CENTER CONSOLE ............................................ 7      .           WORK SUPPORT .............................................. 34       .        L
   DOORS ................................................................ 7
                                                                      .           DATA MONITOR ................................................ 34     .
   TRUNK ................................................................. 8
                                                                      .         Trouble Diagnoses Symptom Chart ...................... 35              .
   SUNROOF/HEADLINER ...................................... 8         .         BCM Power Supply and Ground Circuit Check ..... 37                     .        M
   OVERHEAD CONSOLE (FRONT AND REAR)..... 8                                     Main Power Window and Door Lock/Unlock Switch
   SEATS .................................................................. 8
                                                                      .         Power Supply and Ground Circuit Check .............. 38                .
   UNDERHOOD ...................................................... 8 .         Power Window and Door Lock/Unlock Switch RH
 Diagnostic Worksheet ............................................. 9 .         Power Supply and Ground Circuit Check .............. 39                .
WINDSHIELD GLASS ..............................................11     .         Front Power Window Motor LH Circuit Check ....... 40                   .
 Removal and Installation ........................................11  .         Front Power Window Motor RH Circuit Check ...... 41                    .
   REMOVAL ...........................................................11
                                                                      .         Limit Switch Circuit Check Front LH ...................... 42          .
   INSTALLATION ...................................................11 .         Limit Switch Circuit Check Front RH ..................... 43           .
REAR WINDOW GLASS AND MOLDING .............. 13                       .         Encoder Circuit Check Front LH ............................ 45         .
 Removal and Installation ....................................... 13  .         Encoder Circuit Check Front RH ........................... 47          .
   REMOVAL .......................................................... 13
                                                                      .         Door Switch Check ................................................ 49  .
   INSTALLATION .................................................. 14 .         Front Door Lock Assembly LH (Key Cylinder Switch)
POWER WINDOW SYSTEM ................................... 15            .         Check .................................................................... 51
                                                                                                                                                       .
 Component Parts and Harness Connector Location 15                    ...       Power Window Serial Link Check Front LH and RH 53                      ...
 System Description ............................................... 15.         Rear Power Window Control Unit LH or RH Power
   MANUAL OPERATION ...................................... 16         .         Supply and Ground Circuit Check ......................... 55           .


Revision: October 2005                                                    GW-1                                                               2005 QX56
  Rear Power Window Switch LH or RH Power Supply                             System Description ................................................77.
  and Ground Circuit Check ..................................... 57.         CAN Communication System Description .............78                 .
  Rear Power Window Motor LH Circuit Check ........ 57             .         Schematic ..............................................................79
                                                                                                                                                  .
  Rear Power Window Motor RH Circuit Check ....... 58              .         Wiring Diagram -- DEF -- .....................................80     .
  Limit Switch Circuit Check Rear LH and RH .......... 59          .         Terminal and Reference Value for BCM .................83             .
  Encoder Circuit Check Rear LH or RH .................. 61        .         Terminal and Reference Value for IPDM E/R .........83                .
  Power Window Serial Link Check Rear LH or RH... 63                         Work Flow ..............................................................83
                                                                                                                                                  .
  Rear Power Vent Window Switch Circuit Check .... 64              .         CONSULT-II Function (BCM) .................................84        .
  Rear Power Vent Window Motor LH Circuit Check... 64                          CONSULT-II BASIC OPERATION PROCEDURE
  Rear Power Vent Window Motor RH Circuit Check 65                 ...                                                                            ...84
  Rear Power Vent Window Relay (OPEN) Check ... 65                             DATA MONITOR .................................................85   .
  Rear Power Vent Window Relay (CLOSE) Check... 66                             ACTIVE TEST .....................................................85.
FRONT DOOR GLASS AND REGULATOR ............ 68                     .         Trouble Diagnoses Symptom Chart .......................85            .
  Removal and Installation ....................................... 68
                                                                   .         BCM Power Supply and Ground Circuit Check .....87                    .
    FRONT DOOR GLASS ...................................... 68     .         Rear Window Defogger Switch Circuit Check ........88                 .
    FRONT DOOR GLASS REGULATOR ............... 69                  .         Rear Window Defogger Circuit Check ...................89             .
    SETTING AFTER INSTALLATION ..................... 69            .         Door Mirror Defogger Power Supply Circuit Check...90
REAR DOOR GLASS AND REGULATOR .............. 71                    .         Door Mirror LH Defogger Circuit Check .................92            .
  Removal and Installation ....................................... 71
                                                                   .         Door Mirror RH Defogger Circuit Check ................93             .
    REAR DOOR GLASS ......................................... 71   .         Rear Window Defogger Signal Check ...................94              .
    REAR DOOR GLASS REGULATOR .................. 72                .         Filament Check ......................................................94
                                                                                                                                                  .
SIDE WINDOW GLASS ........................................... 74   .         Filament Repair ......................................................95
                                                                                                                                                  .
  Removal and Installation ....................................... 74
                                                                   .           REPAIR EQUIPMENT ........................................95        .
    REMOVAL .......................................................... 74
                                                                   .           REPAIRING PROCEDURE ................................95             .
    INSTALLATION ................................................... 74
                                                                   .        DOOR MIRROR ........................................................97.
INSIDE MIRROR ...................................................... 75
                                                                   .         Door Mirror Assembly ............................................97  .
  Wiring Diagram -- I/MIRR -- ................................ 75  .           REMOVAL ...........................................................97
                                                                                                                                                  .
  Removal and Installation ....................................... 76
                                                                   .           INSTALLATION ...................................................97 .
    INSIDE MIRROR ................................................ 76
                                                                   .         Door Mirror Glass ...................................................97
                                                                                                                                                  .
REAR WINDOW DEFOGGER ................................. 77          .           REMOVAL ...........................................................97
                                                                                                                                                  .
  Component Parts and Harness Connector Location 77                ...         INSTALLATION ...................................................98 .




Revision: October 2005                                                GW-2                                                              2005 QX56
                                              PRECAUTIONS

PRECAUTIONS                                                         PFP:00001
                                                                                                                          A
Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER"                                                                                            EIS004TI


The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along                             B
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front               C
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:                                                                                                                  D
G    To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
     in the event of a collision which would result in air bag inflation, all maintenance must be per-
     formed by an authorized NISSAN/INFINITI dealer.                                                                      E
G    Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
     sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
     Bag Module, see the SRS section.                                                                                     F
G    Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
     Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
     harness connectors.
                                                                                                                          G
Handling for Adhesive and Primer                                                                              EIS004TJ


G   Do not use an adhesive which is past its usable date. Shelf life of this product is limited to six months after
    the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box.              H
G   Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
G   Open the seal of the primer and adhesive just before application. Discard the remainder.
                                                                                                                    GW
G   Before application, be sure to shake the primer container to stir the contents. If any floating material is
    found, do not use it.
G   If any primer or adhesive contacts the skin, wipe it off with gasoline or equivalent and wash the skin with
                                                                                                                     J
    soap.
G   When using primer and adhesive, always observe the precautions in the instruction manual.
Trouble Diagnosis Precaution                                                                                  EIS004TK    K
When you read wiring diagrams, refer to the following:
G  GI-15, "How to Read Wiring Diagrams".
                                                                                                                          L
G  PG-4, "POWER SUPPLY ROUTING CIRCUIT".
When you perform trouble diagnosis, refer to the following:
G  GI-11, "HOW TO FOLLOW TEST GROUPS IN TROUBLE DIAGNOSES".                                                               M
G  GI-27, "How to Perform Efficient Diagnosis for an Electrical Incident".
Check for any service bulletins before servicing the vehicle.




Revision: October 2005                               GW-3                                               2005 QX56
                                             PREPARATION

PREPARATION                                                                                              PFP:00002

Special Service Tool                                                                                         EIS004TL


The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
    Tool number                                                        Description
    (Kent-Moore No.)
    Tool name
      --                                                               Locating the noise
    (J-39570)
    Chassis ear




                                                       SIIA0993E




       --                                                              Repairing the cause of noise
    (J-43980)
    NISSAN Squeak and Rat-
    tle Kit



                                                       SIIA0994E




Commercial Service Tool                                                                                     EIS004TM


    (Kent-Moore No.)                                                   Description
    Tool name
    (J-39565)                                                          Locating the noise
    Engine ear




                                                       SIIA0995E




    (    --      )                                                     Holding door glass
    Suction Lifter




                                                       LIIA1991E




Revision: October 2005                             GW-4                                               2005 QX56
                       SQUEAK AND RATTLE TROUBLE DIAGNOSES

SQUEAK AND RATTLE TROUBLE DIAGNOSES                                                                       PFP:00000
                                                                                                                         A
Work Flow                                                                                                     EIS004TN




                                                                                                                         B



                                                                                                                         C



                                                                                                                         D



                                                                                                                         E



                                                                                                                         F



                                                                                                           SBT842
                                                                                                                         G

CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diag- H
nostic Worksheet during the interview to document the facts and conditions when the noise occurs and any
customer's comments; refer to GW-9, "Diagnostic Worksheet" . This information is necessary to duplicate the
conditions that exist when the noise occurs.
                                                                                                                       GW
G    The customer may not be able to provide a detailed description or the location of the noise. Attempt to
     obtain all the facts and conditions that exist when the noise occurs (or does not occur).
G    If there is more than one noise in the vehicle, be sure to diagnose and repair the noise that the customer
                                                                                                                        J
     is concerned about. This can be accomplished by test driving the vehicle with the customer.
G    After identifying the type of noise, isolate the noise in terms of its characteristics. The noise characteristics
     are provided so the customer, service adviser and technician are all speaking the same language when
     defining the noise.                                                                                                K
G    Squeak --(Like tennis shoes on a clean floor)
     Squeak characteristics include the light contact/fast movement/brought on by road conditions/hard sur-
     faces = higher pitch noise/softer surfaces = lower pitch noises/edge to surface = chirping.                        L
G    Creak--(Like walking on an old wooden floor)
     Creak characteristics include firm contact/slow movement/twisting with a rotational movement/pitch
     dependent on materials/often brought on by activity.                                                               M
G    Rattle--(Like shaking a baby rattle)
     Rattle characteristics include the fast repeated contact/vibration or similar movement/loose parts/missing
     clip or fastener/incorrect clearance.
G    Knock --(Like a knock on a door)
     Knock characteristics include hollow sounding/sometimes repeating/often brought on by driver action.
G    Tick--(Like a clock second hand)
     Tick characteristics include gentle contacting of light materials/loose components/can be caused by driver
     action or road conditions.
G    Thump--(Heavy, muffled knock noise)
     Thump characteristics include softer knock/dead sound often brought on by activity.
G    Buzz--(Like a bumble bee)
     Buzz characteristics include high frequency rattle/firm contact.
G    Often the degree of acceptable noise level will vary depending upon the person. A noise that you may
     judge as acceptable may be very irritating to the customer.
G    Weather conditions, especially humidity and temperature, may have a great effect on noise level.


Revision: October 2005                               GW-5                                              2005 QX56
                       SQUEAK AND RATTLE TROUBLE DIAGNOSES

DUPLICATE THE NOISE AND TEST DRIVE
If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on
the Diagnostic Worksheet regarding the conditions or location of the noise. This information can be used to
duplicate the same conditions when you confirm the repair.
If the noise can be duplicated easily during the test drive, to help identify the source of the noise, try to dupli-
cate the noise with the vehicle stopped by doing one or all of the following:
1) Close a door.
2) Tap or push/pull around the area where the noise appears to be coming from.
3) Rev the engine.
4) Use a floor jack to recreate vehicle "twist".
5) At idle, apply engine load (electrical load, half-clutch on M/T model, drive position on A/T model).
6) Raise the vehicle on a hoist and hit a tire with a rubber hammer.
G    Drive the vehicle and attempt to duplicate the conditions the customer states exist when the noise occurs.
G    If it is difficult to duplicate the noise, drive the vehicle slowly on an undulating or rough road to stress the
     vehicle body.
CHECK RELATED SERVICE BULLETINS
After verifying the customer concern or symptom, check ASIST for Technical Service Bulletins (TSBs) related
to that concern or symptom.
If a TSB relates to the symptom, follow the procedure to repair the noise.
LOCATE THE NOISE AND IDENTIFY THE ROOT CAUSE
1.   Narrow down the noise to a general area.To help pinpoint the source of the noise, use a listening tool
     (Chassis Ear: J-39570, Engine Ear: J-39565 and mechanic's stethoscope).
2.   Narrow down the noise to a more specific area and identify the cause of the noise by:
G    removing the components in the area that you suspect the noise is coming from.
     Do not use too much force when removing clips and fasteners, otherwise clips and fasteners can be bro-
     ken or lost during the repair, resulting in the creation of new noise.
G    tapping or pushing/pulling the component that you suspect is causing the noise.
     Do not tap or push/pull the component with excessive force, otherwise the noise will be eliminated only
     temporarily.
G    feeling for a vibration with your hand by touching the component(s) that you suspect is (are) causing the
     noise.
G    placing a piece of paper between components that you suspect are causing the noise.
G    looking for loose components and contact marks.
     Refer to GW-7, "Generic Squeak and Rattle Troubleshooting" .
REPAIR THE CAUSE
G   If the cause is a loose component, tighten the component securely.
G   If the cause is insufficient clearance between components:



◦ Jabse Service Manual Search 2024 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
