Image preview - the first page of the document



>> Download EXJ_19 documenatation <<

Text preview - extract from the document

XJ                                                                                                        STEERING        19 - 1



                                                      STEERING
                                                        CONTENTS

                                                          page                                                              page

POWER STEERING . . . . . . . . . . . . . . . . . . . . . . . . 1   STEERING LINKAGE . . . . . . . . . . . . . . . . . . . . . . 23
POWER STEERING PUMP . . . . . . . . . . . . . . . . . . 5          STEERING COLUMN . . . . . . . . . . . . . . . . . . . . . . 27
POWER STEERING GEAR . . . . . . . . . . . . . . . . . . 11



                                             POWER STEERING

                                                              INDEX
                                                          page                                                              page

GENERAL INFORMATION                                                DIAGNOSIS AND TESTING
 STEERING SYSTEM . . . . . . . . . . . . . . . . . . . . . . 1       POWER STEERING SYSTEM
                                                                      DIAGNOSIS CHARTS . . . . . . . . . . . . . . . . . . . . 2

GENERAL INFORMATION
STEERING SYSTEM
  The power steering system has a hydraulic pump.
The pump is a constant flow rate and displacement ,
vane-type pump. The pump on the 4.0L engine has a
reservoir mounted to it (Fig. 1). The 2.5L engine has
a remote mounted reservoir.
  The steering gear used is a recirculating ball type
gear. The gear acts as a rolling thread between the
worm shaft and the rack piston. When the steering
wheel is turned the worm shaft turns which moves
the rack piston. The rack piston movement turns the
pitman shaft which is connected to the steering link-
age by the pitman arm. This gear is used on all mod-
els.
  The power steering system consists of:
