Image preview - the first page of the document



>> Download EXJ_13A documenatation <<

Text preview - extract from the document

XJ                                                                                            FRAME AND BUMPERS        13 - 1



                                              FRAME AND BUMPERS
                                                                CONTENTS

                                                                  page                                                  page

FRAME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2   SWING AWAY SPARE TIRE CARRIER . . . . . . . . . 1


                              SWING AWAY SPARE TIRE CARRIER

                                                                       INDEX
                                                                  page

DISASSEMBLY AND ASSEMBLY
  SWING AWAY SPARE TIRE CARRIER
   MOUNTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

DISASSEMBLY AND ASSEMBLY

SWING AWAY SPARE TIRE CARRIER MOUNTING




                                                   Fig. 1 Spare Tire Carrier Mounting
13 - 2    FRAME AND BUMPERS                                                                XJ


                                                   FRAME

                                                       INDEX
                                                   page

GENERAL INFORMATION
 EMERGENCY TOW EYES . . . . . . . . . . . . . . . . . . 2

GENERAL INFORMATION
EMERGENCY TOW EYES
  If your vehicle is equipped with emergency tow
eyes, one is mounted in the front and one in the rear.
  The front tow eye has two holes, the front hole is
for towing use only and the rear angled hole is for
shipping use only.

CAUTION: Do not use the angled hole for towing.
You could damage your vehicle.


WARNING: Stand clear of vehicles when pulling
with tow eyes. Tow straps and chains may break,
causing serious injury.


CAUTION: Tow eyes are for emergency use only, to
rescue a vehicle stranded off road. Do not use tow
eyes for tow truck hookup or highway towing. You
could damage your vehicle.
                                                               Fig. 1 Emergency Tow Eyes
