Image preview - the first page of the document



>> Download EXJ_8EA documenatation <<

Text preview - extract from the document

XJ                                                                  INSTRUMENT PANEL SYSTEMS               8E - 1



                          INSTRUMENT PANEL SYSTEMS
                                               CONTENTS

                                                 page                                                       page

REMOVAL AND INSTALLATION                                  REAR FOG LAMP SWITCH . . . . . . . . . . . . . . . . . 1
 HEADLAMP LEVELING SWITCH . . . . . . . . . . . . . 1

REMOVAL AND INSTALLATION                                   (5) Depress switch mounting tabs to remove switch
                                                         from bezel.
HEADLAMP LEVELING SWITCH
                                                         REAR FOG LAMP SWITCH
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, REFER TO GROUP 8M - PASSIVE                        WARNING: ON VEHICLES EQUIPPED WITH AIR-
RESTRAINT SYSTEMS BEFORE ATTEMPTING ANY                  BAGS, REFER TO GROUP 8M - PASSIVE
STEERING WHEEL, STEERING COLUMN, OR                      RESTRAINT SYSTEMS BEFORE ATTEMPTING ANY
INSTRUMENT PANEL COMPONENT DIAGNOSIS OR                  STEERING WHEEL, STEERING COLUMN, OR
SERVICE. FAILURE TO TAKE THE PROPER PRE-                 INSTRUMENT PANEL COMPONENT DIAGNOSIS OR
CAUTIONS COULD RESULT IN ACCIDENTAL AIR-                 SERVICE. FAILURE TO TAKE THE PROPER PRE-
BAG DEPLOYMENT AND POSSIBLE PERSONAL                     CAUTIONS COULD RESULT IN ACCIDENTAL AIR-
INJURY.                                                  BAG DEPLOYMENT AND POSSIBLE PERSONAL
                                                         INJURY.
   (1) Disconnect and isolate the battery negative
cable.                                                      (1) Disconnect and isolate the battery negative
   (2) Using a trim stick or another suitable wide       cable.
flat-bladed tool, gently pry the instrument panel cen-      (2) Using a trim stick or another suitable wide
ter bezel away from the instrument panel to release      flat-bladed tool, gently pry the instrument panel cen-
the six snap clip retainers (Fig. 1).                    ter bezel away from the instrument panel to release
                                                         the six snap clip retainers (Fig. 1).
                                                            (3) Remove the center bezel from the vehicle.
                                                            (4) Remove the three screws that secure the acces-
                                                         sory switch bezel to the instrument panel
                                                            (5) Pull the accessory switch bezel out from the
                                                         instrument panel far enough to unplug the wire har-
                                                         ness connectors (Fig. 2).




         Fig. 1 Center Bezel Remove/Install
                                                            Fig. 2 Accessory Switch Bezel Remove/Install
  (3) Disconnect the wiring harness from the switch.
  (4) Remove the center bezel from the vehicle.
8E - 2   INSTRUMENT PANEL SYSTEMS                                                                        XJ
REMOVAL AND INSTALLATION (Continued)
  (6) Remove the accessory switch bezel from the          (8) Reverse the removal procedures to install. Be
instrument panel.                                       certain that both of the switch snap retainers in the
  (7) Carefully pry the snap retainers at the top and   receptacle on the back of the accessory switch bezel
bottom of the rear fog lamp switch receptacle on the    are fully engaged. Tighten the mounting screws to
back of the accessory switch bezel with a small thin-   2.2 N
