Image preview - the first page of the document
exj_13a


>> Download exj_13a documenatation <<

Text preview - extract from the document
XJ                                                                                               FRAME AND BUMPERS          13 - 1



                                               FRAME AND BUMPERS
                                                        TABLE OF CONTENTS

                                                                    page

FRAME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1



                                                                    FRAME

                                                             TABLE OF CONTENTS
                                                                    page

DESCRIPTION AND OPERATION
 EMERGENCY TOW EYES . . . . . . . . . . . . . . . . . . . 1

DESCRIPTION AND OPERATION                                                       Some vehicles are equipped with emergency tow
                                                                              eyes, one can be found in the front and rear of the
EMERGENCY TOW EYES                                                            vehicle (Fig. 1). The tow eyes are attached to the
                                                                              frame rails and intended for short distance emer-
DESCRIPTION                                                                   gency towing only.

                                                                              OPERATION
                                                                                The front tow eye has two holes, the front hole is
                                                                              for short towing use only and the rear angled hole is
                                                                              for shipping use only.
                                                                                The rear tow eye has one hole and is intended for
                                                                              short towing use only.

                                                                              CAUTION: Do not use the angled hole for towing.
                                                                              You could damage your vehicle.


                                                                              CAUTION: Tow eyes are for emergency use only, to
                                                                              rescue a vehicle stranded off road. Do not use tow
                                                                              eyes for tow truck hookup or highway towing. You
                                                                              could damage your vehicle.


                                                                              WARNING: Stand clear of vehicles when pulling
                                                                              with tow eyes. Tow straps and chains may break,
                                                                              causing serious injury.


      Fig. 1 Front and Rear Emergency Tow Eyes
1
