Image preview - the first page of the document
exj_21a


>> Download exj_21a documenatation <<

Text preview - extract from the document
XJ                                                                              TRANSMISSION AND TRANSFER CASE                             21 - 1



                         TRANSMISSION AND TRANSFER CASE
                                                      TABLE OF CONTENTS

                                                                 page                                                                        page

NV3550 MANUAL TRANSMISSION . . . . . . . . . . . . 1                       NV231 TRANSFER CASE . . . . . . . . . . . . . . . . . . . . 5



                                NV3550 MANUAL TRANSMISSION

                                                           TABLE OF CONTENTS
                                                                 page                                                                        page

REMOVAL AND INSTALLATION                                                   SPECIFICATIONS
 TRANSMISSION - 2.5L TURBO DIESEL                                           TORQUE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
  ENGINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

REMOVAL AND INSTALLATION                                                     5. Remove exhaust pipe and heat shield.
                                                                             6. Mark the front and rear propeller shafts for
TRANSMISSION - 2.5L TURBO DIESEL ENGINE                                    installation alignment (Fig. 2).

REMOVAL
  1. Disconnect and isolate the negative battery
cable.
  2. Remove the floor console, shifter boot and
shifter. Refer to group 23, Body for the procedure.
  3. Raise the vehicle on a hoist.
  4. Drain the transmission fluid (Fig. 1).




                                                                                Fig. 2 Marking Propeller Shaft and Axle Yoke
                                                                           1
