Image preview - the first page of the document



>> Download exj_6a documenatation <<

Text preview - extract from the document

XJ                                                                                                                     CLUTCH          6-1



                                                            CLUTCH
                                                   TABLE OF CONTENTS

                                                             page                                                                      page

DESCRIPTION AND OPERATION                                               FLYWHEEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
 CLUTCH COMPONENTS . . . . . . . . . . . . . . . . . . . . 1            FLYWHEEL RING GEAR . . . . . . . . . . . . . . . . . . . . 7
 CLUTCH HYDRAULIC SYSTEM . . . . . . . . . . . . . . 1                 SPECIFICATIONS
REMOVAL AND INSTALLATION                                                SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . 8
 CLUTCH COVER AND DISC . . . . . . . . . . . . . . . . . 1             SPECIAL TOOLS
 PILOT BEARING . . . . . . . . . . . . . . . . . . . . . . . . . . 3    SPECIAL TOOLS . . . . . . . . . . . . . . . . . . . . . . . . . . 8

DESCRIPTION AND OPERATION
CLUTCH COMPONENTS
  The clutch mechanism consists of a single, dry-type
clutch disc and a diaphragm style clutch cover. A
hydraulic linkage is used to operate the clutch disc
and cover. The clutch components are very similar to
those used in gas engine models.
  A pilot bearing is used to support the transmission
input shaft. The bearing is seated in a separate,
removable housing bolted to the flywheel hub.

CLUTCH HYDRAULIC SYSTEM
  The clutch hydraulic system should not require
additional fluid under normal circumstances.

NOTE: The reservoir fluid level will actually
increase as normal clutch wear occurs. For this rea-
son, it is important to avoid over filling, or remov-
ing fluid from the reservoir.

  If inspection indicates additional fluid is needed,
add fluid from a sealed container only. Use Mopar                               Fig. 1 Clutch Cover (Pressure Plate) View
brake fluid, or an equivalent meeting standards SAE                    1
