Image preview - the first page of the document
>> Download exj_8j documenatation <<
Text preview - extract from the document
XJ TURN SIGNAL AND HAZARD WARNING SYSTEMS 8J - 1
TURN SIGNAL AND HAZARD WARNING SYSTEMS
TABLE OF CONTENTS
page page
DESCRIPTION AND OPERATION TURN SIGNAL SWITCH AND HAZARD
TURN SIGNAL SYSTEM . . . . . . . . . . . . . . . . . . . . 1 WARNING SWITCH . . . . . . . . . . . . . . . . . . . . . . 5
HAZARD WARNING SYSTEM. . . . . . . . . . . . . . . . 1 REMOVAL AND INSTALLATION
TURN SIGNAL SWITCH AND HAZARD COMBINATION FLASHER . . . . . . . . . . . . . . . . . . . 5
WARNING SWITCH . . . . . . . . . . . . . . . . . . . . . . 2 TURN SIGNAL SWITCH AND HAZARD
TURN SIGNAL CANCELLING CAM . . . . . . . . . . . . 3 WARNING SWITCH . . . . . . . . . . . . . . . . . . . . . . 6
COMBINATION FLASHER . . . . . . . . . . . . . . . . . . . 3
DIAGNOSIS AND TESTING
TURN SIGNAL AND HAZARD WARNING
SYSTEMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
DESCRIPTION AND OPERATION lamp and rear tail/stop/turn signal lamp to flash on
and off. If the exterior lamps are turned off, the front
TURN SIGNAL SYSTEM park/turn signal lamp and the front side marker
lamp will flash in unison. If the exterior lamps are
DESCRIPTION turned on, the front park/turn signal lamp and the
A turn signal system is standard factory-installed front side marker lamp will flash alternately.
safety equipment on this model. The turn signal sys- See the owner's manual in the vehicle glove box for
tem uses ignition switched battery current, and will more information on the features, use and operation
operate only when the ignition switch is in the On or of the turn signal system.
Accessory positions. The turn signal system includes
the following components: HAZARD WARNING SYSTEM
