Image preview - the first page of the document



>> Download CL-001 documenatation <<

Text preview - extract from the document

                                              CLUTCH PEDAL
CLUTCH PEDAL                             To ESM
On Board Inspection
HEIGHT INSPECTION
1.   Make sure clutch pedal height H1from upper surface of the dash
     panel is within the specified range.
        Pedal height H1
         : 160 - 169 mm (6.30 - 6.65 in)  (LHD with CR engine)
                                          (LHD K9K engine with-
                                          out charge air cooler)
          : 164 - 174 mm (6.46 - 6.85 in) (RHD with CR engine)
                                          (RHD K9K engine with-
                                          out charge air cooler)
          : 170 - 180 mm (6.69 - 7.09 in) (LHD K9K engine with
                                          charge air cooler)
          : 175 - 185 mm (6.89 - 7.23 in) (RHD K9K engine with
                                          charge air cooler)
2.   If pedal height H1is outside the specification, replace pedal
     assembly.
3.   Make sure free play A at pedal pad top surface and pedal height
     H2when clutch is disengaged are within the ranges specified
     below.
                                                                                                 SCIA1256E
        A: Pedal free play at the pedal pad
                 : 0.5 mm (0.02 in)
        Pedal height H2when clutch is disengaged
                 : 100 mm (3.94 in) or more (CR engine)
4.   If free play A at pedal pad top surface and pedal height H2when clutch is disengaged are outside the
     specification, replace clutch pedal assembly.
PLAY INSPECTION
q    Press the clutch pedal by hand until certain resistance can be
     felt. Using a scale, Make sure the free play is within the specified
     range.
        Pedal free play
          : 0.5 mm (0.02 in)




                                                                                                 MAA0023D


CLEARANCE CHECK
1.   Start the engine and let it idle.
2.   Apply parking brake.
3.   Depress the brake pedal.
4.   Fully depress clutch pedal and shift to 1st gear.
5.   Release clutch pedal gradually. Using a scale, check the clear-
     ance between the clutch pedal and floor panel to see if it is
     within the specified range.
        Pedal height when the clutch disengages
                 : 100 mm (3.94 in) or more (CR engine)                                          MAA0024D



                                                      CL-1
                                       CLUTCH PEDAL
NOTE:
Pedal height at clutch disengagement varies slightly from the clutch engagement point. Despite this, pedal
height at clutch engagement is commonly used for both cases in order to simplify the inspection.




                                               CL-2
                         SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)                                     To ESM
Clutch Pedal
                                                                                                                   Unit mm (in)
                                                                                              K9K
 Engine type                                     CR
                                                                  without charge air cooler         with charge air cooler
                    LHD models          160 - 169 (6.30 - 6.65)    160 - 169 (6.30 - 6.65)          170 - 180 (6.69 - 7.09)
 Pedal height
                    RHD models          164 - 174 (6.46 - 6.85)    164 - 174 (6.46 - 6.85)          175 - 185 (6.89 - 7.23)
 Pedal height at clutch disengagement    100 (3.94) or more                                   --
 Pedal free play                                                         0.5 (0.02)




                                                        CL-3
