Image preview - the first page of the document



>> Download EI-001 documenatation <<

Text preview - extract from the document

                                                 HEADLINER
HEADLINER
Removal and Installation                    To ESM




                                                                                                                 MIIB9100E

     1.   Headliner                2.   Sunvisor (LH)                        3.   Sunvisor (RH)
     4.   Sunvisor holder          5.   Room lamp (with map lamp function)   6.   Assist grip (passenger seat)

REMOVAL
1.   Remove front pillar garnish. Refer to EI-19, "BODY SIDE TRIM" in EI section on ESM.
2.   Remove back door weatherstrip.
3.   Remove luggage side upper finishers (LH/RH). Refer to EI-26, "LUGGAGE FLOOR TRIM" in EI section
     on ESM.
4.   Remove center pillar upper garnish (5-door vehicles) and lock pillar upper garnish (3-door vehicles). Refer
     to EI-19, "BODY SIDE TRIM" in EI section on ESM.
5.   Remove assist grip.
     NOTE:
     When removing assist grip, insert a thin screwdriver, etc., into
     the clip and move the clip outside.




                                                                                                                    MIIB0078E



6.   Remove sunvisors (LH/RH).
7.   Remove room lamp (with map lamp function). Refer to LT-229, "Removal and Installation" in LT section on
     ESM.



                                                        EI-1
                                               HEADLINER
8.   Remove sunvisor holder.
     NOTE:
     Insert a screwdriver into the cutout and rotate 90
