Image preview - the first page of the document



>> Download FAX-001 documenatation <<

Text preview - extract from the document

                                         FRONT DRIVE SHAFT
FRONT DRIVE SHAFT
Removal and Installation                             To ESM
FOR CR ENGINES:




                                                                                            MDIA0045E


FOR K9K ENGINES:




                                                                                            MDIA0075E


REMOVAL
1.   Lift up the vehicle and remove tire from the vehicle.
2.   Remove lock plate from strut. Disconnect brake hose from strut. Refer to BR-11, "BRAKE PIPING AND
     HOSE" on ESM.
3.   Remove the ABS wheel sensor from the steering knuckle. Refer to BRC-44, "WHEEL SENSORS" on
     ESM.
     CAUTION:
     Do not pull on ABS wheel sensor harness.




                                                    FAX-1
                                           FRONT DRIVE SHAFT
4.   Use a hub lock nut wrench (SST), remove lock nuts.
5.   Remove tie-rod from steering knuckle. If tie-rod is not easily
     removed, use ball joint remover (commercial service tool).
     CAUTION:
     To prevent damage to threads and to prevent ball joint
     remover (commercial service tool) from sudden coming off,
     temporarily fix lock nuts.
6.   Remove steering knuckle and strut installation bolt.
     CAUTION:
     Do not place drive shaft joint at an extreme angle (22
