Image preview - the first page of the document
>> Download IP-001 documenatation <<
Text preview - extract from the document
INSTRUMENT PANEL ASSEMBLY
INSTRUMENT PANEL ASSEMBLY
Component Parts Location To ESM
MIIB9102E
IP-1
INSTRUMENT PANEL ASSEMBLY
1. Passenger air bag module 2. Instrument mask 3. Upper instrument panel
4. Combination meter 5. Cluster lid "A" 6. Instrument side mask (RH)
7. Switch panel finisher 8. Instrument panel under tray 9. Side ventilator grille (RH)
10. Instrument finisher 11. Fuse block lid 12. Cluster lid C
13. Audio 14. Glove box striker 15. Instrument side mask (LH)
16. Side ventilator grille (LH) 17. Glove box cover assembly 18. Glove box lid
19. Tray 20. Air conditioner finisher 21. Steering column cover
22. Steering lock escutcheon 23. Instrument panel stay cover 24. Console box
25. Coin holder 26. Instrument panel & pad 27. Steering column protector
28. Central ventilator grille (LH) 29. Central ventilator grille (RH) 30. Console mask
Removal and Installation
WORK ITEM TABLE To ESM
Instrument
Reference
panel Instrument Upper instru- Combination Audio, Car-
Component Parts Location page (* : in
&Brake pad ment panel meter Wings unit
this SMA file)
pad
A. Front pillar garnish IP-2 * [1] [1] [1] [1] [1]
B. Upper instrument panel IP-3 * [2] [2] [2] [2] [2]
C. Steering lock escutcheon IP-3 * [3] [3]
D. Instrument panel under tray IP-3 * [4]
E. Switch panel finisher IP-3 * [5] [4]
F. Steering column cover IP-3 * [6] [5] [3]
G. Combination switch IP-3 * [7] [6]
H. Cluster lid "A" IP-4 * [8] [7] [4]
I. Combination meter IP-4 * [9] [8] [5]
J. Instrument finisher IP-4 * [ 10 ] [9] [3]
K. Cluster lid C and audio unit
IP-4 * [ 11 ] [ 10 ] [4]
assembly
L. Air conditioner finisher IP-4 * [ 12 ]
M. Instrument panel stay
IP-5 * [ 13 ]
cover
N. Glove box lid IP-5 * [ 14 ] [ 11 ]
O. Glove box cover assembly IP-5 * [ 15 ] [ 12 ]
P. Side ventilator grille IP-5 * [ 16 ] [ 13 ]
Q. Instrument side mask IP-5 * [ 17 ] [ 14 ]
R. Passenger seat air bag
IP-5 * [ 18 ] [ 15 ]
module
S. Steering wheel IP-5 * [ 19 ]
T. Instrument panel & pad IP-6 * [ 20 ]
U. Instrument pad IP-6 * [ 16 ]
[ ]: The number shows the removal order.
REMOVAL
A. Front Pillar Garnish
Refer to EI-19 "BODY SIDE TRIM" on ESM.
B. Upper Instrument Panel
1. Insert a screwdriver wrapped with cloth into the instrument mask back notch to remove the instrument
mask. When vehicle has sunload sensor, disconnect the sensor harness. Refer to ATC-67 "SUNLOAD
SENSOR" on ESM.
IP-2
INSTRUMENT PANEL ASSEMBLY
2. Insert a screwdriver, etc., wrapped with cloth into the upper instrument panel passenger side back edge
and disengage metal clips and lift up panel.
3. Hold the lifted up part by hand, remove metal clips engaged in instrument pad, and remove upper instru-
ment panel.
C. Steering Lock Escutcheon
Pull toward vehicle and remove.
CAUTION:
To install, align key cylinder end bottom protrusion with escutcheon inside notch and install.
D. Instrument Panel Under Tray
1. Disengage upper metal clips, hold bottom lid by hand, pull panel
forward, and disengage metal clips.
2. Remove being careful of interference from surrounding metal
objects.
MIIB0019E
E. Switch Panel Finisher
Hold lid side (arrow area) by hand, disengage metal clips, and then
pull forward and disengage plastic clips to remove.
MIIB0020E
F. Steering Column Cover
Upper
