                                                   FRONT SEAT
FRONT SEAT
Component Parts Location                                                                                             To ESM
CAUTION:
When removing and installing seats, use shop cloths to protect the parts from damage.




                                                                                                                        MIIB9096E


   1.   Headrest                             2.   Headrest holder (free)                3.   Headrest holder (locked)
   4.   Seatback trim & pad                  5.   Side air bag module                   6.   Fixed inner cross rod
   7.   Seatback frame                       8.   Plastic collar                        9.   Reclining dial
  10.   Seat slide outer finisher           11.   Slide inner cover                 12. Spring
  13.   Seat slide assembly                 14.   Seat slide inner finisher         15. Lumber support lever knob
  16.   Seat lifter lever                   17.   Seat lifter lever bracket         18. Seat cushion trim & pad
  19.   Seat cushion frame                  20.   Front leg cover (inner)           21. Front leg cover (outer)
  22.   Rear leg cover (inner)              23.   Rear leg cover (outer)




                                                           SE-1
                                                FRONT SEAT
Disassembly and Assembly of Seatback                                                                       To ESM
SEATBACK TRIM PAD
Disassembly
1.   Unfasten seatback fastener. (Vehicles with side air bags)
2.   Remove retainer.




                                                                                                             MIIB0035E




3.   Turn over seatback trim, remove nuts (2), and remove fixed
     inner cross rod. (Vehicles with side air bags)




                                                                                                             MIIB9097E



4.   Use pincers, etc., to push up hooks shown by the arrows in the
     figure, and remove headrest holder from seatback.
5.   Remove seatback trim and pad from seatback frame.




                                                                                                             MIIB0037E


Assembly
Install in the reverse order of removal.
CAUTION:
Before installing headrest holder, check its orientation (front/rear and right/left).
SEATBACK FRAME
Disassembly
1.   Remove seatback trim&pad.
2.   Pull out side air bag connector from back of seat cushion.
3.   Remove lumber support lever knob, seat lifter lever, reclining dial, seat slide out finisher, slide inner cover,
     and seat slide inner finisher.
4.   Remove seatback frame bolts and remove seatback frame from seat slide assembly.
Assembly
Install in the reverse order of removal.
CAUTION:
After assembling seatback frame, make sure reclining device operates.


                                                       SE-2
