Image preview - the first page of the document
>> Download SE-002 documenatation <<
Text preview - extract from the document
REAR SEAT
REAR SEAT
Component Parts Location To ESM
BENCH SEAT
MIIB9098E
1. Rear seatback trim and pad 2. Seat cushion trim and pad 3. Seatback lock knob
4. Rear seat lock (RH) 5. Headrest 6. Headrest holder (free)
7. Headrest holder (locked) 8. Seatback frame 9. Rear seat lock (LH)
10. Rear seat side bracket (LH) 11. Rear seat side bracket (RH)
SE-1
REAR SEAT
SPLIT SEAT
MIIB9099E
1. Rear seatback trim and pad (RH) 2. Headrest 3. Headrest holder (free)
4. Headrest holder (locked) 5. Rear seatback trim and pad (LH) 6. Seatback lock knob
7. Rear seat lock (RH) 8. Rear seatback frame (RH) 9. Rear seatback frame (LH)
10. Rear set cushion assembly 11. Rear seat lock (LH) 12. Rear seat side bracket (LH)
13. Rear center bracket (RH) 14. Rear seat side bracket (RH)
SE-2
REAR SEAT
SLIDE SEAT
MIIB9069E
1. Seat slide assembly 2. Slide rail 3. Rear seatback trim and pad
4. Seat cushion trim and pad
SE-3
