Image preview - the first page of the document
>> Download el documenatation <<Text preview - extract from the document ELECTRICAL SYSTEM
SECTION EL
CONTENTS
PRECAUTIONS ...............................................................4 FRONT FOG LAMP.......................................................60
Supplemental Restraint System (SRS) AIR Wiring Diagram - F/FOG - .........................................60
BAG and SEAT BELT PRE-TENSIONER...............4 Bulb Replacement .....................................................61
Wiring Diagrams and Trouble Diagnosis.....................4 Aiming Adjustment .....................................................62
HARNESS CONNECTOR................................................5 REAR FOG LAMP .........................................................63
Description ...................................................................5 Wiring Diagram - R/FOG -.........................................63
STANDARDIZED RELAY................................................7 TURN SIGNAL AND HAZARD WARNING LAMPS .....65
Description ...................................................................7 System Description....................................................65
POWER SUPPLY ROUTING...........................................9 Schematic ..................................................................66
Schematic ..................................................................10 Wiring Diagram - TURN - ..........................................67
Wiring Diagram - POWER - ......................................12 Trouble Diagnoses.....................................................70
Inspection...................................................................22 ILLUMINATION..............................................................71
GROUND........................................................................23 Schematic ..................................................................71
Ground Distribution....................................................23 Wiring Diagram - ILL - ...............................................72
COMBINATION SWITCH ..............................................37 INTERIOR ROOM LAMP...............................................76
Check.........................................................................37 System Description/ With Interior Room Lamp
Replacement..............................................................38 Timer ..........................................................................76
STEERING SWITCH......................................................39 Wiring Diagram - ROOM/L -/ With Interior Room
Check.........................................................................39 Lamp Timer................................................................78
HEADLAMP ...................................................................40 Trouble Diagnoses/ With Interior Room Lamp
Wiring Diagram - H/LAMP -.......................................40 Timer ..........................................................................80
Trouble Diagnoses.....................................................41 Wiring Diagram - ROOM/L -/ Without Timer .............86
Bulb Replacement .....................................................42 SPOT AND TRUNK ROOM LAMPS .............................87
Aiming Adjustment .....................................................42 Wiring Diagram - INT/L - ...........................................87
HEADLAMP - DAYTIME LIGHT SYSTEM - .................44 METERS AND GAUGES...............................................89
System Description....................................................44 Component Parts and Harness Connector
Schematic ..................................................................45 Location .....................................................................89
Wiring Diagram - DTRL -...........................................46 System Description....................................................89
Trouble Diagnoses.....................................................49 Combination Meter ....................................................91
Bulb Replacement .....................................................49 Schematic ..................................................................92
Aiming Adjustment .....................................................50 Construction...............................................................93
HEADLAMP - HEADLAMP AIMING CONTROL -........51 Wiring Diagram - METER - .......................................94
Wiring Diagram - H/AIM - ..........................................51 Combination Meter Self-Diagnosis ............................96
PARKING, LICENSE AND TAIL LAMPS .....................53 Trouble Diagnoses.....................................................99
Wiring Diagram - TAIL/L -..........................................53 Electrical Components Inspection ...........................106
STOP LAMP ..................................................................56 WARNING LAMPS ......................................................107
Wiring Diagram - STOP/L - .......................................56 Schematic ................................................................107
BACK-UP LAMP............................................................58 Wiring Diagram - WARN - .......................................108
Wiring Diagram - BACK/L - .......................................58 Electrical Components Inspection ...........................112
CONTENTS (Cont'd)
WARNING CHIME .......................................................113 Schematic ................................................................171
Component Parts and Harness Connector Wiring Diagram - WINDOW - ..................................172
Location ...................................................................113 Trouble Diagnoses...................................................176
System Description..................................................113 POWER DOOR LOCK.................................................177
Wiring Diagram - CHIME - ......................................115 System Description..................................................177
Trouble Diagnoses...................................................117 Schematic ................................................................178
FRONT WIPER AND WASHER ..................................123 Wiring Diagram - D/LOCK -.....................................180
System Description..................................................123 Trouble Diagnoses...................................................187
Wiring Diagram - WIPER - ......................................125 POWER DOOR LOCK - SUPER LOCK -...................196
Removal and Installation .........................................127 System Description..................................................196
Washer Nozzle Adjustment .....................................128 Schematic ................................................................198
Washer Tube Layout ...............................................128 Wiring Diagram - S/LOCK -.....................................200
REAR WIPER AND WASHER ....................................129 Trouble Diagnoses...................................................207
Wiring Diagram - WIP/R -........................................129 MULTI-REMOTE CONTROL SYSTEM .......................220
Removal and Installation .........................................131 System Description..................................................220
Washer Nozzle Adjustment .....................................131 Wiring Diagram - MULTI - .......................................221
Washer Tube Layout ...............................................132 Trouble Diagnoses...................................................223
HEADLAMP WASHER ................................................133 ID Code Entry Procedure ........................................227
Wiring Diagram - HLC -...........................................133 Remote Controller Battery Replacement.................228
Washer Tube Layout ...............................................134 TIME CONTROL UNIT ................................................229
HORN ...........................................................................135 Description ...............................................................229
Wiring Diagram - HORN - .......................................135 Trouble Diagnoses...................................................230
CIGARETTE LIGHTER................................................136 Schematic ................................................................232
Wiring Diagram - CIGAR -.......................................136 NATS (NISSAN ANTI-THEFT SYSTEM).....................234
CLOCK.........................................................................137 Component Parts and Harness Connetor
Wiring Diagram - CLOCK -......................................137 Location ...................................................................234
REAR WINDOW DEFOGGER.....................................138 System Description..................................................234
System Description..................................................138 System Composition................................................236
Schematic ................................................................139 Wiring Diagram - NATS -.........................................237
Wiring Diagram - DEF -...........................................140 CONSULT-II .............................................................238
Trouble Diagnoses...................................................143 Trouble Diagnoses...................................................241
Electrical Components Inspection ...........................146 How to Replace NATS IMMU..................................258
Filament Check........................................................147 NAVIGATION SYSTEM ...............................................259
Filament Repair .......................................................148 Precautions ..............................................................259
AUDIO ..........................................................................149 Component Parts Location ......................................260
System Description..................................................149 System Description..................................................261
Schematic ................................................................151 Schematic ................................................................269
Wiring Diagram - AUDIO -.......................................152 Wiring Diagram - NAVI -..........................................270
Trouble Diagnoses...................................................160 Self-diagnosis Mode ................................................278
Inspection.................................................................161 Confirmation/Adjustment Mode ...............................281
AUDIO ANTENNA .......................................................162 Control Panel Mode.................................................293
Location of Antenna.................................................162 Guide Volume Setting..............................................300
Antenna Rod Replacement .....................................162 Anti-theft System .....................................................301
HEATED SEAT ............................................................163 CONSULT-II .............................................................302
Wiring Diagram - H/SEAT - .....................................163 Trouble Diagnoses...................................................303
POWER SUNROOF.....................................................165 This Condition Is Not Abnormal...............................309
Wiring Diagram - SROOF - .....................................165 Program Loading .....................................................318
Trouble Diagnoses...................................................166 ELECTRICAL UNITS LOCATION...............................319
DOOR MIRROR ...........................................................167 Engine Compartment...............................................319
Wiring Diagram - MIRROR - ...................................167 Passenger Compartment/LHD Models....................320
POWER WINDOW .......................................................169 Passenger Compartment/RHD Models ...................322
System Description..................................................169
EL-2
CONTENTS (Cont'd)
HARNESS LAYOUT ....................................................324 Room Lamp Harness...............................................358
How to Read Harness Layout .................................324 Front Door Harness/LHD Models ............................359
Outline/Sedan ..........................................................325 Front Door Harness/RHD Models ...........................361
Outline/Hatchback....................................................327 Rear Door Harness..................................................363
Main Harness...........................................................330 Back Door Harness .................................................365
Engine Room Harness ............................................334 BULB SPECIFICATIONS ............................................366
Engine Control Harness/QG Engine Models...........340 Headlamp.................................................................366
Engine Control Harness/YD Engine Models ...........344 Exterior Lamp ..........................................................366
Body Harness/Sedan...............................................348 Interior Lamp............................................................366
Body Harness/Hatchback ........................................354 WIRING DIAGRAM CODES (CELL CODES).............367
EL-3
PRECAUTIONS
Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
Supplemental Restraint System (SRS) "AIR
BAG" and "SEAT BELT PRE-TENSIONER" NJEL0001
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER" used along with
a seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of
collision. The SRS system composition which is available to NISSAN MODEL N16 is as follows (The compo-
sition varies according to the destination and optional equipment.):
+ For a frontal collision
The Supplemental Restraint System consists of driver air bag module (located in the center of the steer-
ing wheel), front passenger air bag module (located on the instrument panel on passenger side), front seat
belt pre-tensioners, a diagnosis sensor unit, warning lamp, wiring harness and spiral cable.
+ For a side collision
The Supplemental Restraint System consists of front side air bag module (located in the outer side of front
seat), side air bag (satellite) sensor, diagnosis sensor unit (one of components of air bags for a frontal
collision), wiring harness, warning lamp (one of components of air bags for a frontal collision).
Information necessary to service the system safely is included in the RS section of this Service Manual.
WARNING:
+ To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance should be per-
formed by an authorized NISSAN dealer.
+ Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the RS section.
+ Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow harness connector.
Wiring Diagrams and Trouble Diagnosis NJEL0002
When you read wiring diagrams, refer to the following:
+ Refer to GI-12, "HOW TO READ WIRING DIAGRAMS"
+ Refer to EL-10, "POWER SUPPLY ROUTING" for power distribution circuit
When you perform trouble diagnosis, refer to the following:
+ Refer to GI-32, "HOW TO FOLLOW TEST GROUPS IN TROUBLE DIAGNOSES"
+ Refer to GI-21, "HOW TO PERFORM EFFICIENT DIAGNOSIS FOR AN ELECTRICAL INCIDENT"
Check for any Service bulletins before servicing the vehicle.
EL-4
HARNESS CONNECTOR
Description
Description NJEL0003
HARNESS CONNECTOR (TAB-LOCKING TYPE) NJEL0003S01
+ The tab-locking type connectors help prevent accidental looseness or disconnection.
+ The tab-locking type connectors are disconnected by pushing or lifting the locking tab(s). Refer to the
illustration below.
Refer to the next page for description of the slide-locking type connector.
CAUTION:
Do not pull the harness or wires when disconnecting the connector.
[Example]
SEL769DA
EL-5
HARNESS CONNECTOR
Description (Cont'd)
HARNESS CONNECTOR (SLIDE-LOCKING TYPE) =NJEL0003S02
+ A new style slide-locking type connector is used on certain systems and components, especially those
related to OBD.
+ The slide-locking type connectors help prevent incomplete locking and accidental looseness or disconnec-
tion.
+ The slide-locking type connectors are disconnected by pushing or pulling the slider. Refer to the illustra-
tion below.
CAUTION:
+ Do not pull the harness or wires when disconnecting the connector.
+ Be careful not to damage the connector support bracket when disconnecting the connector.
[Example]
SEL769V
EL-6
STANDARDIZED RELAY
Description
Description NJEL0004
NORMAL OPEN, NORMAL CLOSED AND MIXED TYPE RELAYS NJEL0004S01
Relays can mainly be divided into three types: normal open, normal closed and mixed type relays.
SEL881H
TYPE OF STANDARDIZED RELAYS NJEL0004S02
1M 1 Make 2M 2 Make
1T 1 Transfer 1M
