Image preview - the first page of the document
>> Download ma documenatation <<
Text preview - extract from the document
MAINTENANCE
SECTION MA
CONTENTS
PRE-DELIVERY INSPECTION ITEMS............................2 Maintenance Schedule for Petrol Engines
GENERAL MAINTENANCE ............................................3 (Annual Mileage > 30,000 km/year) ..........................14
PERIODIC MAINTENANCE (EXCEPT FOR QG15DE/QG18DE ENGINES ....................................14
EUROPE) .........................................................................4 CHASSIS AND BODY MAINTENANCE ......................15
Engine and Emission Control Maintenance Maintenance Schedule for Diesel Engines
(Gasoline engine) ........................................................5 (Annual Mileage > 30,000 km/year) ..........................16
Chassis and Body Maintenance..................................6 YD22DDT ENGINE ..................................................16
Maintenance Under Severe Driving Conditions ..........7 CHASSIS AND BODY MAINTENANCE ......................17
PERIODIC MAINTENANCE (FOR EUROPE).................8 Maintenance Under Severe Driving Conditions
Maintenance Schedule for Petrol Engines (Annual Driving Distance > 30,000 km/year) ............18
(Annual Mileage < 30,000 km/year) ............................8 RECOMMENDED FLUIDS AND LUBRICANTS...........20
QG15DE/QG18DE ENGINES ......................................8 Fluids and Lubricants ................................................20
CHASSIS AND BODY MAINTENANCE ........................9 SAE Viscosity Number ..............................................21
Maintenance Schedule for Diesel Engines GASOLINE ENGINE.................................................21
(Annual Mileage < 30,000 km/year) ..........................10 DIESEL ENGINE......................................................21
YD22DDT ENGINE ..................................................10 Engine Coolant Mixture Ratio....................................22
CHASSIS AND BODY MAINTENANCE ......................11
Maintenance Under Severe Driving Conditions
(Annual Driving Distance < 30,000 km/year) ............12
NJMA0036
PRE-DELIVERY INSPECTION ITEMS
Shown below are Pre-delivery Inspection Items required for the new vehicle. It is recommended that
necessary items other than those listed here be added, paying due regard to the conditions in each
country.
Perform applicable items on each model. Consult text of this section for specifications.
UNDER HOOD -- engine off
Radiator coolant level and coolant hose connections for leaks
Battery fluid level, specific gravity and conditions of battery terminals
Drive belts tension
Fuel filter for water or dusts (Diesel only), and fuel lines and connections for leaks
Engine oil level and oil leaks
Clutch and brake reservoir fluid level and fluid lines for leaks
Windshield and rear window washer and headlamp cleaner reservoir fluid level
Power steering reservoir fluid level and hose connections for leaks
ON INSIDE AND OUTSIDE
Remove front spring/strut spacer (If applicable)
Operation of all instruments, gauges, lights and accessories
Operation of horn(s), wiper and washer
Steering lock for operation
Check air conditioner for gas leaks
Front and rear seats, and seat belts for operation
All moldings, trims and fittings for fit and alignment
All windows for operation and alignment
Hood, trunk lid, door panels for fit and alignment
Latches, keys and locks for operation
Weatherstrips for adhesion and fit
Headlamp aiming
Tighten wheel nuts (Inc. inner nuts if applicable)
Tire pressure (Inc. spare tire)
Check front wheels for toe-in
Install clock/voltmeter/room lamp fuse (If applicable)
Install deodorizing filter to air conditioner (If applicable)
Remove wiper blade protectors (If applicable)
UNDER BODY
Manual transmission/transaxle, transfer and differential gear oil level
Brake and fuel lines and oil/fluid reservoirs for leaks
Tighten bolts and nuts of steering linkage and gear box, suspension, propeller shafts and drive shafts
Tighten rear body bolts and nuts (Models with wooden bed only)
ROAD TEST
Clutch operation
Parking brake operation
Service brake operation
Automatic transmission/transaxle shift timing and kickdown
Steering control and returnability
Engine performance
Squeaks and rattles
ENGINE OPERATING AND HOT
Adjust idle speed
Automatic transmission/transaxle fluid level
Engine idling and stop knob operation (Diesel only)
FINAL INSPECTION
Install necessary parts (outside mirror, wheel covers, seat belts, mat, carpet or mud flaps)
Inspect for interior and exterior metal and paint damage
Check for spare tire, jack, tools (wheel chock), and literature
Wash, clean interior and exterior
: Not applicable to this model
MA-2
NJMA0004
GENERAL MAINTENANCE
General maintenance includes those items which should be checked during the normal day-to-day operation
of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform the
checks and inspections themselves or they can have their NISSAN dealers do them for a nominal charge.
OUTSIDE THE VEHICLE
The maintenance items listed here should be performed from time to time, unless otherwise specified.
Item Reference page
Tires Check the pressure with a gauge periodically when at a service station,
including the spare, and adjust to the specified pressure if necessary. Check --
carefully for damage, cuts or excessive wear.
Windshield wiper
Check for cracks or wear if not functioning correctly. --
blades
Doors and engine Check that all doors, the engine hood, the trunk lid and back door operate
hood properly. Also ensure that all latches lock securely. Lubricate if necessary.
Make sure that the secondary latch keeps the hood from opening when the BT-7
primary latch is released. BT-16
When driving in areas using road salt or other corrosive materials, check for
lubrication frequently.
Tire rotation Tires should be rotated every 10,000 km (6,000 miles). SU-7
INSIDE THE VEHICLE
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the
vehicle, etc.
Item Reference page
Lamps Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps,
and other lamps are all operating properly and installed securely. Also check --
headlamp aim.
Warning lamps and Make sure that all warning lamps and buzzers/chimes are operating prop-
--
chimes erly.
Steering wheel Check that it has the specified play.
Check for changes in the steering conditions, such as excessive free play,
--
hard steering or strange noises.
Free play: Less than 35 mm (1.38 in)
Seat belts Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters
and retractors) operate properly and smoothly, and are installed securely. RS-4
Check the belt webbing for cuts, fraying, wear or damage.
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically e.g. each time you check the engine oil or refuel.
Item Reference page
Windshield washer
Check that there is adequate fluid in the tank. --
fluid
Engine coolant level Check the coolant level when the engine is cold. LC-18, LC-43
Engine oil level Check the level after parking the vehicle (on level ground) and turning off
LC-8, LC-30
the engine.
Brake and clutch Make sure that the brake and clutch fluid levels are between the "MAX" and
BR-7
fluid levels "MIN" lines on the reservoir.
Battery Check the fluid level in each cell. It should be between the "MAX" and "MIN"
--
lines.
MA-3
NJMA0005
PERIODIC MAINTENANCE (EXCEPT FOR EUROPE)
The following tables show the normal maintenance schedule. Depending upon weather and atmospheric
conditions, varying road surfaces, individual driving habits and vehicle usage, additional or more frequent
maintenance may be required.
Periodic maintenance beyond the last period shown on the tables requires similar maintenance.
MA-4
PERIODIC MAINTENANCE (EXCEPT FOR EUROPE)
Engine and Emission Control Maintenance (Gasoline engine)
Engine and Emission Control Maintenance
(Gasoline engine) NJMA0005S04
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, A = Adjust, C = Clean, E = Check and correct the
engine coolant mixture ratio.
MAINTENANCE OPERATION MAINTENANCE INTERVAL
Refer-
km x 1,000 1 10 20 30 40 50 60 70 80 ence
Perform either at number of kilometers (miles)
(Miles x 1,000) (0.6) (6) (12) (18) (24) (30) (36) (42) (48) page
or months, whichever comes first.
Months -- 6 12 18 24 30 36 42 48
Underhood and under vehicle
Torque of manifolds & exhaust tube nuts*1 I --
Intake & exhaust valve clearance*2 A A A A EM-42
Drive belts I*1 I*1 I I*1 I EM-15
Engine oil (Use API SE, SF, SG, SH or SJ
R R R R R R R R LC-8
oil.)5
Engine oil filter (Use Part No. 15208 65F01 or
R R R R R R R R LC-9
equivalent)5
Engine coolant (Use Nissan genuine engine
See NOTE (1) E R LC-17
coolant L2N or equivalent in its quality.)
Cooling system I I I I LC-12
Fuel lines I I FE-5
Air cleaner filter (Dry paper type)5 C C C R C C C R EM-0
Air cleaner filter (Viscous paper type)5 R R EM-17
Fuel filter See NOTE (2) FE-9
Positive crankcase ventilation (PCV) system I*1 I*1 I*1 I*1 EC-37
Spark plugs (Conventional type)*3 R R EM-18
Spark plugs (Conventional type, For leaded
I R I R I R I R EM-18
fuel)*1
Spark plugs (Conventional type, For unleaded
I I I R I I I R EM-18
fuel)*1
EVAP vapor lines (With carbon canister) I I EC-34
Vacuum hoses & connections*1 I I I I EC-27
Heated oxygen sensor (Exhaust gas sensor) I I EC-176
NOTE:
5 Maintenance items with "5" should be performed more frequently according to "Maintenance Under Severe Driving Con-
ditions".
(1) Use Nissan genuine engine coolant, or equivalent in its quality, in order to avoid possible aluminum corrosion within the
engine cooling system caused by the use of non-genuine engine coolant. After first replacement, replace every 40,000 km (24,
000 miles) or 24 months.
(2) Maintenance-free item. For service procedures, refer to FE section.
*1: Models without three way catalyst
*2: For models with three way catalyst, periodic maintenance is not required. However, if valve noise increases, check valve clearance.
*3: Models with three way catalyst
MA-5
PERIODIC MAINTENANCE (EXCEPT FOR EUROPE)
Chassis and Body Maintenance
Chassis and Body Maintenance NJMA0005S05
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, L = Lubricate.
MAINTENANCE OPERATION MAINTENANCE INTERVAL
Perform either at number of kilome- km x 1,000 1 10 20 30 40 50 60 70 80 Reference page
ters (miles) or months, whichever (Miles x 1,000) (0.6) (6) (12) (18) (24) (30) (36) (42) (48)
comes first. Months -- 6 12 18 24 30 36 42 48
Underhood and under vehicle
Brake, clutch & automatic transaxle
I I I I I I I I BR-7, AT-78
fluid (For level & leaks)5
Brake fluid5 R R BR-18
Brake booster vacuum hoses, con-
I I BR-22
nections & check valve
Power steering fluid & lines (For
I*1 I I*1 I I*1 I I*1 I ST-7
level & leaks)
BR-7, FE-11,
Brake, clutch & exhaust systems I I I I I I I I
FE-27
Manual transaxle gear oil (For level
I*1 I I*1 I I*1 I I*1 I MT-15, MT-14
& leaks)
Steering gear & linkage, axle & sus-
I*2 I I I I ST-7, SU-6, SU-7
pension parts & drive shafts5
Outside and inside
Wheel alignment (If necessary,
I I I I SU-7, SU-14
rotate & balance wheels)
Brake pads, rotors & other brake
I I I I I I I I BR-27, BR-35
components5
Brake linings, drums & other brake
I I I I BR-33
components5
Lock, hinges & hood latch5 L*1 L L*1 L L*1 L L*1 L BT-7, BT-16
Seat belts, buckles, retractors,
I I I I RS-4
anchors & adjuster
Foot brake, parking brake & clutch BR-12, BR-47,
I*1 I I*1 I I*1 I I*1 I
(For free play, stroke & operation) CL-5
Ventilation air filter5 Replace every 12,000 km (7,500 miles) or 12 months HA-102
Supplemental air bag systems See NOTE (1) RS-25
NOTE:
(1) Inspect at the first 10 years, and then every 2 years.
5 Maintenance items with "5" should be performed more frequently according to "Maintenance Under Severe Driving Con-
ditions".
*1: Models except for Australia
*2: Models without three way catalyst
MA-6
PERIODIC MAINTENANCE (EXCEPT FOR EUROPE)
Maintenance Under Severe Driving Conditions
Maintenance Under Severe Driving Conditions NJMA0005S06
The maintenance intervals shown on the preceding pages are for normal operating conditions. If the vehicle
is mainly operated under severe driving conditions as shown below, more frequent maintenance must be per-
formed on the following items as shown in the table.
Severe driving conditions
A -- Driving under dusty conditions
B -- Driving repeatedly short distances
C -- Towing a trailer or caravan
D -- Extensive idling
E -- Driving in extremely adverse weather conditions or in areas where ambient temperatures are either
extremely low or extremely high
F -- Driving in high humidity areas or in mountainous areas
G -- Driving in areas using salt or other corrosive materials
H -- Driving on rough and/or muddy roads or in the desert
I -- Driving with frequent use of braking or in mountainous areas
Maintenance operation: Check = Check and correct or replace as necessary.
Maintenance Reference
Driving condition Maintenance item Maintenance interval
operation page
EM-17,
A . . . . . . . . Air cleaner filter Replace More frequently
EM-87
Engine oil & oil filter (Gaso- Every 5,000 km (3,000
A B C D . . . . . Replace LC-8, LC-9
line engine) miles) or 3 months
Every 20,000 km (12,000
. . . . . F . . . Brake fluid Replace BR-7
miles) or 12 months
Every 40,000 km (24,000
. . C . . . . H . Automatic transaxle fluid Replace AT-15
miles) or 24 months
Steering gear & linkage, axle
Every 10,000 km (6,000 ST-7, SU-6,
. . . . . . G H . & suspension parts & drive Check
miles) or 6 months SU-18
shafts
Brake pads, rotors & other Every 5,000 km (3,000 BR-27,
A . C . . . G H I Check
brake components miles) or 3 months BR-35
Brake linings, drums & other Every 10,000 km (6,000
A . C . . . G H I Check BR-33
brake components miles) or 6 months
Every 5,000 km (3,000
. . . . . . G . . Lock, hinges & hood latch Lubricate BT-16, BT-7
miles) or 3 months
A . . . . . . . . Ventilation air filter Replace More frequently HA-102
MA-7
NJMA0043
PERIODIC MAINTENANCE (FOR EUROPE)
Maintenance Schedule for Petrol Engines (Annual Mileage < 30,000 km/year)
The following tables show the normal maintenance schedule. Depending upon weather and atmospheric
conditions, varying road surfaces, individual driving habits and vehicle usage, additional or more frequent
maintenance may be required.
Periodic maintenance beyond the last period shown on the tables requires similar maintenance.
Maintenance Schedule for Petrol Engines
(Annual Mileage < 30,000 km/year) NJMA0043S01
QG15DE/QG18DE ENGINES NJMA0043S0101
Abbreviations: R = Replace I = Inspect: Correct or replace if necessary
MAINTENANCE OPERATION MAINTENANCE INTERVAL
Refer-
Perform on a kilometer basis, but on km x 1,000 15 30 45 60 75 90 105 120 ence
an annual basis when driving less than (miles x 1,000) (9) (18) (27) (36) (45) (54) (63) (72) pages
15,000 km (9,000 miles) per year Months 12 24 36 48 60 72 84 96
Engine compartment and under vehicle
Engine oil (Use recommended oil)5 R R R R R R R R LC-8
Engine oil filter (Use NISSAN genuine
R R R R R R R R LC-9
part or equivalent)5
Drive belts I I I I I I I I EM-15
Cooling system I I I I I I I I LC-12
Engine anti-freeze coolant (Use genu-
ine NISSAN Anti-Freeze Coolant (L2N) See NOTE (1) I R I LC-17
or equivalent)
Air cleaner filter5 R R EM-17
Intake and exhaust valve clearance See NOTE (2) EM-42
FE-5/
Fuel and EVAP vapour lines I I I I
EC-33
Spark plugs R R R R EM-18
Fuel filter See NOTE (3) FE-9
Heated oxygen sensor (Exhaust gas GI-40,
See NOTE (4)
sensor)5 EC-45
NOTE:
(1) First replace at 90,000 km (54,000 miles)/60 months, then every 60,000 km (36,000 miles)/48 months. Perform "I" (Check-
ing the mixture ratio and correcting the mixture ratio if necessary) at the middle of replacement interval.
(2) Periodic maintenance is not required. However, if valve noise increases, check valve clearance.
(3) Fuel filter is maintenance-free. For service procedures, refer to FE section.
(4) Perform only according to "Maintenance Under Severe Driving Conditions" for models without Euro-OBD system. For
models with Euro-OBD system, periodic maintenance is not required.
5 Maintenance items with "5" should be performed more frequently according to "Maintenance Under Severe Driving Con-
ditions".
MA-8
PERIODIC MAINTENANCE (FOR EUROPE)
Maintenance Schedule for Petrol Engines (Annual Mileage < 30,000 km/year) (Cont'd)
CHASSIS AND BODY MAINTENANCE =NJMA0043S0102
Abbreviations: R = Replace I = Inspect: Correct or replace if necessary
MAINTENANCE OPERATION MAINTENANCE INTERVAL
Refer-
Perform on a kilometer basis, but on km x 1,000 15 30 45 60 75 90 105 120 ence
an annual basis when driving less than (miles x 1,000) (9) (18) (27) (36) (45) (54) (63) (72) pages
15,000 km (9,000 miles) in a year. Months 12 24 36 48 60 72 84 96
Underhood and under vehicle
Headlamp aiming I I I I I I I I EL-42
Wheel alignment (if necessary, balance SU-6/
I I I I I I I I
& rotate wheels) SU-18
Brake pads, rotors & other brake com- BR-27/
I I I I I I I I
ponents5 BR-28
BR-12/
Foot brake, parking brake & clutch (for
I I I I I I I I BR-48/
free play, stroke & operation)
CL-0
Brake booster vacuum hoses,
I I I I BR-21
connections, check valve
Brake & clutch, systems and fluid (for
I I I I I I I I BR-7
level and leaks)
Brake fluid5 R R R R BR-7
Power steering fluid and lines (for level
I I I I I I I I ST-7
and leaks)
Supplemental air bag systems See NOTE (1) RS-25
Ventilation air filter5 R R R R
HA-102
Manual transaxle gear oil (check for
MT-14
leakage. Use genuine NISSAN XZ I I I I I I I I
MT-15
gear oil or exact equivalent)
Automatic transaxle fluid (for level and
I I I I I I I I AT-78
leaks)5
ST-7/
Steering gear & linkage, axle & sus-
SU-6/
pension parts, drive shafts, exhaust I I I I
SU-18/
system5
FE-11
NISSAN Mobility System See NOTE (2) I I I I I I I --
Body corrosion See NOTE (3) BT-6
NOTE:
(1) Inspect after 10 years, then every 2 years.
(2) Check expiration date of the tyre sealant bottle. Replace if necessary.
(3) Inspect once per year.
5 Maintenance items with "5" should be performed more frequently according to "Maintenance Under Severe Driving Con-
ditions".
MA-9
PERIODIC MAINTENANCE (FOR EUROPE)
Maintenance Schedule for Diesel Engines (Annual Mileage < 30,000 km/year)
Maintenance Schedule for Diesel Engines
(Annual Mileage < 30,000 km/year) =NJMA0043S02
YD22DDT ENGINE NJMA0043S0201
Abbreviations: R = Replace I = Inspect: Correct or replace if necessary
MAINTENANCE OPERATION MAINTENANCE INTERVAL
Perform on a kilometer basis, but
km x 1,000 20 40 60 80 100 120 Reference pages
on an annual basis when driving
(miles x 1,000) (12) (24) (36) (48) (60) (72)
less than 20,000 km (12,000
Months 12 24 36 48 60 72
miles) per year.
Engine compartment and under vehicle
Engine oil (Use recommended
R R R R R R LC-30
oil)5
Engine oil filter (Use Eco filter or
See NOTE (1) R R R R R R LC-31
equivalent)5
Drive belts I I I I I I EM-84
Cooling system I I I I I I LC-37
Engine anti-freeze coolant (Use
genuine NISSAN Anti-freeze See NOTE (2) I I LC-43
Coolant (L2N) or equivalent)
Air cleaner filter5 R R EM-87
Intake & exhaust valve clearance See NOTE (3) EM-132
Fuel lines I I I FE-16
Injection nozzles See NOTE (4) EC-509
Fuel filter5 R R R FE-16
NOTE:
(1) Oil filter element assembly and O-ring seal are replacement parts.
(2) First replace at 100,000 km (60,000 miles)/60 months, then every 60,000 km (36,000 miles)/36 months. After first replacement,
perform "I" (checking the mixture ratio and correcting the mixture ratio if necessary) at the middle of replacement interval.
(3) If valve noise increases, check valve clearance.
(4) If engine power decreases, black exhaust smoke is emitted or engine noise increases, check injection nozzles and if
necessary, replace injection nozzle assembly.
5 Maintenance items with "5" should be performed more frequently according to "Maintenance Under Severe Driving Con-
ditions".
MA-10
PERIODIC MAINTENANCE (FOR EUROPE)
Maintenance Schedule for Diesel Engines (Annual Mileage < 30,000 km/year) (Cont'd)
CHASSIS AND BODY MAINTENANCE =NJMA0043S0202
Abbreviations: R = Replace I = Inspect: Correct or replace if necessary
MAINTENANCE OPERATION MAINTENANCE INTERVAL
Perform on a kilometer basis, but on
km x 1,000 20 40 60 80 100 120 Reference pages
an annual basis when driving less
(miles x 1,000) (12) (24) (36) (48) (60) (72)
than 20,000 km (12,000 miles) per
Months 12 24 36 48 60 72
year.
Underhood and under vehicle
Headlamp aiming I I I I I I EL-42
Wheel alignment (if necessary, bal- SU-14
I I I I I I
ance & rotate wheels) SU-7
Brake pads, rotors & other brake BR-27
I I I I I I
components5 BR-28
BR-12
Foot brake, parking brake & clutch
I I I I I I BR-48
(for free play, stroke & operation)
CL-0
Brake booster vacuum hoses,
I I I BR-21
connections, check valve
Brake & clutch, systems and fluid
I I I I I I BR-7
(for level and leaks)
Brake fluid5 R R R BR-7
Power steering fluid and lines (for
I I I I I I ST-7
level and leaks)
Supplemental air bag systems See NOTE (1) RS-25
Ventilation air filter5 R R R R R R HA-102
Manual transaxle gear oil (check for
MT-14
leakage. Use genuine NISSAN XZ I I I I I I
MT-15
gear oil or exact equivalent)
ST-7
Steering gear & linkage, axle & sus-
SU-6
pension parts, drive shafts, exhaust I I I
SU-18
system5
FE-27
NISSAN Mobility System See NOTE (2) I I I I I --
Body corrosion See NOTE (3) BT-6
NOTE:
(1) Inspect after 10 years, then every 2 years.
(2) Check expiration date of the tyre sealant bottle. Replace if necessary.
(3) Inspect once per year.
5 Maintenance items with "5" should be performed more frequently according to "Maintenance Under Severe Driving Con-
ditions".
MA-11
PERIODIC MAINTENANCE (FOR EUROPE)
Maintenance Under Severe Driving Conditions (Annual Driving Distance < 30,000 km/year)
Maintenance Under Severe Driving Conditions
(Annual Driving Distance < 30,000 km/year) =NJMA0043S03
The maintenance intervals shown on the preceding pages are for normal operating conditions. If the vehicle
is mainly operated under severe driving conditions as shown below, more frequent maintenance must be per-
formed on the following items as shown in the table.
A -- Driving under dusty conditions
B -- Driving repeatedly short distances
C -- Towing a trailer or caravan
D -- Extensive idling
E -- Driving in extremely adverse weather conditions or in areas where ambient temperatures are either
extremely low or extremely high
F -- Driving in high humidity areas or in mountainous areas
G -- Driving in areas using salt or other corrosive materials
H -- Driving on rough and/or muddy roads or in the desert
I -- Driving with frequent use of braking or in mountainous areas
J -- Frequent off road use or driving in water
K -- Sustained high speed driving
L -- For models without Euro-OBD system
Maintenance Maintenance
Driving condition Maintenance interval
item operation
Engine oil & engine oil filter
Every 7,500 km (4,500 miles) or 6
Petrol models Replace
A B C D . . . . . . . . months
Every 10,000 km (6,000 miles) or 6
Diesel models Replace
months
Air cleaner filter
Every 30,000 km (18,000 miles) or
Petrol models Replace
A . . . . . . . . . . . 24 months
Every 30,000 km (18,000 miles) or
Diesel models Replace
18 months
Fuel filter
A . . . E . . . . . . . Every 20,000 km (12,000 miles) or
Diesel models Replace
12 months
Heated Oxygen Sensor 1 (Front)
. . . . . . . . . . . L Every 30,000 km (18,000 miles) or
Petrol models Inspect
24 months
Heated Oxygen Sensor 2 (Rear)
. . . . . . . . . . . L Every 30,000 km (18,000 miles) or
Petrol models Inspect
24 months
Ventilation air filter
Every 15,000 km (9,000 miles) or
Petrol models Replace
A . . . . . . . . . . . 12 months
Every 10,000 km (6,000 miles) or 6
Diesel models Replace
months
Brake fluid
Every 15,000 km (9,000 miles) or
Petrol models Replace
. . . . . F . . . . . . 12 months
Every 20,000 km (12,000 miles) or
Diesel models Replace
12 months
MA-12
PERIODIC MAINTENANCE (FOR EUROPE)
Maintenance Under Severe Driving Conditions (Annual Driving Distance < 30,000 km/year) (Cont'd)
Maintenance Maintenance
Driving condition Maintenance interval
item operation
Automatic transaxle fluid
. . C . . . . H . . . . Every 30,000 km (18,000 miles) or
Petrol models Replace
24 months
Brake pads, rotors & other brake system components
Every 7,500 km (4,500 miles) or 6
Petrol models Inspect
A . C . . . G H I . . . months
Every 10,000 km (6,000 miles) or 6
Diesel models Inspect
months
Steering gear & linkage, axle & suspension parts, drive shafts,
exhaust system
Every 15,000 km (9,000 miles) or
. . . . . . G H . . . . Petrol models Inspect
12 months
Every 20,000 km (12,000 miles) or
Diesel models Inspect
12 months
MA-13
PERIODIC MAINTENANCE (FOR EUROPE)
Maintenance Schedule for Petrol Engines (Annual Mileage > 30,000 km/year)
Maintenance Schedule for Petrol Engines
(Annual Mileage > 30,000 km/year) =NJMA0043S04
QG15DE/QG18DE ENGINES NJMA0043S0401
Abbreviations: R = Replace I = Inspect: Correct or replace if necessary
MAINTENANCE OPERATION MAINTENANCE INTERVAL Refer-
km x 1,000 15 30 45 60 75 90 105 120 ence
Perform on a kilometer basis only. pages
(miles x 1,000) (9) (18) (27) (36) (45) (54) (63) (72)
Engine compartment and under vehicle
Engine oil (Use recommended oil)5 R R R R R R R R LC-8
Engine oil filter (Use NISSAN genuine
R R R R R R R R LC-9
part or equivalent)5
Drive belts I I I I I I I I EM-15
Cooling system I I I I LC-12
Engine anti-freeze coolant (Use genu-
ine NISSAN Anti-Freeze Coolant (L2N) See NOTE (1) I R I LC-17
or equivalent)
Air cleaner filter5 R R EM-17
Intake & exhaust valve clearance See NOTE (2) EM-42
FE-5/
Fuel and EVAP vapor lines I I
EC-36
Spark plugs R R R R EM-18
Fuel filter See NOTE (3) FE-9
GI-40/
Heated oxygen sensor5 See NOTE (4)
EC-45
NOTE:
(1) First replace at 90,000 km (54,000 miles), then every 60,000 km (36,000 miles). Perform "I" (checking the mixture ratio and
correcting the mixture ratio if necessary) at the middle of replacement interval.
(2) Periodic maintenance is not required. However, if valve noise increases, check valve clearance.
(3) Fuel filter is maintenance-free. For service procedures, refer to FE section.
(4) Perform only according to "Maintenance Under Severe Driving Conditions" for models without Euro-OBD system. For
models with Euro-OBD system, periodic maintenance is not required.
5 Maintenance items with "5" should be performed more frequently according to "Maintenance Under Severe Driving Con-
ditions".
MA-14
PERIODIC MAINTENANCE (FOR EUROPE)
Maintenance Schedule for Petrol Engines (Annual Mileage > 30,000 km/year) (Cont'd)
CHASSIS AND BODY MAINTENANCE =NJMA0043S0402
Abbreviations: R = Replace I = Inspect: Correct or replace if necessary
MAINTENANCE OPERATION MAINTENANCE INTERVAL Refer-
km x 1,000 15 30 45 60 75 90 105 120 ence
Perform on a kilometer basis only. pages
(miles x 1,000) (9) (18) (27) (36) (45) (54) (63) (72)
Underhood and under vehicle
Headlamp aiming I I I I EL-42
Wheel alignment (if necessary, balance SU-6/
I I I I
& rotate wheels) SU-18
Brake pads, rotors & other brake com- BR-27
I I I I
ponents5 BR-28
BR-12/
Foot brake, parking brake & clutch (for
I I I I BR-48/
free play, stroke & operation)
CL-0
Brake booster vacuum hoses,
I I BR-21
connections, check valve
Brake & clutch, systems and fluid (for
I I I I BR-7
level and leaks)
Brake fluid5 R R BR-7
Power steering fluid and lines (for level
I I I I ST-7
and leaks)
Supplemental air bag systems See NOTE (1) RS-25
Ventilation air filter5 R R R R
HA-102
Manual transaxle gear oil (check for
MT-14
leakage. Use genuine NISSAN XZ I I I I
MT-15
gear oil or exact equivalent)
Automatic transaxle fluid (for level and
I I I I AT-78
leaks)5
ST-7/
Steering gear and linkage, axle & sus-
SU-6/
pension parts, drive shafts, exhaust I I
SU-18/
system5
FE-11
NISSAN Mobility System See NOTE (2) I I I I I I I --
Body corrosion See NOTE (3) BT-6
NOTE:
(1) Inspect after 10 years, then every 2 years.
(2) Check expiration date of the tyre sealant bottle. Replace if necessary.
(3) Inspect once per year.
5 Maintenance items with "5" should be performed more frequently according to "Maintenance Under Severe Driving Con-
ditions".
MA-15
PERIODIC MAINTENANCE (FOR EUROPE)
Maintenance Schedule for Diesel Engines (Annual Mileage > 30,000 km/year)
Maintenance Schedule for Diesel Engines
(Annual Mileage > 30,000 km/year) =NJMA0043S05
YD22DDT ENGINE NJMA0043S0501
Abbreviations: R = Replace I = Inspect: Correct or replace if necessary
MAINTENANCE OPERATION MAINTENANCE INTERVAL
Perform on a kilometer basis km x 1,000 20 40 60 80 100 120 Reference pages
only. (miles x 1,000) (12) (24) (36) (48) (60) (72)
Engine compartment and under vehicle
Engine oil (Use recommended
R R R R R R LC-30
oil)5
Engine oil filter (Use Eco filter or
See NOTE (1) R R R R R R LC-31
equivalent)5
Drive belts I I I I I I EM-84
Cooling system I I I I I I LC-37
Engine anti-freeze coolant (Use
genuine NISSAN Anti-Freeze See NOTE (2) I I LC-43
Coolant (L2N) or equivalent)
Air cleaner filter5 R R EM-87
Intake & exhaust valve clearance See NOTE (3) EM-132
Fuel lines I I FE-16
Injection nozzles See NOTE (4) EC-509
Fuel filter5 R R FE-16
NOTE:
(1) Oil filter element assembly and O-ring seal are replacement parts.
(2) First replace at 100,000 km (60,000 miles), then every 60,000 km (36,000 miles). After first replacement, perform "I" (check-
ing the mixture ratio and correcting the mixture ratio if necessary) at the middle of replacement interval.
(3) If valve noise increases, check valve clearance.
(4) If engine power decreases, black exhaust smoke is emitted or engine noise increases, check injection nozzles and if
necessary, replace injection nozzle assembly.
5 Maintenance items with "5" should be performed more frequently according to "Maintenance Under Severe Driving Con-
ditions".
MA-16
PERIODIC MAINTENANCE (FOR EUROPE)
Maintenance Schedule for Diesel Engines (Annual Mileage > 30,000 km/year) (Cont'd)
CHASSIS AND BODY MAINTENANCE =NJMA0043S0502
Abbreviations: R = Replace I = Inspect: Correct or replace if necessary
MAINTENANCE OPERATION MAINTENANCE INTERVAL
Refer-
km x 1,000 ence
Perform on a kilometer basis 10 20 30 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
