Image preview - the first page of the document
>> Download ST documenatation <<
Text preview - extract from the document
STEERING SYSTEM GI
SECTION ST MA
EM
LC
EC
CONTENTS
FE
PRECAUTIONS AND PREPARATION............................3 Steering Worm Assembly......................................21
Supplemental Restraint System (SRS) Bearing ..................................................................21
``AIR BAG'' ...................................................................3 Oil Seals................................................................21 CL
Precautions for Steering System.................................3 POWER STEERING SYSTEM (Model: PB48S)...........22
Special Service Tools ..................................................4 Description .................................................................22
NOISE, VIBRATION AND HARSHNESS (NVH) POWER STEERING GEAR (Model: PB48S) ...............23 MT
TROUBLESHOOTING .....................................................6 Removal and Installation ...........................................23
NVH Troubleshooting Chart.........................................6 Steering Gear........................................................23
ON-VEHICLE SERVICE ..................................................7 Power Steering Gear Component .............................23 AT
Steering System ..........................................................7 Pre-disassembly Inspection and Adjustment.............24
Checking and Adjusting Drive Belts (For power Turning Torque Measurement ...............................24
steering) .......................................................................7 Disassembly...............................................................25
TF
Checking Fluid Level (For power steering) .................7 Adjusting Screw Lock Nut O-Ring ........................25
Checking Fluid Leakage (For power steering) ............8 Sector Shaft Oil Seal ............................................25 PD
Bleeding Hydraulic System (For power steering)........8 Rear Housing O-Ring............................................26
Checking Steering Wheel Turning Force (For Rear Cover O-Ring And Oil Seal..........................26
power steering) ............................................................9 Assembly ...................................................................27 FA
Checking Steering Wheel Play....................................9 Adjusting Screw Lock Nut O-Ring ........................27
Checking Neutral Position on Steering Wheel ..........10 Sector Shaft Oil Seal ............................................27
Checking...........................................................10 Sector Shaft End Play...........................................28 RA
Checking Front Wheel Turning Angle........................10 Rear Cover O-Ring And Oil Seal..........................28
Checking Hydraulic System (For power steering).....11 Rear Housing O-Ring............................................28
STEERING WHEEL AND STEERING COLUMN..........12 Sector Shaft ..........................................................29 BR
Steering Wheel ..........................................................12 POWER STEERING SYSTEM (Model: PB59K) ..........30
Removal And Installation ......................................12 Description .................................................................30
Steering Column ........................................................13 POWER STEERING GEAR (Model: PB59K)...............31
ST
Removal ................................................................13 Removal and Installation ...........................................31
Installation .............................................................13 Steering Gear........................................................31 RS
Disassembly and Assembly.......................................14 Power Steering Gear Component .............................31
Tilt mechanism..................................................15 Pre-disassembly Inspection and Adjustment.............32
Inspection...................................................................15 Turning Torque Measurement ...............................32 BT
MANUAL STEERING GEAR (Model: VB66K).............16 Disassembly...............................................................33
Removal and Installation ...........................................16 Assembly ...................................................................34
Disassembly...............................................................17 POWER STEERING OIL PUMP....................................37 HA
Assembly and Adjustment .........................................17 Disassembly and Assembly.......................................37
Worm Gear Bearing Preload ................................17 Pre-disassembly Inspection.......................................37
Sector Shaft End Play...........................................19 Inspection...................................................................38 EL
Steering Gear Preload And Backlash ...................19 Pulley And Pulley Shaft.........................................38
Inspection...................................................................20 Disassembly...............................................................38
Sector Shaft ..........................................................20 Assembly ...................................................................39
IDX
CONTENTS (Cont'd.)
STEERING LINKAGE....................................................40 SERVICE DATA AND SPECIFICATIONS (SDS) ..........43
Removal and Installation ...........................................40 General Specifications...............................................43
Disassembly...............................................................41 Inspection and Adjustment ........................................43
Idler Arm Assembly ...............................................41 Steering Column Length .......................................43
Cross Rod And Tie-Rod ........................................41 Manual Steering Gear
Inspection...................................................................42 (Model: Vb66K) .....................................................44
Ball Joint And Swivel Joint....................................42 Steering Linkage ...................................................44
Idler Arm Assembly ...............................................42 Power Steering System
Cross Rod And Tie-Rod ........................................42 (Model: Pb48S) .....................................................44
Fixing Location ......................................................42 Power Steering System
(Model: Pb59K) .....................................................45
ST-2
PRECAUTIONS AND PREPARATION
Supplemental Restraint System (SRS) GI
``AIR BAG''
The Supplemental Restraint System ``AIR BAG'', used along with a seat belt, helps to reduce the risk or MA
severity of injury to the driver and front passenger in a frontal collision. The Supplemental Restraint System
consists of air bag modules (located in the center of the steering wheel and on the instrument panel on the
passenger side), a diagnosis sensor unit, a crash zone sensor (4WD models), warning lamp, wiring harness EM
and spiral cable.
The vehicle is equipped with a passenger air bag deactivation switch. Because no rear seat exists where a
rear-facing child restraint can be placed, the switch is designed to turn off the passenger air bag so that a LC
rear-facing child restraint can be used in the front passenger seat. The switch is located in the center of the
instrument panel, near the ashtray. When the switch is turned to the ON position, the passenger air bag is
enabled and could inflate in a frontal collision. When the switch is turned to the OFF position, the passenger EC
air bag is disabled and will not inflate in a frontal collision. A passenger air bag OFF indicator on the instru-
ment panel lights up when the passenger air bag is switched OFF. The driver air bag always remains enabled
and is not affected by the passenger air bag deactivation switch. FE
Information necessary to service the system safely is included in the RS section of this Service Manual.
WARNING:
q To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death CL
in the event of a collision which would result in air bag inflation, all maintenance should be per-
formed by an authorized NISSAN dealer.
q Improper maintenance, including incorrect removal and installation of the SRS, can lead to per- MT
sonal injury caused by unintentional activation of the system.
q Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses are covered with yellow insulation either just before the AT
harness connectors or on the complete harness, for easy identification.
q The vehicle is equipped with a passenger air bag deactivation switch which can be operated by
the customer. When the front passenger air bag is switched OFF, the front passenger air bag is TF
disabled and will not inflate in a frontal collision. When the front passenger air bag is switched ON,
the front passenger air bag is enabled and could inflate in a frontal collision. After SRS mainte-
nance or repair, make sure the front passenger air bag switch is in the same position (ON or OFF) PD
as when the vehicle arrived for service.
Precautions for Steering System FA
q Before disassembly, thoroughly clean the outside of the unit.
q Disassembly should be done in a clean work area. It is important to prevent the internal parts from
becoming contaminated by dirt or other foreign matter. RA
q For easier and proper assembly, place disassembled parts in order on a parts rack.
q Use nylon cloths or paper towels to clean the parts; common shop rags can leave lint that might
interfere with their operation. BR
q Before inspection or reassembly, carefully clean all parts with a general purpose, non-flammable
solvent.
q Before assembly, apply a coat of recommended ATF* to hydraulic parts. Petroleum jelly may be ST
applied to O-rings and seals. Do not use any grease.
q Replace all gaskets, seals and O-rings. Avoid damaging O-rings, seals and gaskets during instal-
lation. Perform functional tests whenever designated. RS
*: Genuine NISSAN PSF II or equivalent.
BT
HA
EL
IDX
ST-3
PRECAUTIONS AND PREPARATION
Special Service Tools
The actual shape of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number Unit application
(Kent-Moore No.) Description Manual Power
Tool name steering steering
ST27180001 Removing steering wheel
(J25726-A)
Steering wheel puller
X X
NT544
HT72520000 Removing ball joint and
(J25730-B) swivel joint
Ball joint remover
X X
a: 33 mm (1.30 in)
b: 50 mm (1.97 in)
NT546 r: R11.5 mm (0.453 in)
ST29020001 Removing pitman arm
(J24319-01)
Steering gear arm puller
X X
a: 34 mm (1.34 in)
b: 6.5 mm (0.256 in)
NT694 c: 61.5 mm (2.421 in)
KV48101500 Removing and installing
(J28802) lock nut
Lock nut wrench
X --
a: 73.1 mm (2.878 in)
b: 100 mm (3.94 in)
c: 12 mm (0.47 in)
NT534 d: 60 mm (2.36 in) dia.
KV48101400 Adjusting and tightening
(J28803) lock nut
Adjusting plug wrench
X --
a: 46.7 mm (1.839 in)
b: 8.5 mm (0.335 in) dia.
NT539 c: 7 mm (0.28 in)
KV48100700 Adjusting worm bearing pre-
(J26364) load
Torque adapter
X X
NT169
ST-4
PRECAUTIONS AND PREPARATION
Special Service Tools (Cont'd)
GI
Tool number Unit application
(Kent-Moore No.) Description Manual Power
Tool name steering steering MA
ST3127S000 Measuring turning torque
(see J25765-A) EM
1 GG91030000
(J25765-A)
Torque wrench LC
2 HT62940000 X X
( -- )
Socket adapter EC
3 HT62900000
( -- )
Socket adapter NT541 FE
KV48100301 Steering gear installation.
( -- )
CL
Strut & steering gearbox
attachment
X X
MT
a: 162 mm (6.38 in) AT
b: 110 mm (4.33 in)
c: 190 mm (7.48 in)
NT688 d: 9 mm (0.35 in)
TF
KV48103500 Measuring oil pressure
(J26357 or J26357-10)
Pressure gauge PD
-- X
FA
NT547
RA
KV48102500 Measuring oil pressure
( -- ) (Use with KV48103500)
Pressure gauge adapter BR
-- X
ST
NT542 RS
KV481009S0 Installing oil seal
( -- ) BT
Oil seal drift set
1 KV48100910
( -- ) HA
Drift
-- X
2 KV48100920
(J26367) EL
Adapter
3 KV48100930
(J26367) IDX
Adapter NT174
ST-5
Symptom
X : Applicable
Reference page
(Possible cause)
SUSPECTED PARTS
STEERING
Noise
Shake
Judder
Shimmy
Vibration
X
Fluid level ST-7
X
Air in hydraulic system ST-8
X
Tie rod ball joint swinging force ST-42
X
Tie rod ball joint rotating torque ST-42
X
Tie rod ball joint end play ST-42
X
Steering gear fluid leakage ST-8
X
ST-6
Steering wheel play ST-9
X
Steering gear turning force ST-9
X
Drive belt looseness Refer to MA section
X
X
X
Improper steering wheel --
X
X
X
Improper installation or looseness of tilt lock lever ST-15
X
Steering column deformation or damage ST-15
X
Improper installation or looseness of steering column ST-12
X
X
NVH Troubleshooting Chart
Steering linkage looseness ST-40
X
X
X
PROPELLER SHAFT NVH in PD section
X
DIFFERENTIAL NVH in PD section
X
X
X
DRIVE SHAFT NVH in RA section
X
X
X
X
X
FRONT AXLE AND FRONT SUSPENSION NVH in FA, RA section
X
X
X
X
X
REAR AXLE AND REAR SUSPENSION NVH in RA section
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
X
X
X
X
X
TIRES NVH in FA section
X
X
X
X
ROAD WHEEL NVH in FA section
Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
X
X
X
X
BRAKES NVH in BR section
ON-VEHICLE SERVICE
Steering System GI
MA
EM
LC
EC
FE
CL
MT
AT
TF
PD
FA
AST215
Checking and Adjusting Drive Belts (For power RA
steering)
Refer to MA section (``Checking Drive Belts'', ``ENGINE MAINTE-
NANCE''). BR
ST
RS
BT
Checking Fluid Level (For power steering)
Check fluid level with engine off.
Check fluid level with dipstick on reservoir cap. HA
