Image preview - the first page of the document
>> Download MA documenatation <<
Text preview - extract from the document
MAINTENANCE GI
SECTION MA MA
EM
LC
EC
CONTENTS
FE
PRECAUTIONS AND PREPARATION............................2 Checking Clutch Fluid Level and Leaks....................18
Supplemental Restraint System (SRS) Checking M/T Oil .......................................................18
``AIR BAG'' ...................................................................2 Changing M/T Oil.......................................................18 CL
Special Service Tool ....................................................2 Checking Water Entry................................................18
Commercial Service Tool.............................................2 Checking A/T Fluid ....................................................18
GENERAL MAINTENANCE ............................................3 Changing A/T Fluid ....................................................19 MT
PERIODIC MAINTENANCE ............................................5 Checking Transfer Fluid.............................................19
Schedule 1...................................................................6 Changing Transfer Fluid ............................................20
Schedule 2...................................................................7 Checking Propeller Shaft...........................................20 AT
RECOMMENDED FLUIDS AND LUBRICANTS.............8 Checking Differential Gear Oil...................................20
Fluids and Lubricants ..................................................8 Changing Differential Gear Oil ..................................21
SAE Viscosity Number ................................................9 Balancing Wheels ......................................................21
TF
Antifreeze Coolant Mixture Ratio.................................9 Tire Rotation ..............................................................21
ENGINE MAINTENANCE ..............................................10 Checking Brake Fluid Level and Leaks.....................22 PD
Checking Drive Belts .................................................10 Checking Brake System ............................................22
Changing Engine Coolant..........................................11 Checking Disc Brake .................................................22
Checking Fuel Lines ..................................................13 Checking Drum Brake ...............................................22 FA
Changing Fuel Filter ..................................................13 Checking Steering Gear and Linkage .......................23
Changing Air Cleaner Filter .......................................14 Checking Power Steering Fluid and Lines ................23
Changing Engine Oil..................................................14 Lubricating Hood Latches, Locks and Hinges...........24 RA
Changing Oil Filter.....................................................15 Checking Seat Belts, Buckles, Retractors,
Changing Spark Plugs...............................................15 Anchors and Adjusters...............................................25
Checking EVAP Vapor Lines .....................................17 SERVICE DATA AND SPECIFICATIONS (SDS) ..........26 BR
CHASSIS AND BODY MAINTENANCE .......................18 Engine Maintenance ..................................................26
Checking Exhaust System.........................................18 Chassis and Body Maintenance................................26
ST
RS
BT
HA
EL
IDX
PRECAUTIONS AND PREPARATION
Supplemental Restraint System (SRS)
``AIR BAG''
The Supplemental Restraint System ``AIR BAG'', used along with a seat belt, helps to reduce the risk or
severity of injury to the driver and front passenger in a frontal collision. The Supplemental Restraint System
consists of air bag modules (located in the center of the steering wheel and in the instrument panel on the
passenger side), a diagnosis sensor unit, a crash zone sensor, warning lamp, wiring harness and spiral cable.
The vehicle is equipped with a passenger air bag deactivation switch. Because no rear seat exists where a
rear-facing child restraint can be placed, the switch is designed to turn off the passenger air bag so that a
rear-facing child restraint can be used in the front passenger seat. The switch is located in the center of the
instrument panel, near the ashtray. When the switch is turned to the ON position, the passenger air bag is
enabled and could inflate in a frontal collision. When the switch is turned to the OFF position, the passenger
air bag is disabled and will not inflate in a frontal collision. A passenger air bag OFF indicator on the instru-
ment panel lights up when the passenger air bag is switched OFF. The driver air bag always remains enabled
and is not affected by the passenger air bag deactivation switch.
Information necessary to service the system safely is included in the RS section of this Service Manual.
WARNING:
q To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance should be per-
formed by an authorized NISSAN dealer.
q Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system.
q Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses are covered with yellow insulation either just before the
harness connectors or on the complete harness, for easy identification.
q The vehicle is equipped with a passenger air bag deactivation switch which can be operated by
the customer. When the passenger air bag is switched OFF, the passenger air bag is disabled and
will not inflate in a frontal collision. When the passenger air bag is switched ON, the passenger air
bag is enabled and could inflate in a frontal collision. After SRS maintenance or repair, make sure
the passenger air bag deactivation switch is in the same position (ON or OFF) as when the vehicle
arrived for service.
Special Service Tool
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.) Description
Tool name
KV10105801 Removing oil filter
(J38956)
Oil filter cap wrench
NT375 a: 64.3 mm (2.531 in)
Commercial Service Tool
Tool name
Description
(Kent-Moore No.)
Belt tension guage Checking drive belt tension
AMA126
MA-2
GENERAL MAINTENANCE
General maintenance includes those items which should be checked during the normal day-to-day operation GI
of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform
checks and inspections themselves or they can have their NISSAN dealers do them.
MA
Item Reference page
OUTSIDE THE VEHICLE
The maintenance items listed here should be performed from time to time, unless otherwise EM
specified.
Tires Check the pressure, including the spare, with a gauge periodically when at a service
station, and adjust to the specified pressure if necessary. Check carefully for damage, cuts and -- LC
excessive wear.
Wheel nuts When checking the tires, make sure no nuts are missing, and check for any loose
-- EC
nuts. Tighten if necessary.
Tire rotation Tires should be rotated every 12,000 km (7,500 miles). MA-21
Wheel alignment and balance If the vehicle pulls to either side while driving on a straight and FE
level road, or if you detect uneven or abnormal tire wear, there may be a need for wheel align- MA-21,
ment. If the steering wheel or seat vibrates at normal highway speeds, wheel balancing may be FA-7
needed. CL
Windshield wiper blades Check for cracks and wear if they do not wipe properly. --
Doors and engine hood Check that all doors, engine hood and tailgate operate smoothly. Also MT
make sure that all latches lock securely; lubricate if necessary. Make sure that the secondary
MA-24
latch keeps the hood from opening when the primary latch is released.
When driving in areas using road salt or other corrosive materials, check lubrication frequently. AT
Lamps Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and other
--
lamps are all operating properly and installed securely. Also check headlamp aim.
INSIDE THE VEHICLE
TF
The maintenance items listed here should be checked on a regular basis, such as when per-
forming periodic maintenance, cleaning the vehicle, etc.
PD
Warning lamps and buzzers/chimes Make sure that all warning lamps and buzzers/chimes are
--
operating properly.
Windshield wiper and washer Check that the wipers and washer operate properly and that the FA
--
wipers do not streak.
Windshield defroster Check that the air comes out of the defroster outlets properly and in suffi-
cient quantity when operating the heater or air conditioner.
-- RA
Steering wheel Check that it has the specified play. Be sure to check for changes in the steer-
ing condition, such as excessive play, hard steering or strange noises. ST-7 BR
Free play: Less than 35 mm (1.38 in)
Seats Check seat position controls such as seat adjusters, seatback recliner, etc. to make sure
they operate smoothly and that all latches lock securely in every position. Check that the head ST
--
restraints move up and down smoothly and that the locks (if equipped) hold securely in all
latched positions. Check jump seats for smooth operation.
Seat belts Check that all parts of the seat belt system (e.g., buckles, anchors, adjusters and
RS
MA-25
retractors) operate properly and smoothly and are installed securely. Check the belt webbing for
RS-6
cuts, fraying, wear and damage.
BT
Accelerator pedal Check the pedal for smooth operation and make sure the pedal does not
--
catch or require uneven effort. Keep the floor mats away from the pedal
Clutch pedal Make sure the pedal operates smoothly and check that it has the proper free play. CL-5 HA
Brakes Check that the brakes do not pull the vehicle to one side when applied. --
Brake pedal and booster Check the pedal for smooth operation and make sure that it has the EL
proper distance under it when depressed fully. Check the brake booster function. Be sure to BR-11, 16
keep floor mats away from the pedal.
Parking brake Check that the lever has the proper travel and make sure that the vehicle is held IDX
BR-27
securely on a fairly steep hill when only the parking brake is applied.
MA-3
GENERAL MAINTENANCE
Item Reference page
Automatic transmission ``Park'' mechanism Check that the lock release button on the selec-
tor lever operates properly and smoothly. On a fairly steep hill check that the vehicle is held --
securely with the selector lever in the ``P'' position without applying any brakes.
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g., each time you check
the engine oil or refuel).
Windshield washer fluid Check that there is adequate fluid in the tank. --
Engine coolant level Check the coolant level when the engine is cold. MA-11
Radiator and hoses Check the front of the radiator and clean off any dirt, insects, leaves, etc.,
that may have accumulated. Make sure that the hoses have no cracks, deformation, deteriora- --
tion or loose connections.
Brake and clutch fluid levels Make sure that the brake and clutch fluid levels are between the
MA-18, 22
``MAX'' and ``MIN'' lines on the reservoirs.
Battery Check the fluid level in each cell. It should be between the ``MAX'' and ``MIN'' lines. --
Engine drive belts Make sure that no belt is frayed, worn, cracked or oily. MA-10
Engine oil level Check the level on the dipstick after parking the vehicle on a level spot and
MA-14
turning off the engine.
Power steering fluid level and lines Check the level on the dipstick with the engine off. Check
MA-23
the lines for improper attachment, leaks, cracks, etc.
Automatic transmission fluid level Check the level on the dipstick after putting the selector
MA-18
lever in ``P'' with the engine idling.
Exhaust system Make sure that there are no loose supports, cracks or holes. If the sound of
the exhaust seems unusual or there is a smell of exhaust fumes, immediately locate the trouble MA-18
and correct it.
Underbody The underbody is frequently exposed to corrosive substances such as those used
on icy roads or to control dust. It is very important to remove these substances, otherwise rust
will form on the floor pan, frame, fuel lines and around the exhaust system. At the end of winter, --
the underbody should be thoroughly flushed with plain water, being careful to clean those areas
where mud and dirt can easily accumulate.
Fluid leaks Check under the vehicle for fuel, oil, water and other fluid leaks after the vehicle
has been parked for a while. Water dripping from the air conditioner after use is normal. If any --
leaks or gasoline fumes are evident, check for the cause and correct it immediately.
MA-4
PERIODIC MAINTENANCE
Two different maintenance schedules are provided, and should be used, depending upon the conditions under GI
which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic
maintenance at the same mileage/time intervals.
MA
SCHEDULE 1
Follow Periodic Maintenance Schedule 1 if your driving habits frequently include one or more of the following
driving conditions: EM
q Repeated short trips of less than 5 miles (8 km).
q Repeated short trips of less than 10 miles (16 km) with outside temperatures remaining below freezing.
q Operating in hot weather in stop-and-go ``rush hour'' traffic. LC
q Extensive idling and/or low speed driving for long distances, such as police, taxi or door-to-door delivery
use.
q Driving in dusty conditions. EC
q Driving on rough, muddy, or salt spread roads.
q Towing a trailer, using a camper or a car-top carrier.
FE
SCHEDULE 2
Follow Periodic Maintenance Schedule 2 if none of the driving conditions shown in Schedule 1 apply to your
CL
driving habits.
Maintenance for off-road driving
MT
Whenever you drive off-road through sand, mud or water, more frequent maintenance may be required of the
following items:
Brake pads and rotors
AT
Brake lining and drums
Brake lines and hoses
Wheel bearing grease and free-running hub grease
Differential gear oil, transmission and transfer fluid
TF
Steering linkage
Propeller shaft and drive shafts
Air cleaner filter PD
Clutch housing (Check water entry. Refer to MA-18.)
FA
RA
BR
ST
RS
BT
HA
EL
IDX
MA-5
Abbreviations: R = Replace I = Inspect. Correct or replace if necessary. [ ]: At the mileage intervals only
MAINTENANCE OPERATION MAINTENANCE INTERVAL
Miles x 1,000 3.75 7.5 11.25 15 18.75 22.5 26.25 30 33.75 37.5 41.25 45 48.75 52.5 56.25 60
Perform at number of miles, kilometers or months, Reference page
(km x 1,000) (6) (12) (18) (24) (30) (36) (42) (48) (54) (60) (66) (72) (78) (84) (90) (96)
whichever comes first.
Months 3 6 9 12 15 18 21 24 27 30 33 36 39 42 45 48
Emission control system maintenance
Drive belts I* I* MA-10
Air cleaner filter See NOTE (1) [R] [R] MA-14
EVAP vapor lines I* I* MA-17
Fuel lines I* I* MA-13
Fuel filter See NOTE (2)* MA-13
Engine coolant See NOTE (3) R* MA-11
Engine oil R R R R R R R R R R R R R R R R MA-14
Engine oil filter (Use part No. 15208 31U00 or equivalent) R R R R R R R R R R R R R R R R MA-15
Spark plugs (PLATINUM-TIPPED type) [R] MA-15
Timing belt See NOTE (4)
Chassis and body maintenance
Brake lines & cables I I I I MA-22
Brake pads, rotors, drums & linings I I I I I I I I MA-22
Automatic transmission, transfer fluid & differential gear oil I I I I MA-18, 19, 20
Manual transmission oil R MA-18
MA-6
Schedule 1
Steering gear (box) & linkage, axle & suspension parts I I I I I I I I MA-23, FA-5, RA-4
Tire rotation See NOTE (5) MA-21
Drive shaft boots & propeller shaft I I I I I I I I MA-20, FA-12. PD-9
Front wheel bearing grease & free-running hub grease See NOTE (6) I R I R FA-7, 14, 15
Exhaust system I I I I I I I I MA-18
PERIODIC MAINTENANCE
Air bag system See NOTE (7) RS-12
NOTE: (1) If operating mainly in dusty conditions, more frequent maintenance may be required.
(2) If vehicle is operated under extremely adverse weather conditions or in areas where ambient temperatures are either extremely low or extremely high, the
filters might become clogged. In such an event, replace them immediately.
(3) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(4) Replace every 105,000 miles (169,000 km).
(5) Refer to ``Tire rotation'' under the ``General maintenance'' heading earlier in this section.
(6) If operating frequently in water, replace grease every 3,750 miles (6,000 km) or 3 months.
(7) Inspect the air bag system 10 years after the date of manufacture noted on the FMVSS certification label.
Maintenance items and intervals with ``*'' are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in
order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.
Abbreviations: R = Replace I = Inspect. Correct or replace if necessary. [ ]: At the mileage intervals only
MAINTENANCE OPERATION MAINTENANCE INTERVAL
Miles x 1,000 7.5 15 22.5 30 37.5 45 52.5 60
Reference page
Perform at number of miles, kilometers or months,
whichever comes first. (km x 1,000) (12) (24) (36) (48) (60) (72) (84) (96)
Months 6 12 18 24 30 36 42 48
Emission control system maintenance
Drive belts I* I* MA-10
Air cleaner filter [R] [R] MA-14
EVAP vapor lines I* I* MA-17
Fuel lines I* I* MA-13
Fuel filter See NOTE (1)* MA-13
Engine coolant See NOTE (2) R* MA-11
Engine oil R R R R R R R R MA-14
Engine oil filter (Use part No. 15208 31U00 or equivalent) R R R R R R R R MA-15
Spark plugs (PLATINUM-TIPPED type) [R] MA-15
Timing belt See NOTE (3)
Chassis and body maintenance
Brake lines & cables I I I I MA-22
MA-7
Schedule 2
Brake pads, rotors, drums & linings I I I I MA-22
Automatic transmission, transfer fluid & differential gear oil I I I I MA-18, 19, 20
Manual transmission oil R MA-18
Steering gear (box) & linkage, axle & suspension parts I I MA-23, FA-5, RA-4
Tire rotation See Note (4) MA-21
PERIODIC MAINTENANCE
Drive shaft boots & propeller shaft I I I I MA-20, FA-12, PD-9
Front wheel bearing grease & free-running hub grease I R I R FA-7, 14, 15
Exhaust system I I MA-18
Air bag system See NOTE (5) RS-12
NOTE: (1) If vehicle is operated under extremely adverse weather conditions or in areas where ambient temperatures are either extremely low or extremely high, the
filters might become clogged. In such an event, replace them immediately.
(2) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(3) Replace every 105,000 miles (169,000 km).
(4) Refer to ``Tire rotation'' under the ``General maintenance'' heading earlier in this section.
(5) Inspect the air bag system 10 years after the date of manufacture noted on the FMVSS certification label.
Maintenance items and intervals with ``*'' are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in
order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.
GI
TF
AT
EL
FE
ST
FA
BT
CL
LC
RS
EC
RA
PD
HA
BR
MT
EM
IDX
MA
RECOMMENDED FLUIDS AND LUBRICANTS
Fluids and Lubricants
Capacity (Approximate)
US Imp Recommended Fluids and Lubricants
Liter
measure measure
Engine oil
q API Certification Mark*1
Drain and refill
With oil filter 3-1/2 qt 2-7/8 qt 3.3 q API grade SG/SH Energy Conserving I & II
or API grade SJ, Energy Conserving *1
Without oil filter 3-1/8 qt 2-5/8 qt 3.0
q ILSAC grade GF-I & GF-II *1
Dry engine (engine overhaul) 4 qt 3-3/8 qt 3.8
50% Genuine NISSAN antifreeze coolant or
Cooling system (With reservoir) 11-5/8 qt 9-5/8 qt 10.95 equivalent
50% Demineralized or distilled water
Manual transmission gear oil FS5R30A 10-3/4 pt 9 pt 5.1 API GL-4 Viscosity SAE 75W-90 only
Nissan Matic ``D'' (Continental U.S. and
Alaska) or Canada NISSAN Automatic Trans-
Transfer fluid TX10A 2-3/8 qt 2 qt 2.2
mission Fluid *2
or API GL-4*1
Manual steering fluid 1-3/8 pt 1-1/8 pt 0.62 API GL-4*1, SAE #80
Differential carrier gear oil
Rear: H233B 5-7/8 pt 4-7/8 pt 2.8 Standard differential gear:
Front: R200A 3-1/8 pt 2-5/8 pt 1.5 API GL-5*1
Nissan Matic ``D'' (Continental U.S. and
Automatic transmission fluid 9 qt 7-1/2 qt 8.5 Alaska) or Canada Nissan Automatic Trans-
mission Fluid *2
Power steering fluid PB59K 33.8-37.2 fl oz 35.2-38.7 fl oz 1.0-1.1 Genuine NISSAN PSF II or equivalent *4
Genuine Nissan Brake Fluid*3 or equivalent
Brake and clutch fluid -- -- --
DOT 3 (US FMVSS No. 116)
NLGI No. 2 (Molybdenum disulphide
Propeller shaft grease -- -- --
Lithium soap base)
Multi-purpose grease -- -- -- NLGI No. 2 (Lithium soap base)
Free-running hub grease (Auto-lock) -- -- -- Genuine Nissan grease or equivalent
*1: For further details, see ``SAE Viscosity Number''.
*2: DexronTM III/MerconTM or equivalent may also be used. Outside the continental United States and Alaska contact a NISSAN dealership for more
information regarding suitable fluids, including recommended brand(s) of DexronTM III/MerconTM Automatic Transmission Fluid.
*3: Available in mainland U.S.A. through your Nissan dealer.
*4: Genuine NISSAN PSF, Canada NISSAN Automatic Transmission Fluid, DexronTM III/MerconTM, or equivalent. ATF may also be used.
MA-8
RECOMMENDED FLUIDS AND LUBRICANTS
SAE Viscosity Number GI
MA
EM
LC
EC
FE
CL
MT
AMA157 AMA124
SAE 5W-30 viscosity oil is preferred for all 75W-90 for transfer and 80W-90 for differential AT
temperatures. SAE 10W-30, 10W-40 viscosity oil are preferable if the ambient temperature is
may be used if the ambient temperature is above below 40◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
