Image preview - the first page of the document
>> Download ST documenatation <<
Text preview - extract from the document
STEERING SYSTEM GI
SECTION ST MA
EM
LC
EC
CONTENTS
FE
PRECAUTIONS AND PREPARATION............................2 POWER STEERING GEAR (Model: PB59K)...............16
Supplemental Restraint System (SRS) Removal and Installation ...........................................16
``AIR BAG'' ...................................................................2 Steering Gear........................................................16 CL
Precautions for Steering System.................................2 Power Steering Gear Component .............................16
Special Service Tools ..................................................3 Pre-disassembly Inspection and Adjustment.............17
NOISE, VIBRATION AND HARSHNESS (NVH) Turning Torque Measurement ...............................17 MT
TROUBLESHOOTING .....................................................5 Disassembly...............................................................18
NVH Troubleshooting Chart.........................................5 Assembly ...................................................................19
ON-VEHICLE SERVICE ..................................................6 POWER STEERING OIL PUMP....................................22 AT
Steering System ..........................................................6 Disassembly and Assembly.......................................22
Checking and Adjusting Drive Belts ............................6 Pre-disassembly Inspection.......................................22
Checking Fluid Level ...................................................6 Inspection...................................................................23
TF
Checking Fluid Leakage ..............................................7 Pulley And Pulley Shaft.........................................23
Bleeding Hydraulic System..........................................7 Disassembly...............................................................23 PD
Checking Steering Wheel Turning Force ....................8 Assembly ...................................................................24
Checking Steering Wheel Play....................................8 STEERING LINKAGE....................................................25
Checking Neutral Position on Steering Wheel ............9 Removal and Installation ...........................................25 FA
Checking.............................................................9 Disassembly...............................................................26
Checking Front Wheel Turning Angle..........................9 Idler Arm Assembly ...............................................26
Checking Hydraulic System.......................................10 Cross Rod And Tie-Rod ........................................26 RA
STEERING WHEEL AND STEERING COLUMN..........11 Inspection...................................................................27
Steering Wheel ..........................................................11 Ball Joint And Swivel Joint....................................27
Removal And Installation ......................................11 Idler Arm Assembly ...............................................27 BR
Steering Column ........................................................12 Cross Rod And Tie-Rod ........................................27
Removal ................................................................12 Fixing Location ......................................................27
Installation .............................................................12 SERVICE DATA AND SPECIFICATIONS (SDS) ..........28
ST
Disassembly and Assembly.......................................13 General Specifications...............................................28
Tilt mechanism..................................................14 Inspection and Adjustment ........................................28 RS
Inspection...................................................................14 Steering Column Length .......................................28
POWER STEERING SYSTEM (Model: PB59K) ..........15 Steering Linkage ...................................................28
Description .................................................................15 Power Steering System (Model: Pb59K) ..............28 BT
HA
EL
IDX
PRECAUTIONS AND PREPARATION
Supplemental Restraint System (SRS)
``AIR BAG''
The Supplemental Restraint System ``AIR BAG'', used along with a seat belt, helps to reduce the risk or
severity of injury to the driver and front passenger in a frontal collision. The Supplemental Restraint System
consists of air bag modules (located in the center of the steering wheel and on the instrument panel on the
passenger side), a diagnosis sensor unit, a crash zone sensor, warning lamp, wiring harness and spiral cable.
The vehicle is equipped with a passenger air bag deactivation switch. Because no rear seat exists where a
rear-facing child restraint can be placed, the switch is designed to turn off the passenger air bag so that a
rear-facing child restraint can be used in the front passenger seat. The switch is located in the center of the
instrument panel, near the ashtray. When the switch is turned to the ON position, the passenger air bag is
enabled and could inflate in a frontal collision. When the switch is turned to the OFF position, the passenger
air bag is disabled and will not inflate in a frontal collision. A passenger air bag OFF indicator on the instru-
ment panel lights up when the passenger air bag is switched OFF. The driver air bag always remains enabled
and is not affected by the passenger air bag deactivation switch.
Information necessary to service the system safely is included in the RS section of this Service Manual.
WARNING:
q To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance should be per-
formed by an authorized NISSAN dealer.
q Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system.
q Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses are covered with yellow insulation either just before the
harness connectors or on the complete harness, for easy identification.
q The vehicle is equipped with a passenger air bag deactivation switch which can be operated by
the customer. When the passenger air bag is switched OFF, the passenger air bag is disabled and
will not inflate in a frontal collision. When the passenger air bag is switched ON, the passenger air
bag is enabled and could inflate in a frontal collision. After SRS maintenance or repair, make sure
the passenger air bag switch is in the same position (ON or OFF) as when the vehicle arrived for
service.
Precautions for Steering System
q Before disassembly, thoroughly clean the outside of the unit.
q Disassembly should be done in a clean work area. It is important to prevent the internal parts from
becoming contaminated by dirt or other foreign matter.
q For easier and proper assembly, place disassembled parts in order on a parts rack.
q Use nylon cloths or paper towels to clean the parts; common shop rags can leave lint that might
interfere with their operation.
q Before inspection or reassembly, carefully clean all parts with a general purpose, non-flammable
solvent.
q Before assembly, apply a coat of recommended ATF* to hydraulic parts. Petroleum jelly may be
applied to O-rings and seals. Do not use any grease.
q Replace all gaskets, seals and O-rings. Avoid damaging O-rings, seals and gaskets during instal-
lation. Perform functional tests whenever designated.
*: Genuine NISSAN PSFII or equivalent.
ST-2
PRECAUTIONS AND PREPARATION
Special Service Tools GI
The actual shape of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number MA
(Kent-Moore No.) Description
Tool name
EM
ST27180001 Removing steering wheel
(J25726-A)
Steering wheel puller LC
EC
NT544
FE
HT72520000 Removing ball joint and swivel joint
(J25730-B)
Ball joint remover CL
a: 33 mm (1.30 in)
b: 50 mm (1.97 in) MT
NT546 r: R11.5 mm (0.453 in)
ST29020001 Removing pitman arm
AT
(J24319-01)
Steering gear arm puller
TF
PD
a: 34 mm (1.34 in)
b: 6.5 mm (0.256 in)
NT694 c: 61.5 mm (2.421 in)
FA
ST3127S000 Measuring turning torque
(see J25765-A)
1 GG91030000
RA
(J25765-A)
Torque wrench
2 HT62940000
( -- )
BR
Socket adapter
3 HT62900000
( -- )
ST
Socket adapter NT541
KV48100301 Steering gear installation RS
( -- )
Strut & steering gearbox attachment
BT
HA
a: 162 mm (6.38 in)
b: 110 mm (4.33 in)
c: 190 mm (7.48 in) EL
NT688 d: 9 mm (0.35 in)
IDX
ST-3
PRECAUTIONS AND PREPARATION
Special Service Tools (Cont'd)
Tool number
(Kent-Moore No.) Description
Tool name
KV48103500 Measuring oil pressure
(J26357 or J26357-10)
Pressure gauge
NT547
KV48102500 Measuring oil pressure
( -- ) (Use with KV48103500)
Pressure gauge adapter
NT542
KV481009S0 Installing oil seal
( -- )
Oil seal drift set
1 KV48100910
( -- )
Drift
2 KV48100920
(J26367)
Adapter
3 KV48100930
(J26367)
Adapter NT174
KV48100700 Adjusting worm bearing preload
(J26364)
Torque adapter
NT169
ST-4
Symptom
X : Applicable
Reference page
(Possible cause)
SUSPECTED PARTS
STEERING
Noise
Shake
Judder
Shimmy
Vibration
X
Fluid level ST-6
X
Air in hydraulic system ST-7
X
Tie rod ball joint swinging force ST-27
X
Tie rod ball joint rotating torque ST-27
X
Tie rod ball joint end play ST-27
X
Steering gear fluid leakage ST-7
X
ST-5
Steering wheel play ST-8
X
Steering gear turning force ST-8
X
Drive belt looseness Refer to MA section
X
X
X
Improper steering wheel --
X
X
X
Improper installation or looseness of tilt lock lever ST-14
X
Steering column deformation or damage ST-14
X
Improper installation or looseness of steering column ST-11
X
X
NVH Troubleshooting Chart
Steering linkage looseness ST-25
X
X
X
PROPELLER SHAFT NVH in PD section
X
DIFFERENTIAL NVH in PD section
X
X
X
DRIVE SHAFT NVH in RA section
X
X
X
X
X
FRONT AXLE AND FRONT SUSPENSION NVH in FA, RA section
X
X
X
X
X
REAR AXLE AND REAR SUSPENSION NVH in RA section
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
X
X
X
X
X
TIRES NVH in FA section
X
X
X
X
ROAD WHEEL NVH in FA section
Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
X
X
X
X
BRAKES NVH in BR section
GI
TF
AT
EL
FE
FA
BT
CL
LC
RS
EC
ST
RA
PD
HA
BR
MT
EM
MA
IDX
ON-VEHICLE SERVICE
Steering System
AST232
Checking and Adjusting Drive Belts
Refer to MA section (``Checking Drive Belts'', ``ENGINE MAINTE-
NANCE'').
Checking Fluid Level
q Check fluid level with engine off.
q Check fluid level on reservoir. Use ``HOT'' range at fluid tem-
peratures of 50 to 80◦ Jabse Service Manual Search 2025 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
