Image preview - the first page of the document
AP


>> Download AP documenatation <<

Text preview - extract from the document
I BODY

                                                                                                                                                           A




                                                                                                SECTION
                                                                                          ADJUSTABLE PEDAL
                                                                                                                         AP                                B



                                                                                                                                                           C



                                                                                                                                                           D



                                                                                                                                                           E
                                                               CONTENTS
PRECAUTIONS ......................................................... 2
                                                                     .         ADJUSTABLE PEDAL SYSTEM ............................... 3         .         F
 Precautions for Supplemental Restraint System                                  Automatic Drive Positioner Adjustable Pedal .......... 3         .
 (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                        Adjustable Pedal (Only Manual Operation Model) 3                 .....
 SIONER" ................................................................. 2
                                                                     .          Trouble Diagnosis .................................................... 7
                                                                                                                                                 .         G
 Trouble Diagnosis Precaution ................................. 2    .          Removal and Installation ....................................... 13
                                                                                                                                                 .


                                                                                                                                                           H



                                                                                                                                                           AP



                                                                                                                                                            J



                                                                                                                                                           K


                                                                                                                                                           L



                                                                                                                                                           M




Revision: November 2005                                                   AP-1                                                     2005 Pathfinder
                                              PRECAUTIONS

PRECAUTIONS                                                         PFP:00001

Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER"                                                                                            EIS0046I


The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
G    To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
     in the event of a collision which would result in air bag inflation, all maintenance must be per-
     formed by an authorized NISSAN/INFINITI dealer.
G    Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
     sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
     Bag Module, see the SRS section.
G    Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
     Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
     harness connectors.
Trouble Diagnosis Precaution                                                                                   EIS0046J


When you read wiring diagrams, refer to the following:
G  GI-15, "How to Read Wiring Diagrams"
G  PG-4, "POWER SUPPLY ROUTING CIRCUIT"
When you perform trouble diagnosis, refer to the following:
G  GI-11, "HOW TO FOLLOW TEST GROUPS IN TROUBLE DIAGNOSES"
G  GI-27, "How to Perform Efficient Diagnosis for an Electrical Incident"
Check for any service bulletins before servicing the vehicle.




Revision: November 2005                               AP-2                                         2005 Pathfinder
                                 ADJUSTABLE PEDAL SYSTEM

ADJUSTABLE PEDAL SYSTEM                                                                              PFP:98800
                                                                                                                          A
Automatic Drive Positioner Adjustable Pedal                                                                EIS0046K


For automatic drive positioner adjustable pedal, refer to SE-11, "AUTOMATIC DRIVE POSITIONER" .
                                                                                                                          B
Adjustable Pedal (Only Manual Operation Model)                                                                 EIS0046L

COMPONENT PARTS AND HARNESS CONNECTOR LOCATION
                                                                                                                          C



                                                                                                                          D



                                                                                                                          E



                                                                                                                          F



                                                                                                                          G


                                                                                                                          H



                                                                                                                          AP



                                                                                                                           J


                                                                                                   LIIA2213E

                                                                                                                          K
SYSTEM DESCRIPTION
The adjustable pedal system power supply is controlled by the pedal adjusting control unit.
Power is supplied at all times
                                                                                                                          L
G   through 50A fusible link (letter g , located in the fuse and fusible link box)
G   to circuit breaker-2 terminal 2
G   through circuit breaker-2 terminal 1                                                                                  M
G   to pedal adjusting control unit terminal 5.
With the ignition switch in ON or START, power is supplied
G   through 10A fuse [No. 12, located in the fuse block (J/B)]
G   to pedal adjusting control unit terminal 4.
Ground is supplied
G   to pedal adjusting switch terminal 4
G   to pedal adjusting control unit terminal 1
G   through body grounds M57, M61 and M79.
When the A/T selector lever is in P position, ground is supplied
G   to pedal adjusting control unit terminal 3
G   through A/T device terminal 4
G   through A/T device terminal 2
G   through body grounds M57, M61 and M79.
Then pedal adjusting control unit recognizes that the A/T selector lever is in P position.

Revision: November 2005                            AP-3                                       2005 Pathfinder
                              ADJUSTABLE PEDAL SYSTEM

With power supplied, pedal adjusting switch is energized.
When pedal is adjusted forward, power is supplied
G   through pedal adjusting switch terminal 3
G   to pedal adjusting motor terminal 1.
Then ground is supplied
G   to pedal adjusting motor terminal 2
G   through pedal adjusting switch terminal 2
G   through pedal adjusting switch terminal 4
G   through body grounds M57, M61 and M79.
When power and ground are supplied, accelerator and brake pedals move forward.
When pedal is adjusted backward, power is supplied
G   through pedal adjusting switch terminal 2
G   to pedal adjusting motor terminal 2.
Then ground is supplied
G   to pedal adjusting motor terminal 1
G   through pedal adjusting switch terminal 3
G   through pedal adjusting switch terminal 4
G   through body grounds M57, M61 and M79.
When power and ground are supplied, accelerator and brake pedals move backward.




Revision: November 2005                        AP-4                               2005 Pathfinder
                          ADJUSTABLE PEDAL SYSTEM

WIRING DIAGRAM -- PEDAL --
                                                                      A



                                                                      B



                                                                      C



                                                                      D



                                                                      E



                                                                      F



                                                                      G


                                                                      H



                                                                      AP



                                                                       J



                                                                      K


                                                                      L



                                                                      M




                                                         WIWA1025E




Revision: November 2005            AP-5             2005 Pathfinder
                          ADJUSTABLE PEDAL SYSTEM




                                                         WIWA0523E




Revision: November 2005            AP-6             2005 Pathfinder
                                     ADJUSTABLE PEDAL SYSTEM

TERMINAL AND REFERENCE VALUE FOR PEDAL ADJUSTING CONTROL UNIT
     TERMI-    WIRE                                                                                             VOLTAGE (V)
                                                                                                                                       A
                                         ITEM                                    CONDITON
      NAL     COLOR                                                                                               (Approx.)
       1         B     Ground                                                         --                              0
                                                                                                                                       B
                                                                  A/T selector lever in other than P position   Battery voltage
       3        SB     A/T device (park position switch) signal
                                                                  A/T selector lever in P position                    0
       4       W/G     Ignition switch (ON or START)              Ignition switch (ON or START position)        Battery voltage        C
       5        W      Battery power supply                                           --                        Battery voltage
                                                                  Ignition switch ON
                                                                                                                      0
                       Pedal adjusting switch power supply out-   A/T selector lever in other than P position                          D
       7        GR
                       put                                        Ignition switch ON
                                                                                                                Battery voltage
                                                                  A/T selector lever in P position
                                                                                                                                       E
Trouble Diagnosis                                                                                                           EIS0046M

WORK FLOW
1.    Check the symptom and customer's requests.
                                                                                                                                       F
2.    Perform the preliminary check. Refer to AP-7, "PRELIMINARY CHECK" .
3.    According to the trouble diagnosis chart, repair or replace the cause of the malfunction. Refer to AP-8,
      "TROUBLE DIAGNOSIS CHART BY SYMPTOM" .
                                                                                                                                       G
4.    Does adjustable pedal system operate normally?
      YES: GO TO 5.
      NO: GO TO 3.
                                                                                                                                       H
5.    Inspection End.
PRELIMINARY CHECK
1. CHECK ADJUSTABLE PEDAL MECHANISM                                                                                                    AP

Check the following.
G   Movable part of accelerator pedal or brake pedal is deformed, or there is foreign material in it.                                   J
G   Accelerator pedal or brake pedal is deformed or broken.
OK or NG
  OK    >> Preliminary check is OK.                                                                                                    K
  NG    >> Repair or replace the malfunctioning part and check again.

                                                                                                                                       L



                                                                                                                                       M




Revision: November 2005                                     AP-7                                                2005 Pathfinder
                                            ADJUSTABLE PEDAL SYSTEM

TROUBLE DIAGNOSIS CHART BY SYMPTOM
NOTE:
Always check the WORK FLOW before troubleshooting. Refer to AP-7, "WORK FLOW" .
                      Symptom                                           Diagnosis / service procedure                      Reference page
                                                      1. Pedal adjusting control unit power supply and ground circuit
                                                                                                                                AP-9
                                                      inspection.
                                                      2. Pedal adjusting switch power supply and ground circuit inspec-
     Adjustable pedal system does not operate.                                                                                 AP-11
                                                      tion.
                                                      3. Pedal adjusting motor circuit inspection.                             AP-12
                                                      4. Replace pedal adjusting motor.                                        AP-13
                                                      1. A/T device circuit inspection.                                        AP-10
     Adjustable pedal system does operate when
     ignition switch is turned ON and A/T selector    2. Pedal adjusting control unit ignition signal inspection.               AP-8
            lever is in other than P position.
                                                      3. Replace pedal adjusting control unit.                                   --
      Adjustable pedal system does not operate
      when ignition switch is turned ON and A/T       1. A/T device circuit inspection.                                        AP-10
            selector lever is in P position.

PEDAL ADJUSTING CONTROL UNIT IGNITION SIGNAL INSPECTION
1. CHECK FUSE
Check 10A fuse [No. 12, located in fuse block (J/B)].
NOTE:
Refer to AP-3, "COMPONENT PARTS AND HARNESS CONNECTOR LOCATION" .
OK or NG
 OK      >> GO TO 2.
 NG      >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-
            4, "POWER SUPPLY ROUTING CIRCUIT" .

2. CHECK PEDAL ADJUSTING CONTROL UNIT IGNITION POWER SUPPLY CIRCUIT
1.     Turn ignition switch OFF.
2.     Disconnect pedal adjusting control unit.
3.     Check voltage between pedal adjusting control unit connector
       M14 terminal 4 and ground.

 Connector                 Terminal                                        Voltage (V)
                                                     Condition
                     (+)              (
