Image preview - the first page of the document
RFD


>> Download RFD documenatation <<

Text preview - extract from the document
D DRIVELINE/AXLE

                                                                                                                                                           A




                                                                                  SECTION                  RFD
                                                                                               REAR FINAL DRIVE
                                                                                                                                                           B



                                                                                                                                                           C



                                                                                                                                                           RFD



                                                                                                                                                           E
                                                                CONTENTS
PRECAUTIONS ......................................................... 2
                                                                      .         REAR FINAL DRIVE ASSEMBLY ........................... 13          .        F
  Precautions for Servicing Rear Final Drive ............. 2          .          Removal and Installation ....................................... 13
                                                                                                                                                  .
PREPARATION .......................................................... 3
                                                                      .            COMPONENTS .................................................. 13
                                                                                                                                                  .
  Special Service Tools .............................................. 3
                                                                      .            REMOVAL .......................................................... 14
                                                                                                                                                  .        G
  Commercial Service Tools ....................................... 6  .            INSTALLATION .................................................. 15
                                                                                                                                                  .
NOISE, VIBRATION AND HARSHNESS (NVH)                                             Disassembly and Assembly ................................... 16  .
TROUBLESHOOTING ............................................... 7     .            COMPONENTS .................................................. 16
                                                                                                                                                  .
                                                                                                                                                           H
  NVH Troubleshooting Chart .................................... 7    .            ASSEMBLY INSPECTION AND ADJUSTMENT 17                          ...
DESCRIPTION ........................................................... 8
                                                                      .            DISASSEMBLY .................................................. 20
                                                                                                                                                  .
  Cross-Sectional View .............................................. 8
                                                                      .            INSPECTION AFTER DISASSEMBLY ............... 24                .
DIFFERENTIAL GEAR OIL ....................................... 9       .            ADJUSTMENT AND SELECTION ADJUSTING                                       I
  Changing Differential Gear Oil ................................ 9   .            WASHERS ......................................................... 25
                                                                                                                                                  .
   DRAINING ............................................................ 9
                                                                      .            ASSEMBLY ........................................................ 30
                                                                                                                                                  .
   FILLING ................................................................ 9
                                                                      .         SERVICE DATA AND SPECIFICATIONS (SDS) ..... 36                    .        J
  Checking Differential Gear Oil ................................. 9  .          General Specifications ........................................... 36
                                                                                                                                                  .
   OIL LEAKAGE AND OIL LEVEL .......................... 9             .          Inspection and Adjustment .................................... 36.
FRONT OIL SEAL ................................................... 10 .            DRIVE GEAR RUNOUT ..................................... 36     .
                                                                                                                                                           K
  Removal and Installation ....................................... 10 .            DIFFERENTIAL SIDE GEAR CLEARANCE ...... 36                     .
   REMOVAL .......................................................... 10
                                                                      .            PRELOAD TORQUE .......................................... 36   .
   INSTALLATION ...................................................11 .            BACKLASH ........................................................ 36
                                                                                                                                                  .
SIDE OIL SEAL ....................................................... 12
                                                                      .            COMPANION FLANGE RUNOUT ...................... 36              .        L
  Removal and Installation ....................................... 12 .            SELECTIVE PARTS ........................................... 36 .
   REMOVAL .......................................................... 12
                                                                      .
   INSTALLATION .................................................. 12 .                                                                                    M




Revision: November 2005                                                  RFD-1                                                     2005 Pathfinder
                                             PRECAUTIONS

PRECAUTIONS                                                                                             PFP:00001

Precautions for Servicing Rear Final Drive                                                                  EDS001M2


G   Before starting diagnosis of the vehicle, understand the symptoms well. Perform correct and systematic
    operations.
G   Check for the correct installation status prior to removal or disassembly. When matching marks are
    required, be certain they do not interfere with the function of the parts they are applied to.
G   Overhaul should be done in a clean work area, a dust proof area is recommended.
G   Before disassembly, completely remove sand and mud from the exterior of the unit, preventing them from
    entering into the unit during disassembly or assembly.
G   Always use shop paper for cleaning the inside of components.
G   Avoid using cotton gloves or a shop cloth to prevent the entering of lint.
G   Check appearance of the disassembled parts for damage, deformation, and abnormal wear. Replace
    them with new ones if necessary.
G   Gaskets, seals and O-rings should be replaced any time the unit is disassembled.
G   Clean and flush the parts sufficiently and blow them dry.
G   Be careful not to damage sliding surfaces and mating surfaces.
G   When applying sealant, remove the old sealant from the mounting surface; then remove any moisture, oil,
    and foreign materials from the application and mounting surfaces.
G   In principle, tighten nuts or bolts gradually in several steps working diagonally from inside to outside. If a
    tightening sequence is specified, observe it.
G   During assembly, observe the specified tightening torque.
G   Add new differential gear oil, petroleum jelly, or multi-purpose grease, as specified.




Revision: November 2005                             RFD-2                                         2005 Pathfinder
                                                       PREPARATION

PREPARATION                                                                                                                      PFP:00002
                                                                                                                                                A
Special Service Tools                                                                                                                EDS001M3

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
  Tool number
                                                                                                                                                B
  (Kent-Moore No.)                                                                       Description
  Tool name
  KV40104000                                                                             Removing and installing drive pinion lock nut
  (    --    )                                                                           a: 85 mm (3.35 in) dia.                                C
  Flange wrench                                                                          b: 65 mm (2.56 in) dia.


                                                                                                                                                RFD

                                                                        NT659


  KV381054S0                                                                             Removing front oil seal                                E
  (J-34286)
  Puller

                                                                                                                                                F


                                                                        ZZA0601D
                                                                                                                                                G
  ST30720000                                                                             G   Installing front oil seal
  (J-25405)                                                                              G   Installing pinion rear bearing outer race
  Drift
                                                                                         a: 77 mm (3.03 in) dia.                                H
                                                                                         b: 55.5 mm (2.185 in) dia.



                                                                        ZZA0811D                                                                 I
  KV40104100                                                                             Removing side flange
  (    --    )
  Attachment                                                                                                                                    J



                                                                                                                                                K
                                                                        ZZA0804D


  ST36230000                                                                             Removing side flange
  (J-25840-A)                                                                                                                                   L
  Sliding hammer


                                                                                                                                                M

                                                                        ZZA0803D


  KV38100200                                                                             Installing side oil seal
  (J-26233)                                                                              a: 65 mm (2.56 in) dia.
  Drift                                                                                  b: 49 mm (1.93 in) dia.




                                                                        ZZA1143D


  KV38107900                                                                             Installing side flange
  (J-39352)
  Protector




                                                                        S-NT129




Revision: November 2005                                        RFD-3                                                     2005 Pathfinder
                                         PREPARATION

  Tool number
  (Kent-Moore No.)                                          Description
  Tool name
  KV38100800                                                Fixing unit assembly
  (J-25604-01)                                              a: 541 mm (21.30 in)
  Attachment                                                b: 200 mm (7.87 in)




                                                SDIA0267E


  ST3127S000                                                Measuring pinion bearing preload and total
  (J-25765-A)                                               preload
  Preload gauge
  1: GG91030000
     (J-25765)
     Torque wrench
  2: HT62940000
     (    --    )
     Socket adapter (1/2)
  3: HT62900000                                 NT124

     (    --    )
     Socket adapter (3/8)
  KV10111100                                                Removing rear cover
  (J-37228)
  Seal cutter




                                                S-NT046


  ST3306S001                                                Removing and installing side bearing inner
  (     --      )                                           race
  Differential side bearing puller set                        a: 28.5 mm (1.122 in) dia.
  1: ST33051001                                               b: 38 mm (1.50 in) dia.
     (J-22888-20)
     Puller
  2: ST33061000
     (J-8107-2)
                                                NT072
     Base
  ST30031000                                                Removing pinion rear bearing inner race
  (J-22912-01)
  Puller




                                                ZZA0700D


  KV40105230                                                Installing pinion rear bearing outer race
  (     -- )                                                a: 92 mm (3.62 in) dia.
  Drift                                                     b: 86 mm (3.39 in) dia.
                                                            c: 45 mm (1.77 in) dia.



                                                PDIA0591E


  ST30613000                                                Installing pinion front bearing outer race
  (J-25742-3)                                               a: 72 mm (2.83 in) dia.
  Drift                                                     b: 48 mm (1.89 in) dia.




                                                ZZA1000D



Revision: November 2005                     RFD-4                                         2005 Pathfinder
                                    PREPARATION

  Tool number
  (Kent-Moore No.)                                    Description                                       A
  Tool name
  ST30611000                                          Installing pinion front bearing outer race (Use
  (J-25742-1)                                         with ST30613000)                                  B
  Drift bar


                                                                                                        C

                                           S-NT090


  ST30901000                                          Installing pinion rear bearing inner race         RFD
  (J-26010-01)                                        a: 79 mm (3.11 in) dia.
  Drift                                               b: 45 mm (1.77 in) dia.
                                                      c: 35.2 mm (1.386 in) dia.
                                                                                                        E

                                           ZZA0978D


  KV38100300                                          Installing side bearing inner race                F
  (J-25523)                                           a: 54 mm (2.13 in) dia.
  Drift                                               b: 46 mm (1.81 in) dia.
                                                      c: 32 mm (1.26 in) dia.                           G


                                           ZZA1046D                                                     H
  (J-8129)                                            Measuring turning torque
  Spring gauge
                                                                                                         I


                                                                                                        J
                                           NT127


  (J-34309)                                           Adjusting bearing preload and pinion gear
  Differential shim selector tool                     height
                                                                                                        K


                                                                                                        L
                                           NT134


  (J-25269-4)                                         Selecting pinion height adjusting washer
  Side bearing disc (2 Req'd)                                                                           M




                                           NT136




Revision: November 2005                RFD-5                                        2005 Pathfinder
                           PREPARATION

Commercial Service Tools                                                                   EDS001M4


  Tool name                                   Description
  Spacer                                      Installing pinion front bearing inner race
                                              a: 60 mm (2.36 in) dia.
                                              b: 36 mm (1.42 in) dia.
                                              c: 30 mm (1.18 in)



                                  ZZA1133D


  Power tool                                  Loosening nuts and bolts




                                  PBIC0190E




Revision: November 2005       RFD-6                                         2005 Pathfinder
