Image preview - the first page of the document
gw


>> Download gw documenatation <<

Text preview - extract from the document
I BODY

                                                                                                                                                               A


                                                                                                                                                               B
                                                                                         SECTION
                            GLASSES, WINDOW SYSTEM & MIRRORS                                                                                                   C


                                                                                                                                                               D


                                                                                                                                                               E
                                                                CONTENTS
PRECAUTIONS ......................................................... 3
                                                                      .          CAN Communication System Description ............. 19                .        F
 Precautions for Supplemental Restraint System                                   Schematic .............................................................. 20
                                                                                                                                                      .
 (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                         Wiring Diagram -- WINDOW -- ............................ 21          .
 SIONER" ................................................................. 3
                                                                      .          Terminal and Reference Value for Main Power Win-                              G
 Handling for Adhesive and Primer .......................... 3        .          dow and Door Lock/Unlock Switch ........................ 26          .
PREPARATION .......................................................... 4
                                                                      .          Terminal and Reference Value for BCM ................ 27             .
 Special Service Tool ................................................ 4
                                                                      .          Work Flow .............................................................. 27
                                                                                                                                                      .
                                                                                                                                                               H
 Commercial Service Tool ........................................ 4   .          CONSULT-II Function (BCM) ................................ 27        .
SQUEAK AND RATTLE TROUBLE DIAGNOSES..... 5                                         CONSULT-II INSPECTION PROCEDURE ......... 27                       .
 Work Flow ............................................................... 5
                                                                      .            ACTIVE TEST .................................................... 28.
   CUSTOMER INTERVIEW .................................... 5          .            WORK SUPPORT .............................................. 28     .        GW
   DUPLICATE THE NOISE AND TEST DRIVE ...... 6                        .            DATA MONITOR ................................................ 28   .
   CHECK RELATED SERVICE BULLETINS .......... 6                       .          Trouble Diagnoses Symptom Chart ...................... 29            .
   LOCATE THE NOISE AND IDENTIFY THE                                             BCM Power Supply and Ground Circuit Check ..... 29                   .        J
   ROOT CAUSE ..................................................... 6 .          Main Power Window and Door Lock/Unlock Switch
   REPAIR THE CAUSE .......................................... 6      .          Power Supply and Ground Circuit Check .............. 30              .
   CONFIRM THE REPAIR ...................................... 7        .          Front Power Window Motor LH Circuit Check ....... 31                 .
                                                                                                                                                               K
 Generic Squeak and Rattle Troubleshooting .......... 7               .          Front Power Window RH Circuit Check (Power Win-
   INSTRUMENT PANEL ......................................... 7       .          dow and Door Lock/Unlock Switch RH Operation) 32                     ...
   CENTER CONSOLE ............................................ 7      .          Front Power Window RH Circuit Check (Main Power
   DOORS ................................................................ 7
                                                                      .          Window and Door Lock/Unlock Switch Operation) 36                     ...      L
   TRUNK ................................................................. 8
                                                                      .          Limit Switch Circuit Check Front LH ...................... 38        .
   SUNROOF/HEADLINING .................................... 8          .          Encoder Circuit Check Front LH ............................ 40       .
   OVERHEAD CONSOLE (FRONT AND REAR)..... 8                                      Door Switch Check ................................................ 43.        M
   SEATS .................................................................. 8
                                                                      .          Rear Power Window LH Circuit Check (Rear Power
   UNDERHOOD ...................................................... 8 .          Window Switch LH Operation) ............................... 44       .
 Diagnostic Worksheet ............................................. 9 .          Rear Power Window LH Circuit Check (Main Power
WINDSHIELD GLASS ..............................................11     .          Window and Door Lock/Unlock Switch Operation) 48                     ...
 Removal and Installation ........................................11  .          Rear Power Window RH Circuit Check (Rear Power
   REMOVAL ...........................................................11
                                                                      .          Window Switch RH Operation) .............................. 50        .
   INSTALLATION ...................................................11 .          Rear Power Window RH Circuit Check (Main Power
POWER WINDOW SYSTEM ................................... 15            .          Window and Door Lock/Unlock Switch Operation) 53                     ...
 Component Parts and Harness Connector Location 15                    ...        Rear Power Window Motor LH Circuit Check ........ 55                 .
 System Description ............................................... 15.          Rear Power Window Motor RH Circuit Check ....... 56                  .
   MANUAL OPERATION ...................................... 16         .         FRONT DOOR GLASS AND REGULATOR ............ 57                        .
   AUTO OPERATION ........................................... 18      .          Front Door Glass ................................................... 57
                                                                                                                                                      .
   POWER WINDOW LOCK .................................. 18            .            REMOVAL .......................................................... 57
                                                                                                                                                      .
   RETAINED POWER OPERATION ..................... 18                  .            INSTALLATION .................................................. 57 .




Revision: September 2005                                                  GW-1                                                        2006 Pathfinder
    FITTING INSPECTION ....................................... 57  .         Schematic ..............................................................72
                                                                                                                                                  .
  Front Door Glass Regulator ................................... 58.         Wiring Diagram -- DEF -- .....................................73     .
    REMOVAL .......................................................... 58
                                                                   .         Terminal and Reference Value for BCM .................76             .
    DISASSEMBLY AND ASSEMBLY ...................... 58             .         Terminal and Reference Value for IPDM E/R .........76                .
    INSPECTION AFTER REMOVAL ....................... 58            .         Work Flow ..............................................................76
                                                                                                                                                  .
    INSTALLATION ................................................... 59
                                                                   .         CONSULT-II Function (BCM) .................................77        .
    SETTING AFTER INSTALLATION ..................... 60            .           CONSULT-II BASIC OPERATION PROCEDURE
REAR DOOR GLASS AND REGULATOR .............. 61                    .                                                                              ...77
  Rear Door Glass .................................................... 61
                                                                   .           DATA MONITOR .................................................78   .
    REMOVAL .......................................................... 61
                                                                   .           ACTIVE TEST .....................................................78.
    INSTALLATION ................................................... 61
                                                                   .         Trouble Diagnoses Symptom Chart .......................78            .
    FITTING INSPECTION ....................................... 61  .         BCM Power Supply and Ground Circuit Check .....79                    .
  Rear Door Glass Regulator ................................... 62 .         Rear Window Defogger Switch Circuit Check ........79                 .
    REMOVAL .......................................................... 62
                                                                   .         Rear Window Defogger Circuit Check ...................80             .
    INSPECTION AFTER REMOVAL ....................... 62            .         Door Mirror Defogger Power Supply Circuit Check...81
    INSTALLATION ................................................... 63
                                                                   .         Door Mirror LH Defogger Circuit Check .................83            .
SIDE WINDOW GLASS ........................................... 64   .         Door Mirror RH Defogger Circuit Check ................84             .
  Removal and Installation ....................................... 64
                                                                   .         Rear Window Defogger Signal Check (With NAVI)...85
    REMOVAL .......................................................... 65
                                                                   .         Filament Check ......................................................85
                                                                                                                                                  .
    INSTALLATION ................................................... 65
                                                                   .         Filament Repair ......................................................86
                                                                                                                                                  .
GLASS HATCH ........................................................ 66
                                                                   .           REPAIR EQUIPMENT ........................................86        .
  Removal and Installation ....................................... 66
                                                                   .           REPAIRING PROCEDURE ................................86             .
INSIDE MIRROR ...................................................... 68
                                                                   .        DOOR MIRROR ........................................................88.
  Wiring Diagram -- I/MIRR -- ................................. 68 .         Wiring Diagram -- MIRROR -- .............................88          .
  Removal and Installation ....................................... 69
                                                                   .         Door Mirror Assembly ............................................90  .
    INSIDE MIRROR ................................................ 69
                                                                   .           REMOVAL ...........................................................90
                                                                                                                                                  .
REAR WINDOW DEFOGGER ................................. 70          .           INSTALLATION ...................................................90 .
  Component Parts and Harness Connector Location 70                ...       Door Mirror Glass ...................................................91
                                                                                                                                                  .
  System Description ................................................ 70
                                                                   .           REMOVAL AND INSTALLATION ........................91                .
  CAN Communication System Description ............. 71            .




Revision: September 2005                                              GW-2                                                        2006 Pathfinder
                                              PRECAUTIONS

PRECAUTIONS                                                         PFP:00001
                                                                                                                         A
Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER"                                                                                           EIS007R2


The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along                            B
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front              C
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:                                                                                                                 D
q    To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
     in the event of a collision which would result in air bag inflation, all maintenance must be per-
     formed by an authorized NISSAN/INFINITI dealer.                                                                     E
q    Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
     sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
     Bag Module, see the SRS section.                                                                                    F
q    Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
     Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
     harness connectors.
                                                                                                                         G
Handling for Adhesive and Primer                                                                              EIS007R3


q   Do not use an adhesive which is past its usable date. Shelf life of this product is limited to six months after
    the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box.              H
q   Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
q   Open the seal of the primer and adhesive just before application. Discard the remainder.
                                                                                                                    GW
q   Before application, be sure to shake the primer container to stir the contents. If any floating material is
    found, do not use it.
q   If any primer or adhesive contacts the skin, wipe it off with gasoline or equivalent and wash the skin with
                                                                                                                     J
    soap.
q   When using primer and adhesive, always observe the precautions in the instruction manual.
                                                                                                                         K


                                                                                                                         L



                                                                                                                         M




Revision: September 2005                             GW-3                                          2006 Pathfinder
                                            PREPARATION

PREPARATION                                                                                                 PFP:00002

Special Service Tool                                                                                            EIS007R5


The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
    Tool number                                                        Description
    (Kent-Moore No.)
    Tool name
        --                                                             Locating the noise
    (J-39570)
    Chassis ear




                                                       SIIA0993E




         --                                                            Repairing the cause of noise
    (J-43980)
    NISSAN Squeak and Rat-
    tle Kit



                                                       SIIA0994E




Commercial Service Tool                                                                                         EIS007R6


    (Kent-Moore No.)                                                   Description
    Tool name
    (J-39565)                                                          Locating the noise
    Engine ear




                                                       SIIA0995E




    (    --      )                                                     Holding door glass
    Suction Lifter




                                                       LIIA1991E




Revision: September 2005                           GW-4                                               2006 Pathfinder
                       SQUEAK AND RATTLE TROUBLE DIAGNOSES

SQUEAK AND RATTLE TROUBLE DIAGNOSES                                                                       PFP:00000
                                                                                                                         A
Work Flow                                                                                                     EIS007R7




                                                                                                                         B



                                                                                                                         C


                                                                                                                         D


                                                                                                                         E



                                                                                                                         F



                                                                                                           SBT842
                                                                                                                         G

CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diag- H
nostic Worksheet during the interview to document the facts and conditions when the noise occurs and any
customer's comments; refer to GW-9, "Diagnostic Worksheet" . This information is necessary to duplicate the
conditions that exist when the noise occurs.
                                                                                                                       GW
q    The customer may not be able to provide a detailed description or the location of the noise. Attempt to
     obtain all the facts and conditions that exist when the noise occurs (or does not occur).
q    If there is more than one noise in the vehicle, be sure to diagnose and repair the noise that the customer
                                                                                                                        J
     is concerned about. This can be accomplished by test driving the vehicle with the customer.
q    After identifying the type of noise, isolate the noise in terms of its characteristics. The noise characteristics
     are provided so the customer, service adviser and technician are all speaking the same language when
     defining the noise.                                                                                                K
q    Squeak --(Like tennis shoes on a clean floor)
     Squeak characteristics include the light contact/fast movement/brought on by road conditions/hard sur-
     faces = higher pitch noise/softer surfaces = lower pitch noises/edge to surface = chirping.                        L
q    Creak--(Like walking on an old wooden floor)
     Creak characteristics include firm contact/slow movement/twisting with a rotational movement/pitch
     dependent on materials/often brought on by activity.                                                               M
q    Rattle--(Like shaking a baby rattle)
     Rattle characteristics include the fast repeated contact/vibration or similar movement/loose parts/missing
     clip or fastener/incorrect clearance.
q    Knock --(Like a knock on a door)
     Knock characteristics include hollow sounding/sometimes repeating/often brought on by driver action.
q    Tick--(Like a clock second hand)
     Tick characteristics include gentle contacting of light materials/loose components/can be caused by driver
     action or road conditions.
q    Thump--(Heavy, muffled knock noise)
     Thump characteristics include softer knock/dead sound often brought on by activity.
q    Buzz--(Like a bumble bee)
     Buzz characteristics include high frequency rattle/firm contact.
q    Often the degree of acceptable noise level will vary depending upon the person. A noise that you may
     judge as acceptable may be very irritating to the customer.
q    Weather conditions, especially humidity and temperature, may have a great effect on noise level.


Revision: September 2005                             GW-5                                         2006 Pathfinder
                       SQUEAK AND RATTLE TROUBLE DIAGNOSES

DUPLICATE THE NOISE AND TEST DRIVE
If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on
the Diagnostic Worksheet regarding the conditions or location of the noise. This information can be used to
duplicate the same conditions when you confirm the repair.
If the noise can be duplicated easily during the test drive, to help identify the source of the noise, try to dupli-
cate the noise with the vehicle stopped by doing one or all of the following:
1) Close a door.
2) Tap or push/pull around the area where the noise appears to be coming from.
3) Rev the engine.
4) Use a floor jack to recreate vehicle "twist".
5) At idle, apply engine load (electrical load, half-clutch on M/T model, drive position on A/T model).
6) Raise the vehicle on a hoist and hit a tire with a rubber hammer.
q    Drive the vehicle and attempt to duplicate the conditions the customer states exist when the noise occurs.
q    If it is difficult to duplicate the noise, drive the vehicle slowly on an undulating or rough road to stress the
     vehicle body.
CHECK RELATED SERVICE BULLETINS
After verifying the customer concern or symptom, check ASIST for Technical Service Bulletins (TSBs) related
to that concern or symptom.
If a TSB relates to the symptom, follow the procedure to repair the noise.
LOCATE THE NOISE AND IDENTIFY THE ROOT CAUSE
1.   Narrow down the noise to a general area.To help pinpoint the source of the noise, use a listening tool
     (Chassis Ear: J-39570, Engine Ear: J-39565 and mechanic's stethoscope).
2.   Narrow down the noise to a more specific area and identify the cause of the noise by:
q    removing the components in the area that you suspect the noise is coming from.
     Do not use too much force when removing clips and fasteners, otherwise clips and fasteners can be bro-
     ken or lost during the repair, resulting in the creation of new noise.
q    tapping or pushing/pulling the component that you suspect is causing the noise.
     Do not tap or push/pull the component with excessive force, otherwise the noise will be eliminated only
     temporarily.
q    feeling for a vibration with your hand by touching the component(s) that you suspect is (are) causing the
     noise.
q    placing a piece of paper between components that you suspect are causing the noise.
q    looking for loose components and contact marks.
     Refer to GW-7, "Generic Squeak and Rattle Troubleshooting" .
REPAIR THE CAUSE
q   If the cause is a loose component, tighten the component securely.
q   If the cause is insufficient clearance between components:
