Image preview - the first page of the document
>> Download fl documenatation <<
Text preview - extract from the document
B ENGINE
A
FL
SECTION
FUEL SYSTEM C
D
E
CONTENTS
PRECAUTIONS ......................................................... 2
. FUEL PUMP ASSEMBLY .......................................... 6 . F
Precautions for Supplemental Restraint System Removal and Installation ......................................... 6
.
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN- REMOVAL ............................................................ 7
.
SIONER" ................................................................. 2
. INSTALLATION .................................................. 10
. G
General Precautions ............................................... 2
. INSPECTION AFTER INSTALLATION ............... 10 .
PREPARATION .......................................................... 4
. FUEL TANK ............................................................. 11
.
Special Service Tools .............................................. 4
. Removal and Installation ....................................... 11.
H
Commercial Service Tool ........................................ 4 . REMOVAL .......................................................... 12
.
FUEL SYSTEM .......................................................... 5
. INSTALLATION .................................................. 15
.
Checking Fuel Lines ................................................ 5
. INSPECTION AFTER INSTALLATION ............... 15 .
FUEL LEVEL SENSOR UNIT, FUEL FILTER AND SERVICE DATA AND SPECIFICATIONS (SDS) ..... 16 . I
Standard and Limit ................................................. 16
.
J
K
L
M
Revision: September 2005 FL-1 2006 Pathfinder
PRECAUTIONS
PRECAUTIONS PFP:00001
Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER" EBS00T2G
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
q To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
q Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
q Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
General Precautions EBS00QUD
WARNING:
When replacing fuel line parts, be sure to observe the following.
q Put a "CAUTION: FLAMMABLE" sign in the workshop.
q Be sure to work in a well ventilated area and furnish the workshop with a CO2 fire extinguisher.
q Do not smoke while servicing the fuel system. Keep open flames and sparks away from the work
area.
CAUTION:
q Use gasoline required by the regulations for the octane rating number. Refer to GI-5, "Precautions
for Fuel (Unleaded Premium Gasoline Recommended)" .
q Before removing fuel line parts, carry out the following procedures:
