Image preview - the first page of the document
>> Download srs documenatation <<
Text preview - extract from the document
H RESTRAINTS
A
B
SECTION
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) C
D
E
CONTENTS
PRECAUTIONS ......................................................... 3
. FROM DIAGNOSTIC PROCEDURE 2) ............. 30 . F
Precautions for Supplemental Restraint System DIAGNOSTIC PROCEDURE 5 .......................... 30 .
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN- Trouble Diagnosis Without CONSULT-II ................ 37 .
SIONER" ................................................................. 3
. DIAGNOSTIC PROCEDURE 6 .......................... 37 . G
Precautions for SRS "AIR BAG" and "SEAT BELT WARNING LAMP FLASH CODE CHART .......... 38 .
PRE-TENSIONER" Service .................................... 3 . Trouble Diagnosis: "AIR BAG" Warning Lamp Does
Occupant Classification System Precaution ........... 3 . Not Turn Off ........................................................... 43
.
SRS
PREPARATION .......................................................... 4
. DIAGNOSTIC PROCEDURE 6 .......................... 43 .
Special Service Tools .............................................. 4
. Trouble Diagnosis: "AIR BAG" Warning Lamp Does
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) ...... 5 . Not Turn On ........................................................... 44
.
SRS Configuration .................................................. 5
. DIAGNOSTIC PROCEDURE 7 .......................... 44 . I
Front Seat Belt Pre-tensioner with Load Limiter ..... 6 DRIVER AIR BAG MODULE ................................... 45 .
Front Side Air Bag ................................................... 6
. Removal and Installation ....................................... 45 .
Side Curtain Air Bag ................................................ 6
. REMOVAL .......................................................... 45
. J
Occupant Classification System (OCS) .................. 6 . INSTALLATION .................................................. 46 .
Direct-connect SRS Component Connectors .......... 7 . SPIRAL CABLE ....................................................... 47.
TROUBLE DIAGNOSIS ............................................. 8 . Removal and Installation ....................................... 47 .
K
Trouble Diagnosis Introduction ................................ 8 . REMOVAL .......................................................... 47
.
DIAGNOSIS FUNCTION ...................................... 8 . INSTALLATION .................................................. 48 .
HOW TO PERFORM TROUBLE DIAGNOSES FRONT PASSENGER AIR BAG MODULE ............. 49 .
FOR QUICK AND ACCURATE REPAIR .............. 8 . Removal and Installation ....................................... 49 . L
WORK FLOW ....................................................... 9
. REMOVAL .......................................................... 49
.
SRS Components Parts Location .......................... 10 . INSTALLATION .................................................. 50 .
Schematic ..............................................................11
. WIRING HARNESS MODIFICATION ................. 51 . M
Wiring Diagram -- SRS -- .................................... 12 . SIDE CURTAIN AIR BAG MODULE ....................... 53 .
CONSULT-II Function (AIR BAG) .......................... 18 . Removal and Installation ....................................... 53 .
CONSULT-II Function ........................................... 18 . REMOVAL .......................................................... 53
.
HOW TO CHANGE SELF-DIAGNOSIS MODE INSTALLATION .................................................. 53 .
WITH CONSULT-II ............................................. 18 . CRASH ZONE SENSOR .......................................... 55 .
HOW TO ERASE SELF-DIAGNOSIS RESULTS 19 ... Removal and Installation ....................................... 55 .
Self-Diagnosis Function (Without CONSULT-II) .... 19 . REMOVAL .......................................................... 55
.
HOW TO CHANGE SELF-DIAGNOSIS MODE... 20 INSTALLATION .................................................. 55 .
HOW TO ERASE SELF-DIAGNOSIS RESULTS 20 ... SIDE AIR BAG (SATELLITE) SENSOR .................. 56 .
SRS Operation Check ........................................... 20 . Removal and Installation ....................................... 56 .
DIAGNOSTIC PROCEDURE 1 .......................... 20 . REMOVAL .......................................................... 56
.
Trouble Diagnosis With CONSULT-II .................... 22 . INSTALLATION .................................................. 56 .
DIAGNOSTIC PROCEDURE 2 .......................... 22 . FRONT SEAT BELT PRE-TENSIONER .................. 57 .
DIAGNOSTIC PROCEDURE 3 .......................... 27 . Removal and Installation ....................................... 57 .
DIAGNOSTIC PROCEDURE 4 (CONTINUED
Revision: September 2005 SRS-1 2006 Pathfinder
DIAGNOSIS SENSOR UNIT .................................... 58 . SRS INSPECTION (FOR FRONTAL COLLI-
Removal and Installation ....................................... 58 . SION) ..................................................................60
.
REMOVAL .......................................................... 58
. For Side and Rollover Collision ..............................61 .
INSTALLATION ................................................... 58. WHEN SRS IS ACTIVATED IN THE SIDE OR
ECU DISCRIMINATED NO. ................................ 58 . ROLLOVER COLLISION ....................................61 .
OCCUPANT CLASSIFICATION SYSTEM CON- WHEN SRS IS NOT ACTIVATED IN THE SIDE
TROL UNIT ............................................................... 59
. OR ROLLOVER COLLISION ..............................61 .
Removal and Installation ....................................... 59 . SRS INSPECTION (FOR SIDE AND ROLLOVER
COLLISION DIAGNOSIS ......................................... 60 . COLLISION) ........................................................62.
For Frontal Collision ............................................... 60
.
Revision: September 2005 SRS-2 2006 Pathfinder
PRECAUTIONS
PRECAUTIONS PFP:00001
A
Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER" EHS001LI
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along B
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front C
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING: D
q To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer. E
q Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section. F
q Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
G
Precautions for SRS "AIR BAG" and "SEAT BELT PRE-TENSIONER" Service
EHS001LJ
q Do not use electrical test equipment to check SRS circuits unless instructed to in this Service Manual. SRS
q Before servicing the SRS, turn ignition switch OFF, disconnect both battery cables and wait at least 3 min-
utes.
For approximately 3 minutes after the cables are removed, it is still possible for the air bag and seat belt I
pre-tensioner to deploy. Therefore, do not work on any SRS connectors or wires until at least 3 minutes
have passed.
q The air bag diagnosis sensor unit must always be installed with the arrow mark "" pointing toward the
front of the vehicle for proper operation. Also check the air bag diagnosis sensor unit for cracks, deformi- J
ties or rust before installation and replace as required.
q The spiral cable must be aligned with the neutral position since its rotations are limited. Do not attempt to
turn steering wheel or column after removal of steering gear. K
q Handle air bag module carefully. Always place driver and front passenger air bag modules with the pad
side facing upward and seat mounted front side air bag module standing with the stud bolt side facing
down. L
q Conduct self-diagnosis to check entire SRS for proper function after replacing any components.
q After air bag inflates, the front instrument panel assembly should be replaced if damaged.
M
Occupant Classification System Precaution EHS001LK
Replace control unit and passenger front seat cushion as an assembly.
Revision: September 2005 SRS-3 2006 Pathfinder
PREPARATION
PREPARATION PFP:00002
Special Service Tools EHS001LM
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number Description
(Kent-Moore No.)
Tool name
-- Removing and installing air bag lock
(J-42057-UPD)
Air bag key set
Part of kit (J-42057)
LRS210
Revision: September 2005 SRS-4 2006 Pathfinder
SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) PFP:28556
A
SRS Configuration EHS001LO
B
C
D
E
F
G
SRS
I
WHIA0194E
J
The air bag deploys if the air bag diagnosis sensor unit is activated while the ignition switch is in the ON or
START position.
The collision modes for which supplemental restraint systems are activated are different among the SRS sys-
K
tems. For example, the driver air bag module, front passenger air bag module and front seat belt pre-tension-
ers are activated in a frontal collision but not in a side collision.
SRS configurations for some collision modes are as follows:
L
Right side colli-
SRS configuration Frontal collision Left side collision Rollover
sion
Driver air bag module x -- -- --
M
Front passenger air bag module x -- -- --
Front LH seat belt pre-tensioner x -- -- x
Front RH seat belt pre-tensioner x -- -- x
Front LH side air bag module (if equipped) -- x -- --
Front RH side air bag module (if equipped) -- -- x --
LH side front curtain air bag module (if equipped) -- x -- x
LH side rear curtain air bag module (if equipped) -- x -- x
RH side front curtain air bag module (if equipped) -- -- x x
RH side rear curtain air bag module (if equipped) -- -- x x
Revision: September 2005 SRS-5 2006 Pathfinder
SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
Front Seat Belt Pre-tensioner with Load Limiter EHS001LP
The seat belt pre-tensioner system with load limiter is installed for
both the driver's seat and the front passenger's seat. It operates
simultaneously with the SRS air bag system in the event of a frontal
collision with an impact exceeding a specified level.
When the frontal collision with an impact exceeding a specified level
occurs, seat belt slack resulting from clothing or other factors is
immediately taken up by the pre-tensioner. Vehicle passengers are
securely restrained.
When passengers in a vehicle are thrown forward in a collision and
the restraining force of the seat belt exceeds a specified level, the
load limiter permits the specified extension of the seat belt by the
WHIA0225E
twisting of the ELR shaft, and a relaxation of the chest-area seat belt
web tension while maintaining force.
Front Side Air Bag EHS001LQ
Front side air bag modules are built into the front seatback assemblies.
Vehicles with side air bags are equipped with labels as shown.
WHIA0008E
Side Curtain Air Bag EHS001LR
Side curtain air bag modules are located above the vehicle headlining.
Vehicles with side curtain air bags are equipped with labels as
shown.
WHIA0041E
Occupant Classification System (OCS) EHS001S8
The occupant classification system (OCS) identifies different size occupants, out of position occupants, and
detects if child seat is present in the front passenger seat. The OCS receives inputs from the occupant classi-
fication sensor (located inside the passenger seat cushion assembly) and belt tension sensor (part of the pas-
senger front seat belt assembly and located at the belt anchor location). Depending on classification of the
passenger, the OCS sends a signal to the air bag diagnosis sensor unit. The air bag diagnosis sensor unit
uses this signal and the seat belt buckle switch RH signal to determine deployment or non deployment of the
passenger front air bag in the event of a collision. Depending on the signals received, the air bag diagnosis
sensor unit can disable the passenger front air bag completely.
NOTE:
In case of customer concern, CONSULT-II can be used to confirm the passenger air bag status (readiness).
Revision: September 2005 SRS-6 2006 Pathfinder
SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
Passenger Air Bag Status Conditions
Front Passenger Seat PASS AIR BAG OFF Indicator Passenger Air Bag Status
A
CONSULT-II Display
(Condition) (Status) (Readiness)
Seat occupied OFF Active (enabled) ON
B
Seat occupied NOTE ON Deactivated (disabled) OFF
Seat empty OFF Deactivated (disabled) OFF
NOTE: C
Passenger does not meet Occupant Classification System specifications for passenger air bag activation.
D
E
F
WHIA0195E
Direct-connect SRS Component Connectors EHS001LT G
The following SRS components use direct-connect style harness connectors.
q Driver air bag module
SRS
q Front passenger air bag module
q LH side front curtain air bag module
q LH side rear curtain air bag module I
q RH side front curtain air bag module
q RH side rear curtain air bag module
q Front LH seat belt pre-tensioner J
q Front RH seat belt pre-tensioner
Always pull up to release black locking tab prior to removing connector from SRS component.
Always push down to lock black locking tab after installing connector K
to SRS component. When locked, the black locking tab is level with
the connector housing.
L
M
WHIA0103E
Revision: September 2005 SRS-7 2006 Pathfinder
TROUBLE DIAGNOSIS
TROUBLE DIAGNOSIS PFP:00004
Trouble Diagnosis Introduction EHS001LU
CAUTION:
q Do not use electrical test equipment on any circuit related to the SRS unless instructed to do so in
this Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harness con-
nectors.
q Do not attempt to repair, splice or modify SRS wiring harnesses. If a harness is damaged, replace
it with a new one.
q Keep ground connections clean.
DIAGNOSIS FUNCTION
The SRS self-diagnosis results can be read by using "AIR BAG" warning lamp and/or CONSULT-II.
The User mode is exclusively prepared for the customer (driver). This mode warns the driver of a system mal-
function through the operation of the "AIR BAG" warning lamp.
The Diagnosis mode allows the technician to locate and inspect the malfunctioning part.
The mode applications for the "AIR BAG" warning lamp and CONSULT-II are as follows:
User mode Diagnosis mode Display type
"AIR BAG" warning lamp X X ON-OFF operation
CONSULT-II -- X Monitoring
HOW TO PERFORM TROUBLE DIAGNOSES FOR QUICK AND ACCURATE REPAIR
A good understanding of the malfunction conditions can make troubleshooting faster and more accurate.
In general, each customer feels differently about a malfunction. It is important to fully understand the symp-
toms or conditions for a customer complaint.
Information From Customer
WHAT - Vehicle model
WHEN - Date, Frequencies
WHERE - Road conditions
HOW - Operating conditions, Symptoms
Preliminary Check
Check that the following parts are in good order.
q Battery (Refer to SC-4, "How to Handle Battery" .)
q Fuse (Refer to SRS-12, "Wiring Diagram -- SRS --" .)
q System component-to-harness connections
Revision: September 2005 SRS-8 2006 Pathfinder
TROUBLE DIAGNOSIS
WORK FLOW
A
B
C
D
E
F
G
SRS
I
J
K
L
WHIA0098E
*1: SRS-8 *2: SRS-20 *3: SRS-30
*4: SRS-37 M
Revision: September 2005 SRS-9 2006 Pathfinder
TROUBLE DIAGNOSIS
SRS Components Parts Location EHS001LV
WHIA0196E
1. Side curtain air bag modules 2. Front RH side air bag module 3. Front RH seat belt pre-tensioner
(If equipped) (If equipped)
4. Belt tension sensor 5. Seat belt buckle switch RH 6. RH side air bag (satellite) sensor
(If equipped)
7. Occupant classification system sen- 8. Occupant classification sys- 9. Front passenger air bag off indicator
sor tem control unit
10. Front passenger air bag module 11. Crash zone sensor 12. Air bag warning lamp
13. Spiral cable 14. Driver air bag module 15. LH side air bag (satellite) sensor
(If equipped)
16. Front LH seat belt pre-tensioner 17. Air bag diagnosis sensor unit 18. Front LH side air bag module
(If equipped)
Revision: September 2005 SRS-10 2006 Pathfinder
TROUBLE DIAGNOSIS
Schematic EHS001LW
A
B
C
D
E
F
G
SRS
I
J
K
L
M
WHWA0256E
Revision: September 2005 SRS-11 2006 Pathfinder
TROUBLE DIAGNOSIS
Wiring Diagram -- SRS -- EHS001LX
WHWA0257E
Revision: September 2005 SRS-12 2006 Pathfinder
TROUBLE DIAGNOSIS
A
B
C
D
E
F
G
SRS
I
J
K
L
M
WHWA0258E
Revision: September 2005 SRS-13 2006 Pathfinder
TROUBLE DIAGNOSIS
WHWA0259E
Revision: September 2005 SRS-14 2006 Pathfinder
TROUBLE DIAGNOSIS
A
B
C
D
E
F
G
SRS
I
J
K
L
M
WHWA0260E
Revision: September 2005 SRS-15 2006 Pathfinder
TROUBLE DIAGNOSIS
WHWA0113E
Revision: September 2005 SRS-16 2006 Pathfinder
TROUBLE DIAGNOSIS
A
B
C
D
E
F
G
SRS
I
J
K
L
M
WHWA0261E
Revision: September 2005 SRS-17 2006 Pathfinder
TROUBLE DIAGNOSIS
CONSULT-II Function (AIR BAG) EHS001LY
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
AIR BAG diagnostic mode Description
A current Self-diagnosis result (also indicated by the number of warning lamp flashes in the Diagnosis
SELF-DIAG [CURRENT] mode) is displayed on the CONSULT-II screen in real time. This refers to a malfunctioning part requir-
ing repairs.
Diagnosis results previously stored in the memory are displayed on the CONSULT-II screen. The
SELF-DIAG [PAST]
stored results will remain until memory erasing is executed.
With TROUBLE DIAG RECORD, diagnosis results previously erased by a reset operation can be dis-
TROUBLE DIAG RECORD
played on the CONSULT-II screen.
The air bag diagnosis sensor unit for each vehicle
model is assigned with its own, individual classifi-
cation number. This number will be displayed on
the CONSULT-II screen, as shown. When replac-
ing the air bag diagnosis sensor unit, refer to the
part number for the compatibility. After installation,
replacement with a correct unit can be checked by
ECU DISCRIMINATED NO.
confirming this classification number on the CON-
SULT-II screen.
The air bag diagnosis sensor unit discrimi-
nated numbers assigned are F63E (for models
with side and side front curtain air bags) and
ARS366
F63D (for models without side and side front
curtain air bags).
The STATUS (readiness) of the front passenger air
bag module is displayed. The STATUS displayed
(ON/OFF) depends on the signals supplied to the
occupant classification system control module and
air bag diagnosis sensor unit. Refer to SRS-6,
"Occupant Classification System (OCS)" for more
PASSENGER AIR BAG information.
WHIA0290E
CONSULT-II Function EHS001LZ
HOW TO CHANGE SELF-DIAGNOSIS MODE WITH CONSULT-II
From User Mode to Diagnosis Mode
After selecting "AIR BAG" on the "SELECT SYSTEM" screen, User mode automatically changes to Diagnosis
mode.
SRS803
From Diagnosis Mode to User Mode
To return to User mode from Diagnosis mode, touch "BACK" key of CONSULT-II until "SELECT SYSTEM"
appears, Diagnosis mode automatically changes to User mode.
Revision: September 2005 SRS-18 2006 Pathfinder
TROUBLE DIAGNOSIS
A
B
C
SRS804
D
HOW TO ERASE SELF-DIAGNOSIS RESULTS
q "SELF-DIAG [CURRENT]"
A current self-diagnosis result is displayed on the CONSULT-II E
screen in real time.
After the malfunction is repaired completely, no malfunction is
detected on "SELF-DIAG [CURRENT]". F
G
SRS701
SRS
q "SELF-DIAG [PAST]"
Return to the "SELF-DIAG [CURRENT]" CONSULT-II screen by
touching "BACK" key of CONSULT-II and select "SELF-DIAG I
[PAST]" in SELECT DIAG MODE. Touch "ERASE" in "SELF-
DIAG [PAST]" mode.
NOTE: J
If the memory of the malfunction in "SELF-DIAG [PAST]" is
not erased, the User mode will continue to show the system
malfunction by the operation of the warning lamp even if
K
the malfunction is repaired completely.
SRS702
L
q "TROUBLE DIAG RECORD"
The memory of "TROUBLE DIAG RECORD" cannot be erased.
Self-Diagnosis Function (Without CONSULT-II) EHS001M0 M
q The reading of these results is accomplished using one of two modes -- "User mode" and "Diagnosis
mode".
q After a malfunction is repaired, turn the ignition switch OFF for at least one second, then back ON. Diag-
nosis mode returns to the User mode. At that time, the self-diagnostic result is cleared.
Revision: September 2005 SRS-19 2006 Pathfinder
TROUBLE DIAGNOSIS
HOW TO CHANGE SELF-DIAGNOSIS MODE
SHIA0183E
HOW TO ERASE SELF-DIAGNOSIS RESULTS
After a malfunction is repaired, turn the ignition switch OFF for at least one second, then back ON. Diagnosis
mode returns to the User mode. At that time, the self-diagnostic result is cleared.
SRS Operation Check EHS001M1
DIAGNOSTIC PROCEDURE 1
Checking SRS Operation Using "AIR BAG" Warning Lamp--User Mode
1. Turn the ignition switch from OFF to ON, and check that the air bag warning lamp blinks.
2. Compare the SRS air bag warning lamp blinking pattern with the
examples.
BF-1845D
Revision: September 2005 SRS-20 2006 Pathfinder
TROUBLE DIAGNOSIS
Warning lamp examples
"AIR BAG" warning lamp operation-User mode- SRS condition Reference item
A
B
q No malfunction is detected.
-- C
q No further action is necessary.
D
SHIA0011E
E
F
Go to SRS-22, "DIAGNOSTIC
The system is malfunctioning and
PROCEDURE 2" or SRS-37,
needs to be repaired as indicated.
"DIAGNOSTIC PROCEDURE 6" .
G
SHIA0012E SRS
q Air bag is deployed. Go to SRS-60, "COLLISION DIAG-
q Seat belt pre-tensioner is deployed. NOSIS" .
I
q Air bag diagnosis sensor unit is mal-
functioning.
Go to SRS-43, "Trouble Diagnosis: J
q Air bag power supply circuit is mal-
"AIR BAG" Warning Lamp Does Not
functioning.
Turn Off" .
q SRS air bag warning lamp circuit is
malfunctioning. K
SHIA0013E
L
q Air bag diagnosis sensor unit is mal- M
functioning. Go to SRS-44, "Trouble Diagnosis:
"AIR BAG" Warning Lamp Does Not
q Air bag warning lamp circuit is mal- Turn On" .
functioning.
SHIA0014E
Revision: September 2005 SRS-21 2006 Pathfinder
TROUBLE DIAGNOSIS
Trouble Diagnosis With CONSULT-II EHS001M2
DIAGNOSTIC PROCEDURE 2
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunction might be detected
in self-diagnosis depending on control unit which carries out CAN communication.
1. Turn ignition switch OFF.
2. Connect CONSULT-II and CONSULT-II CONVERTER to the
data link connector.
BBIA0538E
3. Turn ignition switch ON.
4. Touch "START (NISSAN BASED VHCL)".
BCIA0029E
5. Touch "AIR BAG".
If "AIR BAG" is not indicated, refer to GI-40, "CONSULT-II Data
Link Connector (DLC) Circuit" .
BCIA0030E
6. Touch "SELF-DIAG [CURRENT]".
BCIA0031E
Revision: September 2005 SRS-22 2006 Pathfinder
TROUBLE DIAGNOSIS
7. Diagnostic code is displayed on "SELF-DIAG [CURRENT]".
A
B
C
WHIA0151E
D
If no malfunction is detected on "SELF-DIAG [CURRENT]" even
though malfunction is detected in "SRS Operation Check", refer to
SRS-30, "DIAGNOSTIC PROCEDURE 4 (CONTINUED FROM E
DIAGNOSTIC PROCEDURE 2)" , to diagnose the following cases:
q Self-diagnostic result "SELF-DIAG [PAST]" (previously stored in
the memory) might not be erased after repair. F
q The SRS system malfunctions intermittently.
G
SRS701
SRS
CONSULT-II Diagnostic Code Chart ("SELF-DIAG [CURRENT]")
Repair order
Diagnostic item Explanation
Recheck SRS at each replacement
I
When malfunction is q Low battery voltage (Less than q Go to SRS-27, "DIAGNOSTIC PRO-
indicated by the "AIR 9V) CEDURE 3" .
BAG" warning lamp in
q Self-diagnostic result "SELF-DIAG q Go to SRS-30, "DIAGNOSTIC PRO-
User mode.
[PAST]" (previously stored in the CEDURE 4 (CONTINUED FROM
J
NO DTC IS DETECTED memory) might not be erased DIAGNOSTIC PROCEDURE 2)" .
after repair. q Go to SRS-30, "DIAGNOSTIC PRO-
q Intermittent malfunction has been CEDURE 5" . K
detected in the past.
q No malfunction is detected. --
DRIVER AIRBAG MODULE q Driver air bag module circuit is open (including the spiral 1. Visually check the wiring harness L
[OPEN] cable). connection.
[B1049] or [B1054] 2. Replace the harness if it has visible
DRIVER AIRBAG MODULE q Driver air bag module circuit is shorted to some power sup- damage. M
[VB-SHORT] ply circuit (including the spiral cable). 3. Replace driver air bag module.
[B1050] or [B1055] 4. Replace the spiral cable.
DRIVER AIRBAG MODULE q Driver air bag module circuit is shorted to ground (including 5. Replace the air bag diagnosis sen-
[GND-SHORT] the spiral cable). sor unit.
[B1051] or [B1056]
6. Replace the related harness.
DRIVER AIRBAG MODULE q Driver air bag module circuits are shorted to each other.
[SHORT]
[B1052] or [B1057]
Revision: September 2005 SRS-23 2006 Pathfinder
TROUBLE DIAGNOSIS
Repair order
Diagnostic item Explanation
Recheck SRS at each replacement
ASSIST A/B MODULE q Front passenger air bag module circuit is open.
[OPEN]
[B1065] or [B1070] 1. Visually check the wiring harness
connection.
ASSIST A/B MODULE q Front passenger air bag module circuit is shorted to some
2. Replace the harness if it has visible
[VB-SHORT] power supply circuit.
damage.
[B1066] or [B1071]
3. Replace front passenger air bag
ASSIST A/B MODULE q Front passenger air bag module circuit is shorted to module.
[GND-SHORT] ground.
4. Replace the air bag diagnosis sen-
[B1067] or [B1072]
sor unit.
ASSIST A/B MODULE q Front passenger air bag module circuits are shorted to 5. Replace the related harness.
[SHORT] each other.
[B1068] or [B1073]
q Crash zone sensor 1. Visually check the wiring harness
connection.
CRASH ZONE SEN
[UNIT FAIL] 2. Replace the harness if it has visible
[B1033] or [B1034] damage.
CRASH ZONE SEN 3. Replace the crash zone sensor.
[COMM FAIL] 4. Replace the air bag diagnosis sen-
[B1035] sor unit.
5. Replace the related harness.
SIDE MODULE LH q Front LH side air bag module circuit is open. 1. Visually check the wiring harness
[OPEN] connection.
[B1134] 2. Replace the harness if it has visible
SIDE MODULE LH q Front LH side air bag module circuit is shorted to some damage.
[VB-SHORT] power supply circuit. 3. Replace front LH seat back assem-
[B1135] bly (front LH side air bag module).
SIDE MODULE LH q Front LH side air bag module circuit is shorted to ground. 4. Replace the air bag diagnosis sen-
[GND-SHORT] sor unit.
[B1136] 5. Replace the related harness.
SIDE MODULE LH q Front LH side air bag module circuits are shorted to each
[SHORT] other.
[B1137]
SIDE MODULE RH q Front RH side air bag module circuit is open. 1. Visually check the wiring harness
[OPEN] connection.
[B1129] 2. Replace the harness if it has visible
SIDE MODULE RH q Front RH side air bag module circuit is shorted to some damage.
[VB-SHORT] power supply circuit. 3. Replace front RH seat back assem-
[B1130] bly (front RH side air bag module).
SIDE MODULE RH q Front RH side air bag module circuit is shorted to ground. 4. Replace the air bag diagnosis sen-
[GND-SHORT] sor unit.
[B1131] 5. Replace the related harness.
SIDE MODULE RH q Front RH side air bag module circuits are shorted to each
[SHORT] other.
[B1132]
q LH side air bag (satellite) sensor 1. Visually check the wiring harness
connection.
SATELLITE SENS LH 2. Replace the harness if it has visible
[UNIT FAIL] damage.
[B1118] or [B1119]
3. Replace the LH side air bag (satel-
SATELLITE SENS LH
lite) sensor.
[COMM FAIL]
[B1120] 4. Replace the air bag diagnosis sen-
sor unit.
5. Replace the related harness.
Revision: September 2005 SRS-24 2006 Pathfinder
TROUBLE DIAGNOSIS
Repair order
Diagnostic item Explanation
Recheck SRS at each replacement A
q RH side air bag (satellite) sensor 1. Visually check the wiring harness
connection.
SATELLITE SENS RH 2. Replace the harness if it has visible B
[UNIT FAIL] damage.
[B1113] or [B1114]
3. Replace the RH side air bag (satel-
SATELLITE SENS RH
lite) sensor.
[COMM FAIL] C
[B1115] 4. Replace the air bag diagnosis sen-
sor unit.
5. Replace the related harness.
D
PRE-TEN FRONT LH q The circuit for front LH seat belt pre-tensioner is open. 1. Visually check the wiring harness
[OPEN] connections.
[B1086] 2. Replace the harness if it has visible
damage. E
PRE-TEN FRONT LH q The circuit for front LH seat belt pre-tensioner is shorted to
[VB-SHORT] some power supply circuit. 3. Replace front LH seat belt pre-ten-
[B1087] sioner.
PRE-TEN FRONT LH q The circuit for front LH seat belt pre-tensioner is shorted to 4. Replace the air bag diagnosis sen- F
[GND-SHORT] ground. sor unit.◦ Jabse Service Manual Search 2025 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
