Image preview - the first page of the document

>> Download ps documenatation <<

Text preview - extract from the document

G STEERING

B
SECTION
POWER STEERING SYSTEM C

E
CONTENTS
PRECAUTIONS ......................................................... 2
. INSPECTION AFTER INSTALLATION ............... 12 . F
Precautions for Supplemental Restraint System Disassembly and Assembly ................................... 13 .
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN- DISASSEMBLY .................................................. 13 .
SIONER" ................................................................. 2
. ASSEMBLY ........................................................ 14. PS
Precautions for Steering System ............................. 2 . INSPECTION AFTER ASSEMBLY ..................... 14 .
PREPARATION .......................................................... 3
. POWER STEERING GEAR AND LINKAGE ........... 15 .
Special Service Tools (SST) .................................... 3 . Removal and Installation ....................................... 15 .
H
Commercial Service Tools ....................................... 4 . REMOVAL .......................................................... 15
.
NOISE, VIBRATION, AND HARSHNESS (NVH) INSTALLATION .................................................. 16 .
TROUBLESHOOTING ............................................... 5 . INSPECTION AFTER INSTALLATION ............... 16 .
NVH Troubleshooting Chart .................................... 5 . Disassembly and Assembly ................................... 17 . I
POWER STEERING FLUID ....................................... 6 . DISASSEMBLY .................................................. 17 .
Checking Fluid Level ............................................... 6
. INSPECTION AFTER DISASSEMBLY ............... 18 .
Checking Fluid Leakage .......................................... 6 . ASSEMBLY ........................................................ 18. J
Air Bleeding Hydraulic System ................................ 6 . POWER STEERING OIL PUMP .............................. 20 .
STEERING WHEEL ................................................... 8 . On-Vehicle Inspection and Service ........................ 20 .
On-Vehicle Inspection and Service ......................... 8 . CHECKING RELIEF OIL PRESSURE ............... 20 .
K
CHECKING CONDITION OF INSTALLATION ..... 8 Components .......................................................... 21
.
CHECKING STEERING WHEEL PLAY ............... 8 . Removal and Installation ....................................... 21 .
CHECKING NEUTRAL POSITION ON STEER- REMOVAL .......................................................... 21
.
ING WHEEL ......................................................... 8
. INSTALLATION .................................................. 21 . L
CHECKING STEERING WHEEL TURNING Disassembly and Assembly ................................... 22 .
FORCE ................................................................. 8
. INSPECTION BEFORE DISASSEMBLY ............ 22 .
CHECKING FRONT WHEEL TURNING ANGLE 9 ..... DISASSEMBLY .................................................. 22 . M
Removal and Installation ......................................... 9. INSPECTION AFTER DISASSEMBLY ............... 22 .
REMOVAL ............................................................ 9
. ASSEMBLY ........................................................ 22.
INSTALLATION .................................................... 9
. HYDRAULIC LINE ................................................... 24 .
STEERING COLUMN .............................................. 10 . Removal and Installation ....................................... 24 .
Removal and Installation ....................................... 10 . SERVICE DATA AND SPECIFICATIONS (SDS) ..... 26 .
REMOVAL .......................................................... 10
. Steering Wheel ...................................................... 26
.
INSPECTION AFTER REMOVAL .......................11 . Steering Column .................................................... 26
.
INSTALLATION ...................................................11. Steering Outer Socket and Inner Socket ............... 27 .
Oil Pump ................................................................ 27
.
Steering Fluid ......................................................... 27
.

Revision: September 2005 PS-1 2006 Pathfinder
PRECAUTIONS

PRECAUTIONS PFP:00001

Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER" EGS00118

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
q To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
q Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
q Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Steering System EGS00119

q Before disassembly, thoroughly clean the outside of the unit.
q Disassembly should be done in a clean work area. It is important to prevent the internal parts from becom-
ing contaminated by dirt or other foreign matter.
q For easier and proper assembly, place disassembled parts in order on a parts rack.
q Use nylon cloth or paper towels to clean the parts; common shop rags can leave lint that might interfere
with their operation.
q Before inspection or reassembly, carefully clean all parts with a general purpose, non-flammable solvent.
q Before assembly, apply a coat of recommended Genuine NISSAN PSF or equivalent to hydraulic parts.
Petroleum jelly may be applied to O-rings and seals. Do not use any grease.
q Replace all gaskets, seals and O-rings. Avoid damaging O-rings, seals and gaskets during installation.
Perform functional tests whenever designated.

Revision: September 2005 PS-2 2006 Pathfinder
PREPARATION

PREPARATION PFP:00002
A
Special Service Tools (SST) EGS0011A

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number Description B
(Kent-Moore No.)
Tool name
ST3127 S000 Inspecting of pinion rotating torque and rota- C
(See J-25765-A) tional torque for ball joint
Preload gauge
1. GG9103000
(J-25765-A) D
Torque wrench
2. HT62940000
( -- )
Socket adapter E
3. HT62900000 S-NT541

( -- )
Socket adapter
F
HT72520000 Removing steering outer socket
(J-25730-A)
Ball joint remover
PS

NT146
H

1. KV48105300-4 and 5295262U10 Measuring oil pump relief pressure
( -- )
Connector A and O-ring I
2. KV48105300-3 and 5295262U00
( -- )
Eye-bolt and O-ring
3. KV48103500 J
(J-26357 and J-26357-10)
Pressure gauge and shut-off valve
4. KV48105300-1 and 5295262U00
K
( -- )
Connector B and O-ring SGIA0427E

5. KV48105300-2
( -- ) L
Nut
-- Measuring steering wheel turning force
(J-44372)
Spring gauge
M

LST024

KV40107300 Crimping boot bands
( -- )

ZZA1229D

Revision: September 2005 PS-3 2006 Pathfinder
PREPARATION

Tool number Description
(Kent-Moore No.)
Tool name
KV481J0010 Removing steering wheel
(J-1859A)
Steering wheel puller

LHIA0043E

KV481J0020 Removing steering wheel
(J-42578)
Steering wheel puller legs

LHIA0044E

Commercial Service Tools EGS0011B

Tool name Description
Power tool Removing nuts and bolts

PBIC0190E

Revision: September 2005 PS-4 2006 Pathfinder
